Coleman H2Oasis Series User manual

Instructions for Use
IMPORTANT
Read these instructions for use carefully. Familiarise yourself with the appliance before connecting it to its gas
container. Keep these instructions for future reference.
This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.
Follow all warnings and instructions when using the appliance. If you have questions about assembly, operation, servicing
or repair of this product, please call Coleman on 1800 224 350. Coleman Brands Pty Ltd. Suite W2C1, 75-85 O’Riordan St,
Alexandria, NSW 2015. Gas cylinders shall be changed in a well-ventilated location, preferably outside away from people
and any sources of ignition, such as naked flames, pilot flames, electric heaters / equipment. If there is a leak on your
appliance (smell of gas) and you cannot stop the gas flow, remove the appliance to a well-ventilated location away from any
ignition source. Check for leaks using soapy water. Do not try to detect leaks using a flame.
- Outdoor use only -
This appliance is designed to heat a water source up to about 30°C above ambient temperature (to a maximum of 50°C +/- 2°C).
(For illustration purpose only, may look different from your model)
MODEL -
H2Oasis Series

2
Open side at least 25% of
total wall area.
Open side at
least 25% of total
wall area.
30% or more in total
of the remaining wall
area is open and
unrestricted.
30% or more in total
of the remaining wall
area is open and
unrestricted.
(A) An enclosure with walls on all sides, but at least one permanent
opending at ground level and no overhead cover.
(B) Within a partial enclosure that includes an overhead cover and no more
than two walls.
(C) Within a partial enclosure that includes an overhead cover and more
than two walls, the following shall apply:
(1) At least 25% of total wall area is completely open.
Both ends open
(2) 30% or more in total of the remaining wall side, back and front wall
areas is open and unrestricted.
(3) In the case of balconies 20% or more of the total wall area shall be and
remain open and unrestricted.
Outdoor Use Only
This appliance shall only be used in an above ground open air situation with natural ventilation, without stagnant areas, where gas leakage and products of
combustion are rapidly dispersed by wind and natural convection. Any enclosure in which the appliance is used shall comply with one of the following:
Electrical Safety
WARNING! READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury.
1. The HWOD must be recharged only with the specified charger for the battery. A charger that may be suitable for one type of battery may create a risk of
fire when used with another battery.
2. Use only the battery pack specifically designated for the HWOD. Use of any other batteries may create a risk of fire.
3. Do not charge or use the battery pack if it is damaged. Use of damaged batteries may create a risk of fire or explosion.
4. Do not expose batteries to fire or heat. Disposing of batteries in a fire may create a risk of explosion.
5. Do not modify or repair this appliance, battery pack, or charger. Modifying this appliance may result in fire or personal injury.
6. Do use an extension cord.
7. When used outdoors, install only to receptacles approved per local and regional electrical requirements. If one is not provided, contact a qualified
electrician for proper installation.
8. Do not install in a bathroom.
SAVE THESE INSTRUCTIONS – This manual contains important safety and operating instructions for power units.

3
Contents
General Safety Information 3-4
System Overview 4
Before You Go 5
To Set Up 5-7
Use and Operation 7-8
Helpful Hints 9
Storage 9
Maintenance 9
Chart of Indicators 10
Troubleshooting Guide 11
Technical Characteristics 11
Replacement Parts 11
Warranty Information 12
General Safety Information
This manual contains important information about the assembly, operation
and maintenance of this water heater. General safety information is
presented in these first few pages and is also located throughout the
manual. Particular attention should be paid to information accompanied by
the safety alert symbol “ DANGER”, “ WARNING”, “ CAUTION”.
Keep this manual for future reference and to educate new users of this
product. This manual should be read in conjunction with the labeling on the
product.
Safety precautions are essential when any mechanical or propane fueled
equipment is involved. These precautions are necessary when using,
storing, and servicing. Using this equipment with the respect and caution
demanded will reduce the possibilities of personal injury or property
damage.
The symbols shown below are used throughout this manual. Always heed
these precautions, as they are essential when using any mechanical or
propane fueled equipment.
DANGER
DANGER indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
WARNING indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate personal injury, or property
damage.
FOR YOUR SAFETY
If you smell gas:
1. Do not attempt to light appliance.
2. Extinguish any open flame.
3. Disconnect from fuel supply.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
General Safety Information (continued)
DANGER
• CARBON MONOXIDE HAZARD
ONLY USE IN WELL-VENTILATED AREAS. CARBON
MONOXIDE HAZARD—USING THIS APPLIANCE IN
AN ENCLOSED SPACE MAY CAUSE DEATH. DO
NOT USE IN CARAVANS, TENTS, MARINE CRAFT,
CARS,MOBILE HOMES OR SIMILAR LOCATIONS.
