Coleman 500174 User manual

STURDY • EASY TO USE • DURABLE
QUESTIONS, PROBLEMS, MISSING PARTS?
Before returning to your retailer, visit our web site or call our customer service at
www.coleman-tools.com / 1-888-253-4620
PLEASE KEEP THE ORIGINAL BOX, PACKAGING AND RECEIPT. BEFORE OPERATING
THIS UNIT, PLEASE READ THIS MANUAL THOROUGHLY AND RETAIN IT FOR FUTURE
REFERENCE.
Purchase Date: _____________________ Serial #: _______________________
20V LI-ION 4-PC. CORDLESS
COMBO KIT
OWNER’S MANUAL
Model No: 500174
is a registered trademark of
The Coleman Company, Inc. used under license.
© 2012 The Coleman Company, Inc.

1 2
TABLE OF CONTENTS
Safety Guidelines – Definitions ............................................................................................................1
General Power Tool Safety Warnings............................................................................................... 2
Specific Safety Rules ..........................................................................................................................3-4
Important Safety Instructions for Chargers...............................................................................5-6
Important Safety Instructions for Battery Packs.....................................................................6-7
Charging Procedure............................................................................................................................7-8
Functional Description.................................................................................................................... 9-26
Drill Functional Description..................................................................................................... 9-12
Impact Driver Functional Description................................................................................ 13-15
Reciprocating Saw Functional Description.....................................................................17-20
Circular Saw Functional Description .................................................................................21-26
Troubleshooting Functional Description.......................................................................................27
Warranty................................................................................................................................................... 28
SAFETY GUIDELINES - DEFINITIONS
It is important for you to read and understand this manual.
The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS.
The symbols below are used to help you recognize this information.
DANGER
Indicates an imminently hazardous
situation that, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation
which, if not avoided, could result in death
or serious injury.
CAUTION
Indicates a potentially hazardous situation
that, if not avoided, may result in minor or
moderate injury.
NOTICE
Used without the safety alert symbol
indicates a potentially hazardous situation
that, if not avoided, may result in property
damage.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING
Read all safety warnings and instructions.
Failure to follow the warnings and
instructions may result in electric shock, fire
and/or serious injury.
NOTICE
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks, which may ignite the
dust or fumes.
c) Keep children and bystanders away while
operating a power tool. Distractions can
cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified
plugs and matching outlets will reduce
risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators. There
is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions. Water entering a power tool
will increase the risk of electric shock.
d) Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
e) When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp
location is unavoidable, use a ground
fault circuit interrupter (GFCI) protected
supply. Use of a GFCI reduces the risk of
electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication. A moment
of inattention while operating power
tools may result in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the o-position before
connecting to power source and/or
battery pack, picking up or carrying
the tool. Carrying power tools with your
finger on the switch or energizing power
tools that have the switch on invites
accidents.
d) Remove any adjusting key or wrench
before turning the power tool on.
A wrench or a key left attached to a
rotating part of the power tool may result
in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewelry. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair
can be caught in moving parts.
g) If devices are provided for the connection
of dust extraction and collection
facilities, ensure these are connected
and properly used. Use of dust collection
can reduce dust-related hazards.
h) Wear ear protectors while using power
drill and/or impact driver. Exposure to
noise can cause hearing loss.

3 4
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
b) Do not use the power tool if the switch
does not turn it on and o. Any power
tool that cannot be controlled with
the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may aect the power
tool’s operation. If damaged, have
the power tool repaired before use.
Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
GENERAL POWER TOOL SAFETY WARNINGS
• Hold power tool by insulated gripping
surfaces when performing an operation
where the cutting accessory may contact
hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may
make exposed metal parts of the power
tool “live” and could give the operator an
electric shock.
• Use clamps or another practical way to
secure and support the work piece to a
stable platform. Holding the work by hand
or against your body leaves it unstable
and may lead to loss of control.
• When not in use, place tool on its side on
a stable surface where it will not cause a
tripping or falling hazard. Some tools with
large battery packs will stand upright but
may be easily knocked over.
• Keep your hair, clothing, and gloves away
from air vents. Air vents often cover
moving parts in which these items can be
caught.
• Hold tool firmly with two hands, one hand
on the handle, and the other gripping
the bottom around the battery area.
Use auxiliary handle if provided. Loss of
control can cause personal injury.
WARNING
Some dust created by power sanding,
sawing, grinding, drilling, and other
construction activities contains chemicals
known to the State of California to cause
cancer, birth defects or other reproductive
harm.
Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement
and other masonry products, and
• arsenic and chromium from chemically-
treated lumber.
g) Use the power tool, accessories and
tool bits etc., in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger specified
by the manufacturer. A charger that
is suitable for one type of battery pack
may create a risk of fire when used with
another battery pack.
b) Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c) When battery pack is not in use, keep
it away from other metal objects like
paper clips, coins, keys, nails, screws,
or other small metal objects that can
make a connection from one terminal to
another. Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery, avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from
the battery may cause irritation or burns.
6) SERVICE
a) Have your power tool serviced by
a qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool
is maintained.
SPECIFIC SAFETY RULES
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemicals: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
• Avoid prolonged contact with dust from
power sanding, sawing, grinding, drilling,
and other construction activities. Wear
protective clothing and wash exposed
areas with soap and water. Allowing dust
to get into your mouth, eyes, or lay on the
skin may promote absorption of harmful
chemicals.
WARNING
Improper connection of power outlet can
result in a risk of electric shock. Check with
a qualified electrician or service personnel if
you are in doubt as to whether the outlet is
properly grounded. Do not modify the plug
provided with the product—If it will not fit
the outlet; have a proper outlet installed by
a qualified electrician. Do not use any type
of adaptor with this product.
WARNING
ALWAYS use safety glasses. Everyday eye
glasses are NOT safety glasses. Also use
face or dust mask if cutting operation is
dusty.
SPECIFIC SAFETY RULES
The label on your tool may include the following symbols:
V ............................................................................................................................................................... Volts
Hz ............................................................................................................................................................ Hertz
min ..................................................................................................................................................... Minutes
A ....................................................................................................................................................... Amperes
W ............................................................................................................................................................ Watts
~ .................................................................................................................................. Alternating Current
n
o ........................................................................................................................................... No Load Speed
.../min ............................................................................. Revolutions or Reciprocations Per Minute
Always Wear Certified Safety Equipment:
• ANSI Z87.1 eye protection (CAN/CSA
Z94.3)
• ANSI S12.6 (S3.19) hearing protection
• NIOSH/OSHA/MSHA respiratory
protection

