1. Table (list) of contents.
:
1. Tableofcontents sid. 2
2. General 3
3. Overviewofcomponents,membranswitch 4
3. Overviewofcomponents,front 5
3. Overviewofcomponentsmixingsystem 6
4. SERVICE;Installationandstart 7-8
Placethe brewer
Connectings:Electricity/Water
Startingupmachine
Fillcanisters
5. Operation
Brewingof coffeein cup, , 9
Brewingof jug 10
6. Cleaningprogram
Automaticcleaning of brewmechanism 11-12
Automaticcleaning of mixingbowl 13
AutomaticcleaningofIn/Outletvalves 14
Rotatebrewmechanism withoutwater or ingredients 15
7. Weeklycleaning
dismantlemixersystem 16
washtheseparts 16
assemblemixer system 17
8. Cleaningandmaintenance
dismantlingexchangeand cleaningof coffee filter 18
outsidecleaning 19
9. CupcounterandEasy access 20
10. Safetyfunctions 21
11. Failure messages 21
12. Storage/Transport. 21
13. Dimensionsketch 22
14. Circuit diagram. 23
2.

2. General. Future
We congratulate toyour choiceof aCQ Future automat.
Please read this manual before you take the machine into operation for the first time.
Themanualcontains importantinstructions for asafe andproperuse ofthe machine.
Alwayskeepthis manualwithin reach forthe user!
CQ Future Combi automat
- Makingcoffee cupby cup
- Jugfacilitywith key switch
- 8 choices of drinks,
- 3or 4 ingredients canisters,
- Brewingmechanismwith coffeefilter
- Electronicallytemperaturecontrolled
- Adjustablecoffeestrength
- Illuminatedcupwhilebrewing
- Clockfunctions
Facts: Future III / IV
Height 780mm base cabinet 800mm
Width 420 mm base cabinet 420mm
Depth 550 mm base cabinet 460mm
Weight 35kg(emballage cá 4kg)
Tankage 2.4 litre
Electricity 230V/2200W
Waterconnection ½”outsidethread
Capacity:Future III
Cups of coffee 200cups/filling
Ingredientscanisters 3st.(coffee, chocolate,topping).
Capacity: Future IV
Cups of coffee 200cups/filling
Ingredientscanisters 3st. (coffee, instantcoffee, chocolate,topping).
3.

3. Overview of components membranswitch. Future
4.
Drink 1 Drink 5
Drink 2 Drink 6
Drink 3 Drink 7
Drink 4 Drink 8
Membranswitch

Outlet drinks
Drip tray
Display
5.
3. Overview of components , front Future
Key switch
Membran switch
8 choices of
drinks
Door lock
Strength of
drinks ++ / - -
Drip tray insert

Chute
Mixerbowls
Ingredients-
canisters
Brewing
mechanism
3. Overview of components , mixer system Future
6.
Detail; Ingredients; Width; Height; Volume/litre; Amount/unit
Canister; coffee 160 250 5,3 ´ 1
Canister; choco 78 250 - 1
Canister; topping 78 250 - 1
Outlet
Detail; Ingredients; Width; Height; Volume/litre; Amount/unit
Canister; coffee 160 250 5,3 ´ 1
Canister; instant coffee 67 250 - ´ 1
Canister; choco 67 250 - 1
Canister; topping 67 250 - 1
FUTUREIII
FUTUREIV
FUTUREIV
2mixer bowls
FUSEholder
Mainswitch

4. Service. Installation and start Future
1. Placethe machine ona flatleveland waterproofsurface.
Connectthe electricalplug toa separate
grounded wall socket 230V 10A.
OBSERVE!
Make sure there is a space
behindthe machine for free flowof air.(minimum 10cm).
2. Connectattached watertube to coldwater withan R 1/2”.
Makesurethat thewater hose notare kinkedanywherewhen machineis
pushedinto place.
Please flush water tube before connecting it to machine, this to avoid any
particles to damage the inlet valve.
3. Openthewaterinlet.
4. Turnontheswitch insidethedoor.
Water is been filled into the tank
automatically with 2,4 litres of water.
Theheatingwill notstartbefore thewater
levelreachesthelevelsensor.
Set temperature is approx. 97ºC.
5. Close door.
7.
4.

