Coemar LEDko FullSpectrum 2 + RGBL User manual

USER MANUAL
vrs. 1.1  19.04.2023
FullSpectrum 2 +
RGBL

© 2023 Coemar Lighting Srl. All rights reserved.
Information subject to change without notice. Coemar and all aliated companies disclaim
liability for any injury, damage, direct or indirect loss, consequential or economic loss or any
other loss occasioned by the use of, inability to use or reliance on the information contained in
this document. The Coemar logo, the Coemar name and all other trade-marks in this document
pertaining to services or products by Coemar or its aliates and subsidiaries are trademarks or
licensed by Coemar or its aliates or subsidiaries.
No part of this document may be used for distribution, reproduction, transmission, transcription,
storage in a data retrieval system, or translated into any language in any form by any means
without the prior written permission of Coemar ®. If you are downloading files from our web
pages for your personal use, make sure to check for updated versions. Coemar ® cannot take any
liability whatsoever for downloaded files, as technical data are subject to change without notice.

3
Index
1. Packaging and transportation .......................................................................................................Pag. 5
1.1 Packaging ....................................................................................................................................Pag. 5
1.2 Transportation ............................................................................................................................Pag. 5
2. General information.........................................................................................................................Pag. 5
2.1 Safety informations....................................................................................................................Pag. 5
2.2 Warranty conditions..................................................................................................................Pag. 6
2.3 EC Norms ...................................................................................................................................Pag. 6
3. Product specifications................................................................................................................... Pag. 7
3.1 Technical characteristics...........................................................................................................Pag. 7
3.2 Dimensions.................................................................................................................................Pag. 7
3.3 Weights and dimensions of the projector with various optics ...........................................Pag. 8
3.4 Unit’s main components ..........................................................................................................Pag. 9
3.5 Back panel description............................................................................................................Pag. 10
4. Installation....................................................................................................................................... Pag. 11
4.1 Optical Installation.................................................................................................................... Pag. 11
4.2 Mechanical installation........................................................................................................... Pag. 12
4.3 Safety chain.............................................................................................................................. Pag. 12
4.4 Adjusting unit’s tilt.................................................................................................................. Pag. 12
5. Powering up..................................................................................................................................... Pag. 13
5.1 Operating voltage and frequency ......................................................................................... Pag. 13
5.2 Connection to mains power................................................................................................... Pag. 13
6. Control signal connections.......................................................................................................... Pag. 14
6.1 Control signal connection by XLR5 plugs ............................................................................ Pag. 14
7. Turning on the projector................................................................................................................ Pag. 15
7.1 DMX address of the unit .......................................................................................................... Pag. 15
8. DMX Chart ...................................................................................................................................... Pag. 17
8.1 DMX modes ............................................................................................................................... Pag. 17
8.2 DMX Chart 14, 8, 1 channels ................................................................................................... Pag. 18
8.3 DMX Chart Studio mode ....................................................................................................... Pag. 21
8.4 DMX Chart RGBL mode ........................................................................................................ Pag. 22
8.5 DMX Chart SUNRISE mode .................................................................................................. Pag. 23
9. Setup via RDM ............................................................................................................................... Pag. 25
9.1 Quick guide to menu .............................................................................................................. Pag. 25
9.2 RDM Chart ............................................................................................................................... Pag. 25
9.3 RDM Error Chart ..................................................................................................................... Pag. 26
10. Display panel functions.............................................................................................................. Pag. 27
10.1 Quick guide to menu.............................................................................................................. Pag. 27
10.2 Rapid count............................................................................................................................ Pag. 27
10.3 Potentiometer Knob............................................................................................................. Pag. 27
10.4 Main functions menu............................................................................................................ Pag. 28
10.5 Settings .................................................................................................................................. Pag. 31
10.6 Display .................................................................................................................................... Pag. 33
10.7 Eects .................................................................................................................................... Pag. 34
10.8 Measures ............................................................................................................................... Pag. 36

4
11. Wireless DMX Menu (OPTIONAL)............................................................................................ Pag. 38
11.1 Wireless DMX................................................................................................................................ Pag. 38
12. Special Function and Error Messages ..................................................................................... Pag. 39
12.1 Special functions of the fixture .......................................................................................... Pag. 39
12.2 Error messages ..................................................................................................................... Pag. 39
13. Accessories and Spare parts .................................................................................................... Pag. 40
14. Maintenance ................................................................................................................................ Pag. 42
14.1 Firmware update.................................................................................................................... Pag. 42
14.2 Periodic cleaning................................................................................................................... Pag. 42
14.3 Periodic controls................................................................................................................... Pag. 42
14.4 Fuses....................................................................................................................................... Pag. 42
15. F.A.Q. and answers...................................................................................................................... Pag. 43

