Comica CVM-WM200 User manual

CVM-WM200
UHF Wireless Microphone
USER MANUAL

Foreword
Main Features
Thanks for purchasing COMICA WM200 UHF wireless microphone. To ensure a good
using experience and customers’ physical safety, please carefully read this instruction
before using and properly assemble and operate.
. Dual Transmitters Triggered by One Receiver, A/B Double Group Options
. Quick A/B/A+B Group Switch
. Used for Multiple Devices Working Together
. Working Distance is Up to 120m (120m in Open Area, 80m in Area with Obstacle)
. LCF Low Cut Filtering Mode
. Auto-scanning for Quick Channel Selection
. IR Sync
. Adjustable RF Signal Strength
. AA Batteries and External Power Supply
. Audio Dynamic Display Bar
. 16 Levels Volume Adjustment
. Optional Language
. Transmitter Power Monitor
. Output Modes Mono/Stereo Switch
. Low-consumption, Super-long Standby Time
. Lattice LCD Display, High Resolution
. Full Metal Manufacturing, Excellent Shielding
1

Notice
Package Contents
Transmitter should be placed at a distance more than 10cm from Receiver. When the
distance is less than 10cm, Receiver’s wireless signal receiving part will take protect
action to shut down the receiving wireless signal, then audio may be intermittent, which is
normal
When using auto IR sync, please stay within 30cm, otherwise the signal may be too weak
and the sync will not be successful
In the case of stereo/mono mode switch, please preset the mode before using to avoid
the transient interference caused by switching during usage
When there is any need for long time using, external power bank is better for power
supplying instead of using AC-DC power to avoid noise problem
The antenna will aect the working distance. Please protect the antenna and avoid any
man-made damage
The working distance will be aected by the surrounding environment. Please try to keep
the environment open without interference during usage, and close the WIFI of the device
itself
When using this product in a short distance, it is recommended to set RF strength at
‘LOW’ to reduce the power consumption
For smartphone shooting, customers need to separately purchase a TRS-TRRS audio
cable adapter, and remember to set the mobile phone mode to 'Flight Mode' for avoiding
incoming call interference (It does not support the original recording system of some
android systems, the third-party APP is recommended to be used in this case)
Please keep this product in dry environment
Do not expose the device in rain or humid environment, otherwise there will be a danger
of short circuit
Main Parts：
Lavalier Transmitter (TX) Hand-held Transmitter (HTX) Receiver (RX)
2

For the method of WM200/300-XLR using, please refer to the user
manual that comes with the product
WM200(A) = 2TX + RX
WM200(C) = TX + RX
TX TX RX
++
TX RX
+
WM200-TX WM200-RX WM200-HTX WM200/300-XLR
Multiple Selections:
3

1234
56 7 8
9
10
CVM-WM200
UHF Wireless Microphone
USER MANUAL
3.5mm Mic Audio Input Cable
3.5mm-3.5mm Audio Output Cable
3.5mm-XLR Audio Output Cable
USB-C Charging Cable
Belt Clip
Cold Shoe Mount
Wind Mu
Portable Box
User Manual
Warranty Card
Accessories:
1
2
3
4
5
6
7
8
9
10
4
The accessories of each combination include：
WM200(A)= x2 + + + + x3 + + x2 + + +
WM200(C)= + + + + x2 + + + + +
12 3 4 6 7 8 9 10
123 4 6
5
57 8 9 10

1
3
2
4
5
6
7
8
10
9
11
12
13
14
15
Components and Instruction
Components
Lavalier Transmitter (TX)
Antenna
Matching Status Indicator
Sound Status Indicator
Power / Muting Button
LCD Screen
Function Selection Button -
SET Function Menu
Function Selection Button +
IR Sensor
MIC / LINE IN External Input
Group Selection Switch
Battery Tray
1/4 Mounting Hole
Belt Clip
USB-C Charging Socket
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
5

2
1
3
4
65
Microphone
LCD Display
Power / Muting Button
IR Screen
Low Cut Filter/Normal Audio Switch
Signal Strength “High/Low” Switch
Hand-held Transmitter (HTX)
1
2
3
4
5
6
LCF
RF
LCF
-
RF
High
Low
6

1
911
10
3
2
4
5
6
7
8
12
13
14
15
16
Receiver (RX)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Group A Antenna
Group B Working Status Indicator
Group A Working Status Indicator
Power Switch
LCD Screen
Function Selection Button -
SET Function Menu
Function Selection Button +
3.5mm Audio Output Socket
IR Sensor
3.5mm Monitoring Socket
Group B Antenna
Group Selection Switch
Battery Tray
Belt Clip
USB-C Charging Socket
7