5 6
IMPORTANT SAFETY INSTRUCTIONS FOR CHARGER
SAVE THESE INSTRUCTIONS
This manual contains important safety
instructions for battery chargers.
Before using charger, read all
instructions and cautionary markings on
charger, battery pack, and product using
battery pack.
CAUTION
Under certain conditions, with the
charger plugged in to the power
supply, the charger can be shorted by
foreign material. Foreign materials of
a conductive nature such as, but not
limited to, steel wool, aluminum foil, or
any buildup of metallic particles should
be kept away from charger cavities.
Always unplug the charger from the
power supply when there is no battery
pack in the cavity. Unplug charger before
attempting to clean.
WARNING
Shock hazard. Do not allow any liquid to
get inside charger.
WARNING
• DO NOT attempt to charge the battery
pack with any chargers other than the
ones in this manual. The charger and
battery pack are specifically designed
to work together.
• These chargers are not intended
for any uses other than charging
designated Coleman® rechargeable
batteries. Any other uses may result
in risk of fire, electric shock or
electrocution.
• Do not expose charger to rain or
snow.
• Pull by plug rather than cord when
disconnecting charger. This will
reduce risk of damage to electric
plug and cord.
• Make sure that cord is located so that
it will not be stepped on, tripped over,
or otherwise subjected to damage or
stress.
• Do not use an extension cord unless
it is absolutely necessary. Use of
improper extension cord could
result in risk of fire, electric shock, or
electrocution.
WARNING
An extension cord must have adequate wire size (AWG or American Wire Gauge) for
safety. The smaller the gauge number of the wire, the greater the capacity of the cable,
that is 16 gauge has more capacity than 18 gauge When using more than one extension
to make up the total length, be sure each individual extension contains at least the
minimum wire size.
Recommended Minimum Wire Size for Extension Cords
Total Length of Cord
25 ft. 50 ft. 75 ft. 100 ft. 125 ft. 150 ft. 175 ft.
7.6 m 15.2 m 22.9 m 30.5 m 38.1 m 45.7 m 53.3 m
Wire Size AWG
18 18 16 16 14 14 12
CAUTION
Burn hazard. To reduce the risk of injury,
charge only designated Coleman®
batteries. Other types of batteries
may burst causing personal injury and
damage.
IMPORTANT SAFETY INSTRUCTIONS FOR CHARGER
• Do not place any object on top of charger
or place the charger on a soft surface
that might block the ventilation slots and
result in excessive internal heat. Place the
charger in a position away from any heat
source. The charger is ventilated through
slots in the top and the bottom of the
housing.
• Do not mount charger on wall or
permanently ax charger to any surface.
The charger is intended to use on a flat,
stable surface (i.e., table top, bench top).
• Do not operate charger with damaged
cord or plug — have them replaced
immediately.
• Do not operate charger if it has received
a sharp blow, been dropped, or otherwise
damaged in any way. Take it to an
authorized service center.
• Do not disassemble charger; take it to an
authorized service center when service or
repair is required. Incorrect reassembly
may result in a risk of electric shock,
electrocution or fire.
• Disconnect the charger from the outlet
before attempting any cleaning. This will
reduce the risk of electric shock. Removing
the battery pack will not reduce this risk.
• NEVER attempt to connect 2 chargers
together.
• The charger is designed to operate on
standard household electrical power
(120 Volts). Do not attempt to use it on
any other voltage.
IMPORTANT SAFETY INSTRUCTION FOR BATTERY PACKS
• Do not incinerate the battery pack even
if it is severely damaged or is completely
worn out. The battery pack can explode
in a fire. Toxic fumes and materials are
created when battery packs are burned.
• Do not charge or use battery in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Inserting
or removing the battery from the charger
may ignite the dust or fumes.
• If battery contents come into contact
with the skin, immediately wash area with
mild soap and water. If battery liquid gets
into the eye, rinse water over the open eye
for 15 minutes or until irritation ceases. If
medical attention is needed, the battery
electrolyte for Lithium-Ion batteries is
composed of a mixture of liquid organic
carbonates and lithium salts.
• Contents of opened battery cells may
cause respiratory irritation. Provide fresh
air. If symptoms persist, seek medical
attention.
WARNING
For safe operation, read this manual and
manuals originally supplied with tool
before using the charger.
The battery pack is not fully charged out
of the carton. Before using the battery
pack and charger, read the safety
instructions below. Then follow charging
procedures outlined.
WARNING
Burn hazard. Battery liquid may be
flammable if exposed to spark or flame.
• Charge the battery packs only in
Coleman® chargers.
• DO NOT splash or immerse in water
or other liquids. This may cause
premature cell failure.
• Do not store or use the tool and
battery pack in locations where the
temperature may reach or exceed
105°F (40˚C) (such as outside sheds
or metal buildings in summer).
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS

