Coleman AKTIV SOUNDS CBT40 User manual

Powering CBT40 On / Off
Press and Hold the POWER button for 3
seconds to power ON. You will hear an audible
tone. A blue LED will flash quickly to indicate
that it is powered on and searching for a
Bluetooth source to pair with.
To power the speaker off, press and hold the
POWER button for 3 seconds to power off.
NOTE: The speaker will automatically power off
after several minutes if the Bluetooth connection
is not paired with a device.
NOTE: An additional battery icon will appear
next to the Bluetooth icon at the top right of your
battery level. This is compatible only with certain
devices.
Connecting CBT40 via Bluetooth
Once powered on, the speaker will automatically
enter pairing mode.
Bluetooth settings and enable Bluetooth. Next,
enter the Bluetooth device list and select
Coleman_CBT40. After selected, wait a few
seconds for the pairing to complete. Once the
pairing is successful, you will hear an audible
tone from the speaker and a blue LED will flash
slowly.
NOTE: The CBT40 will automatically connect to
a previously paired device if the pa
Bluetooth radio is powered, enabled and within
reachable distance.
Connecting CBT40 via Auxiliary Input
If you would like to use a device that is not
equipped with Bluetooth technology, simply
connect the included auxiliary 3.5mm cable from
your device to the Aux-In input at the side of the
CBT40. Bluetooth audio will mute while a 3.5mm
cable is plugged in. While connected via
Auxiliary, the only controls that will function on

the speaker is the PLAY/PAUSE button. All
other functions are controlled from the
connected device.
Controlling the Sound on Your CBT40
PLAY / PAUSE
Tap the PLAY/PAUSE button.
VOLUME UP / DOWN
Press and hold the + button to increase the
volume and press and hold the - button to
decrease the volume.
FORWARD / BACKWARD TRACK
Tap + button to skip a track forward. Tap the -
button to go to the previous track.
ANSWER / END PHONE CALL
Tap the PLAY/PAUSE button.
DECLINE PHONE CALL
Press and hold the PLAY/PAUSE button.
Answering or Making Calls
If there is an incoming call on your paired
phone/tablet, the music will pause and the ringer
will ring through the CBT40 speaker. To answer
a call, simply press the PLAY/PAUSE button.
To end a call, simply press the PLAY/PAUSE
button. Press and hold the PLAY/PAUSE button
to decline a phone call.
NOTE: For best performance and clarity,
operate the CBT40
Ensure that the microphone faces your direction.
Charging your CBT40
Open the watertight sealed door, and simply
plug the included micro USB cord into the micro
USB port at the base of the speaker. Once
plugged in, the LED will flash red slowly. It will
turn off once the internal battery is fully charged.

Preserving the Waterproof Seal
Ensure that the side compartment door is fully
pushed in. This will prevent any dust and
moisture from entering the USB and AUX ports.
Factory Reset
If you are experiencing connectivity issues, you
may need to perform a hard reset on your
CBT40. To do so, turn off the speaker, then
press the power button for ten seconds. An
audible tone will sound, followed by the LED
flashing blue. Once reset successfully, the LED
indicator will flash quickly and will enter pairing
mode.
Specifications
Bluetooth Version: 5.0
Built-in Lithium-Polymer Battery: 3.7V, 1500mAh
Charging Voltage: 5V
Speaker: 50 6.5W x 1
Frequency: 100Hz-20KHz
1%
Effective Distance: 10M
Waterproof Grade: IPX4