DANGER
• EXPLOSION - FIRE HAZARD
•Never store propane near high heat, open flames, pilot lights, direct
sunlight, other ignition sources or where temperatures exceed 120
degrees F (49°C).
•Propane is heavier than air and can accumulate in low places. If you
smell gas, leave the area immediately.
•Never install or remove propane tank while heater is operating, near
flame, pilot lights, other ignition sources or while heater is hot to
touch.
•During operation, this product can be a source of ignition. Never use
the heater in spaces that contain or may contain volatile or air-borne
combustibles, or products such as gasoline, solvents, paint thinner,
dust particles or unknown chemicals. Minimum clearances from
combustible materials: 600 mm from the sides & 1200 mm from the
top.
•Provide adequate clearances around air openings into the product.
DANGER
Failure to comply with the precautions and instructions provided with
this product can result in death, serious bodily injury and property loss
or damage from hazards of fire, explosion, burn, asphyxiation, and/or
carbon monoxide poisoning.
Only persons who can understand and follow the instructions should
use or service this product.
If you need assistance or information such as an instruction manual or
labels, contact The Coleman Company, Inc.

4
Recharger cord storage compartment –
12V auto recharger and 240V household
recharger cords are stored here (240V charger
Available on Elite version only)
Shower (varies by model)-
Detachable handheld shower
Fuse Socket -
Replaceable fuse is
installed here.
Shower Arm–
Adjustable shower
arm that holds the
shower in place.
Power socket for pump –
Power the pump by
connecting the pump
power cord to this socket.
Regulator –
where the gas
cylinder is to be
connected to.
USB Ports x 2 –
(Available on Elite version only)
For charging USB compatible
devices. (voltage: 5V each;
current: ≤1A total)
Display panel (varies by model)-
A display that shows the status of the appliance,
like water temperature, error codes etc. See section
“Chart of Indicators”
Control knob – press to turn in a
counterclockwise direction. Adjust
knob to desired water temperature.
Water outlet –
connects to
shower.
Water inlet –
connects to
pump.
Recharging Port–
plug 12V and 240V
Recharger cords
General Safety Information (continued)
WARNING
•This product is fueled by propane gas. Propane gas is invisible,
odorless, and flammable. An odorant is normally added to help
detect leaks and can be described as a “rotten egg” smell. The
odorant can fade over time so leaking gas is not always detectable
by smell alone.
•Propane gas is heavier than air and leaking propane will sink to
the lowest level possible. It can ignite by ignition sources including
matches, lighters, sparks or open flames of any kind many feet
away from the original leak. Use only propane gas set up for vapor
withdrawal.
•Gas cylinders must be stored outdoors in a well ventilated area out of
the reach of children, any indoor storage shall comply with
AS/NZS 1596.
•Disconnect propane before storing the heater.
WARNING
Not for home or recreational vehicle use.
We cannot foresee every use which may be made of our products.
Check with your local fire safety authority if you have questions
about use.
Other standards govern the use of fuel gases and heat producing
products for specific uses. Your local authorities can advise you about
these.
•Neverrefilldisposablecylinders.
•Usethepresetregulatorthatisinstalledinthewaterheater.Do
not attempt to adjust.
WARNING
• BURN HAZARD
•Never leave heater unattended when hot or in use.
•Do not touch metal parts and venting holes of the heater, which may
get very hot when in use.
•Keep out of reach of children.
WARNING
SERVICE SAFETY
•Keep all connections and fittings clean. Inspect propane cylinder and
propane connections for damage before attaching.
•During set up, check all connections and fittings for leaks using
soapy water. Never use a flame. Bubbles indicate a leak. Check that
the connection is not cross-threaded and that it is tight. Perform
another leak check. If there is still a leak, remove the cylinder and
contact Coleman for service or repairs.
•Use for water heating only. Never alter in any way or use with any
device or part not expressly approved by Coleman.
•Always use in an upright position.
NOTE: THIS APPLIANCE IS NOT INTENDED FOR THE SUPPLY OF
DRINKING WATER.
System Overview
Thank you for purchasing Coleman’s Hot Water on DemandTM unit. This portable and self-contained water heater is designed to provide hot water for outdoor
showering / cleaning tasks only. Do not use the product to heat drinking water.
