Installation Instructions
MRC1 Series
STEP 1: The door must be machined with a 3/8”wire raceway,
mortise lock pocket & prepped for a energy transfer
hinge. Make sure the mortise pocket is free of debris.
STEP 4: Connect the wires exiting the mortise pocket to the
Bridge Rectier (included).
STEP 2: Run the wires from the ETH hinge through the 3/8”
raceway starting at the ETH hinge & exiting into the
mortise pocket.
STEP 5: Connect the Bridge Rectier to the plug exiting the
mortise chassis.
STEP 3: Screw the ETH hinge to the door. At this time DO NOT
connect the hinge wires on the jamb side to the wires
coming from the power supply.
EU: (Fail Secure) When power is applied, the outside trim will unlock. When
power is removed, the outside trim is locked.
EL: (Fail Safe) When power is applied, the outside trim will lock. When
power is removed, the outside trim is unlocked.
REX: (Request to Exit Switch) Monitors the inside handle.
DPS: (Door Position Switch) Monitors the door position via the anti pick
(Deadlatch).
LBM: (Latchbolt Monitor Switch) Monitors the position of latchbolt.
* Not Available in all locks
*
STEP 8: Connect the wires from the power supply at the ETH
hinge on the jamb side. Connect the hinge to the jamb.
STEP 6: Carefully slip the connected mortise lock chassis into the
mortise pocket paying close attention not to pinch any
wires.
STEP 7: Mount the chassis per manufacturer’s instructions.
LEGEND OF TERMS
SOLENOIDS:
VOLTS
24VAC/DC
12VAC/DC
CURRENT
350mA
700mA
COIL RESISTANCE
69 Ohms +/- 10%
18 Ohms +/- 10%
SWITCHES: .25A 24VAC/DC
REX: Green - Common (C)
Blue - Normally Open (NO)
Gray - Normally Closed (NC)
LBM: Green/Black - Common (C)
Blue/Black - Normally Open (NO)
Gray/Black - Normally Closed (NC)
ELECTRICAL SPECIFICATIONS
Command Access Technologies is not a licensee, aliated, associated or connected with Allegion, Assa Abloy, or Best any of their subsidiaries or aliates.
Command Access Technologies | 22901 La Palma Ave. Yorba Linda, CA 92831 | Phone: [phone] | www.CommandAccess.com
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EU (Fail Secure)
EU (Fail Secure)
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EL (Fail Safe)
EL (Fail Safe)
Mortise
Lock
Pocket
3/8 Wire Raceway
ETH Hinge Pocket
Bridge
Rectifier
Wire Transfer Hinge
Bridge
Rectifier
Plug
3/8 Wire Raceway
Mortise
Lock
Pocket
Mortise
Lock
Pocket
Mortise
Lock
Pocket
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EU (Fail Secure)
EU (Fail Secure)
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EL (Fail Safe)
EL (Fail Safe)
Mortise
Lock
Pocket
3/8 Wire Raceway
ETH Hinge Pocket
Bridge
Rectifier
Wire Transfer Hinge
Bridge
Rectifier
Plug
3/8 Wire Raceway
Mortise
Lock
Pocket
Mortise
Lock
Pocket
Mortise
Lock
Pocket
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EU (Fail Secure)
EU (Fail Secure)
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EL (Fail Safe)
EL (Fail Safe)
Mortise
Lock
Pocket
3/8 Wire Raceway
ETH Hinge Pocket
Bridge
Rectifier
Wire Transfer Hinge
Bridge
Rectifier
Plug
3/8 Wire Raceway
Mortise
Lock
Pocket
Mortise
Lock
Pocket
Mortise
Lock
Pocket
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EU (Fail Secure)
EU (Fail Secure)
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EL (Fail Safe)
EL (Fail Safe)
Mortise
Lock
Pocket
3/8 Wire Raceway
ETH Hinge Pocket
Bridge
Rectifier
Wire Transfer Hinge
Bridge
Rectifier
Plug
3/8 Wire Raceway
Mortise
Lock
Pocket
Mortise
Lock
Pocket
Mortise
Lock
Pocket
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EU (Fail Secure)
EU (Fail Secure)
12VAC/DC
24VAC/DC
or
Power
Supply
Bridge Rectifier Energy Transfer Hinge
Switch
EL (Fail Safe)
EL (Fail Safe)
Mortise
Lock
Pocket
3/8 Wire Raceway
ETH Hinge Pocket
Bridge
Rectifier
Wire Transfer Hinge
Bridge
Rectifier
Plug
3/8 Wire Raceway
Mortise
Lock
Pocket
Mortise
Lock
Pocket
Mortise
Lock
Pocket
Command Access Technologies MRC1 Series: Best 35, Cal Royal 8000, Corbin 2000, & Falcon MA Series
#20299_B

Handing Instructions for Mortise Locks
STEP 1:Remove screw STEP 2: Remove latchbolt and rotate 180 .
Note: Figure A. Piece must sit below faceplate.
STEP 3: Re-install latchbolt and screw.
Figure A
Command Access Technologies | 22901 La Palma Ave. Yorba Linda, CA 92831 | Phone: [phone] | www.CommandAccess.com
Command Access Technologies is not a licensee, aliated, associated or connected with Allegion, Assa Abloy, or Best any of their subsidiaries or aliates.

STEP 4: Move handing screws to opposite side.
Note: Handing screws should be located on the non-locking side.
