Cocoon Cocoon Create 3D pen User manual

Getting Started Guide
After Sales Support 1300 663 907
www.winplus.com.au
1. UNPACK
Unpack your Cocoon Create 3D Pen from the packaging and check you have all of the components:
• Cocoon Create 3D Pen
• 3x3Metre1.75mmABSlament
• 1 x Power Adaptor
• 1 x Getting Started Guide
• 1 x Instruction Manual
• 1 x Warranty card
2. CONNECT TO POWER
Connect one end of the power adaptor to the power jack located at the end of the pen,
then connect the other end to a mains power outlet and switch on. The Power Indicator
LED will turn on.
HE150277
02/2016
3. HEATING THE 3D PEN
Press the Forward Button to begin heating the 3D Pen. The Heat Indicator LED will
turn red when the pen is being heated. Once the 3D Pen has reached the pre-set
temperature, the Heat Indicator LED will turn green.
NOTE: Refer to manual for temperature settings

Getting Started Guide
After Sales Support 1300 663 907
www.winplus.com.au
HE150277
02/2016
4. TRIM FILAMENT
Cutyourdesiredlengthlamentandensurethetipsofbothendsareat.
5. INSERT AND LOAD FILAMENT
InsertoneendofthelamentintotheFilamentPort.PressandholdtheForwardButton
tobeginloadinguntillamentisextrudedfromthenozzle.
6. DRAW!
Hold the Forward Button to extrude and draw. To stop, release the Forward Button. You
canchangethespeedoflamentextrusionwiththeSpeedSlider.
For ideas and templates visit
cocooncreate.com.au