Battery compartment –
12 volt / 2000 mAh
rechargeable Li-Ion battery
is located in compartment.
Battery operates the pump &
circuitry.
Flame Window –
check status of
pilot light or insert
a lit match through
this window to
light the heater
manually.
Main Power Switch–
(Available on Elite
version only)

5
Before You Go
UNPACKING THE PRODUCT.
Unpack your new water heater from the carton and make sure that all of the parts are included. If you find that one of the components is missing, please
contact Coleman for a replacement: 1-800-224-350. Make sure to remove the protective film on the display panel on the front of the heater before use.
5-Gallon Collapsible Water
Carrier
12 Volt Auto Recharger Cord
(Located in storage compartment
of the appliance)
240 Volt Household Recharger
Cord (available on Elite version only,
located in storage compartment)
Pump Assembly Shower Hose Mesh Hose Carrybag
Shower
(varies by model)
Shower Arm
CHARGING THE BATTERY
1. Charge the battery before using your water heater for the first time.
2. Turn the main power switch to “OFF” position (available on Elite
version only)
3. (Fig. 1) Remove the rubber flap covering the charging port.
4. Plug either 12 Volt Auto Recharger Cord or 240 Volt Household
Recharger Cord into unit and the power source.
5. See indicator chart for battery status / charging status.
NOTE: Please charge the battery for 6 hours at the first time to
maximize the performance of the battery.
CLEANING THE PRODUCT
Clean before first use. It is strongly recommended that you clean the heater prior to using for the first time. Follow the simple steps on page 7 before you leave
home, and then clean at least once a year or when the hose becomes discolored with a white calcium build up.
To Set Up
Select a level, sturdy surface for your water heater. A picnic table or camp table is ideal. Do not
operate Hot Water on DemandTM unit from a position directly on the ground. (This allows water to drain,
preventing damage while the unit is off in freezing temperatures.)
Fill the 5-gallon collapsible water container with water. The product may use water from a lake or
stream, but make sure that there’s no debris or sand in the water, which may clog the water system
and damage the product. It’s recommended to use a piece of cloth
as filter to cover the opening of the water carrier before filling in
water.
SHOWER HEAD CONNECTION (FIG. 2)
•Shower end: threaded connector
Screw the threaded connector on the shower hose onto the end of
the shower.
•Heater end: sleeved connector
A- Pull up & hold the sleeve on the connector.
B&C- While holding the sleeve, push the connector into water outlet until it
stops.
D- Release the sleeve and the connector is locked.
IMPORTANT: To unplug the shower hose from the heater, pull up the sleeve to unlock
first, while holding the sleeve, pull out the connector.
A B
CD
Fig. 2
THIS SIDE UP
Fig. 1
OFF
1
2

6
To Set Up (continued)
WATER PUMP CONNECTION
•Pump end (Fig. 3):
1. Place the water carrier at a level below the water heater
for proper drainage.
2. Screw the water pump to the opening of the water
container & hand tighten.
3. Lay the water container on its side so the pump is
towards the bottom of the container (step 2).
4. Make sure to rotate the pump where “THIS SIDE UP” is
facing upward so pump will prime and water will flow.
TIP: You can also submerge The Water Pump into an open
water container such as a cooler (cooler not included). Or if available, you can connect a garden hose directly to the unit. Ensure water flow is not too high,
this will affect the ability of the unit to heat water and could possibly force the outlet connection to disconnect. Conversely ensure water flow is not too low,
this can cause a low flow error. Ensure water is flowing before lighting the unit and adjust flow as required.
•Heater end (Fig. 4):
1. Plug the pump power jack into the pump power socket on the heater.
2. Plug the sleeved connector of the pump into the water inlet on the heater. (Follow same steps A, B, C, D given in section “SHOWER CONNECTION”)
SHOWER ARM INSTALLATION
1. Dismantle The Shower Arm by screwing off
the adjustment knob (Fig. 5).
2. Install The Shower Arm to the rail on
heater, and tighten by screwing on the
adjustment knob. (Fig. 6)
3. Loosen the Adjustment Knob and adjust
the angle & height of The Shower Arm,
once the desired position is reached,
tighten the adjustment knob (Fig. 7).
4. After the Shower Arm is installed, you may put The Shower onto The Shower Arm.
GAS CYLINDER INSTALLATION (FIG. 8)
This appliance shall only be used with Propane LPG Coleman disposable gas cylinders
certified to DOT-39 NRC 232/290 M1110.
IT MAY BE HAZARDOUS TO ATTEMPT TO
FIT OTHER TYPES OF GAS CONTAINERS.
