Code 3 CD3766 Owner's manual

Page 1 of 4
Installation and Operation Instructions
CD3766 Directional LED
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturer’s recommendations may result in property damage, serious injury, and/
or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understood the safety information
contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including re.
4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of
the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without
losing eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or located in an air bag
deployment area may reduce the e󰀨ectiveness of the air bag or become a projectile that could cause serious personal injury or death.
Refer to the vehicle owner’s manual for the air bag deployment area. It is the responsibility of the user/operator to determine a suitable
mounting location ensuring the safety of all passengers inside the vehicle particularly avoiding areas of potential head impact.
6. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),
people, vehicles or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.
Never take the right-of-way for granted. It is the vehicle operator’s responsibility to be sure they can proceed safely before entering an
intersection, drive against tra󰀩c, respond at a high rate of speed, or walk on or around tra󰀩c lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws
regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The
manufacturer assumes no liability for any loss resulting from the use of this warning device.

Page 2 of 4
LED Color 1 & Color 3
LED Color 2 & Color 4
Wire:
Input Voltage 12-24VDC
Work Current 0.9A Max @ DC12V
0.5A Max @ DC24V
Physical H x W x L 1.07 in x 1.48 in x 6.38 in
2.76 cm x 3.75 cm x 16.2 cm
Ship Weight 0.463 lb (0.21 Kg)
SPECIFICATIONS: Important! This unit is a safety device and it must be
connected to its own separate, fused power point to assure its
continued operation should any other electrical accessory fail.
Caution: When drilling into any vehicle surface, make sure the
area is free from any electrical wires, fuel lines, vehicle upholstery,
etc. that could be damaged
Mounting:
RED: Positive, Colors 1 & 3 (need to add 5A fuse)
WHITE: Positive, Colors 2 & 4 (need to add 5A fuse)
BLACK: Negative
BLUE: Pattern Select Negative
YELLOW: Synchronized Function
(Up to 8 units can be Synchronized)
Phase Operation:
Phase 1 (Ph1) ashes simultaneously with Ph1
Phase 2 (Ph2) ashes simultaneously with Ph2
Ph1 alternates with Ph2
(Up to 8 units can be Synchronized)
Apply BLUE TO BLACK wire:
-Less than 1 sec. for next pattern
-Between 1-3 sec for previous pattern
-Between 3-5 sec. for default
-More than 5 sec. for steady burn
Operation Environment:
Ambient Temperature: -30 to 50°C
RED WHITE
Product 1&3 Colors 2&4 Colors
CD3766AG AMBER GREEN
CD3766AW AMBER WHITE
CD3766BA AMBER BLUE
CD3766BW BLUE WHITE
CD3766RA AMBER RED
CD3766RB RED BLUE
CD3766RW RED WHITE
Positive - LED Color 2 & Color 4 ---------------------------------------- RED
Positive - LED Color 1 & Color 3 --------------------------------------------- WHITE
Negative --------------------------------------------------------------------------------------- BLACK
Pattern Select ---------------------------------------------------------------------------------------------- BLUE
SYCHRONIZATION ------------------------------------------------------------------------------------------- YELLOW
Mounting:
MOUNTING
GASKET
LIGHTHEAD
FLANGE
SCREWS

Page 3 of 4
CA T13 ECE R65
RED,
AMBER,
BLUE
WHITE RED, AMBER, BLUE RED, AMBER, BLUE
1-Default 1 Single 75FPM Ph1 Color 1 Synchronous Color 3 yes Class 1 Class 1 Class B N/C
2 2 Single 75FPM Ph2 Color 1 Synchronous Color 3 yes Class 1 Class 1 Class B N/C
3 Single 75FPM Ph1 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
4 Single 75FPM Ph2 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
1-Default 5 Single 75FPM Ph1 Color 2 Synchronous Color 4 yes Class 1 Class 1 Class B N/C
2 6 Single 75FPM Ph2 Color 2 Synchronous Color 4 yes Class 1 Class 1 Class B N/C
3 3 7 Single 38FPM Ph1(Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
4 4 8 Single 38FPM Ph2(Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