7 8
IMPORTANT SAFETY INSTRUCTION FOR BATTERY PACKS
WARNING
Fire hazard. Do not store or carry
battery so that metal objects can
contact exposed battery terminals. For
example, do not place battery in aprons,
pockets, toolboxes, product kit boxes,
drawers, etc., with loose nails, screws,
keys, etc.
CHARGING PROCEDURE
Coleman®chargers are designed to charge Coleman®battery packs in 1 - 2 hours depending
on the pack being charged.
1. Plug the charger into an appropriate outlet before inserting
the battery pack.
2.Insert the battery pack into the charger as shown in figure A.
3.The green LED will flash indicating that the battery is being
charged.
4.The completion of charge is indicated by the green LED
remaining on continuously. The pack is fully charged and may
be used at this time or left on the charger.
Recharge discharged batteries as soon as possible after use
or battery life may be greatly diminished. For longest battery
life, do not discharge batteries fully. It is recommended that the
batteries be recharged after each use.
WARNING
Never attempt to open the battery pack
for any reason. If battery pack case is
cracked or damaged, do not insert into
charger. Do not crush, drop or damage
battery pack. Do not use a battery
pack or charger that has received a
sharp blow, been dropped, run over or
damaged in any way (i.e., pierced with
a nail, hit with a hammer, stepped on).
Damaged battery packs should be
returned to service center for recycling.
Transporting batteries can possibly cause
fires if the battery terminals inadvertently
come in contact with conductive materials
such as keys, coins, hand tools and the
like. The US Department of Transportation
Hazardous Material Regulations (HMR)
actually prohibits transporting batteries in
commerce or on airplanes (i.e., packed in
suitcases and carry-on luggage) UNLESS
they are properly protected from short
circuits.
So when transporting individual batteries,
make sure that the battery terminals are
protected and well insulated from materials
that could contact them and cause a short
circuit.
NOTE: Lithium-Ion batteries should not be
put in checked baggage.
STORAGE RECOMMENDATIONS
1. The best storage place is one that is cool
and dry away from direct sunlight and
excess heat or cold.
2.Long storage will not harm the battery
pack or charger.
Figure A
CHARGER DIAGNOSTICS
This charger is designed to detect certain
problems that can arise with the battery
packs or the power source. Problems are
indicated by two LED flashing in dierent
patterns.
CHARGING PROCEDURE
1. The battery pack should be recharged
when it fails to produce sucient power
on jobs, which were easily done previously.
DO NOT CONTINUE to use under these
conditions. Follow the charging procedure.
You may also charge a partially used pack
whenever you desire with no adverse
aect on the battery pack.
2.Foreign materials of a conductive nature
such as, but not limited to, steel wool,
aluminum foil, or any buildup of metallic
particles should be kept away from charger
cavities. Always unplug the charger from
the power supply when there is no battery
pack in the cavity. Unplug charger before
attempting to clean.
3.Do not freeze or immerse charger in water
or any other liquid.
LEAVING THE BATTERY IN THE
CHARGER
The charger and battery pack can be left
connected with the green LED glowing
indefinitely. The charger will keep the
battery pack fresh and fully charged.
IMPORTANT CHARGING NOTES
1. Longest life and best performance can be
obtained if the battery pack is charged
when the air temperature is between 65°F
and 75°F (18°- 24°C). DO NOT charge
the battery pack in an air temperature
below +40°F (+4.5°C), or above +105°F
(+40.5°C). This is important and will
prevent serious damage to the battery
pack.
2.The charger and battery pack may become
warm to touch while charging. This is a
normal condition, and does not indicate
a problem. To facilitate the cooling of
the battery pack after use, avoid placing
the charger or battery pack in a warm
environment such as in a metal shed, or an
uninsulated trailer.
3.If the battery pack does not charge
properly:
a. Check current at receptacle by plugging
in a lamp or other appliance.
b. Check to see if receptacle is connected
to a light switch which turns power o
when you turn out the lights.
c. Move charger and battery pack to a
location where the surrounding air
temperature is approximately 65°F -
75°F (18°- 24°C).
d. If charging problems persist, take the
tool, battery pack and charger to your
local service center.
WARNING
Shock hazard. Do not allow any liquid to
get inside charger. Never attempt to open
the battery pack for any reason. If the
plastic housing of the battery pack breaks
or cracks, return to a service center for
recycling.
BAD BATTERY
The charger can detect a weak or damaged
battery. The red LED flashes in the pattern
indicated on the label. If you see this bad
battery blink pattern, do not continue to
charge the battery. Return it to a service
center or a collection site for recycling.
CHARGER
This Class B digital apparatus complies with
Canadian ICE5-003.
This device complies with Part 15 of the FCC
Rules.
This ISM device complies with Canadian
ICES-001.
Operation is subject to the following two
conditions:
1. This device may not cause interference,
and
2.This device must accept any interference,
including interference that may cause
undesired operation of the device.