Lavalier
Transmitter
/ Receiver
Hand-held
Transmitter
Power / Muting Button
Long Press
Short Press
Power On / O
Power / Muting Button
“Low cut/ Normal”
Sound Switch
Signal Strength
“High/Low”
Switch
Long Press Power On / O
Muting Mode（This function is only
for transmitter, when the mute
function is turned on and the
screen is lighted up）
Short Press Muting Mode（Only goes into
eect when the screen lights up）
SET Function Menu
+ Button
- Button
Long Press Enter the function adjustment menu
Short Press
Short Press
Short Press
1.Confirm the selected function
2.Exit the function adjustment menu
Function Adjustment (+)
Function Adjustment (-)
Push-up Signal strength--high
Push-down Signal strength--low
Push-up Low cut
Push-down Normal
Function Button Instruction
LCF
-
RF
High
Low
Signal strength high / low switching eect:
With high signal strength, the wireless working distance is up to 80-120M, high
power consumption, battery life is short; With low signal strength, the wireless
working distance is up to 30-60M, low power consumption, the battery can be
used for a long time.
8

Indicator Light Instruction
Transmitter
Receiver
AUDIO
A IR/RF
B IR/RF
A IR/RF：Group A Working Status Indicator
B IR/RF：Group B Working Status Indicator
IR
Green Light Keeps on
Green Light Keeps on
Green Light Keeps on
Red Light Keeps on
Red Light Flickers
Red Light Flickers
Red Light Flickers
Red Light keeps on
Green Light Flickers
Normal Recording Status
（This state is only for the
transmitter, when the channel
matches successfully, then
the receiver can pick up the
sound）
Muting Mode
Low-power reminder
Channel matches
（No matter the channel
matched or not）
Channel is matching......
（only for IR Sync）
Normal working status after
the channel matched
Channel match failed
Channel is matching......
（only for IR Sync）
Low-power reminder
Group closed
Low cut function:
Appropriately remove the low frequency part of the sound, reduce the ambient
noise of the low frequency part, to make sound more clean and clear.
9

AA
AA
USB-C Plug
When there is any need for long time
using, external power bank is better
for power supplying instead of using
AC-DC power to avoid noise problem
POWER
5V/1A
Installation and Usage
1. Install two AA batteries into the battery tray according to the
positive and negative electrode. It supports external
power-supplying through USB-C Plug
Lavalier Transmitter
10

2. Insert the 3.5mm audio input cable into MIC socket
3. Long press the power button to turn on the transmitter
11

H
A
Group A
A
4. Place the MIC at the audio source and check the working status
according to the volume indicator on the screen
5. Insert the belt clip to the connection hole
6. After the channel matched with the receiver, it can be used
Please refer to screen operation instruction for channel matching.
Audio Dynamic Display Bar
12

Please refer to screen operation instruction for channel matching.
2.Long press the button switch to turn on
the hand-held transmitter
3. After the channel matched with the receiver, it can be used
Hand-held Transmitter
1. Install two AA batteries into the battery tray
according to the positive and negative electrode
AA AA
13

AA
AA
USB Plug
When there is any need for long time
using, external power bank is better
for power supplying instead of using
AC-DC power to avoid noise problem
POWER
5V/1A
Receiver
1. Install two AA batteries into the battery tray according to the positive
and negative electrode. It supports external power-supplying through
USB-C Plug
14

3. Connect one end of the 3.5mm-3.5mm audio OUTPUT cable to the
OUTPUT port of WM200RX and another end to the AUDIO INPUT
port of the camera or camcorder.Insert the headphone into the
3.5mm monitoring port for real-time monitoring and then long press
power button to trun on the receiver.
2. Connect the receiver to the video device through the Cold Shoe
Mount
Most DSLR cameras has 3. 5mm port, if you use the XLR camcorder,
you need to use the 3. 5mm-XLR audio output cable.
15

Please refer to screen operation instruction for channel matching.
4. After the channel matched with the receiver, it can be used
3.5MM-XLR Audio
Output Cable
3.5mm-3.5mm
Audio Output Cable
3.5mm Audio Output
Monitoring Cable
16

H
A
Group A
A
Screen Display and Operation Instruction
Screen Display Instruction
Operation Instruction
Lavalier Transmitter
Signal Strength High
Signal Strength Low
Group A
Group B
Normal recording
Muting
Muting（Unlocking）
Muting（Locking）
Battery Level
Group A/B
Channel
Group A/B
Audio dynamic display bar Channel Frequency
H
L
1. Group A/B Selection
1.1 Use A/B Group selection switch to select the group, when push
up to A, Group A truns on; when push to B,Group B truns on.
You could choose Group A or Group B according to your demand.
A/B Group Selection Switch
17

H
A
Group A
A
H
A
Group A
A
CH11
H
A
Group A
A
CH45 533.500MHz
561.400MHz
H
A
Group A
A
CH45 533.500MHz
H
B
Group B
B
2.1 Long press button to CH setting display page
2.2 Short press button to select the channel
2.Manually Adjust the Channel of Transmitter
2.3 Short press button to confirm
A Group B Group
18
