People
PL8461M
FULL TECHNICAL MANUAL

Quadra and People Handset Kit
art.PL8461M for Simplebus 2 system
Single-family kit consisting of Quadra series entrance panel art. 4893M
and 4.3” People series door entry monitor with handset art. PL6701 for
Simplebus 2 system.
The entrance panel is supplied with call buttons to expand the kit for up
to 4 residences.
The system can also be expanded with additional door entry monitors
and entrance panels (available to purchase separately); for further
information please refer to the technical documentation.
The kit is supplied pre-programmed, ready to use and with all the
accessories required to create the system.
Suitable for installation in homes, commercial premises or offices.
Think before you
print
and use the
interactive links
Help us to save the planet.
Think of the planet before printing this document.
You are reading an interactive document: quickly access the
content you are interested in via links.
| Table of contents |

3
Table of contents
Kit art. PL8461M 4
Notes for the installer 5
Art. 4893M 6
Description 6
Technical specifications 8
Installation 9
Programming 12
Art. 1209 19
Description 19
Technical specifications 20
Art. PL6701 21
Description 21
Technical specifications 25
Programming the user code 27
Installation 31
Programming 34
Operating distances 40
Wiring diagrams 41
System expansion diagrams 43
Using the entrance panel relay on generic actuator control 46
Table of user codes 47
| Table of contents |

4
Kit art. PL8461M
The kit components are supplied pre-programmed to work as a single-family setup.
1216
1214/2C
PL8461M
1209
4893M
PL6701
The door entry monitor has an NFC connection which means it can be programmed
quickly and easily via the MyComelit app, available to download free of charge.
Programming can even take place while the door entry monitor is off!
The door entry monitor can nevertheless be used to program the user code via dip-switch
and change the functions associated with the buttons using the menu.
| Table of contents |

5
Notes for the installer
165 cm
72 cm
201 cm
72°
72°
72°
50 cm
166 cm
130 cm
50 cm
150 cm
186 cm
50 cm
50 cm
92 cm
85°
72 cm
72 cm
The camera must not be installed in front of light sources, or in places where the filmed subject is against the
light. In dim environments, we recommend additional lighting is provided.
95 mm
195 mm
28 mm
106 mm
89 mm
62 mm
186 mm
180 mm
35 mm
| Table of contents |

6
Art. 4893M
Description
Wall-mounted external unit for Quadra series door entry monitor. Die-cast aluminium front panel, wide-angle
colour video camera and single LED for lighting at night. Mechanical buttons with the option of setting 1 to 4
call buttons via DIP-switch. Indicator LED for call sent, lock-release activated, audio activated and system busy.
Loudspeaker volume adjustment and audio balancing. Bus line power supply. Dimensions: 95x195x28 mm.
2
1
3
4
5
6
1
1
2
1
2
3
4
7
1. Die-cast aluminium cover.
2. Default camera lighting LED, call activated (see Entrance panel settings on page 12).
3. Wide-angle colour video camera.
4. Speaker.
5. Indicator LED:
call sent / lock-release activated
audio activated / system busy.
6. Call button 1 / 2 / 4 users.
7. Microphone.
| Table of contents |

7
8
9
10
12
11
B
A
PR
B
A
CNF
C NC
NO
JP1
NC
NO
JP1
NC
C NC
NO
NO
13
14
8. DIP-SWITCH for function programming.
9. PR programming input/output switch.
CNF programming confirmation switch.
10. Terminal block M1:
LL bus line connection.
RTE request to exit button input.
COM common input for RTE and DO contacts.
DO door open indication input.
11. Audio balancing and loudspeaker volume adjustment.
12. Terminal block M2:
SE- SE+ connection for electric door lock.
NC NO C relay contacts.
13. JP1 enabling the RC network for door lock filter on relay contacts.
14. Microphone volume control.
| Table of contents |