Check that all seals between the appliance
and the gas cylinder are in place and in good condition before connecting the gas cartridge.
Remove all transit protection material. DO NOT move the appliance during operation. After use,
turn the control knob off. Do not use MAPP gas cylinders or any other fuel except propane.
1. Turn the control knob to OFF position.
2. Remove cap from the propane gas cylinder but do not discard.
3. While holding the propane cylinder upright, thread it into The Regulator.
A B
CD
THIS SIDE UP
THIS SIDE UP
To water
carrier / tank
To water inlet
on heater
To power socket on heater
THE WATER PUMP
Fig. 3 Fig. 4
OFF
REGULATOR
Fig. 5 Fig. 6 Fig. 7
Fig. 8
THIS SIDE UP

7
To Set Up (continued)
GAS LEAK CHECK
WARNING
•Perform leak test outdoors.
•Extinguish all open flames.
•NEVER leak test when smoking.
•Do not use Hot Water on DemandTM unit until connection has been leak tested and does
not leak.
1. Make 60 to 90 ml of leak check solution
(one part liquid dishwashing detergent
and three parts water).
2. Apply several drops of solution at the
connection between the propane cylinder
and the regulator.
3. Bubbles indicate a leak.
4. Check that the connection is not cross-
threaded and that it is tight.
5. Perform another leak check. If there is still
a leak, remove the cylinder and contact
Coleman for services or repair.
Use and Operation
Clean before first use. It is strongly recommended that you clean the heater prior to using for the first time. Follow these simple steps before you leave home,
and then clean at least once a year or when the hose becomes discolored with a white calcium build up.
CAUTION: accessible parts may be very hot. Keep young children away, USE OUTDOORS ONLY. Must only be operated on a horizontal surface. Not suitable
for marine environments. Do not modify this appliance. Annual service by an authorised person is recommend. Or if any of the following conditions are
noticed; incomplete ignition, appreciable yellow tipping, carbon deposition, lifting, floating, lighting back or objectionable odor. DO NOT use this appliance
if it has damaged or worn seals. DO NOT use this appliance if it is leaking, damaged or does not operate properly. To check if the gas cylinder is empty,
disconnect the cylinder from the appliance and shake from side to side. If there is no sound or movement of liquid, the cylinder is empty.
LIGHTING THE HEATER
Before lighting the heater, please make sure that the water supply is ready, the shower connection & pump connection is setup, the gas cylinder is installed and
the rechargeable battery is not running low (check battery status by referencing the section “Chart of Indicators” or see section “Charging the Battery”).
• Electronic Ignition
1. Turn on the main power switch (available on Elite version only).
2. Turn on the electrical system by switching the power button “ON”, which is located
on the display panel. When powered on:
On ELITE version - battery indicator is lit and the current environment temperature is
displayed.
On STANDARD version - a flashing green light on Display Panel indicates that the
electrical system is powered on.
IMPORTANT: When powered on, the pump starts to pump & water starts to run,
before the heater being ignited. To conserve water usage, get yourself familiar
with the complete operation instructions before you switch the power on.
3. Press and turn the control knob counter-clockwise to the ignition position “ PILOT”.
4. Press and hold (7~10 seconds) the control knob to start the electronic ignition sequence, you will hear the clicking sound.
5. While pressing control knob, check whether the pilot light is lit by reading the indicator on the display (see section Chart of Indicators).
NOTE: Ignition takes longer time at the first use for the reason that gas runs through and fills the gas line.
6. When the pilot light is lit, then turn the control knob counter-clockwise to a setting between “MAX” and “MIN” for a desired water temperature.
NOTE: At “MAX” setting, the heater can increase the water temperature by about 30°C. If the electronic ignition fails to light the pilot light, please refer to
the below section “Match Lighting” or the “Troubleshooting” section.
• Match Lighting
1. Switch the power button on.
2. Press and turn the control knob counter-clockwise to the ignition position “ PILOT”.
3. Put a lit match near the burner by inserting it through the flame window, then press and
hold the control knob until the pilot is lit (see indicator on display)
4. Turn the control knob counter-clockwise to a setting between “MAX” and “MIN” for a
desired water temperature.
NOTE: It is typical to experience a slight change in water flow & temperature when moving
spray adapter from high to low heights.