9 10
FUNCTIONAL DESCRIPTION
9
2
8
10
4
3
5
6
1
7
1. Variable Speed Switch
2. Forward/Reverse Button
3. Torque Adjustment Collar
4. Keyless Chuck
5. Dual Range Gearing
6. LED Work Light
7. Battery Pack
8. Battery Pack Release Button
9. Screwdriver Bit Holder
10. Bubble Level
Model No. 500101
INSTALLING & REMOVING THE BATTERY FROM THE TOOL
SAFETY WARNINGS & INSTRUCTIONS
Figure B Figure C
OPERATING INSTRUCTIONS
TRIGGER SWITCH & REVERSING BUTTON (FIGURE D)
• The drill is turned ON and OFF by pulling and releasing
the trigger switch (1). The farther the trigger is depressed,
the higher the speed of the drill.
• A forward/reverse control button (2) determines the direction
of the tool and also serves as a lock o button.
• To select forward rotation, release the trigger switch and
depress the forward/reverse control button to the left.
• To select reverse, depress the forward/reverse control button
the opposite direction.
NOTE: The center position of the control button locks the tool in the o position.
When changing the position of the control button, be sure the trigger is released.
Figure D
1. Hold drill firmly with one hand on the grip
and the other hand on the bottom of the
battery pack.
2.When attaching accessories in the drill
chuck, hand tightens the keyless chuck
firmly.
WARNING
Make certain the lock-o button is engaged to prevent switch actuation before removing
or installing battery.
WARNING
Drill may stall (if overloaded or improperly
used) causing a twist. Always expect
the stall. Grip the drill firmly with both
hands to control the twisting action
and prevent loss of control, which could
cause personal injury. If a stall does occur,
release the trigger immediately and
determine the reason for the stall before
re-starting.
TO INSTALL BATTERY PACK:
Insert battery pack into tool until an audible
click is heard (figure B). Make sure battery
pack is fully seated and fully latched into
position.
TO REMOVE BATTERY PACK:
Depress the battery release button and pull
battery pack out of tool (figure C).
DRILL SPECIFICATIONS
No Load Speed ................................ 0~400 RPM (low)
..............................0~1400 RPM (high)
Motor .......................................................... 20V DC Motor
Chuck ............................................................... 1/2” Keyless
Gear Train .............................................................. 2 Speed
Clutch ............................................................. 20 Positions
Switch ....................................................... Variable Speed
Charging Voltage .............................. 120V / 60 Hz AC
Charge Rate ................................. 1 hour Fast Charging

11 12
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
DUAL RANGE GEARING (FIGURE G)
The dual range feature of your drill allows you to shift gears
for greater versatility. To select low speed, high torque setting
(position 1), turn tool o and permit to stop. Slide gear shifter
button (5) away from the chuck. To select the high speed, low
torque setting (position 2), turn tool o and permit to stop.
Slide gear shifter button towards the chuck.
NOTE: Do not change gears when tool is running. If you are having
trouble changing gears, make sure that the dual range gear button
is either completely pushed forward or completely pushed back.
SCREW DRIVING
For driving fasteners, the reversing button should be pushed to the left. Use reverse
(button pushed to the right) for removing fasteners. When moving from forward to
reverse, or vice versa, always release the trigger switch first.
DRILLING
• Use sharp drill bits only.
• Support and secure work properly, as
instructed in the Safety Instructions.
• Use appropriate and required safety
equipment, as instructed in the Safety
Instructions.
• Secure and maintain work area, as
instructed in the Safety Instructions.
• Run the drill very slowly, using light
pressure, until the hole is started enough
to keep the drill bit from slipping out of it.
• Apply pressure in a straight line with the
bit. Use enough pressure to keep the bit
biting but not so much as to stall the
motor or deflect the bit.
• Hold the drill firmly with two hands to
control its twisting action.
• DO NOT CLICK THE TRIGGER OF A
STALLED DRILL OFF AND ON IN AN
ATTEMPT TO START IT. DAMAGE TO THE
DRILL CAN RESULT.
• Minimize stalling on breakthrough by
reducing pressure and slowly drilling
through the last part of the hole.
• Keep the motor running while pulling
the bit out of a drilled hole. This will help
reduce jamming.
• Make sure switch turns drill on and o.
Figure G
Figure H
Figure I
DRILLING IN WOOD
Holes in wood can be made with the same
twist drill bits used for metal or with spade
bits. These bits should be sharp and should
be pulled out frequently when drilling to
clear chips from the flutes.
DRILLING IN METAL
Use a cutting lubricant when drilling metals.
The exceptions are cast iron and brass, which
should be drilled dry. The cutting lubricants
that work best are sulfurized cutting oil or
lard oil.
DRILLING IN MASONRY
Use carbide tipped masonry bits. Refer to
Drilling section. Keep even force on the
drill but not so much that you crack the
brittle material. A smooth, even flow of dust
indicates the proper drilling rate.
MAINTENANCE
Use only mild soap and damp cloth to clean
the tool. Never let any liquid get inside the
tool; never immerse any part of the tool into
a liquid.
IMPORTANT: To assure product SAFETY
and RELIABILITY, repairs, maintenance
and adjustment (other than those listed
in this manual) should be performed by
authorized service centers or other qualified
service personnel, always using identical
replacement parts.
KEYLESS CHUCK (FIGURE F)
To insert a drill bit or other accessory:
1. Grasp the chuck (4) with one hand rotates the chuck in the
counterclockwise direction, as viewed from the chuck end.
2.Insert the bit or other accessory fully into the chuck, and
tighten securely by holding the chuck and rotate it in the
clockwise direction as viewed from the chuck end.
Figure F
WARNING
Make certain the lock-off button is
engaged to prevent switch actuation
before installing or removing accessories.
WARNING
Do not attempt to tighten drill bits (or
any other accessory) by gripping the
chuck and turning the tool on.
Damage to the chuck and personal injury
may occur when changing accessories.
ON BOARD BIT STORAGE (FIGURE H)
Two bit storage slots (9) is built-in to the area just above the
battery pack.
LED WORK LIGHT (FIGURE I)
When drill is activated by pulling the trigger switch (1), the
integrated LED work light (6) will automatically illuminate the
work area. Do not use LED work light as flashlight.
TORQUE CONTROL (FIGURE E)
This tool is fitted with a torque adjustment collar (3) to select
the operating mode and to set the torque for tightening screws.
Large screws and hard workpiece materials require a higher
torque setting than small screws and soft workpiece materials.
• For drilling in wood, metal and plastics, set the collar to the
drilling position symbol.
• For screwdriving, set the collar to the desired setting. If you do
not yet know the appropriate setting, proceed as follows:
• Set the collar to the lowest torque setting.
• Tighten the first screw.
• If the clutch ratchets before the desired result is achieved,
increase the collar setting and continue tightening the screw.
Repeat until you reach the correct setting. Use this setting for
the remaining screws.
Figure E

