CL100 Video Light User Manual
Thank you for choosing COLBOR product. Please read this manual
carefully before use and follow all instructions mentioned herein.
Caring For Your COLBOR Product
Operation Instructions
Product Instructions
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
The product is not waterproof.
Do not leave the product unattended while in use. Keep out of reach of
children.
Must remove the protective cover before use.
Do not handle with wet hands. Do not touch hot COB surface.
Please do not block the ventilation and do not look at the light directly when
it is on.
Do not attempt to disassemble or modify the product. Doing so voids
warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Disconnect from the power supply when it is not in use.
Malfunction may be caused by dropping, impact of external force.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
If there is no operation for 10 seconds, the current settings are
automatically saved and the selection mode is exited.
① Power Button
Short press to turn on/ o the light
② Mode Switch
Default Mode: CCT
Each press switches to next lighting mode
(CCT → EFF-CANDLE → EFF-BONFIRE → EFF-BLN → EFF-FAULTY BULB
→ EFF-FLASH → EFF-LIGHTNING)
Long press for 3 seconds to enter Overclock mode.
In overclock mode, the output power will be enhanced for 60s. At this time,
the fan runs at full speed with the fan status of "FULL". When the mode
ends, the previous fan status restores.
③ Adjustment Dial
1.Short press the dial to switch between Brightness and Color Temperature
Control
2.Roll the dial to adjust the value
Brightness (0-100%); Color Temperature (2700-6500K)
3.Press the dial again to switch to another control
④Group Option
Press the button to set group (Group A/B/C/D/E)
⑤ Fan Option
Default Status: SMART
SMART-The xture will adjust the fan speed according to working temperature.
Press the Fan Option and switch to QUIET status.
QUIET-The fan is o. In order to protect the light, the power will be reduced to
avoid overheating damage.
⑥ Fan Status
SMART / QUIET / FULL
⑦Power Status
Percentage icon means battery power is being used
Plug icon means AC power is being used
Brightness Control 0-100%(5% Stepping)
Color Temperature Control (2700~6500K)
EFF
CANDLE
BONFIRE
Specic color temperature range: 2700~3000K
Specic brightness range: 30~100
Rate: 5 levels of icker frequency (05 ﹥ 04 ﹥
03 ﹥ 02 ﹥ 01)
Specic color temperature range: 2700~4000K
Specic brightness range: 30~100
Rate: 5 levels of icker frequency (05 ﹥ 04 ﹥
03 ﹥ 02 ﹥ 01)
CCT Mode
EFF Mode
1. Connect the xture with the power adapter, then plug it into an electricity
supply.
2. Press the Power Button to turn on the light.
Press to switch
⑧ Brightness
⑨Color Temperature
⑩Group
BLN (Pulsing)
FAULTY BULB
FLASH
LIGHTNING
Specic color temperature range: 2700~6500K
Specic brightness range: 30~100
Rate: 5 levels of icker frequency (05 ﹥ 04 ﹥
03 ﹥ 02 ﹥ 01)
Specic color temperature range: 2700~6500K
Specic brightness range: 30~100
Rate: 5 levels of icker frequency (05 ﹥ 04 ﹥
03 ﹥ 02 ﹥ 01)
Specic color temperature range: 5600~6500K
Specic brightness range: 30~100
Rate: 5 levels of icker frequency (05 ﹥ 04 ﹥
03 ﹥ 02 ﹥ 01)
Specic color temperature: 6500K
Specic brightness range: 30~100
Rate: 5 levels of icker frequency (05 ﹥ 04 ﹥
03 ﹥ 02 ﹥ 01)
EFF
Brightness Control / Color Temperature / Rate Control
Short press the Adjustment Dial to switch among color temperature control (
“CCT” ashes), rate control (“RATE” ashes) and brightness control, then roll
the dial to adjust.
Remote Control Instructions
① Switch
② Overclock Mode
③ Brightness +
④ Brightness -
⑤ Color Temperature -
⑥ Color Temperature +
⑦ Fade In/ Fade Out
⑧ CCT Mode
⑨ EFF Mode/ Remote Pairing
⑩ Rate (Flicker Frequency)
⑪ Preset Color Temperature: 3200K
⑫ Preset Color Temperature: 6500K
