Comica VS09 MI User manual

User Manual
LIGHTNING INTERFACE MICROPHONE

Foreword
Thanks for purchasing Comica CVM-VS09 MI Lightning Interface Microphone.
To ensure bring you a good using experience, please read this manual book carefully before using
and correctly install and operate.
Notice
The product may be incompatible with part of iOS system devices as there are too many
dierent versions
When using the playback recording function with devices of iOS system, it can not achieve it
due to the protection of the iOS system if the volume of the device is adjusted to the maximum
before monitoring, you need to readjust the volume of the device to realize playback recording
(It is recommended that the headphone volume is not adjusted to the maximum)
In the course of use, please set the smartphone to Flight Mode to avoid any interference
Do not use this equipment in the vicinity of heat source or interference source, such as radiator,
oven, refrigerator or air conditioner, smartphone or next to the WIFI AP
This product belongs to high-precision instruments, please avoid falling, collision or pounding
Do not use the equipment in rain or in a damp environment to avoid short-circuit danger
1

Main Features
. Specially Designed for Devices with Lightning Interface
. 44.1KHz/48KHz 16bit Digital Mic, Superior Audio Quality and Low Noise
.180 Degree Rotation, Flexibly Used for Multiple Scenes
. Muting Function and Support Real-time Monitor
. High-density Windscreen, Eectively Filter the Wind Noise
. Cardioid Directional, Accurately Pickup
Package List
Body of Microphone Mic Windscreen Hand Bag User Manual Warranty Card
User Manual
iOS SMARTPHONE MICROPHONE
2

5
Components
Microphone
Mic Capsule
Work Indicator Light
Muting Button
3.5mm TRS/TRRS Monitoring Jack
Lightning Connector
1
2
3
4
5
3

Installation and Use
1. Install the windscreen to microphone
4

2. Install the microphone onto the phone
5

3. Rotate the microphone for dierent usage scenarios and angles
Self-recording Mode Interview ModeRecording Mode
6

4. Insert the earphone into the 3.5mm TRS/TRRS monitoring jack, then you can real-time monitor
7

5. Muting Function
Switch Muting Mode by pressing Muting Button. When in normal recording mode, the indicator
light turns green; When in muting mode, the indicator light turns red.
When replaying recorded audio or video with phone, muting mode should be turned on to avoid
the influence of microphone real-time sound
Microphone Muting Button Work Indicator Light
8

Polar Pattern Frequency Response
Specification
50
40
30
20
-20
-30
-40
-50
10 100 1000 10000
10
-10
0
0
90
180
-2.0
-20.0
-10.0
125 Hz:
250 Hz:
500 Hz:
1000 Hz:
2000 Hz:
4000 Hz:
8000 Hz:
9

Technology Parameter:
Polar Pattern
Frequency Response
Signal/Noise
Max SPL
Output Interface
Monitoring Interface
OS Requirements
Dimension
Net Weight
Working Temperature
Cardioid
60Hz~20kHz
>70dB
>100dB
Lightning
3.5mm TRS/TRRS
iOS 10 or Above
38x71x53mm
36g
0℃~50℃
10

用户使用手册
Lightning接口专用麦克风

前 言
感谢您购买科唛CVM-VS09 MI Lightning接口专用麦克风。
为保证产品的顺畅使用，请在使用前严格阅读本说明书，并正确组装及操作。
注意事项
由于iOS系统存在多种版本，可能会有少部分手机出现不兼容情况
搭配iOS系统设备使用回放监听功能时，如耳机音量在监听前被调至最大，由于iOS系统的保护机制，
会导致监听无输出，此时重新调整耳机音量大小即可。（建议耳机音量不要调至最大）
使用过程中，请尽可能将手机设置为飞行模式，以避免手机信号干扰
请勿将本设备放置在热源或干扰源附近使用，如散热器、烤箱、冰箱、空调、手机和WIFI热点旁边
本产品属于高精密仪器类产品，请避免使用时掉落、碰撞或重击
请勿在下雨或潮湿环境环境中使用，否则会有短路的危险
1

产品主要功能
. 专用于Lightning接口设备
. 44.1KHz/48KHz 16bit数字麦克风，高保真、低底噪
. 180度旋转，灵活运用于多种拍摄场景
. 一键静音功能，支持实时监听
. 高密度防风棉，可有效取代防风毛滤除风噪
. 心型指向，精确拾音
包装清单
麦克风主体 便携袋防风棉 说明书 保修卡
User Manual
iOS SMARTPHONE MICROPHONE
2

5
部件介绍及说明
麦克风
拾音头
工作指示灯
麦克风静音按钮
3.5mm TRS/TRRS耳机监听插孔
Lightning接头
1
2
3
4
5
3

安装与使用
1.把防风棉安装到麦克风主体上
4

２.把麦克风主体安装到手机上
5

3.把麦克风转到适当的角度以便适应不同使用场景
自录音模式 采访模式对外录音模式
6