13 14
FUNCTIONAL DESCRIPTION
INSTALLING & REMOVING THE BATTERY FROM THE TOOL
OPERATING INSTRUCTIONS
VARIABLE SPEED TRIGGER SWITCH (FIGURE D)
To turn the tool on, squeeze the trigger switch (1).
To turn the tool o, release the trigger switch. Your tool is equipped
with a brake. The chuck will stop as soon as the trigger switch is
fully released. The variable speed switch enables you to select
the best speed for a particular application. The more you squeeze
the trigger, the faster the tool will operate. Use lower speeds for
starting holes without a center punch, drilling in metals or plastics,
or driving screws. For maximum tool life, use variable speed only
for starting holes or fasteners.
NOTE: Continuous use in variable speed range is not recommended. It may damage the
switch and should be avoided.
Figure D
WARNING
Make certain the lock-o button is engaged to prevent switch actuation before removing
or installing battery.
TO INSTALL BATTERY PACK:
Insert battery pack into tool until an audible
click is heard (figure B). Make sure battery
pack is fully seated and fully latched into
position.
TO REMOVE BATTERY PACK:
Depress the battery release button and pull
battery pack out of tool (figure C).
SAFETY WARNINGS & INSTRUCTIONS
1. Hold driver firmly with one hand on the
grip and the other hand on the bottom of
the battery pack.
2.When attaching accessories in the driver
chuck, insert the bit into the chuck in place
while pulling the chuck sleeve forwards.
WARNING
Driver may stall (if overloaded or
improperly used) causing a twist. Always
expect the stall. Grip the drill firmly with
both hands to control the twisting action
and prevent loss of control, which could
cause personal injury. If a stall does occur,
release the trigger immediately and
determine the reason for the stall before
re-starting.
6
2
8
4
3
5
1
7
1. Trigger Switch
2. Forward/Reverse Button
3. Chuck Collar
4. 1/4 Inch Hex Quick-Release Chuck
5. LED Work Light
6. Screwdriver Bit Holder
7. Battery Pack
8. Battery Pack Release Button
Model No. 500106
IMPACT DRIVER SPECIFICATIONS
No Load Speed .......................................... 0~2800 RPM
Torque ............................................. 1,148 in. lbs(130Nm)
Blow Per Minute ............................................ 3200 BPM
Motor .......................................................... 20V DC Motor
Coupler .................................................................. 1/4” Hex
Gear Train ............................................................... 1 Speed
Switch ....................................................... Variable Speed
Charging Voltage .............................. 120V / 60 Hz AC
Charge Rate ................................. 1 hour Fast Charging
WARNING
Wear ear protectors when using impact
driver. Exposure to noise can cause
hearing loss.
Figure B Figure C

15 16
OPERATING INSTRUCTIONS
QUICK RELEASE CHUCK (FIGURE G)
NOTE: The chuck accepts 1/4 inch (6.35 mm) hex accessories only.
Place the switch in the locked o (center) position or remove
battery pack before changing accessories.
To install an accessory, pull the chuck collar (3) away from the
front of the tool, insert the accessory, and release the collar. The
accessory is locked in place.
To remove an accessory, pull the chuck collar (3) away from the
front of the tool, remove the accessory and release the collar. Figure F
Figure H
Figure I
ON BOARD BIT STORAGE (FIGURE H)
Two bit storage slots (6) is built-in to the area just above
the battery.
LED WORK LIGHT (FIGURE I)
There is a worklight (5) located just above the trigger switch (1).
The worklight will be activated when the trigger switch is squeezed.
NOTE: The worklight is for lighting the immediate work surface
and is not intended to be used as a flashlight.
FORWARD/REVERSE CONTROL BUTTON (FIGURE E)
A forward/reverse control button (2) determines the direction of
the tool and also serves as a lock o button. To select forward
rotation, release the trigger switch and depress the forward/
reverse control button on the right side of the tool. To select
reverse, depress the forward/reverse control button on the left
side of the tool. The center position of the control button locks
the tool in the OFF position.
When changing the position of the control button, be sure the
trigger is released.
NOTE: The first time the tool is run after changing the direction of rotation, you may hear a
click on start up. This and the impacting noise that the tool makes is normal and does not
indicate a problem.
This page is intentionally left blank
Figure E

