Comfort Glow GCH480 Manual
PROPANE
CONSTRUCTION
HEATER
USER'S
MANUAL
AND
OPERATING INSTRUCTIONS
MODEL#
GCH480
c us
CSA
2.14a-2007, ANSI Z83.7a-2007
IMPORTANT:
READ
AND
UNDERSTAND
THIS
MANUAL
BEFORE
ASSEMBLING,
STARTING
OR
SERVICING
HEATER.
IMPROPER
USE
OF
HEATER
CAN
CAUSE
SERIOUS
INJURY.
KEEP
THIS
MANUAL
FOR
FUTURE
REFERENCE.
CALIFORNIA PROPOSITION 65 WARNING:
Fuels
used
in
gas
or
oil
fired
appliances
and the
products
of
combustion
of
such
fuels, contain chemicals
known
to
the
State
of
California
to
cause cancer,
birth
defects
or
other
reproductive
harm.
This
product
contains
chemicals,
including
lead and lead
compounds,
known
to
the
state
of
California
to
cause cancer,
birth
defects
or
other
reproductive
harm.
Wash
hands
after
handling.
1\.
GENERAL
HAZARD WARNING:
ft
FAILURE TO COMPLY WITH
THE
PRECAUTIONS AND INSTRUCTIONS PROVIDED
WITH THIS HEATER, CAN RESULT IN DEATH,
SERIOUS BODILY INJURYAND PROPERTY
LOSS,
OR
DAMAGE FROM THE HAZARDS OF
FIRE, EXPLOSION, BURN. ASPHYXIATION,
CARBON MONOXIDE POISONING, AND/OR
ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND
FOLLOWTHE INSTRUCTIONS SHOULD
USE
OR
SERVICE THIS HEATER.
IF YOU NEEDASSISTANCE
OR
HEATER
INFORMATION SUCH AS AN INSTRUCTION
MANUAL, LABELS, ETCETERA, CONTACT
THE
MANUFACTURER.
CONSUMER: Retain this manual forfuture reference.
50-10-102
Questions, problems, missing parts? Before returning
to
your retailer,
call ourTechnical service department at 1-814-643-1775
Printed
in
China Rev.l/10
PROPANE
CONSTRUCTION
HEATER~
TABLE OF CONTENTS
General Safety Information .............................................................................. 3 - 4
Specifications .............................................................................................................. 5
Product Features ..................................................................................................... 5
Unpacking and Assembly ............................................................................................ 6
Propane Supply ........................................................................................................... 7
Connecting Heater to Gas Supply ............................................................................. 8
Propane Safety ........................................................................................................... 9
Checking For Leaks .................................................................................................... 9
Lighting & Shutdown Instructions ....................................................................... 10 -
11
Storage
of
Heater ......................................................................................................
11
Moving and Positioning ..............................................................................................
11
Maintenance ............................................................................................................... 12
Troubleshooting ....
..
...
..
....
..
...
..
....
..
...
..
....
..
...
..
...
..
....
..
...
..
....
..
...
..
....
..
...
..
....
..
...
..
...
..
.....
13-14
Warranty ................................................................................................................
15-16
Replacements Parts List ............................................................................................. 17
Exploded Parts Drawing ............................................................................................ 18
t...
WARNING:
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD,
~KEEP
SOLID COMBUSTIBLES, SUCH AS BUILDING MATERIALS,
PAPER OR CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER
AS RECOMMENDED BY THE INSTRUCTIONS.
NEVER USE THE HEATER
IN
SPACES WHICH DO OR MAY CONTAIN VOLATILE
ORAIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNERS, DUST PARTICLES OR UNKNOWN CHEMICALS.
~
WARNING!
ft.
NOT FOR HOME OR RECREATIONAL VEHICLE USE.
World Marketing
of
America, Inc.
PO
Box
192, 12256William Penn Hwy., Mill Creek, PA 17060-0192
Tel (800) 776-9425 Web: www.worldmkting.com 2
~~
PROPANE CONSTRUCTION HEATER
GENERAL SAFETYINFORMATION
Radiant
Propane
Construction
Heaters
The heater is designed and approved for use
as
a construction heaterunderANSI
Z83
.7a, CSA2.14a.
It is hard to anticipate every use which may be made
of
this heater. CHECK WITH YOUR
LOCAL
FIRE SAFETYAUTHORITY IF YOU HAVE QUESTIONS
ABOUT
APPLICATIONS.
