Comfort Glow GCH480 and Manual
Wash hands after handling.
TABLE OF CONTENTS
WARNING!
WARNING
:
2
PROPANE CONSTRUCTION HEATER
World Marketing of America, Inc.
PO Box 192, 12256 William Penn Hwy., Mill Creek, PA 17060-0192
Tel (800) 776-9425 Web: www.worldmkting.com
CHECK WITH YOUR LOCAL
FIRE SAFETY AUTHORITY IF YOU HAVE QUESTIONS ABOUT APPLICATIONS.
IMPORTANT:
3
4
GENERAL SAFETY INFORMATION
Radiant Propane Construction Heaters
IMPORTANT INSTRUCTIONS - Safety Information
NEVER LEAVE HEATER UNATTENDED WHILE BURNING
OR WHILE CONNECTED TO A FUEL SOURCE.
WARNING
WARNING
a
a
CAUTION
WARNING
:
PROPANE CONSTRUCTION HEATER
3
4
GENERAL SAFETY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
PROPANE CONSTRUCTION HEATER
UNPACKING THE HEATER
CAUTION:
5
6
FIGURE 1
PROPANE CONSTRUCTION HEATER
PROPANE SUPPLY
78
PROPANE CONSTRUCTION HEATER
UNPACKING THE HEATER
7
8
PROPANE CONSTRUCTION HEATER
CONNECTING TO GAS SUPPLY
IMPORTANT!
THE PROPANE (LP) GAS PRESSURE REGULATOR AND HOSE
ASSEMBLY SUPPLIED WITH THE HEATER MUST BE USED
WITHOUT ALTERATION. BE SURE TO INSPECT THE REGULATOR
HOSE BEFORE EACH USE. IF THE HOSE IS CUT OR FRAYED, REPLACE IT WITH THE
MANUFACTURER SUGGESTED ASSEMBLY.
CAUTION
CAUTION
WARNING
FIGURE 2
910
WARNING
PROPANE SAFETY
THE DISCONNECTED TANK MUST NEVER BE STORED IN A BUILDING,
GARAGE OR ANY OTHER ENCLOSED AREA.
CHECKING FOR LEAKS
PROPANE CONSTRUCTION HEATER
9
10
LIGHTING INSTRUCTIONS
Note:
Note:
FIGURE 3 (A) (B)
(C)
PROPANE CONSTRUCTION HEATER
11 12
SHUTDOWN INSTRUCTIONS
Turning burner only OFF (pilot stays lit).
STORAGE
MOVING AND POSITIONING HEATER
PROPANE CONSTRUCTION HEATER
11
12
MAINTENANCE
Pilot and Burning Inspection
Burner and ODS Pilot Cleaning
Cleaning Air Passageways and Unit Casings
PROPANE CONSTRUCTION HEATER
13 14
TROUBLESHOOTING
Problem Possible Cause What To Do
When ignitor is depressed there is no spark
at ODS pilot.
1. Ignitor electrode positioned wrong.
2. Ignitor electrode broken.
3. Ignitor cable pinched or broken.
4. Ignitor cable not connected to ignitor
electrode.
5. Ignitor defective.
1. Reposition ignitor electrode.
2. Replace electrode.
3. Free ignitor cable, if damaged, replace.
4. Connect cable to electrode.
5. Replace ignitor.
When control knob is pressed in and turned
counterclockwise to pilot and piezo is
depressed, pilot does not light.
1. Gas supply turned off.
2. Control knob not in pilot position.
3. Control knob not pressed in while in pilot
position.
4. ODS pilot is clogged.
5. Air in gas lines.
1. Turn gas supply on.
2. Turn control knob to pilot position.
3. Press in control while in pilot position.
4. Call a qualified service technician.
5. Purge gas lines and repeat ignition
operation.
ODS pilot lights but flame goes out when
control knob is released.
1.Control knob not pressed long enough.
2. Safety interlock is triggered.
3. Pilot flame not touching the
thermocouple.
Problem could be result of one or both of
the following:
• Partially clogged ODS pilot orifice.