17 18
FUNCTIONAL DESCRIPTION INSTALLING & REMOVING THE BATTERY FROM THE TOOL
Figure B Figure C
OPERATING INSTRUCTIONS
HOLDING THE RECIPROCATING SAW
• Place blade and shoe lightly against work
to be cut.
• Switch on saw motor and allow it to
obtain maximum speed before applying
pressure.
• Always hold saw firmly with both hands
while cutting as shown in figure D.
Whenever possible, the saw shoe must be
held firmly against the material being cut.
This will prevent the saw from jumping
or vibrating and will minimize blade
breakage.
Figure D
Handle Grip
Handle
Grip
WARNING
Make certain the lock-o button is engaged to prevent switch actuation before removing
or installing battery.
WARNING
Always use proper eye protection that
conforms to ANSI Z87.1 (CAN/CSA
Z94.3) while operating this power tool.
TO INSTALL BATTERY PACK:
Insert battery pack into tool until an audible
click is heard (figure B). Make sure battery
pack is fully seated and fully latched into
position.
TO REMOVE BATTERY PACK:
Depress the battery release button and pull
battery pack out of tool (figure C).
8
9
1
6
3
4
5
2
7
1. Trigger Switch
2. Safety Button
3. Shoe
4. Blade Clamp Release Lever
5. Blade
6. Main Handle
7. Secondary Gripping Handle
8. Battery Pack
9. Battery Pack Release Button
NOTE: Before cutting any type of material,
be sure it is firmly anchored or clamped to
prevent slipping.
Model No. 500118
RECIPROCATING SAW SPECIFICATIONS
Stroke Per Minute .................................... 0~3000 SPM
Length of Stroke .................................................... 6/7 in.
Blade Length ....................................................... 5-7/8 in.
Motor .......................................................... 20V DC Motor
Switch ....................................................... Variable Speed
Charging Voltage .............................. 120V / 60 Hz AC
Charge Rate ................................. 1 hour Fast Charging

19 20
SAFETY SWITCH (FIGURE E)
Release lock-o by switching to the unlocked position shown in
figure E. Push the safety switch to turn the motor ON. Releasing
the trigger turns the motor OFF.
NOTE: This tool has no provision to lock the switch in the ON
position, and should never be locked in the ON position by any
other means.
OPERATING INSTRUCTIONS MAINTENANCE
BLADE CLAMP RELEASE LEVER
NOTE: Turn o and remove battery from tool before making any
adjustments or removing or installing attachments or accessories.
TO INSTALL BLADE INTO SAW:
1. Open blade clamp release lever to its full open position as
shown in figure F.
2. Insert blade shank from the front.
3. Close blade clamp release lever. Check to make sure blade is
clamped securely.
TO REMOVE BLADE FROM SAW:
1. Open blade clamp release lever to its full open position.
2. Remove blade.
Figure F
REMOVE BATTERY FROM SAW WHEN PERFORMING ANY CLEANING OR OTHER
MAINTENANCE. WHEN SERVICING USE ONLY IDENTICAL REPLACEMENT PARTS.
• Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to various
types of commercial solvents and may be damaged by their use. Use only mild soap and
damp cloth to clean the tool. Never let any liquid get inside the tool; never immerse any
part of the tool into a liquid.
• When electric tools are used on fiberglass boats, sports cars, drywall etc., they are subject
to accelerated wear and possible premature failure, as the fiberglass chips and grindings
and drywall dust are highly abrasive to bearings, brushes, commutator, etc. During any
use on fiberglass or drywall it is extremely important that the tool be cleaned frequently
by blowing with an air jet.
Figure E
WARNING
Cut hazard. Turn off and remove battery
from tool before making any adjustments
or removing or installing attachments or
accessories.
WARNING
Burn hazard. Do not touch the blade
immediately after use. Contact with the
blade may result in personal injury.
WARNING
Cut hazard. Blade breakage may occur
if the blade does not extend past the
shoe and the work piece during the cut.
Increased risk of personal injury, as well as
damage to the shoe and work piece may
result.

21 22
FUNCTIONAL DESCRIPTION
1. Trigger Switch
2. Lock-O Button
3. Laser
4. Laser On/O Switch
5. Main Handle
6. Secondary Handle
7. Laser Battery Door
8. 2X AAA Batteries (Included)
9. Spindle Lock
10. Depth Adjustment Knob
11. Blade Wrench
12. Bevel Adjustment Knob
13. Guide Lock Knob
14. Battery Pack
15. Battery Pack Release Button
16. Upper Guard
17. Saw Blade Guard
18. Saw Blade
19. Screw
20.Clamp Washer
21. Cutting Guide
22. Shoe
23. Depth Scale
24.Bevel Scale
INSTALLING & REMOVING THE BATTERY FROM THE TOOL
Figure B Figure C
ASSEMBLY / ADJUSTMENT SET-UP
CUTTING DEPTH ADJUSTMENT (FIGURES D)
• The depth of cut should be set according
to the thickness of the work piece.
• Loosen the depth adjustment knob (10)
to unlock the saw shoe (22) as shown in
figure D.
• Move the saw shoe into the desired
position. The corresponding depth of cut
can be read from the scale (23).
• Tighten the knob or lever to lock the saw
shoe in place.
• Set depth adjustment of saw such that
one tooth of the blade projects below the
workpiece.
WARNING
Make certain the lock-o button is engaged to prevent switch actuation before removing
or installing battery.
WARNING
TO REDUCE THE RISK OF INJURY, ALWAYS REMOVE BATTERY FROM SAW BEFORE
ANY OF THE FOLLOWING ADJUSTMENT OPERATIONS.
TO INSTALL BATTERY PACK:
Insert battery pack into tool until an audible
click is heard (figure B). Make sure battery
pack is fully seated and fully latched into
position.
TO REMOVE BATTERY PACK:
Depress the battery release button and pull
battery pack out of tool (figure C).
Model No. 500114
Front View
Top View
13
12
3
24
21
1
16
17
18
22
23
6 2
1920
5 14
151011
7 8 9 4
Figure D
CIRCULAR SAW SPECIFICATIONS
No Load Speed .............................................. 3600 RPM
Blade Diameter ................................................... 5-3/8 in.
Blade Arbor .............................................................. 3/8 in.
Cutting Depth .............................................. 0o— 1-9/16”
............................................. 45o— 1-1/16”
Motor .......................................................... 20V DC Motor
Charging Voltage .............................. 120V / 60 Hz AC
Charge Rate ................................. 1 hour Fast Charging
Laser Guide ..................... 1mW max, 600 nm Class II
Laser Battery .................................. 2 pcs. AAA Battery