Other standards govern the use
of
fuel gases and heat producing products in specific applications.
Your local authority can advise you about these.
IMPORTANT: READ THIS USER'S MANUAL CAREFULLY AND COMPLETELY BEFORE TRYING
TO OPERATE
OR
SERVICE THIS HEATER. IMPROPER USE OF THIS HEATER CAN CAUSE SE-
RIOUS INJURY
OR
DEATH FROM FIRE, EXPLOSION AND CARBON MONOXIDE POISONING.
This is a direct-fired cabinet construction heater for indoor construction. The heater must be placed where it
is not directly exposed to water spray, rain, and/or dripping water. Its intended use is primarily the temporary
heating
of
buildings or structures under construction, alteration or repair.All the products
of
combustion
generated by the heater are released into the area being heated. This heater operates
at
approximately 99%
combustion efficiency but still produces a small amount
of
carbon monoxide. Humans can tolerate small
amounts
of
carbon monoxide
for
short periods. Carbon monoxide can build up in a heated space and
failure to provide adequate ventilation could result in poisoning or death.
AwA
RN1N
G:
NoT
FoR
usE
wiTH
DucrwoRK.
IMPORTANT INSTRUCTIONS -Safet Information
NEVER LEAVE HEATER UNATTENDED WHILE BURNING
OR
WHILE CONNECTED TO A FUEL SOURCE.
A
WARNING
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID
COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER
OR
CARDBOARD, A SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY THESE
INSTRUCTIONS. NEVER USE THE HEATER IN SPACES WHICH DO OR MAY CONTAIN
VOLATILE
OR
AIRBORNE COMBUSTIBLES,
OR
PRODUCTS SUCH AS GASOLINE, SOLVENTS,
PAINTTHINNERS, DUST PARTICLES
OR
UNKNOWN CHEMICALS.
Ac
AuT
I0N
THIS
IS
AN
UNVENTED
PORTABLE
HEATER.
IT
USES
AIR (
OXYGEN)
FROM
THE
AREA
WHICH
IT
IS
USED.
AMPLE
COMBUSTI
ON
AND
VENTILATI
ON
AIR
MUST
BE
PROVI
DED.
A
WARN
INGIF
THE
INFORMATION
IN
THIS
MANUAL
IS
NOT
FOLLOWED
EXACTLY,
A
FIRE
OR
EXPLOSION
MAY
RESULT
CAUSING
PROPERTY
DAMAGE,
PERSONAL
INJURY
OR
LOSS
OF
LIFE.
¢ DO NOT STORE
OR
USE GASOLINE
OR
OTHER FLAMMABLE VAPORS AND LIQUIDS IN
THE VICINITY OF THIS
OR
ANY OTHERAPPLIANCE.
¢ AN LP CYLINDER NOT CONNECTED FOR USE SHALL NOT BE STORED
IN
THE VICINITY
OF THIS OR ANY OTHER APPLIANCE.
3
4
GENERAL SAFETY INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
PROPANE CONSTRUCTION HEATER
IJ/_,~
~k
PROPANE
CONSTRUCTION
HEATER
SPECIFICATIONS
Vent Free
Radiant
Heater-
Propane
Vapor
Only
Fuel Type ..
..
.
..
.
..
.
....
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
....
.
..
.
..
.
..
.
..
.
..
.....
..
.
..
.
..
.
..
.
..
.
..
.
..
.
....
.
..
.
..
.
..
.
..
.
..
.
..
.
..
. Propane Vapor Only
Ignition Type ..
....
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
....
.....
..
.
..
.
..
.
..
.
..
.
..
.
..
.
....
.
..
.
..
.
..
.
..
.
..
.
..
. Piezo El
ec
tric/ODS Pilot
Min Operating Temperature .
..
.
..
.
..
.
..
.
..
.
..
.
..
.
....
.
..
.
..
..
..
.
..
.
..
.
..
.
..
.
....
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
..
.
....
.
..
.
..
.
..
.
..
.
..
0 F (-18 C)
Clearances to Combustibles
..
....
..
....
..
.... Front: 3' (92cm),
Top:
2'
(60cm), Sides: and Rear: 1' (30cm),
Floor: Combustible, not for use on finished floors.
