COMFILE CUWIN V2 Series User manual

CUWIN V2 Series
Hardware Manual
CWV2-070BR/CWV2-070WR/CWV2-102BR
[Version 1.1]
COMFILE Technology, Inc.

CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
COMFILETechnology,Inc. www.comfiletech.com • page 2
1.HardwareSpecification
ITEM
MODEL
CWV2-070BR CWV2-070WRCWV2-102BR
MCU
32Bit RISC CPU, ARM Cortex-A8,1GHz
Memory
SDRAM : 512MB
eMMC: 4GB
LCD TFT LCD(260,000 Color)
7 Inch (800 x 480)
400cd/m2
TFT LCD(260,000 Color)
10.2 Inch (800 x 480)
350cd/m2
Backlight
LED Backlight (ON/OFF switchable)
Ethernet 100Base-T (1Port)
Touch 4 wire resistive panel
RTC Highly Accurate RTC(DS3231)(1) (Battery replaceable)
Audio <0.8W Micro speaker embedded
Stereo audio output (ø3.5 Audio Jack)
USB OTG 1Port
Device 1Port (Support USB Storage/ WiFi)
Serial COM1 (RS232C / RS485 switchable)
COM2 (RS232C)
COM3 (RS232C)
SDCARD Support external SD CARD (SD/SDHC)
Input Power DC12V~DC24V
Power
Consumption
<6W (0.5A@12V) <10W (0.8A@12V)
MAX. Current
500mA 800mA
Dimension (mm) 216(H)x120(V)x41(D) 222(H)x152(V)x56(D) 284(H)x163(V)x56(D)
Weight 450g 650g 1040g
Operating
Temperature
0℃~70℃
Storage
Temperature
-30℃~80℃
(1) The accuracy of the RTC depends on circumstances.

CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Manual
CO M FILE
COMFILETechnology,Inc. www.comfiletech.com •
page 3
TECHNOLOGY CUWIN V2
Series
2. External
Parts
fl o 1 mmmmmmm mmr Til
C Cj [ J J
0
0
G--.
J
K
A----
'---- c

CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
COMFILETechnology,Inc. www.comfiletech.com • page 4
Name Description
A Power input DC-Jack φ2.5 DC Power Input Jack for adaptor
B Power terminal Power terminal for cables
C Power S/W Power input ON/OFF
D COM3 COM3 (RS232C / Female Type D-SUB 9PIN)
E COM2 COM2 (RS232C / Female Type D-SUB 9PIN)
F COM1_RS232C COM1_RS232C (RS232C / Female Type D-SUB 9PIN)
G COM1 Mode Switch DIP Switch for selecting COM1 mode
H COM1_RS485 COM1_RS485 Port (RS485)
I Ethernet 10Base-T Ethernet Port (RJ-45)
J USB_HOST USB Host Port (USB A Type Connector)
K USB_DEVICE USB OTG Port (USB mini AB Type Connector)
L SD Card Connector SD Card slot
M Audio Out Stereo Audio Output Port (φ3.5)
N Boot Mode S/W DIP Switch for selecting Boot mode

CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Manual
CO M FILE
COMFILETechnology,Inc. www.comfiletech.com •
page 5
0
r- -- -
13 . 5
M
.... >
0">
d
0
J
TECHNOLOGY CUWIN V2
Series
3.
Dimensions
[CWV2-070BR]
M -------------------------
318
....
,.;
1 12 . 4 . 5
I I
- ,
I I
"
,..
'
_
;
I
-
o=t Ll}
0
C
..
\
.
J
-
ro
154.08(Active Area ) <(
(!)
c
..
o
.:
u
-f
_ ._
M
r-
"
,..:
'
M
N
c
..
o
n
r-
r-
lr-' <D
II
I
3 1 . 2 155.4 3 1 . 2
216
1 81
4 . 3
D
28.9
I
40.4
Un i t : mm
d
....
oo
"'<D
-'--++Htt-HJ-ffi
,.;
N <»
1 00
1 99
7
Back cover
of
product
Avoid using long bolts when assembling VESA mounts or add-
on board.
The inner maximum length is about
7mm.

CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
COMFILETechnology,Inc. www.comfiletech.com • page 6
[CWV2-070WR]
Back cover
of product
Avoid using long bolts
when assembling
VESA mounts or add-
on board.
The inner ma x imum
length is about 9mm.

COMFILETechnology,Inc. www.comfiletech.com •
page 7
CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
[CWV2-102BR]
Back cover
of product
Avoid using long bolts
when assembling
VESA mounts or add-
on board.
The inner ma x imum
length is about 9mm.