23 24
BEVEL ANGLE ADJUSTMENT (FIGURE E)
This tool can be set to bevel angles between 0° and 45°.
ATTACHING AND REMOVING THE BLADE (FIGURE L)
• Retract lower guard and assemble blade (18) and clamp washer (20) as shown in figure L.
• Depress the spindle lock (9) while turning the saw spindle with the blade wrench (11) until
the blade lock engages and the blade stops rotating.
ASSEMBLY / ADJUSTMENT SET-UP
OPERATING INSTRUCTIONS
OPERATING INSTRUCTIONS
BLADE SELECTION
Your circular saw is designed for use with 5-/inch (137 mm) diameter blades that have
a 3/8-inch (9.5 mm) diameter bore. Blades must be rated for 7000-RPM operation (or
higher). DO NOT use any abrasive wheels.
GENERAL CUTS
To reduce the risk of injury, remove the battery, and follow all assembly, adjustment and
set up instructions.
Make sure lower guard operates. Select the proper blade for the material to be cut.
Figure E
Figure H
Figure L
CAUTION
To reduce the risk of serious personal injury, read, understand and follow all important
safety warnings and instructions prior to using tool.
To reduce the risk of injury, It is important to support the work properly and to hold
the saw firmly to prevent loss of control, which could cause personal injury. Figure H
illustrates typical hand support.
• Measure and mark work for cutting.
• Support and secure work properly
(See Safety Rules and Instructions).
• Use appropriate and required safety
equipment (See Safety Rules).
• Secure and maintain work area
(See Safety Rules).
• With battery inserted, make sure switch
turns saw on and o.
Handle Grip Handle Grip
To Loosen
To Tighten
• Loosen the bevel adjustment knob (12) to
unlock the saw shoe.
• Move the saw shoe (22) into the desired
position. The corresponding bevel angle
can be read from the scale (24).
• Tighten the bevel adjustment knob (12) to
lock the saw shoe in place.

25 26
OPERATING INSTRUCTIONS OPERATING THE LASER
LOWER BLADE GUARD
Laceration Hazard. The lower blade guard is
a safety feature, which reduces the risk of
serious personal injury. Never use the saw if
the lower guard is missing, damaged, mis-
assembled or not working properly. Do not
rely on the lower blade guard to protect
you under all circumstances. Your safety
depends on following all warnings and
precautions as well as proper operation of
the saw.
Check lower guard for proper closing before
each use as outlined in Additional Safety
Rules for Circular Saws. If the lower blade
guard is missing or not working properly,
have the saw serviced before using. To
assure product safety and reliability, repair,
maintenance and adjustment should be
performed by an authorized service center
or other qualified service organization,
always using identical replacement parts.
To minimize the risk of eye injury, always use
eye protection. Carbide is a hard but brittle
material. Foreign objects in the work piece
such as wire or nails can cause tips to crack
or break. Only operate saw when proper
saw blade guard is in place. Mount blade
securely in proper rotation before using, and
always use a clean, sharp blade.
Do not cut ferrous metals (steel), masonry,
glass or tile with this saw.
A dull blade will cause slow, inecient
cutting overload on the saw motor,
excessive splintering, and could increase the
possibility of kickback.
ON BOARD LASER
Some saw models are equipped with an on board laser which is turned on and o separately
from the saw.
LASER RADIATION. Never aim the beam at a work piece with a reflective surface. Bright
shiny reflective sheet steel or similar reflective surfaces are not recommended for laser use.
Reflective surfaces could direct the beam back toward the operator.
LASER RADIATION. AVOID DIRECT EYE EXPOSURE. Do not stare into the laser light
source. Never aim light at another person or object other than the work piece. Laser light
can damage your eyes.
DO NOT use tinted glasses to enhance the laser light. Tinted glasses will reduce overall
vision for the application and interfere with the normal operation of the tool.
SWITCHING THE LASER ON AND OFF
• To turn the laser on, press the laser on/o button (4). To turn the
laser o, press the button a second time.
NOTE: The laser on/o button occupies two dierent positions,
the lower position is “on” (slightly depressed below flush) and
the upper position is “o” (button is flush with the surface).
TO USE THE LASER LINE
• Mark the line that you intend to cut on the work piece.
• Adjust the depth and angle of cut as required.
• Push the laser on/o switch (3) to the “ON” position and project the laser beam.
• Push in on the lock-o button (2) and depress the saw on/o switch (1) and allow the
blade to reach maximum speed.
• Place the saw shoe on the work piece. Align the laser line with the mark on the work piece
and slowly push the saw forward keeping the laser line on the mark.
• Upon completion of the cut, release the trigger and allow the saw blade to come to a
complete stop before switching o the laser.
OPERATING THE LASER
INSTALLING THE BATTERIES - FIGURE N
LASER RADIATION. BE CERTAIN THE LASER ON/OFF BUTTON IS
IN THE OFF POSITION (SEE SECTION “SWITCHING THE LASER
ON AND OFF) BEFORE INSTALLING BATTERIES.
Lift the battery door (7) o the laser module (3) by gently
squeezing the front of the door as shown in figure N. Insert 2 AAA
batteries making sure to match (+) and (-) terminals correctly.
Reattach the battery door.
Figure N
Figure M
SWITCH
Saw is equipped with a switch lock-o
feature to prevent unintentional running.
• To operate the tool, press in on the lock-
o button (2) from either side of the saw
and hold it in as you depress the trigger
switch (1).
• After you have depressed the trigger and
the tool is running, release the lock-o
button. The tool will continue to run as
long as the trigger is depressed.
• To turn the tool o, release the trigger
switch.
NOTE: This tool has no provision for locking
the tool on, and the switch should never be
locked on by any other means.
AUTOMATIC ELECTRIC BRAKE
Your saw is equipped with an electric blade
brake, which stops the saw blade within
1-1/2 seconds of trigger release. This is
automatic and requires no adjustment.