InputRating (BTU/Hr) SupplyPressure Manifold Gaa Consumption
Model#
Preaaure
High Medium
Low
Maximum Minimum lbs/hr
kg/hr
GCH480 18,000 12,
000
6,000 Bo
tt
le Press
ur
e Spsi 11.o" we 0.8
3/
0.28 0.377/0.127
PRODUCTFEATURES
5
~~~~~~o~~o
oo
~-
O
xy
gen
Depletion
Sens
or
(ODS)
---t1t!f~~
Weight
16
.8 lbs
7.6 kg
Handle
Slot
Size
(Assembled)
(LXWXH)
18" x
14~f
x
23r
458x380 x600mm
Back
Cover
Castor
PROPANE CONSTRUCTION HEATER
~
UNPACKING THE HEATER
1.
Remove heater from carton.
2. Remove all protective packaging applied to heaterfor shipment.
3. Retain carton and packing material until you confirm the unit operates and is found
in
good condition.
4. Check heaterfor any shipping damage.
If
heater shows any external
or
internal damage, promptly inform
dealer/distributorwhere you purchased heater.
5.
Remove back cover.
6. Locate the four (4) casters shipped with the unit. There are two (2) locking casters and two
non-locking casters. Also find the four (4) washers and wrench shipped with the casters.
7. Carefully lay the unit on its back.
8. Place one washer on each
of
the threaded portions
of
the caster. (see Figure 1
).
9. Thread the casters into the four threaded holes
in
the base
of
the unit by turning them
clockwise
.........-..
The locking casters should be placed at the front
of
the unit and the other two
at the back
of
the unit. (See Figure 1
).
10. Tighten The casters using the wrench supplied with the casters.
11.
lnstall20
lb
propane cylinder. (see Propane Supply section)
12. Install back cover
by
inserting the mounting tabs into the slots on the rear flange
of
the heater.
1\..
CAUTION: The casters must be installed onto the unit before it is used. Failure to install the
~
casters may result
in
a fire
or
explosion causing property damage, personal injury
or
loss
of
life.
FIGURE 1
WASHER
LOCKING
CASTERS
NON-LOCKING
CASTERS
WRENCH
INCLUDED
WITH
CASTERS
2)))
/75
6
PROPANE SUPPLY
7
PROPANE CONSTRUCTION HEATER
PROPANE CONSTRUCTION HEATER
~
CONNECTING
TO
GAS SUPPLY
IMPORT
'ANTI
ALWAYS USE A PROPANE (LP) CYLINDER THAT HAS A CONNECTION DEVICE
/'\ • THAT
IS
COMPATIBLE WITH THE HOSE AND REGULATORASSEMBLY SUPPLIED.
ACAUTION
THE PROPANE (LP) GAS PRESSURE REGULATOR AND HOSE
ASSEMBLY SUPPLIED WITH THE HEATER MUST BE USED
WITHOUT ALTERATION. BE SURE TO INSPECTTHE REGULATOR
HOSE BEFORE EACH USE. IF THE HOSE IS CUT OR FRAYED, REPLACE IT WITH THE
MANUFACTURER SUGGESTED ASSEMBLY.
1. Provide propane/LP supply system (see Propane Supply, page 7).
2. Insert the 20 lb propane cylinder into the rear
of
the heater and position it such that the outlet
of
the cylinder
valve is facing towards the front-left corner
of
the unit. See Figure
2.
3. Connect the fitting
of
the hose/regulator assembly to the cylinder outlet. Turn the fitting counterclockwise
~
into the threads
of
the cylinder valve. Some models have a hand wheel that can be slid offthe nut
so that a wrench can be used to tighten the fitting,
if
desired.
A
CAUTION
Position the regulator such that the side with the tower is facing
down and the flat side is facing up. See Figure 2.
AW
'ARNING
Ensure that the gas hose is not touching the unpainted heat shield
/'\ at the front
of
the cylinder enclosure. See Figure 2.
4. Open propane/LP supply valve on propane/LP tank(s) slowly.
NOTE:
If
not opened slowly, excess flow device
in regulator may stop gas flow.
If
this happens,
close propane/LP supply valve, wait one minute
(
or
until you hear a click) and open again slowly.
5. Check all connections for leaks. Apply a
50
1
50
solution
of
liquid dish soap and waterto
gasjoints. Bubbles forming show a leak
that must be corrected.
