Coline CW1542 User manual

CW1542
PREMIUM KITCHENWARE
LONGER
FRESHNESS
MORE
JUICE
EASY TO
CLEAN

ENGLISH
4
Slow Juicer
Art.no 18-4655 Model JE5621G-GS
44-1542 JE5621G-GS
Please read theentire instruction manual before using theproduct and then save
it for future reference. We reserve theright for any errors in text or images and any
necessary changes made to technical data. In theevent of technical problems or other
queries, please contact our Customer Services (see address details on theback).
Safety
• Never use theproduct for longer than 15 minutes at atime.
Switch theproduct off and let themotor cool down for at least
30 minutes before using it again.
• Incorrect handling of this product could result in personal injury.
• Theproduct should always be disconnected from
themains when it is not in use, when it is to be assembled/
disassembled and when it is to be cleaned.
• Switch theproduct off and disconnect it from themains before
changing any accessories or handling any of themoving parts.
• This appliance may not be used by children.
• Keep the appliance and its mains lead out of children’s reach.
• Theproduct may be used by persons with reduced physical,
sensory or mental capability, lack of experience or knowledge
which could jeopardise their safety, provided they have been
given supervision or instruction concerning thesafe use of
theproduct and understand thehazards involved.
• Never let children play with theproduct.
• Ensure that theproduct is used with thecorrect voltage.
Refer to therating plate on theproduct.
• To prevent electric shocks, theproduct and its mains lead
should be kept dry.
• Never lay themains lead over hot surfaces, sharp edges or corners.
• Always disconnect theproduct from thepower supply by
holding and pulling theplug. Do not pull themains lead.
• Make sure that all parts are correctly assembled and that theproduct
is switched off before it is connected to thepower supply.

ENGLISH
5
1
2
3
5
6
7
8
15
9
10
4
11
12
13
14
• Never operate theproduct without food in thecontainer.
• Never use theproduct close to heat sources.
• Only use theincluded accessories.
• Never use theproduct for anything other than its intended use.
• Do not use theproduct if thefilter is damaged.
• Do not use theappliance without thepulp bin attached.
• Avoid contact with moving parts.
• Ensure that theappliance is placed on aneven and steady surface.
• Themains lead should be checked regularly. Never use
appliances with faulty or damaged power leads. Thepower
lead should only be replaced by aqualified tradesman.
• Make sure that all parts are correctly attached and that
theappliance is switched off when it is connected to
thepower supply.
Parts
1. Food pusher
2. Hopper
3. Squeezing screw
4. Small cleaning brush
5. Strainer
6. Spinning brush
7. Juice bowl
8. Pulp spout
9. Juice spout
10. Lid
11. Motor unit
12. Power switch
13. Reset switch
14. Juice container
15. Pulp container

ENGLISH
6
Before initial use
1. Carefully unpack theparts and place them on aflat surface.
2. Wash all thedetachable parts in warm soapy water. Never immerse themotor unit
into any type of liquid.
3. Allow all theparts to air-dry before reassembling them. Make sure that themains
lead is not plugged into alive electrical socket.
Note: Thestrainer can be cleaned using theincluded small brush.
Preparing the fruit and vegetables
1. Hard, fibrous foods should be cut into small pieces, 3–5cm in length and
1.5–2cm in width.
2. Tough skin, peel, stalks and seeds, pips should be removed before juicing.
3. Never juice frozen foods or ice.
4. Never juice sugar cane, coconut or cereals without first soaking them in water to
soften them.
5. Do not try to juice too much food at atime.
Assembly
1. Place thejuice bowl (7)
onto themotor unit
(11) so that the ▼ and
▲symbols line up
with each other. Push
thebowl down and twist
it clockwise until it locks
and the lines up with
thebottom arrowhead.
2. Make sure that it is tight.
Thejuicer will not start if
thebowl is not locked in
position.
3. Make sure that thesluice
flap is fitted correctly in
thepulp spout (8).