8.
4. Service. Installation and start Future
6. Fill canisters with ingredients.
Takeout(thisto avoidunnecessery
spillagein the machine)ingredient
canistersandfill themwithingredients.
7. When placing the ingredient canisters;
Makesure that theoutlet pipeson the ingredientcanisters aretouching the
steamtraps (B)and that the coffee powderwill fallinto thecentre ofthe brew
mechanism(A).
Whenthe water isheated upto right temperature
the text ”Low temp” will disappear and ”Low temp”
the machine is ready to use.
(B).
(A).

Brewing of coffe etc. in a cup
1. Placea cupin thecentre ofthe cupholder.
2. The strength has a standard setting,
if you wish to increase or decrease it, do as
follows, ifnot continue to point 3.
Stronger drink;
Increase by pushing + or ++ for 5% or 10%
alternative
Weaker drink;
Decrease by pushing - or -- for 5% or 10%
(theindication lampwill goup ordown
dependingof choice).
3. Choosedrinkby pushingthe
buttonofeachmenu
Thedisplaywill show;”Pleasewait”,
andthelight on thecup will lightup.
4. Waituntilthelight oncupand the text
”Pleasewait” has beenturned off
beforeyoutake your cup.
5. Enjoyyourdrink.
9.
5. Operation; Brewing of coffee in cup Future
2.
1.

5. Operation; Brewing of coffee into jug. Future
Brewing of jug.
1. Placea jugin thecentre of drip tray. (For jug1,8L dismantledriptray).
Serving pot1, 8L: Serving pot 1,2L: art.nr. 1103091
art.nr.110001 Thermos pot 1L : art.nr. 1103251
10.
1.
2. Turnonthekey withjugsymboleclockwise.
3. 6cups of brewing is standardsettings,
Changeamountof cupsbypushing + or- button.
Optionalup to12 cups ordown to1 cup brewing.
4. Push button for drink 1.
5. Waituntil the lightand text”Please wait” hasbeen
turnedoffbefore you takeoutthe jug.
6. Servea jugwith goodcoffee.
2.
3.
4.

1. Turn the key slowly ninety degress and back again.
2. Push button for drink 1 for 6 seconds.
After 4 seconds the signal will go faster.
3. After 6 seconds The display shows; ”Open door”
”load detergent”.
4. Fill 25gr detergent (A) (one portion bag) into the brew
mechanism (B). (Detergent will be supplied from your
retaildealer)
The display shows; ”Close door”
The display shows; ” When ready press key”
Place a jug into the drip tray.
5. Push button for drink 1
The display shows; ”Cleaning mixer” (2....)
The display shows: ”Rinsing coffee” ”Soak time:”
The machine start to count down from 300 seconds.
The display shows. ”Brewer cycle” the machine is counting down.
11.
Automatic cleaning of brew mechanism, mixing bowl:
Should be done every week.
The brewmechanism can easily be cleaned with the key switch in ”cup” (normal) position.
6. Cleaning program CLEANING Future
6. Push ”+” button in 6 seconds
The display shows: ”Change paper/Rotate” ”Push E/ +”
7. Push button for drink 2.
The display shows; ”Preparing paperload”.
8. The machine will rotate in position.
The display shows,”Change paper”
9. Open door, dismantle, clean and reassemble brew house.
page 12.
10. Close door.
11. Machine is ready to use again.
12. Take out a cup of coffee and waste it, just to make sure
that there is nothing left of detergent.
IMPORTANT! Dismantling and cleaning/washing brew house:
After the automatic cleaning program is finished. Clean brew house! This must be done, to make sure
that you will remove residual detergents and coffee remains! Do as follow in paragraph 10- 19. (See
fig. 1,2,3,4 page12).
If machine not will go
back in start position.
Restart machine.
B
1.
5.
6.
7.
2.
To stop cleaning process: push ”Stop” button.The brew mechanism will go back to start position.
NOTE! Dont stop the process when detergent has been loaded. Then the cleaning must be finished.
A

12.
6. Cleaning program CLEANING Future
Dismantling and cleaning/washing brew house:
Dismantle brew house:
1. 2.
4. Reassemble brew house.
NOTE! When reassemble brew house
make sure that (B) wiper are
between (A) arms.
3. Flush brew house!
Toremovedetergentand coffeeremnants.