6. Close propane I LP supply valve
before attempting to
repair connection.
REGULATOR
PROPANE
TANK
FIGURE 2
HOSE
TO
HEATER
PROPANE
/LP
SUPPLY
VALVE
8
~~
PROPANE CONSTRUCTION HEATER
PROPANE
SAFETY
Propane is safe to use when properly handled. Careless handling
of
the Propane gas tank could result in
fire and/or an explosion. Therefore:
•Always keep tank/cylinder securely fastened in an upright position.
•Avoid tipping tank on its side when connected to a regulator since this may cause damage to
diaphragm in regulator.
• Handle valves with care.
• Never connect an unregulated Propane tank to construction heater.
• Do not subject Propane tank to excessive heat.
• Tightly close the gas shutoffvalve on the Propane tank after each use.
• The POLfitting must be protected when disconnected from the propane tank.
• Never store a Propane gas tank inside a building or in the vicinity
of
any gas burning appliance.
THE DISCONNECTED TANK MUST NEVER BE STORED
IN
A BUILDING,
GARAGE OR
ANY
OTHER ENCLOSED AREA.
CHECKING FOR LEAKS
Check all gas connections with a soap solution to be sure they are tight and leak proof. Soap bubbles indicate
gas leakage that must be corrected.
• The installation
of
your heater must meet all local codes and/
or
gas utility requirements or, in the absence
of
local codes, with the Storage and Handling
of
Liquefied Petroleum Gases, ANSI/NFPA58 and the Natural
and Propane Installation Code, CSA 8149.1 .
• Do not use a match or flame to check for gas leaks.
• The hose assembly should be visually inspected prior to each use
of
the heater.
If
it is evident that there is
excessive abrasion orwear, or the hose is cut, it must be replaced pri
or
to the heater being put into operation.
·The
replacement hose assembly shall be that specified by the manufacturer (See page 13 for part numbers).
9
/\.WARNING
PURGING AND FILLING OF LP GAS TANKS MUST BE PERFORMED
~
BY PERSONNEL WHO HAVE BEEN THOROUGHLY TRAINED IN
ACCEPTED LP GAS INDUSTRY PROCEDURES. FAILURE TO FOLLOWTHESE INSTRUCTIONS
MAY RESULT
IN
EXPLOSION, FIRE, SEVERE PERSONAL INJURY, OR DEATH.
PROPANE CONSTRUCTION HEATER
~
LIGHTING INSTRUCTIONS
1. STOP! Read and head warnings and cautions on the si
de
of
the heater.
2. Check that the gas supply to the heater is on.
3. Push in
gas
control knob slightly and turn clockwise
~
to "OFF" 0 position. (A)
Note:
knob cannot be turned from "
PILOT".
pos
ition to "OFF"0 unless the knob is pushed in slightly.
Do
not force.
4. Wait five (5) minutes to clear any gas. Then smell for
gas
, including
near
the floor. if you smell gas, STOP!
Follow the leak checking section in the manual.
if
you
do
not smell
gas
,
go
to next step.
5. Push in the
gas
control knob slightly and turn counterclock
wi
se ..--..-, to "PILOT"
..
position
and depress
for
5 seconds. (B)
Note:
The first time that the heater is operated after connecting the
gas
supply, the control knob should be
depressed for
at
least 30 seconds. This will allow
air
to bleed from the
gas
system.
6. Depress control knob while depressing the piezo ignitor button f.This should cause the spark from the
piezo ignitor to light the pilot gas. Keep control knob depressed thirtry (30) seconds before releasing.
If
the pilot does not light, depress the control knob and turn to the "OFF"O position. Repeat steps 5 and
6.
7. When pilot is lit, turn the knob counterclockwise ..--..-, to
des
ired heat level,
LOW
e.
MEDIUM
ee
.
or
HIGHeee
.(C)
FIGURE 3
(C)
10
11
SHUTDOWN INSTRUCTIONS
Turning burner only OFF (pilot stays lit).
STORAGE
MOVING AND POSITIONING HEATER
PROPANE CONSTRUCTION HEATER
PROPANE CONSTRUCTION HEATER
~
MAINTENANCE
Repair should be done by a qualified service person. The appliance should be inspected before use and at
least annually by a professional service person. More frequent cleaning may be required due to excessive
debri
s.