8
Technical specifications
GENERAL DATA
Type Complete unit
Height (mm) 195
Width (mm) 95
Depth (mm) 28
Product weight (g) 300
Product colour Grey RAL 9006, Black RAL9005
Surface mounting Ye s
COMPATIBLE SYSTEMS
Simplebus 2 audio/video kit with power
supply unit art. 1209 Ye s
AUDIO SPECIFICATIONS
Microphone 6 mm (ø), Omnidirectional
Loudspeaker 36 mm (ø), 8 Ohm, 1W
CAMERA FEATURES
Camera Colour
Sensor type 1/4" CMOS
Fixed lens dimensions (mm) 2.1
Viewing angle (H x V - °) 85 x 72
Sensitivity (lux) 0.1 (colours)
ELECTRICAL SPECIFICATIONS
Type of power supply Power supply via video entry bus
Power supply voltage 33 VDC
Maximum absorption (W) 8.25
HARDWARE SPECIFICATIONS
Call type Buttons
Type of buttons Mechanical
Number of buttons 4
Backlighting colour White
Terminals LL RTE COM DO SE- SE+C NC NO
Number of inputs 2
Number of outputs 2
Output type Relay (C-NO-NC, 10A@12-24 VAC/VDC), SE: 4A unlock pulse, maintenance
current 200 mA for 12 VAC/DC door locks (maximum impedance 18 Ohm)
SETTINGS
Loudspeaker volume Yes
Mic volume Ye s
ENVIRONMENTAL AND CONFORMITY SPECIFICATIONS
IP protection rating IP54
IK anti-vandal protection rating IK08
Operating temperature -25 to 55
Operating humidity (max. RH) 25 to 95
Environmental class IV
CE certification RoHS II - 2011/65/EU (EN IEC 63000:2018), EMC 2014/30/EU (EN 61000-6-
1:2007, EN 61000-6-3:2007+A1:2011)
MAIN FUNCTIONS
Lock-release Yes
Number of auxiliary relays 1
Input for local lock-release button Yes
Input for door open indication Ye s
| Table of contents |

9
1
2
1
2
1
2
3
COM
L L RTE
5
13
JOHN DOE
2
6
2
1
4
Installation
You can download the free software (art. 1235A) to print the entrance panel name cards,
using the adhesive pre-cut sheets available in our catalogue (art. 1217A).
OPEN
| Table of contents |

10
1
2
JOHN DOE
9
2
3
JOHN DOE
JOHN DOE
1
CLACK!
7
1
1
1
2
8
Before securing the screw, make sure that you do not need to program the external
unit and make sure that the metal front panel does not rub against other metal parts,
with consequent risk of damage to its insulating coating.
While the system is running, take care not to accidentally call users when replacing
the nameplate labels.
To guarantee the product is
water-tight: fit it properly.
CLOSE
| Table of contents |

11
PRESS
1
2
3
JOHN DOE
MR. SMITH
A
JOHN DOE
MR. SMITH
1
2
3
4
B
CHANGING NAMEPLATES
| Table of contents |

12
Programming
ENTRANCE PANEL SETTINGS
fPermanently set the S1 DIP-switches corresponding to the function you want to program in accordance
with the table below (you do not need to enter programming mode)
FUNCTION
DIP 1
ON
1 2 3 4 6 75 8
The SE output and the C-NO relay are controlled by 2 separate
buttons on the door entry monitor: the key button (SE) and the generic
actuator button (C-NO)
ON
1 2 3 4 6 75 8
default The SE output and the C-NO relay are controlled by a single button
on the door entry monitor: the key button
DIP 2
ON
1 2 3 4 6 75 8
Lock-release activation time: 8 seconds
ON
1 2 3 4 6 75 8
default Lock-release activation time: 2 seconds
DIP 3
ON
1 2 3 4 6 75 8
Relay activation time: 8 seconds
ON
1 2 3 4 6 75 8
default Relay activation time: 2 seconds
DIP 4
ON
1 2 3 4 6 75 8
Awaiting reset time: 1 second
ON
1 2 3 4 6 75 8
default Awaiting reset time: 10 seconds
DIP 5
ON
1 2 3 4 6 75 8
Call transmission: TRIPLE
ON
1 2 3 4 6 75 8
default Call transmission: SINGLE
DIP 6
ON
1 2 3 4 6 75 8
Confirmation tones (call, lock-release, relay, audio enabled):
DISABLED
ON
1 2 3 4 6 75 8
default Confirmation tones (call, lock-release, relay, audio enabled):
ENABLED
DIP 7
ON
1 2 3 4 6 75 8
Camera lighting LED: DISABLED
ON
1 2 3 4 6 75 8
default Camera lighting LED: ENABLED
DIP 8
ON
1 2 3 4 6 75 8
LED lighting of name-holder front panels: OFF
ON
1 2 3 4 6 75 8
default LED lighting of name-holder front panels: ON
| Table of contents |