• Low gas pressure.
4. Thermocouple damaged.
5. Thermocouple connection loose at gas
control valve.
6. Gas control valve damaged.
1. After ODS pilot lights, keep control knob
pressed in approximately 30 seconds.
2. Wait one minute, repeat ignition
operation.
3. Contact your gas company, gas supplier
or qualified service technician.
4. Replace thermocouple.
5. Hand tight until snug then tighten
1/4 turn with a wrench.
6. Replace gas control.
Burner does not light after ODS pilot is lit. 1. Burner orifice clogged.
2. Gas supply pressure is very low.
1. Clean burner orifice.
2. Contact gas supplier.
Delayed ignition. 1. Main burner carry over ports clogged.
2. Gas supply pressure is very low.
1. Clean main burner ports.
2. Contact gas supplier.
Burner backfiring during operation. 1. Burner orifice is clogged.
2. Burner ports damaged.
1. Clean burner orifice.
2. Replace burner.
Yellow flames during burner operation. 1. Not enough air.
1. Check air passageways and burner for
dirt and debris.
(Refer to Maintenance section)
Burner plaque(s) does not glow.
1. Plaque(s) is damaged.
2. Inlet gas pressure too low.
3. Control knob set between locked
positions.
1. Replace burner.
2. Contact local gas supplier.
3. Turn control knob until it locks at
desired setting.
Slight smoke and odor during
Initial operation. 1. Residues from manufacturing processes. 1. Will stop after a few hours of operation.
Heater produces a whistling noise
when burner is lit.
1. Air passageways blocked.
2. Air in gas line.
1. Check minimum installation clearances
and air passageways for debris.
2. Operate burner until the air is completely
purged.
Heater produces a clicking noise just after
burner is lit or turned off. 1. Metal expanding and contracting.
1. This is common with heaters.
If noise is excessive, contact a
qualified, service technician.
PROPANE CONSTRUCTION HEATER
13
14
TROUBLESHOOTING (continued)
Problem Possible Cause What To Do
Gas odor even when control knob is
in OFF position.
1. Gas leaks. Refer to front of page
Warnings.
2. Gas control defective.
1. Locate and correct leaks immediately.
2. Replace gas control
Gas odor during combustion.
1. Foreign matter in gas or on burner ports.
2. Heater burning vapors form paint,
impurities in air.
3. Gas leaks, refer to front page Warnings
1. Check gas passage way and burner.
2. Ventilate room, stop storing and using
odor causing products near heater.
3. Locate and correct leaks immediately.
Heater shuts off on ODS.
1. Not enough fresh air is available.
2. Low gas pressure.
3. ODS pilot partially clogged.
1. Open window.
2. Contact gas supplier.
3. Clean the pilot.
PROPANE CONSTRUCTION HEATER
15 1615 16
LIMITED WARRANTY:
This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any
defect in materials and workmanship for a period of one (1) year from the date of retail sale. World Marketing of America, Inc., at it’s option, will
either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers
as directed by World Marketing, within one (1) year of retail purchase. (Shipping costs, labour costs, etc. are the responsibility of the purchaser.)
DUTIES OF THE OWNER:
This heating appliance must be operated in accordance with the written instructions furnished with this heater. This warranty shall not excuse
the owner from properly maintaining this heater in accordance with the written instructions furnished with this heater. A bill of sale, canceled
check or payment record must be kept to verify purchase date and establish warranty period. Original carton should be kept in case of warranty
return of unit.
WHAT IS NOT COVERED:
1. Damage resulting from use of improper fuel.
2. Damage caused by misuse or use contrary to the owners manual and safety guidelines.
3. Damage caused by a lack of normal maintenance.
4. Fuses
5. Use of non-standard parts or accessories.
6. Damage caused in transit. Freight charges on warranty parts or heaters to and from the factory shall be the responsibility of the owner.
