Code CR900FD User manual

Using the CR900FD in a Universal Stand
The CR900FD has a stand detecon feature. By
default, when the CR900FD is placed in the stand,
the reader will automacally enter into moon
detecon mode. When in this mode, simply place
a bar code in the scan eld to acvate the reader.
The CR900FD will beep and ash a green LED to
indicate a ‘good read’ has occurred.
When the CR900FD is removed from the stand,
the reader switches to manual mode and the
trigger must be pressed to read a bar code.
Press and hold the CR900FD trigger, the two
blue bars eming from the reader are used for
targeng. Center the blue bars in the middle of
a bar code.
The opmal reading distance from reader to bar
code is approximately 4.0” (10 cm).
For USB Cable: plug the USB end of the Anity® cable into a USB port on the host device.
Aer several seconds, the reader will beep twice and the LED will turn o to indicate the
CR900FD is ready for use.
For RS232 Cable: plug the power supply into the AC outlet, plug the power supply cord into
the barrel jack of the cable, and connect the RS232 connector to the appropriate serial port
on the host device. Aer several seconds, the reader will beep twice and the LED will turn o
to indicate the CR900FD is ready for use.
Using the CR900FD Out of a Universal Stand
Powering on the CR900FD CR900FD Default Sengs
Codabar
Code 39
Code 93
The CR900FD, out of the box, will read the following 1D bar codes:
The CR900FD can be upgraded to read 2D bar codes with the purchase of a license key. 2D
license keys can be purchased individually or as a package. Available licenses:
Conguraon Codes
Once the reader is at the opmal distance, the CR900FD will read the bar code (when the
trigger is pressed). The CR900FD will beep and ash a green LED to indicate a ‘good read’ has
occurred.
2 3
Code 128
Interleaved 2 of 5
GS1 DataBar (RSS)
MSI Pessey
UPC/EAN/JAN
Aztec Code
Data Matrix
Han Xin
PDF417/Micro PDF417/Composite Code
QR Code/Micro QR
Package of all 2D bar codes listed
Visit www.codecorp.com for upgrading/license key informaon.
Upgrade Opons
Note: a CR900FD will read Data Matrix conguraon codes without a purchase of a license key.
The CR900FD can be quickly and easily congured to meet the needs of dierent use cases.
Commonly used conguraon codes have been included in the quickstart guide for your
convenience. For more conguraon opons refer to the CR900FD Conguraon Guide
located at www.codecorp.com. For custom conguraon opons, please contact us at
[email protected].
To enable or disable cell phone reading mode, scan the appropriate code below.
Enable Cell Phone Reading Mode Disable Cell Phone Reading Mode
To enable the following 1D bar codes, reference the CR900FD Conguraon Guide available
at www.codecorp.com:
Matrix 2 of 5
Pharmacode
Plessey
Straight 2 of 5
Telepen
Triopc
Code 11
Code 32
Hong Kong 2 of 5
www.codecorp.com www.codecorp.com

Quickstart Guide
C007258_06_CR900FD_Quickstart_Guide
Code Reader™ 900FD (CR900FD)
USB Anity® Cable RS232 Anity® Cable
w/ Power Supply
Aaching/Detaching a Cable
To aach a cable, plug the RJ-50 end of the Anity® cable into boom of the reader (Figure
1). Firmly push the connector into the reader unl a snap can be heard, to indicate the cable
is properly aached. To detach a cable, press a paper clip into the hole on the back of the
CR900FD (Figure 2), and gently pull the cable from the reader.
Figure 2Figure 1
Included with your CR900FD
Depending on the kit ordered, the following may have been shipped with your reader:
Universal Stand
Universal Stand Assembly (included when ordered as a Kit/Package)
© 2013. Code Corporaon. All Rights Reserved. 4
Sux Enter is on by default in USB mode. To congure your CR900FD for a Sux - Carriage
Return Line Feed in RS232 (Serial) Mode, scan the following code:
Sufx - Carriage Return Line Feed (Serial Mode Only)
Sufx - Tab (USB Keyboard Mode Only) Sufx-Tab (Serial Mode Only)