5
Congratulations on having purchased a Coemar product. You have assured yourself of a fixture
of the highest quality, both in componentry and in the technology used. We renew our invitation
to you to complete the service information on the previous page, to expedite any request for
service information or spares (in case of problems encountered either during, or subsequent
to, installation). This information will assist in providing prompt and accurate advice from your
Coemar service centre. Following the instructions and procedures outlined in this manual will
ensure the maximum eciency of this product for years to come.
1. Packaging and transportation
1.1 Packaging
Open the packaging and make sure that no part of the equipment has suered any damage
during the transportation. In case of damage to the fixture, contact your currier and your
supplier immediately by telephone, fax or e-mail, and inform them you will formally notify them
in writing through registered letter.
Packing list
Ensure the packaging contains:
1  LEDko FullSpectrum 2 +
1  Instruction manual
1  Gobo holder
1  1.5 m power cable with PowerCON TRUE1 Top and bare ends
2. General information
2.1 Safety informations
Fire prevention:
1. Never locate the fixture on any flammable surface.
2. Minimum distance from flammable materials: 0,5 m.
3. Minimum distance from the closet illuminable surface: 0,5 m.
4. Replace any blown or damaged fuse only with those of identical values. Refer
to the schematic diagram if there is any doubt.
5. Connect the projector to mains power protected by a thermal magnetic circuit
breaker.
Prevention from electric shock:
1. Presence of high voltage inside of the fixture. Insulate the projector from mains
supply before opening or performing any function which involves touching the
inside of the fixture, including lamp replacement.
2. For the connection to the mains, adhere strictly to the guidelines outlined in
this manual.
1.2 Transportation
The LEDko FullSpectrum 2 + should be transported in either its original packaging or in an ap-
propriate flight case.

6
Safety:
1. The projector must always be installed with bolts, clamps, or other fixing
devices which are suitably rated to support the weight of the projector.
2. Always use a secondary safety fixing device with chain or steel wire of a
suitable rating to sustain the weight of the unit in case of failure of the principal
fixing point.
3. The external surfaces of the unit, at various points, may reach 60°C. Never
handle the unit until at least 10 minutes have elapsed since the LED was
turned o.
4. Never install the fixture in an enclosed area lacking sucient air flow; the room
temperature must not exceed 40°C.
5. The projector contains electronic and electrical components which must under
no circumstances be in contact with water, oil or any other liquid. Failure to do
so will compromise the proper functioning of the projector.
Protection rating of the body against liquids and solids:
1. The standard version of the fixture is classified ordinary apparatus; its
protection grade against penetration by external agents,solid or liquid, is IP20.
2.2 Warranty conditions
1. The fixture is under warranty for 24 months from the purchase date against factory
defections.
2. Damage ought to unskillfulness, inappropriate use, or lack of suggested maintenance are
excluded from the warranty.
3. Warranty expires when the projector is opened by unauthorized personnel.
4. Warranty doesn’t include the replacement of the fixture.
5. Serial number and model ofthe fixture are necessaryto retrieve informations and assistance
from the dealer.
2.3 EC Norms
1. The fixture satisfies the essential requirements of the directive 2004/108/EC, 2006/95/
EC, 2011/65/EC, 2002/96/EC  2003/108/EC.
2. The fixture is in accordance with the standard EN 50419 (RoHS) and satisfies the
requirements of the directive 2002/96/EC (WEEE).
3. The level of technology of LEDko FullSpectrum 2 + requires the use of
specialised personnel for all service applications; refer all work to your
authorised Coemar service centre.
4. A good earth connection is essential for the proper functioning of the projector.
Never connect the fixture if there is no earth connection.
5. Mains cables must not come into contact with other cables.
6. Do not operate the projector with wet hands or in an area where water is
present.
7. The fixture must never be located in an exposed position, or in areas of extreme
humidity.