This warranty does not imply or assume any responsibility for consequential damages that may result from the use, misuse, or the lack of
routine maintenance of this heating appliance. A cleaning fee and the cost of parts may be charged for appliance failures resulting from lack of
maintenance. This warranty does not cover claims which do not involve defective workmanship or materials. FAILURE TO PERFORM
GENERAL MAINTENANCE (INCLUDING CLEANING) WILL VOID THIS WARRANTY.
THIS LIMITED WARRANTY IS GIVEN TO THE PURCHASER IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE. THE
REMEDY PROVIDED IN THIS WARRANTY IS EXCLUSIVE AND IS GRANTED IN LIEU OF ALL OTHER REMEDIES. IN NO EVENT WILL
WORLD MARKETING OF AMERICA BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Some states do not
allow the exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you.
CLAIMS HANDLED AS FOLLOWS:
1. Contact your retailer and explain the problem.
2. If the retailer is unable to resolve the problem, contact our Consumer Warranty Dept. detailing the heater model, the problem, and proof
of date of purchase.
3. A representative will contact you. DO NOT RETURN THE HEATER TO WORLD MARKETING OF AMERICA, INC. unless instructed by
our Representative.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
TO REGISTER THE WARRANTY ON YOUR HEATER, PLEASE FILL OUT THIS CARD COMPLETELY
AND MAIL WITHIN 14 DAYS FROM DATE OF PURCHASE OR REGISTER ON-LINE AT www.worldmkting.com
NAME: ______________________________________ PHONE: ( ) __________________ EMAIL: ____________________________
ADDRESS: _________________________________ CITY: ______________________________ STATE: __________ ZIP: ____________
MODEL: ____________________ SERIAL #: _______________________________________ DATE PURCHASED: __________________
DEALER PURCHASED FROM: ____________________________________________ TYPE OF STORE: __________________________
CITY & STATE WHERE PURCHASED: ______________________________________________ PRICE PAID: _______________________
Please Take a Minute To Give Us Your Answers To The Following Questions.
All Responses Are Used Solely For Market Research And Are Held In Strict Confidence.
Who primarily decided this purchase? Male Female 18-24 25-39 40-59 60 and over
Purpose of Purchase? _______________________________________________________________________________________________
Do you own any other portable heaters? Yes No If yes, type____________________________brand_____________________
How do you intend to use your new heater? Construction Site Farm Warehouse/Commercial Garage/Outbuilding Other
How did you become aware of this heater? In-Store Display Newspaper Ad Magazine Ad Friend/Relative
£TV Commercial £Store Salesperson Other ___________________________
What made you select this heater? Style Size/Portability Price Package Brand Other ___________________
Do you: own rent Would you recommend this heater to a friend? Yes No
Please give us your comments:________________________________________________________________________________________
THANK YOU FOR COMPLETING THIS FORM!
Information will be held confidential.
Part No. 09LPWTY
WARRANTY
15
16
15
16
WARRANTY REGISTRATION
IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14)
days of date of purchase. You can also register your warranty on the internet at
www.worldmkting.com. Complete the entire serial number. Retain this portion of the card
for your records.
World Marketing of America, Inc.
PO Box 192, 12256 William Penn Hwy.
Mill Creek PA 17060-0192
Tel) 1-800-776-9425
www.worldmkting.com
SAVE THIS CARD!
World Marketing of America, Inc.
PO Box 192, 12256 William Penn Hwy.
Mill Creek PA 17060-0192
Place
Postage
Stamp
Here
17 18
REPLACEMENT PARTS LIST
1. Lower Shield PT-N11B-8 10. Tilt Switch FD4
2. Guard Assembly PT-N11B-3 11. Gas Pipe PT-N11B-7
3. Front Panel PT-N11B-1 12. Regulator & Hose Assembly KR-106A
4. Reflector PT-N11B-2 13. Rear Chassis PT-N11B-4
5. ODS Assembly PT-N11B.6 14. Castor With Lock PT-N06-33
6. Burner Assembly PT-N11B.4 15. Castor Without Lock PT-N06-32
7. Gas Valve PT-N11B-13 16. Heat Insulation Board PT-N11-6
8. Piezo Ignitor PT-N11B.5 17. Back Cover PT-N11B.2-1
9. Knob Base PT-N11B-10 18 Knob PT-N06-24
Item/Model Number Part No. Item/Model Number Part No.
