COMFILE P200 User manual

CUPC
Hardware Manual
(P200, P220)
[Version 2.0]
COMFILE Technology, Inc.

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 2
1. Hardware Specification
Model name
Item CUPC-P200 CUPC-P220
CPU Intel ATOM N270 1.6GHz
Chipset Intel 945GSE + ICH7M
Memory 2GB SODIMM DDR2 SDRAM
Graphic & Display Intel 945GSE Embedded Graphics Support VGA CRT output
Support Pivot
LCD 15inch
16.7M Colors,
XGA(1024x768), 300cd/m2
10.4inch
262K Colors,
XGA(1024x768), 300cd/m2
Backlight 2Channel CCFL
LT : >50,000hr 1Channel CCFL LT : >30,000hr
Ethernet VIA VT6130 Gigabit Ethernet(2Port)
Audio VIA High Definition Audio Audio Out (1Port)
MIC In (1Port)
USB Universal Serial Bus Support (4Port)
Support USB2.0 Host Controller
HDD SATA HDD Interface
Serial RS232C Serial (2Port)
Input Power DC+12V
Power Consumption <32W (2.6A@12V) <28W (2.3A@12V)
Dimension(mm) 376(H) x 300(V) x 60(D) 280(H) x 300(V) x 60(D)
Weight 5.1Kg 2.5Kg
Operating Temperature 0℃~ 60℃

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 3
2. External Parts
Name Description
A Power/HDD LED
The green LED is turned on, when the power is supplied.
The red LED is turned on, when the hard disk is read or written.
B ATX Power S/W ATX mode power switch. Boot or exit the system.
C Ext. Power S/W The connector which can be linked to external switch. Same
function with ATX Power switch
D Power S/W Power input ON/OFF
E DC IN ø2.5 Adaptor Input Connector (DC +12V)
F USB Port USB1/USB2 (USB2.0)
G VGA Port VGA output for external monitor.
H Audio Out Sound output for external speaker
I MIC IN Microphone input
J LAN2 Port Support 100BaseT, with RJ-45 type connector
K LAN1 Port Support 100BaseT, with RJ-45 type connector
L USB Port USB3/USB4 (USB2.0)
M COM1 Port COM1 (RS232C, D-SUB 9Pin Male Type)
N COM2 Port COM2 (RS232C, D-SUB 9Pin Male Type)

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 4
3. Dimensions
[CUPC-P200]
Avoid using long bolts when
assembling VESA mounts or
add-on board.
The inner maximum length is
about 12mm.
Back cover of
product

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 5
[CUPC-P220]
Avoid using long bolts when
assembling VESA mounts or
add-on board.
The inner maximum length is
about 10mm.
Back cover of
product

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 6
4. PANEL CUTOUT
▌Installation Requirements
▌CUPC-P200/P220 Installation
X: Panel Cutout Width, Y: Panel Cutout Height, T: Panel Thickness
Unit: mm[in.]
CUPC X Y T
P200 355
[13.98] 279 [10.99] 1.6 to 12.0 [0.06 to 0.47]
P220 263
[10.36] 210 [8.27] 1.6 to 6.0 [0.06 to 0.24]

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 7
5. Bracket Installation
▌CUPC-P200
To fasten CUPC-P200 to an upright panel, the brackets (left, right) are supplied when you
purchase P200.
* Procedure *
1) Push and install the CUPC-P200 into your panel.
2) Press the bracket as the following directions in two steps.
3) To fix the CUPC-P200 to the panel, fasten the bolts.

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 8
▌CUPC-P220
To fasten CUPC-P220 to an upright panel, the brackets (left 2ea, right 2ea) are supplied
when you purchase P220.
* Procedure *
1) Push and install the CUPC-P220 into your panel.
2) Press the bracket as the following directions in two steps.
3) To fix the CUPC-P220 to the panel, fasten the bolts.

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 9
6. Input/Output Connectors
▌VGA Output Connector
Connector Type
* D-SUB 15Pin Female
Pin Assignment
Order Name Order Name
1 RED 2 GREEN
3 BLUE 4 -
5 GND 6 GND
7 GND 8 GND
9 DDC VCC (+5V) 10 GND
11 - 12 DDC DATA
13 HSYNC 14 VSYNC
15 DDC CLK - -
▌RS232C Input/Output Connector (COM1, COM2)
Connector Type
*D-SUB 9Pin Male
Pin Assignment
Order Name Order Name
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
7 RTS 8 CTS
9 RI - -

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 10
▌Power Input Connector
* ø 2.5 Adaptor Jack

CUPC manual
CUPC-P200/P220 Hardware Manual
COMFILE Technology, Inc. www.comfiletech.com •page 11
7. Warranty Policy
▌Warranty Period
The products are warranted to be free of defects in materials and workmanship
for 1 year from the date of purchase.
▌Warranty Exclusions
The warranty does not cover abrasion and is considered void if the product is
opened by unauthorized person, damaged by abnormal use, heat or humidity, or used
against user manual.
▌Request of Warranty Repair
If the products have defect(s) during the warranty period, the customer should
inquire at the manufacturer or dispatch the products with the description to the
address the manufacturer provides. If the request is appropriate, the manufacturers
repairs and dispatch it to the customer.
▌Limitation of Liability
The manufacturer and distributor are not responsible for damages or breakdowns
caused by direct or indirect reasons, and the maximum duty of manufacturer and
distributor are limited to the total amount paid by the customer. The limitations or
exclusions of warranty have priority over any other warranty expressed explicitly,
implicatively, in writing, or orally.

CUPC
Hardware Manual
(P200, P220)
Contact Information
Should you need any additional information or assistance about CUPC, please feel free
to contact us.
Comfile Technology Inc.
1175 Chess Dr., Suite F, FOSTER CITY, CA 94404, U.S.A
Telephone
Toll-Free : (888) 9CUBLOC, [phone]
Office : [phone]
Fax : [phone]
Office Hours: Monday-Friday 8am-5pm PST
E-mail
Sales: [email protected]
Technical Support: [email protected]