5 5 9 Single 38FPM (Color 1 Alternately Color 2) Alternately (Color 3 Alternately Color 4) yes N/C N/C N/C N/C
6 10 Single 375FPMFPM Ph1 Color 1 Synchronous Color 3 yes N/C N/C N/C N/C
7 11 Single 375FPMFPM Ph2 Color 1 Synchronous Color 3 yes N/C N/C N/C N/C
12 Single 375FPMFPM Ph1 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
13 Single 375FPMFPM Ph2 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
6 14 Single 375FPMFPM Ph1 Color 2 Synchronous Color 4 yes N/C N/C N/C N/C
7 15 Single 375FPMFPM Ph2 Color 2 Synchronous Color 4 yes N/C N/C N/C N/C
8 8 16 Single 187FPMFPM Ph1 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
9 9 17 Single 187FPMFPM Ph2 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
10 10 18 Single 187FPMFPM (Color 1 Alternately Color 2) Alternately (Color 3 Alternately Color 4) yes N/C N/C N/C N/C
11 19 Double 75FPM Ph1 Color 1 Synchronous Color 3 yes Class 1 Class 1 Class B N/C
12 20 Double 75FPM Ph2 Color 1 Synchronous Color 3 yes Class 1 Class 1 Class B N/C
21 Double 75FPM Ph1 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
22 Double 75FPM Ph2 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
11 23 Double 75FPM Ph1 Color 2 Synchronous Color 4 yes Class 1 Class 1 Class B N/C
12 24 Double 75FPM Ph2 Color 2 Synchronous Color 4 yes Class 1 Class 1 Class B N/C
13 13 25 Double 38FPM Ph1 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
14 14 26 Double 38FPM Ph2 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
15 15 27 Double 38FPM (Color 1 Alternately Color 2) Alternately (Color 3 Alternately Color 4) yes N/C N/C N/C N/C
16 28 Double 120FPM Ph1 Color 1 Synchronous Color 3 yes Class 1 Class 1 N/C Class 1
17 29 Double 120FPM Ph2 Color 1 Synchronous Color 3 yes Class 1 Class 1 N/C Class 1
30 Double 120FPM Ph1 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
31 Double 120FPM Ph2 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
16 32 Double 120FPM Ph1 Color 2 Synchronous Color 4 yes Class 1 Class 1 N/C Class 1
17 33 Double 120FPM Ph2 Color 2 Synchronous Color 4 yes Class 1 Class 1 N/C Class 1
18 18 34 Double 60FPM Ph1 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
19 19 35 Double 60FPM Ph2 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
20 20 36 Double 60FPM (Color 1 Alternately Color 2) Alternately (Color 3 Alternately Color 4) yes N/C N/C N/C N/C
21 37 Triple 75FPM Ph1 Color 1 Synchronous Color 3 yes Class 1 Class 2 Class B N/C
22 38 Triple 75FPM Ph2 Color 1 Synchronous Color 3 yes Class 1 Class 2 Class B N/C
39 Triple 75FPM Ph1 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
40 Triple 75FPM Ph2 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
21 41 Triple 75FPM Ph1 Color 2 Synchronous Color 4 yes Class 1 Class 2 Class B N/C
22 42 Triple 75FPM Ph2 Color 2 Synchronous Color 4 yes Class 1 Class 2 Class B N/C
23 23 43 Triple 38FPM Ph1 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
24 24 44 Triple 38FPM Ph2 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
25 25 45 Triple 38FPM (Color 1 Alternately Color 2) Alternately (Color 3 Alternately Color 4) yes N/C N/C N/C N/C
26 46 Quad 75FPM Ph1 Color 1 Synchronous Color 3 yes Class 1 Class 2 Class B N/C
27 47 Quad 75FPM Ph2 Color 1 Synchronous Color 3 yes Class 1 Class 2 Class B N/C
48 Quad 75FPM Ph1 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
49 Quad 75FPM Ph2 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
26 50 Quad 75FPM Ph1 Color 2 Synchronous Color 4 yes Class 1 Class 2 Class B N/C
27 51 Quad 75FPM Ph2 Color 2 Synchronous Color 4 yes Class 1 Class 2 Class B N/C
28 28 52-Default Quad 38FPM Ph1 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
29 29 53 Quad 38FPM Ph2 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
30 30 54 Quad 38FPM (Color 1 Alternately Color 2) Alternately (Color 3 Alternately Color 4) yes N/C N/C N/C N/C
31 55 Quad 120FPM Ph1 Color 1 Synchronous Color 3 yes Class 1 Class 2 N/C N/C
32 56 Quad 120FPM Ph2 Color 1 Synchronous Color 3 yes Class 1 Class 2 N/C N/C
57 Quad 60FPM Ph1 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
58 Quad 120FPM Ph2 Color 1 Alternately Color 4 yes N/C N/C N/C N/C
31 59 Quad 120FPM Ph1 Color 2 Synchronous Color 4 yes Class 1 Class 2 N/C N/C