27 28
TROUBLESHOOTING
Problem Possible Cause Possible Solution
Unit will not start. Battery pack not installed
properly
Check battery pack installation
Battery pack not charged Check battery pack charging
requirements
Battery pack will not charge. Battery pack not inserted
into charger.
Insert battery pack into charger
until green LED appears.
Charger not plugged in. Plug charger into a working
outlet. Refer to “Important
Charging Notes” for more
details.
Surrounding air temperature
too hot or too cold .
Move charger and battery pack
to a surrounding air temperature
of above 4.5°C (40°F) or below
40.5°C (105°F).
Unit shuts o abruptly. Battery pack has reached its
maximum thermal limit.
Allow battery pack to cool
down.
Out of charge (To maximize
the life of the battery pack
it is designed to shuto
abruptly when the charge is
depleted).
Place on charger and allow to
charge
For assistance with your product, visit our website WWW.COLEMAN-TOOLS.COM
or call the Coleman® help line at 1-888-253-4620.
The RBRC™ (Rechargeable Battery Recycling Corporation) Seal on
the lithium-ion battery (or battery pack) indicates that the costs to
recycle the battery (or battery pack) at the end of its useful life have
already been paid by Coleman. In some areas, it is illegal to place spent
lithium-ion batteries in the trash or municipal solid waste stream and
the RBRC program provides an environmentally conscious alternative.
RBRC in cooperation with Coleman and other battery users has established programs in
the United States and Canada to facilitate the collection of spent lithium-ion batteries. You
may also contact your local recycling center for information on where to drop o the spent
battery, or call 1-800-8-BATTERY.
WARRANTY
LIMITED 1 YEAR WARRANTY
This product is warranted to be free of defects in materials and workmanship under normal
residential use for one (1) year.
The warranty period is calculated from the date of purchase by the end user and covers
the cost for replacement parts/equipment. In order to verify a warranty situation a copy
of the original receipt or gift receipt must accompany the warranty claim, along with the
manufacturer’s serial number from the product. Any warranty claim, work, or replacements
given are to fulfill the terms of the original warranty period only.
The manufacturer’s obligation under this warranty shall strictly be limited, at manufacturer’s
option, to replace any product or parts thereof, which in the opinion of the manufacturer
shows defect in workmanship or material. All decisions of Coleman with regard to this limited
warranty shall be final. The retailer or manufacturer will allow NO RETURNS or REFUNDS. To
make a warranty claim or inquiry, you must call 1-888-253-4620. You must have the product
serial number and receipt information ready.
If defects should appear within one year of purchase, you may return the unit with your
receipt as proof of purchase to the place of purchase for an exchange of either a new or
refurbished unit, at manufacturer’s discretion. There will be no REFUNDS provided.
The warranty does NOT cover:
• Merchandise sold as reconditioned, used, demonstration or floor models.
• Any commercial, industrial or rental usage of this product. Any such usage will void the
implied warranty.
• Any product that has been damaged by freezing, dropping, misuse, neglect, accident,
abuse, improper handling, normal wear and tear, or non-compliance with the owner’s
manual.
• Any product that has been damaged by a contaminated water supply, water sediment or
chemicals/detergents that are not approved by or recommended by Coleman.
• Any product that has been damaged by acts of nature such as fires, floods, earthquakes,
lightening strikes, etc.
• Damage caused by repairs made by the end user or any service center not authorized by
Coleman. Any such tampering will void the implied warranty.
• Any cost for shipping by the customer or authorized service center of the allegedly
defective product.
• Any cost for shipping of replacement parts or accessories. Such shipping costs will be
borne in full by the end user.
• Any non-standard or bonus accessory/attachment included with the original product.
The manufacturer shall in no event be liable for injuries to persons or property, or for
incidental, contingent, special or consequential damages arising from the use of this
product. This warranty does not apply to damage due directly or indirectly to misuse, abuse,
negligence or accidents; repairs or alterations; or lack of maintenance. The manufacturer
shall not be liable for any misrepresentations by stores, store employees, or any parties, that
make claims on this product.
This warranty is non-transferable and only applies to products that were sold in and
reside in USA and Canada. If you have any questions or comments, visit our web site at
www.coleman-tools.com or call our toll free customer service line at 1-888-253-4620.