By cleaning means that water is flushed and whipper motor rotates.
13.
6. Cleaning program. CLEANING Future
1.
3.
2.
Themixer bowls caneasily becleaned with thekey
switchin”cup” (normal)position.
Automatic cleaning of mixer bowl No:2
Weekly cleaning! Automatic cleaning of mixing bowls 2 or 3.
Ifyouonly wish tocleanthe mixer bowlandwhipper house;Followthese
instructions:
1. Place a jug in the drip tray.
2. Turn thekey(1) slowlyninetydegrees andbackagain.
3. Push button 3 for 6 seconds.
After4seconds thesignal willgo faster.
After6 secondsthe mixerbowl andthe whipper
houseno.2 startsto becleaned for5 seconds.
The display shows: ”Cleaning 2”.
Automatic cleaning of mixer bowl No:3
1. Place a jug in the drip tray.
2. Turn thekeyslowly ninetydegreesand back again.
3. Push button 4 for 6 seconds.
After4seconds thesignal willgo faster.
After6 secondsthe mixerbowl andthe whipper
houseno.3 startsto becleaned for5 seconds.
The display shows: ”Cleaning 3”.

14.
6. Cleaning program CLEANING Future
Automatic cleaning of In/Outlet valves:
TheIn/Outletvalvescaneasily becleanedwiththekey switch in”cup”(normal)
position.
1.
5.
2. Turn thekeyslowly ninety degreesandback
again.
3. Push buttons for drinks 1 and 2 at the same
time for 6 seconds.
Hold the buttons.
1. Place a jug under the outlet.
(dismantledriptray).
4. AllIn/Outletvalveswill now starttoopenand close
with 2 pulses/second in 10 seconds or as long as
youholdthebuttons.
Thedisplayshows:”Cleaningvalves”.
5. Push button for drink 2 for making a brew
cycleandflush remainingwaterand scalefrom
thecleaning.
By cleaning is meant that valves
”knocks” away eventual scale and other
particles which has been attached in the
cylinders and that they are flushed away
with the water.
3.
2.
3.

15.
6. Cleaning program CLEANING Future
1. Push ”+” button for 6 seconds
After4seconds thesignal willgo faster.
Thedisplay shows:”Changepaper/Rotate”
”PushE/+”
2. Push + button.
Thedisplayshows:”Rotatecyclewithoutwater”.
3. Push button for drink 2.
Thedisplayshows:”Rotate”
Thebrewmechanismrotate oneturnwithoutwater and
ingredientsand themechanism falls into position if it has
beendismounted.
Observe! The push rod shall be in position
”8 o clock”
If not take out again and repeat the procedure.
Eight (8) o clock.
Rotate brew mechanism without water or ingredients:
Thebrewmechanism canbe rotatedwithout waterand ingredients withthe keyswitchin ”cup”
(normal)position.Tobe used whenbrew mechanismhas been dismountedfor washingand shall
beremounted.
2.
1.
3.

16.
7. CLEANING: Weekly cleaning Future
(D)
Dismantle : Mixer system
1.
Loosenoutlethose (A) and
turnlockknob (B)
anti-clockwise.
3.
Loosenwhipper (D) pull
whipper straight out from the
machine.
(E)
(A)
(B) (C)
Cleaning
Wash these parts:
.6.
A. Mixerbowl
B. Steam trap
C. Whipper
D. Assemblyplate
Make sure this parts are dry
before use
2.
Loosenmixer bowl.
Pullapart (C).
4.
Turnlockknobanti-
clockwise.(E) untilit stops
5.Clean with a wet ragand
droughtdrily.