COMFILETechnology,Inc. www.comfiletech.com • page 8
CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
4.
PANEL CUTOUT
▌ Installation Requirements
▌Installation
X: Panel Cutout Width, Y: Panel Cutout Height, T: Panel Thickness
Unit: mm[in.]
CUWIN XYT
CWV2-070BR 200
[7.88] 110 [4.34] 1.6 to 6.0 [0.06 to 0.24]
CWV2-070WR208
[8.19] 139 [5.48] 1.6 to 4.5 [0.06 to 0.18]
CWV2-102BR 265
[10.44] 151 [5.95] 1.6 to 5.0 [0.06 to 0.20]

COMFILETechnology,Inc. www.comfiletech.com •
page 9
CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
5. BracketInstallation
▌CWV2-070BR/CWV2-070WR/CWV2-102BR
1. Insert a bolt into each mounting bracket as shown in the diagram below.
[CWV2-070BR]
[CWV2-070WR, CWV2-102BR]
2. Make a hole in the panel according to the CWV2-070BR/CWV2-070WR/CWV2-
102BR's cutout diagram, and insert the CWV2-070BR/CWV2-070WR/CWV2-102BR
into place.
3. Press the bracket as the following directions in two steps.
4. Tighten the bolt against the panel to secure the CWV2-070BR/CWV2-070WR/CWV2-
102BR to the panel.(Be careful not to tighten the bolts too tightly, or the CWV2-
070BR/CWV2-070WR/CWV2-102BR could be damaged.)
[CW V2-070BR]
[CWV2-070WR, CW V2-102BR]
5. Repeat steps 3 and 4 for each mounting bracket.

COMFILETechnology,Inc. www.comfiletech.com • page 10
CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
6.
Input/Output Connectors
▌ RS232C Input/Output Connector (COM1_RS232C, COM2, COM3)
Connector Type
Order
Name
Order
Name
*D-SUB 9Pin Female
1 - 6 -
2 TXD 7 -
3 RXD 8 -
4 - 9 -
5 GND - -
▌RS485 Input/Output Connector (COM1_RS485)
Connector Type
Order
Name
1 D+
2 GND
3 GND
4 D-
▌ COM1 ModeS/W
RS485 Mode Sel.
Order
ON
OFF
4 Term Res. N.C.
3 -Bias N.C.
2 +Bias N.C.
COM1 Mode Sel.
Order
ON
OFF
1 RS232C RS485

COMFILETechnology,Inc. www.comfiletech.com •
page 11
CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
▌BootModeS/W
ConnectorType
Order
Setting
1
BootDevice
Selection
- ON
eMMCBoot OFF
2
BootMode
Reserved 2 ON
3
ON
AutoRunMode
2
ON
3
OFF
3
BootLoaderMode 2 OFF
3
ON
DevelopmentMode
2
OFF
3
OFF
4 Reserved
5 Reserved
6 Reserved
* Boot Device Selection S/W must be turned OFF for normal b ooti ng.
▌ Power InputConnector
Power
DC_IN(+)

COMFILETechnology,Inc. www.comfiletech.com • page 12
CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
7. EMI/EMCCertifications
►CWV2-070BR:
KCC Registration No. : MSIP-REM-CUL-CWV2-070BR
►CWV2-070WR:
KCC Registration No. : MSIP-REM-CUL-CWV2-070WR
►CWV2-102BR:
TDB

COMFILETechnology,Inc. www.comfiletech.com •
page 13
CVW2-070BR/CWV2-070WR/CWV2-102BR Hardware Ma n ua l
CUWIN V2 Series
8.WarrantyPolicy
▌ Warranty Period
The products are warranted to be free of defects in materials and workmanship for
1 year from the date of purchase.
▌ Warranty Exclusions
The warranty does not cover abrasion and is considered void if the product is
opened by unauthorized person, damaged by abnormal use, heat or humidity, or used
against user manual.
▌ Request of Warranty Repair
If the products have defect(s) during the warranty period, the customer should
inquire at the manufacturer or dispatch the products with the description to the
address the manufacturer provides. If the request is appropriate, the manufacturers
repairs and dispatch it to the customer.
▌ Limitation of Liability
The manufacturer and distributor are not responsible for damages or breakdowns
caused by direct or indirect reasons, and the maximum duty of manufacturer and
distributor are limited to the total amount paid by the customer. The limitations or
exclusions of warranty have priority over any other warranty expressed explicitly,
implicatively, in writing, or orally.
Contact Information
Should you need any additional information or assistance about CWV2 Series, please
feel free to contact us.
Saelig Company, Inc.
71 Perinton Parkway, Fairport, NY, 14450, U.S.A
Telephone
Toll-Free : (888) 7SAELIG, [phone]
Office : [phone]
Fax : [phone]
Office Hours: Monday-Friday9am-5:30pm EST
E-mail
Sales: [email protected]
Technical Support: [email protected]