7
3. Product specifications
3.1 Technical characteristics
Power supply 90264 V, 50/60 Hz, auto-sensing
Maximum current 0.89 A at 230 V, 1.77 A at 115 V
Power factor Cosφ= 0.98
Max power consumption 200 W
Color temperature RGBL, with pure color mixing throughout the field
and all whites from 2.700 to 10.000 K
Weight Body: 6 Kg / 13.23 lbs
With Profile Zoom 28°/40° optic: 8.5 Kg / 18.74 lbs
Maximum ambient temperature 0°C - +40°C / 32°F  104°F
IP rating 20
3.2 Dimensions
Date: 15.11.2019
Castiglione delle Stiviere (MN) - Italy - Via Carpenedolo, 90
Tel. [phone] - Fax. [phone] - www.coemar.com
LEDko
Descrizione:
This drawing cannot be copied, reproduced, shown to third parties without our permission
Questo disegno non può essere copiato, riprodotto, mostrato a terzi senza nostra autorizzazione
40 mm
1.5 in
212 mm
8.3 in
229 mm 9.0 in
188 mm 7.4 in
362 mm
14.2 in
194 mm 7.6 in
372 mm 14.6 in
275 mm 10.8 in
189 mm 7.4 in
198.8 mm
7.8 in
0.8 mm
0.03 in
180 mm
7.1 in
93.5 mm
3.7 in
75 mm
2.9 in
212 mm
8.3 in
354 mm
13.9 in
355 mm
13.9 in
40 mm
1.5 in
275 mm
10.8 in
189 mm
7.4 in
254 mm
10.0 in
601 mm
23.6 in
210 mm
8.2 in
69.85 mm
2.75 in
95.3 mm
3.8 in
258 mm
10.2 in
Standard gobo holder Gobo holder for glass gobo
* with Soft Profile Fresnel optic

8
3.3 Weights and dimensions of the projector with various optics
Optics
Optics
Optics
Optics
Lens Tube Profile 19°
Lens Tube Profile 26°
Lens Tube Profile 36°
Lens Tube Profile 50°
Profile Zoom 15°-35°
Profile Zoom 25°-50°
Profile Zoom 28°-40°
Soft Profile Fresnel
Zoom 14°-40°
Soft Profile PC
Zoom 11°-38°
Lens Tube Profile 14°
Lens Tube Profile 70°
Lens Tube Profile 10°
Length
Length
Length
Length
670 mm (26.3 in)
670 mm (26.3 in)
670 mm (26.3 in)
670 mm (26.3 in)
886 mm (34.9 in)
783 mm (30.8 in)
601 mm (23.7 in)
601 mm (23.7 in)
601 mm (23.7 in)
750 mm (35.4 in)
750 mm (35.4 in)
900 mm (35.4 in)
Weight
Weight
Weight
Weight
9.15 Kg (20.17 lbs)
9.05 Kg (19.95 lbs)
9.35 Kg (20.60 lbs)
9.05 Kg (19.95 lbs)
13.05 Kg (28.77 lbs)
11.2 Kg (24.69 lbs)
8.3 Kg (18.3 lbs)
7.75 Kg (17.09 lbs)
8.25 Kg (18.19 lbs)
9 Kg (19.8 lbs)
8.68 Kg (19.14 lbs)
9 Kg (19.8 lbs)
Optics Length Weight
Optics Length Weight

9
3.4 Unit’s main components
Components description
AAdjustable yoke
B Iris (optional)
C Gobo holder (included)
D Lens adjusting handles
E Yoke locking handle
F Gel frame locking spring
G Profile blade
H Interchangeable optic
A
B
C
D
F
E
G
H

10
3.5 Back panel description
Display
Menu button
Enter button
PowerCon
TRUE1 Top In
PowerCon
TRUE1 Top Out
Intensity /
Selector Knob
Plus button
DMX Out
DMX In
Minus button

11
4. Installation
Remove the frontal cap by loosening the upper and lower screws enough to free the cap itself,
set the optic’s flange tilted about 60°. Insert the optic’s flange into the body’s receptacle and
turn the optic 60° until it is firmly assembled to the projector body, free to rotate but not free to
detach itself from the body. Ensure the optic to the body by tightening the two screws previously
loosened.
4.1 Optical installation
Warning!!
When the protective cap is removed, never lean the fixture facing down.
The front lens can be seriously damaged.