ENGLISH
7
4. Place thestrainer (5) into thespinning brush (6),
line up the ▼on thestrainer with the ▲
on themotor unit (11) and then push
thestrainer downwards. Make sure that
thestrainer (5) is securely attached to
thejuice bowl (7).
5. Fit thesqueezing screw (3) into thejuice
bowl (7). Thesqueezing screw might need to
be turned alittle until it fits properly.
6. Attach thehopper (2) to thejuice bowl by first
lining the ▲symbol up with the symbol
and then twisting thehopper clockwise until
thetab locks into theslot .
7. Place thejuice container (14) under thejuice
spout (9) and thepulp container (15) under
thepulp spout (8).
Note: Pull back thesluice flap to facilitate thecleaning of thepulp spout (8).
Refit thesluice flap before using thejuicer again.
Operating instructions
1. Before plugging themains lead into awall socket, make sure that thepower
switch (12) is set to the0position (OFF). Thepower switch has 3 positions: “1”
symbolises ON, “0” symbolises OFF and “R” symbolises REVERSE (can be used
for freeing clogged food).
2. Make sure that thejuice container (14) and pulp container (15) are placed under thespouts.
3. Cut fruits and vegetables into small pieces. For example, carrots can be in pieces
sized 1.5×1.5cm before they are fed into thejuicer.
4. Place thefood into thehopper (2) and if necessary push it down carefully using
thefood pusher (1).
5. Set thepower switch to position 1 (ON). After afew seconds juice will begin to
flow out of thespout.
6. If any food becomes stuck during operation, first set the power switch to 0
and then press the reset button (13). Set the power switch (12) to Rfor a few
seconds and then try again. If that does not free the clogged food, you will need to
dismantle the juicer to remove the blockage.
7. When thejuice container (14) is full (approx 600ml) or there is no more food to be
juiced, thejuicer should be switched off.
Note:
• Remove any seeds, pits, pips or stones before processing.
• Never process hard foods.
• Remove thepeel of oranges, lemons, grapefruits and melons before juicing.
• Never operate thejuicer without any food in it.
• Never push food into thehopper using your fingers when thejuicer is switched on.

ENGLISH
8
• Never use thejuicer for longer than 15 minutes at atime. Thejuicer must rest for at
least 30 minutes between operating cycles.
• Themotor will stop if theinterlock switch between thehopper and themotor unit is
disconnected during operation.
Care and maintenance
1. Unplug themains lead and let thejuicer cool before cleaning it.
2. Unlock thehopper (2) by twisting it anticlockwise and then remove it.
3. Detach thesqueezing screw (3), strainer (5) and thespinning brush (6).
4. Rotate thejuice bowl (7) to and then remove it.
5. Empty the pulp container (15) and wash all the parts except the motor unit (11) in
running water. The detachable parts (except the motor unit) are also dishwasher safe.
6. Themotor unit can be cleaned using asoft, damp cloth. Never immerse themotor
unit in water.
7. Make sure that all theparts are dry before reassembling thejuicer.
Note: Pull back thesluice flap to facilitate thecleaning of thepulp spout (8).
Refit thesluice flap before using thejuicer again.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.
Specifications
Voltage 220–240 V, 50/60 Hz
Power 150W

SVENSKA
9
Slow juicer
Art.nr 18-4655 Modell JE5621G-GS
44-1542 JE5621G-GS
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid tekniska
problem eller andra frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
• Använd aldrig produkten längre än 15 minuter åt gången.
Stäng av motorn och låt den kylas ner minst 30 minuter innan
du använder den igen.
• Felaktig användning av produkten kan medföra personskada.
• Koppla alltid bort produkten från elnätet när den inte används,
när du monterar ihop/isär delarna och när den ska rengöras.
• Slå av produkten och koppla bort den från elnätet innan du
byter tillbehör eller handskas med de rörliga delarna.
• Apparaten får inte användas av barn.
• Håll apparaten och dess sladd utom räckhåll för barn.
• Produkten får användas av personer med någon form av
funktionsnedsättning, brist på erfarenhet eller kunskap som
skulle kunna äventyra säkerheten, om de har fått instruktioner
om hur den på ett säkert sätt ska användas och förstår faror
och risker som kan uppkomma.
• Låt aldrig barn leka med produkten.
• Kontrollera att rätt nätspänning används. Se produktens märkskylt.
• För att undvika elektrisk stöt, skydda produkten och dess
nätsladd från fukt och väta.
• Placera aldrig nätsladden över heta ytor, skarpa kanter eller hörn.
• Koppla aldrig bort produkten från elnätet genom att dra
i nätsladden, dra alltid i stickproppen.
• Se till att produktens delar är korrekt monterade och att
produkten är avstängd före anslutning till elnätet.
• Använd aldrig produkten utan innehåll i behållaren.
• Använd aldrig produkten i närheten av värmekällor.

SVENSKA
10
1
2
3
5
6
7
8
15
9
10
4
11
12
13
14
• Använd endast medföljande tillbehör.
• Använd endast produkten till det den är avsedd för.
• Produkten får inte användas om silen är skadad.
• Använd inte produkten utan fruktköttsbehållaren inkopplad.
• Undvik kontakt med delar som rör sig.
• Se till att produkten står på ett plant och stabilt underlag.
• Nätsladden bör regelbundet kontrolleras. Använd aldrig
apparaten om dess nätsladd eller stickpropp är skadad.
Nätsladden får endast bytas ut av försäljningsstället eller
kvalificerad yrkesman.
• Se till att produktens delar är korrekt monterade och att den
är avstängd före anslutning till elnätet.
Delar
1. Påmatare
2. Påfyllningsrör
3. Skärhuvud
4. Liten borste
5. Sil
6. Roterande rengöringsborste
7. Juicetratt
8. Fruktköttspip
9. Juicepip
10. Lock
11. Motordel
12. Strömbrytare
13. Återställning
14. Juicebehållare
15. Fruktköttsbehållare