PRESSE
PRESSE PRESSE
Varies by model
PRESSE PRESSE
Fig. 9
ON

8
Use and Operation (continued)
SHUTTING OFF THE HEATER
1. Turn the control knob clockwise to the “OFF” position.
2. Switch off the power button on the display panel.
3. Turn the main power switch to “OFF” (available on Elite version only).
IMPORTANT: User must not change the order of the shut-off-operation sequence. Always shut off the burner and
gas supply by turning the control knob to the “OFF” position first, then switch off the power button.
STOPPING THE HEATER TEMPORARILY
Due to safety reasons, there’s no switch to pause the water flow while taking a shower. You can only shut off the main burner by turning the control knob
clockwise back to the ignition position “ PILOT” to conserve gas, the pilot light remains lit, the pump & water keeps running. To resume heating the water, turn
the control knob counter-clockwise to a setting between “MAX” & “MIN” position.
Or you may shut off the heater completely by following steps in above section “Shutting Off the Heater”, then restart the whole ignition process illustrated in
section “Lighting the Heater”.
CLEANING INSTRUCTIONS
1. In a clean container mix two-gallons of water with 12 oz. of
calcium, lime, and rust remover (available at the cleaner section
of hardware, general merchandise and food stores).
2. Place the pump and shower in the container with the water/
solution. The label “This Side Up” on pump should be facing up.
3. Start the heater by following instructions in section “Lighting the
Heater” and turn the control knob to a “warm” setting.
4. Circulate the water/solution through the heater for 2 minutes,
then turn off heater by turning the knob clockwise to the “off”
position and switching off the power button on display panel.
5. Dispose of the cleaning solution in a sink or other drain, do not
dump on the ground.
6. Fill container with 9 litres of clean water.
7. Place the pump and shower in the container with the water.
8. Turn the heater on and circulate the clean water through the
water heater for 2 minutes at the “cool” setting,
9. Turn the heater off.
10.Repeat steps 6-9 with another batch of clean water.
11.Clean the screen at the pump water inlet to remove the residue that may clog the pump. See maintenance section on page 8 for instructions.
CHARGING USB COMPATIBLE DEVICES (Available on ELITE version only)
You may charge 2 mobile phones at the same time by connecting the phones to the USB ports on the
heater. The capacity of the rechargeable battery inside the heater is 2000 mAh, which could charge a
1570 mAh mobile phone (iPhone 5s) one complete cycle.
IMPORTANT: USB ports only work when the Main Power Switch is turned on. Do not connect
devices to the USB ports on the heater when the heater is in operation or is still hot to touch. Do
not connect devices to the USB ports on the heater if there’s a “LOW BATTERY” indication on the
Display Panel (see chart of indicators in section “Chart of Indicators”). Do not charge devices
whose battery capacity exceeds 1700 mAh.
CHANGING TEMPERATURE DISPLAY
(available on ELITE version only)
Current water temperature is shown on Display
Panel, cycle through the Celsius / Fahrenheit
display by pressing the button repeatedly
on the Display Panel.
CHANGING SHOWER SPRAYS
(available on ELITE version only)
The shower features aerated, full and
fine sprays. Change the spray by rotating
the dial on the shower head. You may
shut-off the water by rotating the dial on
shower head to OFF position.
NOTE: When the heater is powered on, turning the dial on the shower
head to “OFF” position will trigger the LOW WATER FLOW warning and
shut off the unit. Please ensure shower head is open before restarting.
PRESSE
PRESSE
Cool
Warm
Water / solution cycle
Clean water cycle
OFF
IGNITE
IGNITE OFF
OFF

9
Helpful Hints
•There’s a hook-&-loop strap on the back of the shower, you may tie the shower onto an overhead object (available on ELITE version only).
•If you do not intend to use the water heater for a period of time (3 days or longer), it is strongly recommended to turn the main power switch to ‘OFF’. This
will prolong the charge of your battery (applicable to Elite version only).
•Never place the shower 2 metres above the heater, otherwise the water flow may drop to a warning level triggering the shut-off mechanism.
•Never twist or bend hoses that the water runs through, which will lead to a drop of water flow and trigger the shut-off mechanism.
•The heater will typically make 150 Litres of warm or hot water on one full battery charge and a 16.4 oz. cylinder of propane. Make sure to pack sufficient fuel
for the duration of your outing.
•Due to the integrated mechanical and electrical over-temperature shut-off devices, the burner will be shut off immediately when the water temperature
reaches 50°C at the water outlet on the heater. Meanwhile the pump will continue to pump for 30 seconds, to cool down the heater.