32 60 Quad 120FPM Ph2 Color 2 Synchronous Color 4 yes Class 1 Class 2 N/C N/C
33 33 61 Quad 60FPM Ph1 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
34 34 62 Quad 60FPM Ph2 (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) yes N/C N/C N/C N/C
35 35 63 Quad 60FPM (Color 1 Alternately Color 2) Alternately (Color 3 Alternately Color 4) yes N/C N/C N/C N/C
864 Modulation (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) no N/C N/C N/C N/C
965 2 Double,2 Quad (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) no N/C N/C N/C N/C
10 66 4 Single,2 Triple (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) no N/C N/C N/C N/C
11 67 1Doube 1Triple 1Quad (Color 1 Synchronous Color 3) Alternately (Color 2 Synchronous Color 4) no N/C N/C N/C N/C
36 68 Steady burn-Color 1 & 3 no N/C N/C N/C N/C
36 69 Steady burn-Color 2 & 4 no N/C N/C N/C N/C
DUAL COLOR Flash Pattern Chart
Pattern LED Color 1 & Color
3 Red line
LED Color 2 & Color
4 White line
LED Color 1 & Color 3
LED Color 2 & Color 4
Red & White line
PATTERNS Mark SYNC.
SAE J595
1
A
E
2
D
H
3
A
E
4
B
F
5
A
E
6
A
E
7
B
F
N/A
12

Page 4 of 4
Troubleshooting
The CD3766 series has been factory tested and approved. If the functions of the device fail, please check the following:
1. After connecting with the power supply, be sure that the power source end is joined correctly. Make sure there is not a short circuit.
2. Plug in the device; ensure the LED power switch is on.
3. Press the Pattern Switch to ensure “OFF” pattern is not selected. If the blue wire touches the black wire over 5 seconds, it would switch to the
steady burn pattern. It will light up again when the blue wire touches the black wire continuously for less than 1 second.
Product Returns:
If a product must be returned for repair or replacement*, please contact our factory to obtain a Return Goods Authorization Number (RGA
number) before you ship the product to Code 3®, Inc. Write the RGA number clearly on the package near the mailing label. Be sure you use
su󰀩cient packing materials to avoid damage to the product being returned while in transit.
*Code 3®, Inc. reserves the right to repair or replace at its discretion. Code 3®, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring
service and/or repair.; nor for the packaging, handling, and shipping: nor for the handling of products returned to sender after the service has been rendered.
Manufacturer Limited Warranty Policy:
Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specications for this product (which are avail-
able from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase.
DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA-
TIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE
MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED WAR-
RANTY.
Exclusion of Other Warranties:
MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY
OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY EX-
CLUDED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW. ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.
Remedies and Limitation of Liability:
MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY
OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE
REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING PROD-
UCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELATED TO
THE MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL PURCHASE.
IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR, PROPERTY
DAMAGE, OR OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF CONTRACT, IM-
PROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESENTATIVE HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR LIABILITY WITH RESPECT
TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR AUTHORIZES THE ASSUMPTION OF
ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.
This Limited Warranty denes specic legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some jurisdic-
tions do not allow the exclusion or limitation of incidental or consequential damages.
An ECCO SAFETY GROUP™ Brand
ECCOSAFETYGROUP.com
10986 North Warson Road, St. Louis, MO 63114 USA
Technical Service USA [phone]
[email protected]
CODE3ESG.com
© 2013 Code 3, Inc. all rights reserved.
920-1003-00 Rev. G