12
4.2 Mechanical installation
LEDko FullSpectrum 2 + may be hung from an appropriate structure in any position or on
tripod. If hanging the fixture from a lighting truss or similar, we recommend the use of an ap-
propriate clamp “A”, as shown in the following diagram.
Warning!!
Always ensure that your support structure
and fixing (bolts, clamps, etc…) are rated
A to support the weight of the fixture.
4.3 Safety chain
When hanging it is recommended to use a safety chain, as required by current legislation. The
safety chain must pass through the handles of the unit and then attached to the structure.
If using steel cables and chains not ’s production, make sure they are suitable to support the
weight of the unit according to normative UL/ETL (required: the weight of 6 complete devices
for at least one hour).
4.4 Adjusting unit’s tilt
In order to adjust the tilt of the unit simply loose the side handle adjust the tilt and lock the yoke
by tightening the handle again.
A

13
5. Powering up
5.2 Connection to mains power
Mains cable characteristics
The mains cable provided is thermally resistant, complying to the most recent International
standards.
Note: in case of cable replacement, similar cable with comparable thermal resistant qualities
must be used exclusively (cable 3 X 1,5 ø external 10 mm, rated 300/500V, tested to 2 KV,
operating temperature -40°C + 180°C, Coemar cod. CV5311).
Connection to mains power
LEDko FullSpectrum 2 + is equipped with two power connectors, one as input and one as
output, which can be used to feed up to 8 (at 230 V) or 4 (at 115 V) fixtures.
The max absorption of LEDko FullSpectrum 2 + is reported in the following table:
- 230 V 0.89 A constant during normal exercise.
- 115 V 1.77 A constant during normal exercise.
5.1 Operating voltage and frequency
The unit may operates at voltages ranges from 90 to 264 V at a frequency of 50 or 60 Hz. It is
not needed to eect any setup procedures: LEDko FullSpectrum 2 + will automatically adjust
its operation to suit any frequency or voltage within this range.
DMX
DMX512
Standard:
pin1:gnd, pin2: data-,
pin3:data+, pin4: n.c.
pin5:n.c.
Autosensing
ACinput
90-230V
56/60Hz
serialnumber
Power
In OutIn Out DMX
DMX512
Standard:
pin1:gnd, pin2: data-,
pin3:data+, pin4: n.c.
pin5:n.c.
Autosensing
ACinput
90-230V
56/60Hz
serialnumber
Power
In OutIn OutDMX
DMX512
Standard:
pin1:gnd, pin2: data-,
pin3:data+, pin4: n.c.
pin5:n.c.
Autosensing
ACinput
90-230V
56/60Hz
serialnumber
Power
In OutIn Out
Warning!!
• The use of a thermal/magnetic circuit breaker is recommended. Strict adherence to
regulatory norms is strongly recommended.
• LEDko + should not be powered through a dimmer as this may damage the internal
switching power supply.
• Prior to connecting the device to mains power, ensure that the mains characteristics are
within the recommended range for the use of LEDko +.
• All cabling and connections should be carried out by a suitably qualified personnel.
brown
blue
yellow/green
neutral
mass
fase

14
Warning!
Make sure that screening and conductors are not in contact one another or with the
metal housing of the connector.
Pin#1 and housing must never be connected to the power supply unit.
6.1 Control signal connection by XLR5 plugs
The digital control signal is transmitted to the projector via a two pole cable screened in ac-
cording to the International standards for DMX 512 data transmission. The connection must be
serial, using connectors XLR5 male and female located on the back of LEDko FullSpectrum 2 +
labelled DMX512 IN e OUT.
6. Control signal connections
Controller
Standard
DMX 512
OUT
3
2
1
Pin 1 = Ground (GND)
Pin 2 = Data -
Pin 3 = Data +
Pin 4 = Not connected
Pin 5 = Not connected
DMX
DMX512
Standard:
pin1:gnd, pin2: data-,
pin3:data+, pin4: n.c.
pin5:n.c.
Autosensing
ACinput
90-230V
56/60Hz
serialnumber
Power
In Out In Out
DMX
DMX512
Standard:
pin1:gnd, pin2: data-,
pin3:data+, pin4: n.c.
pin5:n.c.
Autosensing
ACinput
90-230V
56/60Hz
serialnumber
Power
In Out In Out