•The water heater is ideal for many outdoor cleaning tasks. Coleman supports the Leave No Trace Principles that encourage minimal impact to the
environment while camping. You’ll find that less soap is necessary with warm water than with cool or cold water, so use small amounts of biodegradable
soap. Please dispose of your gray water responsibly. Wash yourself or dishes 61 metres away from streams or lakes to avoid soap run-off finding its way to
a natural water source. Contact your campground or park to learn about their specific gray water disposal policy.
•Continuous operation of water heater at warm setting for 20 minutes may cause the propane cylinder to freeze up. Let the cylinder thaw or replace with a
fresh propane cylinder.
Storage
• Remove propane cylinder from heater after use and before transporting or storing the heater. If using a bulk tank, disconnect the hose from the bulk tank
before transporting or storing. Always store propane outdoors.
• Drain water from hoses and unit before storing: Disconnect hoses and lean product toward the hose connection side. Move the unit left to right while
leaning until water drainage stops.
• Recharge the battery before storing. Turn off the main power switch (applicable to Elite version only).
• For long term storage, clean and dry the heater and store indoors in a clean and dry location.
•Coleman’s padded carry case is ideal for storing and transporting.
Maintenance
This appliance must only be serviced by an authorised person.
• Clean water heater at least once a year or whenever a white build up appears in the hose. Refer to Cleaning Instructions on page 6 of this manual.
• Charge battery immediately after each outing to reach optimum performance.
• Replacing battery (see illustrations below)- Use only a Coleman®replacement battery #1394551 (12 Volt, 2000 mAh Li-Ion battery).
1. Remove the screw from the battery cover on the right side of your water heater and remove the cover.
2. Pull the battery out from storage compartment and unplug the connectors.
3. Replace the battery and connect the connectors, make sure the circular pin and the rectangular pin on male connector are correctly aligned with the
circular hole and rectangular hole on the female connector. Replacement batteries are available to order from Coleman.
• Replacing fuse (see illustrations below)- Use only a Coleman® replacement fuse #1394557 (current rating: 5A).
Remove the screw from the fuse socket right above the battery compartment, discard the defective fuse and replace with a new one.
• Replacing the Recharging Cords - Use only a Coleman replacement recharging cord #1394553 (240V) or #1394554 (12VDC). Unplug the cord if
necessary, and replace with the new one.
• Cleaning pump screen (see illustrations below)-
1. Grip the nozzle at the end of the pump and rotate counter-clockwise to screw it off.
2. Separate the nozzle and the ring cap.
3. Use your finger to push the pump screen out from the nozzle and clean the screen.
4. Then reverse the steps to put the parts together.
Battery Replacement
Fuse Replacement
Sealing O-ring
Screen Cleaning

10
Chart of Indicators
Standard
Version
Steady light: Flashing light:
/ /
(Red / Yellow / Green)
/ /
(Red / Yellow / Green)
Explanation Display of Indicators Trigger System Reaction Corrective Action
Battery being charged
Battery fully charged
Electrical system is
turned on
Pilot Light is lit
Hot water warning
(chamber)
Water temperature at heat
exchanger exceeds 55°C.
Gas will be cut off immediately. Pump will
be shut off in 30 seconds.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Hot water warning
(water outlet)
Water temperature at water
outlet exceeds 50°C.
Gas will be cut off immediately. Pump will
be shut off in 30 seconds.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Tilt warning Heater is tilted more than 30
degrees. Gas & pump will be shut off immediately.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Flames out warning Flames out / pilot light out Gas & pump will be shut off immediately.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Low battery warning In-house battery voltage is
lower than 9.8V. Gas & pump will be shut off immediately.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Low water flow
warning
Water flow rate is lower that
1.5 L/min.
2 seconds after the first warning is
signaled, system will detect the flow rate
again; if the flow rate is still lower than the
specified level, gas & pump will be shut off.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Elite Version
Explanation Display of Indicators Trigger System Reaction Corrective Action
Battery being charged (animated)
Battery fully charged
Pilot Light is lit
Water is running
Hot water warning
(chamber)
Water temperature at heat
exchanger exceeds 55°C.
Gas will be cut off immediately. Pump will be
shut off in 30 seconds.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Hot water warning
(water outlet)
Water temperature at
water outlet exceeds 50°C.
Gas will be cut off immediately. Pump will be
shut off in 30 seconds.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Tilt warning Heater is tilted more than
30 degrees. Gas & pump will be shut off immediately.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Flames out warning Flames out / pilot light out Gas & pump will be shut off immediately.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Low battery warning In-house battery voltage is
lower than 9.8V. Gas & pump will be shut off immediately.