It is imperative that control compartments, burners and circulating airpassageways
of
the heater be
kept clean. Dust, lint, cobwebs
or
debris may affect heater performance. The heater draws air into it during
normal operation and in the process dust, lint
or
debris may be drawn into
it.
Before cleaning ensure the gas
supply is turned off at the cylinder and the gas control knob is in the "OFF" position.
Pilot
and
Burning
Inspection
Each time you light the heater check that the pilot flame and burner flame patterns are as shown in fugures 4
and
5.
Ifflame patterns are incorrect, turn the heater offand contact your dealer
or
qualified service person for
assistance. Do not operate the heater until the pilot and burner flames are correct.
Note: Do not mistake orange flames with yellow tipping. Dirt or dust particles may enter the burner flames and
cause transient patches
of
orange flame.
FIGURE 4 Proper Pilot Flame
Thermocouple Ignitor Electrode FIGURE 5
Correct Burner Flame Pattern
\
...
...
...
...
...
...
...
...
v .
..
...
.
..
"
... ...
..
..
.
....
• "
...
...
.,
...
..
.,
.,
.
...
...
...
..
...
.
.,
"
..
...
..
...
.
..
.
..
..
..
..
..
..
..
.
..
"
..
..
·
.·
....
..
.
..
..
.
..
" v
.,
"
.,."""'
y..,
..
y
..
..
Correct Incorrect Correct Incorrect
Burner
and
ODS
Pilot
Cleaning
Clean the exteriorwith soft bristle brush, vacuum cleaner
or
pressurized air. Neveruse a wooden toothpi
ck
as
it may break offand clog the ODS pilot
or
main burner port.
Use a flashlight to inspect the main burner inlet to ensure it is not blocked.
If
obstruction can be seen, use a
metal coat hanger that has been straightened out. Use a vacuum cleanerto clean the primary air openings
to the main burners.
f'L
WARNING: FAILURE TO KEEP THE PRIMARYAIR OPENINGS TO THE BURNER(S) CLEAN
~
"
MAY
RESULT
IN
SOOTING, PROPERTY DAMAGE AND INCREASED CARBON MONOXIDE
PRODUCTION".
In order to clean ODS pilot orifice, use pressurized air to blow dust out through the primary air opening on the
side
of
the pilot.
Cleaning
Air
Passageways
and
Unit
Casings
Use a vacuum cleaner
or
pressurized air to clean the combustion and circulating air passageways and a damp
cloth to clean the cabinet/casing.
12
13
TROUBLESHOOTING
Problem Possible Cause What To Do
When ignitor is depressed there is no spark
at ODS pilot.
1. Ignitor electrode positioned wrong.
2. Ignitor electrode broken.
3. Ignitor cable pinched or broken.
4. Ignitor cable not connected to ignitor
electrode.
5. Ignitor defective.
1. Reposition ignitor electrode.
2. Replace electrode.
3. Free ignitor cable, if damaged, replace.
4. Connect cable to electrode.
5. Replace ignitor.
When control knob is pressed in and turned
counterclockwise to pilot and piezo is
depressed, pilot does not light.
1. Gas supply turned off.
2. Control knob not in pilot position.
3. Control knob not pressed in while in pilot
position.
4. ODS pilot is clogged.
5. Air in gas lines.
1. Turn gas supply on.
2. Turn control knob to pilot position.
3. Press in control while in pilot position.
4. Call a qualified service technician.
5. Purge gas lines and repeat ignition
operation.
ODS pilot lights but flame goes out when
control knob is released.
1.Control knob not pressed long enough.
2. Safety interlock is triggered.
3. Pilot flame not touching the
thermocouple.
Problem could be result of one or both of
the following:
• Partially clogged ODS pilot orifice.
• Low gas pressure.
4. Thermocouple damaged.
5. Thermocouple connection loose at gas
control valve.
6. Gas control valve damaged.
1. After ODS pilot lights, keep control knob
pressed in approximately 30 seconds.
2. Wait one minute, repeat ignition
operation.
3. Contact your gas company, gas supplier
or qualified service technician.
4. Replace thermocouple.
5. Hand tight until snug then tighten
1/4 turn with a wrench.
6. Replace gas control.
Burner does not light after ODS pilot is lit. 1. Burner orifice clogged.
2. Gas supply pressure is very low.
1. Clean burner orifice.
2. Contact gas supplier.
Delayed ignition. 1. Main burner carry over ports clogged.