15
7. Turning on the projector
After having followed the preceding steps described, proceed with the power supply and turn on
the projector connecting it to the mains power.
The software version installed on the internal microprocessors will be shown on the display,
suddenly it will show the current DMX addressing. If the address blinks, it means that the DMX
signal has not been received. Check the connection cable and the mixer functioning.
7.1 DMX address of the unit
Each projector can use 14 / 8/ 1, Studio mode, RGBL mode or Sunrise mode for its complete
operation and is controlled by a DMX 512 signal.
DMX addressing
When powered up initially, each projector will show A001, which indicates DMX address 001;
for example, when set at 14 channels a projector thus addressed will respond to commands
of channel 1 to 14 from your DMX 512 controller. A second unit must be addressed as
A015, a third one as A030 and so on. The operation must be carried out on every LEDko
FullSpectrum 2 + which has an address dierent from A001.
Altering the DMX address:
1. Press the + or – button until the display shows the required DMX address. The digits on the
display will blink to indicate that the variation has not been registered.
2. Press the enter key to confirm your selection. The digits on the display panel will cease to
blink and the projector will now respond to the new address.
Note: by holding the + or – button down the scrolling will be faster; thus allowing a faster
selection

16
Warning!!
If you alter the DMX address with no DMX signal connected, the digits on the display
panel will continue to flash even after you have pressed ENTER button to confirm the
address.
A001
5 CH
Auto
!
!
It means the projector has entered protection
It means there is an error, it flashes intermittently with address
Wireless DMX Enabled
The keys are locked
I
n
t
e
n
s
i
t
y
/
S
e
l
e
c
t
o
r

17
8. DMX chart
8.1 DMX modes
DMX
channels ↓
14
channels
8
channels
1
channel
Studio
mode
RGBL
mode
Sunrise
mode
1Master
Dimmer
Master
Dimmer
Master
Dimmer
Master
Dimmer Red Master Dimmer
2Red Red White
Tone Green Dimmer Fine
3Green Green Green
Saturation Blue Proportional CCT
4Blue Blue Saturation Lime Step
CCT
5Lime Lime Hue Green
Saturation
6Strobe
Eect
Strobe
Eect
Dimmer
Fine
7Dimmer
Fine
Dimmer
Fine
Special
Function
8Special
Function
Special
Function
9Red
Tone
10 Green
Tone
11 Blue
Fine
12 White
Tone
13 Green
Saturation
14 Saturation

18
8.2 DMX Chart: 14, 8, 1 channels
channel function type of control effect decimal percentage
14 8 1
1 1 1 master dimmer proportional adjust luminous output intensity from 0% to
100% 0 - 255 0% - 100%
2 2 - red proportional proportional control of the color
percentage from 0% to 100% 0 - 255 0% - 100%
3 3 - green proportional proportional control of the color
percentage from 0% to 100% 0 - 255 0% - 100%
4 4 - blue proportional proportional control of the color
percentage from 0% to 100% 0 - 255 0% - 100%
5 5 - lime proportional proportional control of the color
percentage from 0% to 100% 0 - 255 0% - 100%
6 6 - strobe effect
step no effect 0 - 9 0% - 4%
proportional variable speed strobing effect, from slow to
fast 10 - 57 4% - 22%
step stop strobe 58 - 59 23% - 23%
proportional
sequenced pulsed strobe, slow closing, fast
operating
(variable speed pulsing, from slow to fast)
60 - 108 24% - 42%
step stop strobe 109 - 110 43% - 43%
proportional
sequenced pulsed strobe, fast closing, slow
operating
(variable speed pulsing, from slow to fast)
111 - 159 44% - 62%
step stop strobe 160 - 161 63% - 63%
proportional random strobe effect with variable speed from
slow to fast and synchronized colors 162 - 207 64% - 81%
step stop strobe 208 - 209 82% - 82%
proportional random strobe effect with variable speed from
slow to fast and non-synchonized colors 210 - 255 82% - 100%
7 7 - dimmer fine proportional fine dimmer control 16 bit 0 - 255 0% - 100%
8 8 - special functions
step
park 0 - 9 0% - 4%
600 Hz 10 - 22 4% - 9%
no effect 23 - 84 9% - 33%
fan at SILENT mode 85 - 96 33% - 38%
fan at STUDIO mode 97 - 108 38% - 42%
fan at AUTO mode 109 - 120 43% - 47%
proportional fan speed control 121 - 133 47% - 52%
step
enables the automatic display blackout 134 - 185 53% - 73%
disables the automatic display blackout 186 - 199 73% -78%
LED control frequency tuning 1.500 Hz 200 - 205 78% - 80%
LED control frequency tuning 2.000 Hz 206 - 211 81% - 83%
LED control frequency tuning 5.000 Hz 212 - 217 83% - 85%
no effect 218 - 240 85% 94%
LED control frequency tuning 20.000 Hz 241 - 255 95% - 100%