13
3
5
1
ON
1 2 3 4 6 75 8
1
ON 1
2
1 2 3 4 6 75 8
ON 1
2
3
4
1 2 3 4 6 75 8
default
4
6
2
fSet the code corresponding to the desired
programming.
fMake a note of the DIP-switch
settings
PROGRAMMING CALL CODES FOR TWO-FAMILY AND FOUR-FAMILY VERSION
| Table of contents |

14
7 8
fReset the DIP-switch settings.
| Table of contents |

15
ON
1 2 3 4 6 75 8
1
3
2
4
PROGRAMMING AN ADDITIONAL ENTRANCE PANEL
With switching device art. 1405, only one additional entrance panel may be installed.
The two entrance panels must be programmed as main and secondary ; see table below.
• The “Main entrance panel” carries out lock-release (or actuator) commands only when it is in call or
self activation status.
• The “Secondary entrance panel” carries out lock-release (or actuator) commands whether it is in
standby or in call or self activation status.
• If the system is in standby mode the first self-activation command will activate the camera of the secondary
entrance panel. Further commands switch between the two entrance panels, activating the main entrance
panel and the secondary entrance panel alternately.
With switching device art. 1404, more than one additional entrance panel may be installed.
All the entrance panels must be programmed as shown in the table below.
Please refer to the full manual for product 1404, which is available to download from the website pro.
comelitgroup.com
fMake a note of the DIP-switch
settings
fSet the code corresponding to the desired
programming (example=32)
PROGRAMMING DIP-SWITCH CODE
Programming an entrance panel with switching device 1404
ON
1 2 3 4 6 75 8
cod. 8
8
Programming a secondary entrance panel with switching device
1405
ON
1 2 3 4 6 75 8
cod. 16
16
Programming a main entrance panel with switching device 1405
ON
1 2 3 4 6 75 8
cod. 32
32
| Table of contents |

16
5
7
6
8
fReset the DIP-switch settings.
| Table of contents |

17
ON
1 2 3 4 6 75 8
3
5
1
4
6
2
example code 2
PROGRAMMING A GENERIC CALL ADDRESS
fSet the call code of the apartment you wish
to call (see Table of user codes)
fMake a note of the DIP-switch
settings
| Table of contents |

18
ON
1 2 3 4 6 75 8
1
5
3
7
2
6
4
8
RESTORE DEFAULT
fMake a note of the DIP-switch
settings
fSet the DIP-switches to position 254
(ON 2, 3, 4, 5, 6, 7, 8)
fReset the DIP-switch settings.
| Table of contents |

19
Art. 1209
Description
33 VDC power supply unit for Simplebus 2 KIT, for direct connection to the external unit and internal unit.
Equipped with overload and short circuit protection. Input voltage 110-240 VAC. Dimensions: 106 x 62 x 89 mm
(6 DIN modules).
LNL2
L2
L1
L1
1 2 3 4
1. L N mains power input 110-240 V~.
2. Terminal protection.
3. L1 L1 main bus line output (31 V ).
4. L2 L2 riser bus line input (31 V ).
Appliance exclusively for indoor use. Risk of electric shock; proceed with caution.
Install inside a closed electrical panel so that it may only be accessed by authorised
personnel.
A suitable omnipolar switch with a contact opening of at least 3 mm must be installed
upstream of the video entry phone system.
• Disconnect the power supply before carrying out any operations on the wiring.
• Replace the protections on the terminals.
• Do not obstruct the ventilation and cooling slots or apertures.
| Table of contents |

20
Technical specifications
MAIN FEATURES
Power supply voltage 110-240 VAC
Max. current delivered (A) 1.2
Applicable to DIN rail Yes
Number of DIN modules 6
GENERAL DATA
Height (mm) 62
Width (mm) 106
Depth (mm) 89
Coating material type Plastic
Product colour White
Operating temperature (°C) -5 to 40
Operating humidity (max. RH) (%) 25 to 95
COMPATIBILITY
Audio/Video Kit system Ye s
ELECTRICAL SPECIFICATIONS
Maximum power delivered (W) 37
| Table of contents |