2. Gas supply pressure is very low.
1. Clean main burner ports.
2. Contact gas supplier.
Burner backfiring during operation. 1. Burner orifice is clogged.
2. Burner ports damaged.
1. Clean burner orifice.
2. Replace burner.
Yellow flames during burner operation. 1. Not enough air.
1. Check air passageways and burner for
dirt and debris.
(Refer to Maintenance section)
Burner plaque(s) does not glow.
1. Plaque(s) is damaged.
2. Inlet gas pressure too low.
3. Control knob set between locked
positions.
1. Replace burner.
2. Contact local gas supplier.
3. Turn control knob until it locks at
desired setting.
Slight smoke and odor during
Initial operation. 1. Residues from manufacturing processes. 1. Will stop after a few hours of operation.
Heater produces a whistling noise
when burner is lit.
1. Air passageways blocked.
2. Air in gas line.
1. Check minimum installation clearances
and air passageways for debris.
2. Operate burner until the air is completely
purged.
Heater produces a clicking noise just after
burner is lit or turned off. 1. Metal expanding and contracting.
1. This is common with heaters.
If noise is excessive, contact a
qualified, service technician.
PROPANE CONSTRUCTION HEATER
14
TROUBLESHOOTING (continued)
Problem Possible Cause What To Do
Gas odor even when control knob is
in OFF position.
1. Gas leaks. Refer to front of page
Warnings.
2. Gas control defective.
1. Locate and correct leaks immediately.
2. Replace gas control
Gas odor during combustion.
1. Foreign matter in gas or on burner ports.
2. Heater burning vapors form paint,
impurities in air.
3. Gas leaks, refer to front page Warnings
1. Check gas passage way and burner.
2. Ventilate room, stop storing and using
odor causing products near heater.
3. Locate and correct leaks immediately.
Heater shuts off on ODS.
1. Not enough fresh air is available.
2. Low gas pressure.
3. ODS pilot partially clogged.
1. Open window.
2. Contact gas supplier.
3. Clean the pilot.
PROPANE CONSTRUCTION HEATER
1515
LIMITED WARRANTY:
This limited warranty is extended to the original retail purchaser of this Forced Air/Convection/Radiant Heater and warrants against any
defect in materials and workmanship for a period of one (1) year from the date of retail sale. World Marketing of America, Inc., at it’s option, will
either provide replacement parts or replace or repair the unit, when properly returned to the retailer where purchased or one of our service centers
as directed by World Marketing, within one (1) year of retail purchase. (Shipping costs, labour costs, etc. are the responsibility of the purchaser.)
DUTIES OF THE OWNER:
This heating appliance must be operated in accordance with the written instructions furnished with this heater. This warranty shall not excuse
the owner from properly maintaining this heater in accordance with the written instructions furnished with this heater. A bill of sale, canceled
check or payment record must be kept to verify purchase date and establish warranty period. Original carton should be kept in case of warranty
return of unit.
WHAT IS NOT COVERED:
1. Damage resulting from use of improper fuel.
2. Damage caused by misuse or use contrary to the owners manual and safety guidelines.
3. Damage caused by a lack of normal maintenance.
4. Fuses
5. Use of non-standard parts or accessories.
6. Damage caused in transit. Freight charges on warranty parts or heaters to and from the factory shall be the responsibility of the owner.
This warranty does not imply or assume any responsibility for consequential damages that may result from the use, misuse, or the lack of
routine maintenance of this heating appliance. A cleaning fee and the cost of parts may be charged for appliance failures resulting from lack of
maintenance. This warranty does not cover claims which do not involve defective workmanship or materials. FAILURE TO PERFORM
GENERAL MAINTENANCE (INCLUDING CLEANING) WILL VOID THIS WARRANTY.
THIS LIMITED WARRANTY IS GIVEN TO THE PURCHASER IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY OF FITNESS FOR A PARTICULAR PURPOSE. THE
REMEDY PROVIDED IN THIS WARRANTY IS EXCLUSIVE AND IS GRANTED IN LIEU OF ALL OTHER REMEDIES. IN NO EVENT WILL
WORLD MARKETING OF AMERICA BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Some states do not
allow the exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you.