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.
Low water flow
warning
Water flow rate is lower
that 1.5 L/min. Gas & pump will be shut off 2 seconds later
Turn off the control knob and the power button.
See troubleshooting section and solve the
problem, then restart the ignition sequence.

11
Troubleshooting Guide
Symptom Possible Cause Solution
Hot water warning
Water tank/carrier is running out of water Fill water tank/carrier with water.
Environment temperature is high Turn control knob to a cooler setting.
Temperature sensor defective Contact Coleman Service Center and return the product to Coleman when necessary.
Tilt warning Heater is tilted more than 30 degrees. Gas & pump will be shut off immediately.
Sensor defective Contact Coleman Service Center and return the product to Coleman when necessary.
Flames out warning
Flames blown out by strong wind / pilot light is
out
Do not use in strong wind condition. Turn off the heater completely and restart the ignition
sequence.
Flame detection module defective Contact Coleman Service Center and send to Coleman when necessary.
Low battery warning Battery voltage lower than 9.8V. Recharge the battery.
Defective battery Contact Coleman Service Center and replace the rechargeable battery.
Low water flow warning
Pump is not in correct position Rotate pump so “THIS SIDE UP” is facing upward.
Water tank/carrier out of water Fill water tank/carrier with water.
Pump inlet screen clogged Clean the screen, seen instructions given in maintenance section.
Hose twisted / kinked Straighten hose.
Battery lead disconnected Remove battery cover & reinstall lead.
Pump power cord disconnected Plug cord into power socket on heater.
Low battery Recharge the battery.
Flow rate sensor defective Contact Coleman Service Center and send to Coleman when necessary.
Burner will not light
Propane cylinder empty Replace cylinder.
Propane cylinder frosted Replace cylinder and reuse after thawing.
Fuse defective Refer to maintenance section and replace the fuse.
Electronic circuit defective Contact Coleman Service Center and send to Coleman when necessary.
Water leakage
Connectors cross-threaded;
Sleeved-connectors were not locked into place
Reconnect the connectors.
Read instructions for connecting sleeved connectors and reconnect the connectors.
Defective seal or break Replace sealing components (O-rings) or send to Coleman when necessary
Hose turns white or
discolors inside Calcium buildup Clean heater (refer to section “cleaning instructions” on page 7)
Battery won’t hold a Charge Defective Battery Refer to replacement parts section and replace battery
Main power switch is neglected See Helpful Hints section on how to use the main power switch
No display
Battery lead disconnected Remove battery cover & reinstall lead
Fuse defective Refer to maintenance section and replace the fuse.
Electronic circuit defective Contact Coleman Service Center and send to Coleman when necessary.
Low battery Recharge the battery.
Main power switch at “OFF” position (for Elite
version only) Turn on the main power switch
Technical Characteristics
Pressure: 2.8 kPa
Injector size: 0.66mm
Total gas consumption: 21.0 MJ/h
Gas type: Propane LPG
Replacement Parts
Parts List
Part No.# Description
1. 1391737 HWOD H2Oasis Elite Shower Head
2. 1392747 HWOD H2Oasis 8 Foot Silicone Hose
3. 1392757 HWOD H2Oasis Adaptor Storage Cover
4. 1392758 HWOD H2Oasis Shower Head Bag
5. 1394550 HWOD H2Oasis Regulator
6. 1394551 HWOD H2Oasis Lithium Ion Battery
7. 1394552 HWOD H2Oasis Pump & Hose
8. 1394553 HWOD H2Oasis Recharging Cord 240V
9. 1394554 HWOD H2Oasis Recharging Cord 12VDC
10. 1394555 HWOD H2Oasis Knob
11. 1394556 HWOD H2Oasis Shower Head Bracket
12. 1394557 HWOD H2Oasis Fuse

Coleman Brands Pty. Ltd.
ABN 74 091 681 195
Suite W2C1, 75-85 O’Riordan Street, Sydney Corporate Park, Alexandria, NSW 2015
Australia
Telephone: [phone] or + 61 2 8762 5000
www.colemanaustralia.com.au
©2015 The Coleman Company, Inc. All Rights reserved.
Coleman® and are registered trademarks and
HOT WATER ON DEMAND™ is a trademark of The Coleman Company, Inc.