19
9 - - red tone step
no effect 0 - 9 0% - 4%
COR01 - GELS RED 1 10 - 34 4% - 13%
COR02 - GELS RED 2 35 - 59 14% - 23%
COR03 - GELS RED 3 60 - 84 24% - 33%
COR04 - GELS RED 4 85 - 109 33% - 43%
COR05 - GELS RED 5 110 - 134 43% - 53%
COR06 - GELS RED 6 135 - 159 53% - 62%
COR07 - GELS RED 7 160 - 184 63% - 72%
COR08 - GELS RED 8 185 - 209 73% - 82%
COR09 - GELS RED 9 210 - 234 82% - 92%
COR10 - GELS RED 10 235 - 255 92% - 100%
10 - - green tone step
no effect 0 - 9 0% - 4%
COG01 - GELS GREEN 1 10 - 34 4% - 13%
COG02 - GELS GREEN 2 35 - 59 14% - 23%
COG03 - GELS GREEN 3 60 - 84 24% - 33%
COG04 - GELS GREEN 4 85 - 109 33% - 43%
COG05 - GELS GREEN 5 110 - 134 43% - 53%
COG06 - GELS GREEN 6 135 - 159 53% - 62%
COG07 - GELS GREEN 7 160 - 184 63% - 72%
COG08 - GELS GREEN 8 185 - 209 73% - 82%
COG09 - GELS GREEN 9 210 - 234 82% - 92%
COG10 - GELS GREEN 10 235 - 255 92% - 100%
11 - - blue tone step
no effect 0 - 9 0% - 4%
COB01 - GELS BLUE 1 10 - 34 4% - 13%
COB02 - GELS BLUE 2 35 - 59 14% - 23%
COB03 - GELS BLUE 3 60 - 84 24% - 33%
COB04 - GELS BLUE 4 85 - 109 33% - 43%
COB05 - GELS BLUE 5 110 - 134 43% - 53%
COB06 - GELS BLUE 6 135 - 159 53% - 62%
COB07 - GELS BLUE 7 160 - 184 63% - 72%
COB08 - GELS BLUE 8 185 - 209 73% - 82%
COB09 - GELS BLUE 9 210 - 234 82% - 92%
COB10 - GELS BLUE 10 235 - 255 92% - 100%

20
12 - - white tone
step no effect 0 - 9 0% - 4%
2.700 K 10 - 15 4% - 6%
proportional proportional value from 2.700 to 3.200 K 16 - 30 6% - 12%
step 3.200 K 31 - 45 12% - 18%
proportional proportional value from 3.200 to 4.000 K 46 - 60 18% - 24%
step 4.000 K 61 - 75 24% - 29%
proportional proportional value from 4.000 to 5.000 K 76 - 90 30% - 35%
step 5.000 K 91 - 105 36% - 41%
proportional proportional value from 5.000 to 5.600 K 106 - 120 42% - 47%
step 5.600 K 121 - 135 47% - 53%
proportional proportional value from 5.600 to 7.000 K 136 - 10 53% - 59%
step 7.000 K 151 - 165 59% - 65%
proportional proportional value from 7.000 to 8.000 K 166 - 180 65% - 71%
step 8.000 K 181 -195 71% -76%
proportional proportional value from 8.000 to 9.000 K 196 - 210 77% - 82%
step 9.000 K 211 - 225 83% - 88%
proportional proportional value from 9.000 to 10.000 K 226 - 240 89% - 94%
step 10.000 K 241 - 255 95% - 100%
13 - - green saturation
step no effect 0 0%
proportional exalts the green color in the mixing and
diminishes the presence of magenta 1 - 127 0% - 50%
step no effect 128 50%
proportional diminishes the presence of green in the
mixing and exalts the green color 129 -254 51% -99%
step no effect 255 100%
14 - - saturation proportional the white tone fades to the tone built with
the RGBL channels 0 - 255 0% - 100%
Note 1: color macros of channels 9 -10 -11 - 12 can also be obtained through the mixing of channels 2 - 3 - 4 - 5.
Note 2: the one channel function mode can be selected through the DMX function menu. The color of the light will be a
white 5.600 K.
Note 3: the rest position of the +-green DMX channel is 128. Diminishing the DMX value augments the presence of the
green color. Increasing the DMX value augments the presence of magenta
Note 4: increasing the value of the Saturation DMX channel the white light will fade to the color selected with the Color
Wheel DMX channel.
Projector: LEDko FullSpectrum 2 + Chart name: DMX512 function Software version: 0.76 or
following
Edition: 1