CLAIMS HANDLED AS FOLLOWS:
1. Contact your retailer and explain the problem.
2. If the retailer is unable to resolve the problem, contact our Consumer Warranty Dept. detailing the heater model, the problem, and proof
of date of purchase.
3. A representative will contact you. DO NOT RETURN THE HEATER TO WORLD MARKETING OF AMERICA, INC. unless instructed by
our Representative.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
TO REGISTER THE WARRANTY ON YOUR HEATER, PLEASE FILL OUT THIS CARD COMPLETELY
AND MAIL WITHIN 14 DAYS FROM DATE OF PURCHASE OR REGISTER ON-LINE AT www.worldmkting.com
NAME: ______________________________________ PHONE: ( ) __________________ EMAIL: ____________________________
ADDRESS: _________________________________ CITY: ______________________________ STATE: __________ ZIP: ____________
MODEL: ____________________ SERIAL #: _______________________________________ DATE PURCHASED: __________________
DEALER PURCHASED FROM: ____________________________________________ TYPE OF STORE: __________________________
CITY & STATE WHERE PURCHASED: ______________________________________________ PRICE PAID: _______________________
Please Take a Minute To Give Us Your Answers To The Following Questions.
All Responses Are Used Solely For Market Research And Are Held In Strict Confidence.
Who primarily decided this purchase? Male Female 18-24 25-39 40-59 60 and over
Purpose of Purchase? _______________________________________________________________________________________________
Do you own any other portable heaters? Yes No If yes, type____________________________brand_____________________
How do you intend to use your new heater? Construction Site Farm Warehouse/Commercial Garage/Outbuilding Other
How did you become aware of this heater? In-Store Display Newspaper Ad Magazine Ad Friend/Relative
£TV Commercial £Store Salesperson Other ___________________________
What made you select this heater? Style Size/Portability Price Package Brand Other ___________________
Do you: own rent Would you recommend this heater to a friend? Yes No
Please give us your comments:________________________________________________________________________________________
THANK YOU FOR COMPLETING THIS FORM!
Information will be held confidential.
Part No. 09LPWTY
WARRANTY
16
16
WARRANTY REGISTRATION
IMPORTANT: We urge you to fill out your warranty registration card within fourteen (14)
days of date of purchase. You can also register your warranty on the internet at
www.worldmkting.com. Complete the entire serial number. Retain this portion of the card
for your records.
World Marketing of America, Inc.
PO Box 192, 12256 William Penn Hwy.
Mill Creek PA 17060-0192
Tel) 1-800-776-9425
www.worldmkting.com
SAVE THIS CARD!
World Marketing of America, Inc.
PO Box 192, 12256 William Penn Hwy.
Mill Creek PA 17060-0192
Place
Postage
Stamp
Here
"""
"
~
~~
PROPANE CONSTRUCTION HEATER
REPLACEMENT PARTS
LIST
GCH480
Item/Model
Number
Part
No.
Item/Model
Number
Part
No.
1.
Lower
Shield
PT-N11B-8
10
.
Tilt
Sw~ch
FD4
2.
Guard
Assembly
PT-N11B-3
11.
Gas
Pipe
PT-N11B-7
3.
Front
Panel
PT-N11B-1
12
.
Regulator
&
Hose
Assembly
KR-106A
4.
Reftector
PT-N11B-2
13
.
Rear
Chassis
PT-N11B-4
5.
ODS
Assembly
PT-N11B
.6
14
.
Castor
With
Lock
PT-NOS-33
6.
Burner
Assembly
PT-N11B
.4
15
.
Castor
Without
Lock
PT-NOS-32
7.
Gas
Valve
PT-N11B-13
16
.
Heat
Insulation
Board
PT-N11-6
8.
Piezo
lgn~or
PT-N11B
.5
17
.
Back
Cover
PT-N11
8.2-1
9.
Knob
Base
PT-N11B-10
18
Knob
PT-NOS-24
AwARNING!
This heater is not intended for residential use.
17
18
17. Back Cover 13. Rear Chassis
12. Regulator and Hose Assembly
7.Gas Valve
6. Burner Assembly
2. Guard Assembly
11. Gas Pipe
14. Castor With Lock
10. Tilt Switch
15. Castor Without Lock
16. Heat Insulation Board
8. Piezo Ignitor
9. Knob Base
4. Reector
1. Lower Shield
3. Front Panel
EXPLODED PARTS DRAWING
5. ODS Assembly
18.Knob