17.
7. CLEANING: Weekly cleaning Future
REASSEMBLE: Mixer system
7.
Reassembletheassembly plateby turning
lock knob (F) clockwise. INSPECT gaskets.
pil (G).
9.
Assemblewhipper, pulluntil
youhear aclicking noise.(H).
10.
Assemble mixerbowl and steam
trap(J) see picture.
11.
Easilypushthe mixerbowl
towards,according to(K) andlock
withlockknob(L).Connect outlet
hose(M).
(NOTE!make surethat allwater
hoseare connectedat rightplace
(H)
(J)
(J)
(J)
(K)
(M)
(L)
(G)
F F
F
8.
Makesure that themotor whippersplane side
willbe inaccordance withthe whippers plane
side.see next(G) and picture(H).
INSPECT
INSPECT

5. Remountthescreen assembly andclosethe door.Then the
machinewill return tostart positionand themachineis
readyforuse.
Ifmachine dontgo backin start position. Restart machine!
6. Takeout acup ofcoffeeand wasteit justto make sure that
thereisnothing leftofdetergent.
18.
8. Cleaning and maintenance. Cleaning Future
Dismantling; Cleaning or exchanging coffee filter.
A dismantling tool for coffee filter is included with the machine.
4. Soakthe screenassembly ina solutionof 25gr.
detergentin 3dl water for amaximum of10 minutes.
Prolonged contact with detergent may damagethe screenassembly.Once thisis
done,thescreen shouldthen be thoroughlyrinsed with dishsoap andwarmwater to
removeanyleftoverresidu
4.
1. Push”+ button” for 6 seconds.
After6 secondsthe displayshows; ”Changepaper/
Rotate” ”PushE/+”.
2. Push button for drink 2.
The display shows; ”Preparing paperload”.
3. Themachine will rotatein position.
Display shows,”Change paper”
openthedoor andinsertthe dismantlingtoolthrough
thebrewer spout allthe wayto theback ofthe
cylinder,then slideitup untilcontactismade withthe
screenassembly. Pushup on therear ofthescreen
assemblyuntilit popsout of thecylinder.
.10 minutes
.3 dl water
97º Celsius
Cleaning agent: (brew mechanism) CoffeeQueen artikel nr 1104161
Filter: (brew mechanism) Coffee Queenartikelnr 47200213
Tool: (dismantling filter) CoffeeQueen artikel nr 4720090
1.
2.
Cleaning of coffee filter
Dismantling coffee filter

Outside cleaning; use a soft rag
and liquid cleaning agent that
doesn´t scratch.
19.
8. Cleaning and maintenance CLEANING Future
Outside cleaning;

20.
9. Cup counter -Easy Access Future
1. Push ”-” button for 6 seconds.
After4seconds thesignal willgo faster..
The display shows: ”Total xxx cups”
2. Pushbuttonfor drink 2.
Thedisplayshows:
”Choice 1 free xxx cups”
3. Pushbuttonfor drink 2.
Thedisplayshows
”Choice 1 coin xxx cups”
4. Pushbuttonfor drink 2.
Thedisplayshows
”Choice 1 xxx cups in can”
5. Push”+” button toreach to”choice 2”etc.
6. Pushchoice 3 toreset thecounter.
7. Push”Stop”button togo backto usermode.
Cup counter:
Themachinehasan inbuiltcupcounter which
is available to
seeand reset withthe keyswitch in ”cup”(nor-
mal)position.
Easy Access:
Volumeand strengthcan be adjustedwith±15%
withthekeyswitch
in”cup”(normal) position.
1. Push ”+” and ”-” button at the same time.
After4seconds thesignal willgo faster.
Thedisplayshows:
”Easyaccess” ”strength1 100%”
2. Choosethedrink youwant to change
bypushing”+”or”-”button.
3. Pushbuttonfor drink 2.
Thedisplayshows: for example.
Volume 4 and” Blinking100%”
Changebypushing”+” or”-”button.
4. Pushbuttonfor drink2to confirmthechange.
Press ”stop” to go back to user mode.
7.
5.
6. 1.
2. 3. 4. 3. 5. 1.
6.