RA18 SERIES
WARNING!
PROPANE CONSTRUCTION HEATER
17
18
17. Back Cover 13. Rear Chassis
12. Regulator and Hose Assembly
7.Gas Valve
6. Burner Assembly
2. Guard Assembly
11. Gas Pipe
14. Castor With Lock
10. Tilt Switch
15. Castor Without Lock
16. Heat Insulation Board
8. Piezo Ignitor
9. Knob Base
4. Reector
1. Lower Shield
3. Front Panel
EXPLODED PARTS DRAWING
5. ODS Assembly
18.Knob
PROPANE CONSTRUCTION HEATER
Se laver les mains après toute manipulation.
2
Table of contents
Languages:
Other Comfort Glow Gas Heater manuals
Comfort Glow
Comfort Glow CCL3924NRA User manual
Comfort Glow
Comfort Glow 000 to 30 Quick start guide
Comfort Glow
Comfort Glow Comfort Glow CGD3018N Quick start guide
Comfort Glow
Comfort Glow SBN20 Original instructions
Comfort Glow
Comfort Glow RADIANT FLAME RFP28TD Operation manual
Comfort Glow
Comfort Glow CGD3924PRA Quick start guide
Comfort Glow
Comfort Glow CGP20TB Quick start guide
Comfort Glow
Comfort Glow CRL2718PA Quick start guide
Comfort Glow
Comfort Glow Comfort Glow CGD3018N Quick start guide
Comfort Glow
Comfort Glow CGP28TB Quick start guide
Comfort Glow
Comfort Glow CGP10LA Quick start guide
Comfort Glow
Comfort Glow RADIANT FLAME RFN28TD Quick start guide
Comfort Glow
Comfort Glow CGD3924NT Quick start guide
Comfort Glow
Comfort Glow CGN10A Quick start guide
Comfort Glow
Comfort Glow CSM2618NR User manual
Comfort Glow
Comfort Glow CGD3018P Quick start guide
Comfort Glow
Comfort Glow KWD216 User manual
Comfort Glow
Comfort Glow and CVDR30 Quick start guide
Comfort Glow
Comfort Glow CG3324NTA Quick start guide
Comfort Glow
Comfort Glow CGN10LA Quick start guide
Popular Gas Heater manuals by other brands
Insnrg
Insnrg GI 160 Installation & operating manual
Vermont Castings
Vermont Castings Jefferson JUVSR3095 installation manual
Cedar Ridge
Cedar Ridge CRHED24RT OWNER'S OPERATION AND INSTALLATION MANUAL
ReddyHeater
ReddyHeater BLUE FLAME BWH10NLMC OWNER'S OPERATION AND INSTALLATION MANUAL
Empire
Empire VFDR18LBW10N-4 Installation instructions and owner's manual
Empire Comfort Systems
Empire Comfort Systems SR-18T-1 Installation instructions and owner's manual
Jøtul
Jøtul GF3 DVII Allagash Installation and operation instructions
USSC
USSC Ambiance B9945L Installation and operation instructions
Empire
Empire SR-18-3 Installation instructions and owner's manual
Empire Comfort Systems
Empire Comfort Systems KENSINGTON LKF-2 Installation instructions and owner's manual
White Mountain Hearth
White Mountain Hearth LS-18H-1 Installation instructions and owner's manual
Sealey
Sealey LP14 manual
Hastings
Hastings COUNTERFLO CF SERIES Installation and service manual
Desa
Desa CLD3018PT OWNER'S OPERATION AND INSTALLATION MANUAL
Rinnai
Rinnai REH-20DT Owner's operation and installation manua
HearthStone
HearthStone Hase-Modena 8140 owner's manual
Desa
Desa BLUE-FLAME A Operation and installation manual
Bromic Heating
Bromic Heating platinum Smart-heat Installation, instruction and service manual