4010047123 (ECN20054446-03)
Warranty Information
Three Year Limited Warranty
Coleman Brands Pty. Ltd. (“Coleman”) warrants that for a period of three (3) years from the date of original retail purchase, this product will be free from
defects in material and workmanship. Coleman will, depending on the circumstances, refund, repair or replace this product or any component of the product
found to be defective during the warranty period. Replacement will be made with a new or remanufactured product or component. If the product is no longer
available, replacement may be made with a similar product of equal or greater value. To the extent permitted by law and subject to your non-excludable rights
under the Australian Consumer Law (Schedule 2 to the Competition and Consumer Act 2010 (Cth)) and the New Zealand Consumer Guarantees Act, which are
not limited to a one (1) year period, this is your exclusive remedy for any breach of this limited warranty or for any other claims otherwise relating to this limited
warranty.
In Australia, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a
major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure. The benefits provided under this warranty are in addition to and do not affect
purchaser’s statutory rights under the Australian Consumer Law or other rights at law.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable. Please keep your proof of purchase doc-
umentation, such as the original sales receipt or the relevant credit card statement. Proof of purchase is required to obtain warranty performance. Coleman
dealers, Coleman service centres, or retail stores selling Coleman® products do not have the right to alter, modify or in any way change the terms and con-
ditions of this warranty. The warranty is valid only for products that are purchased new and unused in Australia and New Zealand, from Coleman or Coleman
dealers or retailers.
WARRANTY EXCLUSIONS AND LIMITATIONS
THE AUSTRALIAN CONSUMER LAW PROVIDES CONSUMERS WITH CERTAIN ‘CONSUMER GUARANTEES’. THESE GUARANTEES APPLY WHERE
THE GOODS AND SERVICES COLEMAN SUPPLIES TO YOU ARE OF A KIND ORDINARILY ACQUIRED FOR PERSONAL, DOMESTIC OR HOUSEHOLD
USE OR COST LESS THAN $40,000, AND IN THE CASE OF GOODS, ARE NOT RE-SUPPLIED BY YOU. NOTHING IN THIS LIMITED WARRANTY
EXCLUDES, RESTRICTS OR MODIFIES RIGHTS WHICH YOU HAVE UNDER THE AUSTRALIAN CONSUMER LAW IN RESPECT OF THE CONSUMER
GUARANTEES AND ALL OF THE PROVISIONS IN THIS SECTION ARE TO BE READ SUBJECT TO THE AUSTRALIAN CONSUMER LAW.
This warranty does not cover: (a)normal wear of the product and/or its parts; (b) parts that are not genuine Coleman® parts, consumables, lost parts and
accessories; (c) damage resulting from any of the following: negligent use or misuse of the product, commercial use of the product, use contrary to the operat-
ing instructions; disassembly, repair or alteration by anyone other than Coleman or Coleman service centre, the use of a part other than a genuine Coleman®
part; or (d) acts of God, such as fire, flood, hurricanes and tornadoes.
To the extent permitted by the Australian Consumer Law, the Competition and Consumer Regulation 2010 and the New Zealand Consumer Guarantees Act,
Coleman’s liability is limited, depending on the circumstances, to refund, replacement or repair of Coleman® products or components.
For the avoidance of doubt, any and all other warranties or conditions which are not guaranteed by the Australian Consumer Law, the Competition and
Consumer Regulation 2010 and the New Zealand Consumer Guarantees Act and which are not expressly included in this warranty as additional warranties or
conditions are expressly excluded, including liability for incidental or consequential damages caused by the breach of any express or implied warranty or con-
dition.
MAKING A WARRANTY CLAIM - RETURN TO COLEMAN FOR REPAIR
Take the product to an authorised Coleman retailer or Coleman service centre as soon as the warranty claim arises. You may locate the nearest authorised
Coleman retailer or Coleman service centre by visiting www.colemanaustralia.com.au or calling 1800 224 350 or + 61 2 8762 5000. Please ensure that you pro-
vide a written description of the problem with the product, together with your contact name, address and telephone number and proof of purchase.
Subject to the applicable consumer laws in your jurisdiction, you must pay for the costs of transporting the product, including packaging, freight and insur-
ance costs, to an authorised Coleman retailer or Coleman service centre for warranty service. If the warranty claim is substantiated and accepted by Coleman,
Coleman will at its cost, repair or replace any product or parts and return the product to you. Additionally, if the warranty claim is substantiated and accept-
ed by Coleman, Coleman will reimburse you for the costs of transporting the product to an authorized Coleman retailer or Coleman service centre. Coleman
reserves the right to seek reimbursement for any costs and expenses incurred for a warranty claim if the product is found to be in good working order.
If you have any questions regarding this warranty please call 1800 224 350 or + 61 2 8762 5000.
