Command access PD10-UL-M-KIT User manual

Kit Includes Tools Required
CordlessDrillorPhillipsScrewdriver
Hacksaw
A.
B.
C.
Motor Mount w/MM4
1- 8’ Lead w/ Connector
2-Setsofnishedphillipsscrews
Command Access Technologies | 22901 La Palma Ave, Yorba Linda, CA 92887 | Phone:[phone]
PD10-UL-M KIT
INSERT Instructions
ThePD10-UL-M-KITisaeldinstallablemotorizedlatchpullbackforthePD10/11,DoromaticorFalcon
1690/1790, & First Choice 3600/3700.
C.
A.
B.
#20410_A

PTS Video
Click or Scan
Selectyourpreferredtorquemode(shipsinstandardtorque)Pressthedevicepushpadtothe
desiredsetting.(Recommendtofullydepressandrelease5%,givingthedeviceroomforchangingdoor
conditions.)
Step 2- Whiledepressingthepushpad,applypower.(i.e.presentingthecredentialtothereader).
Step 3- Continuetokeeppaddepressed,thedevicewillbeep6times.Afterthebeepshavestopped,releasethepad
and now the adjustment is complete. If not to your liking repeat the 3 steps.
Step 4- Once you found the correct location, turn PTS switch to OFF position.
Setting PTS
**Important Info**
Make sure to set PTS before finishing installation
Technical Information
SPECIFICATIONS
USCUSTOMERSUPPORT1-888-622-2377|WWW.COMMANDACCESS.COM|CACUSTOMERSUPPORT1-855-823-3002
Step 1-
Troubleshooting & Diagnostics
2 Beeps
3 Beeps
5 Beeps
6 Beeps
6 Beeps
Beeps Explanation Solution
Over Voltage
Under Voltage
Retractionordoggingfailure
PUSH TO SET
PUSH TO SET
> 28V unit will shut down. Check voltage & adjust to 24 V.
< 22V unit will shut down. Check voltage & adjust to 24 V.
Device will automatically re-engage within 5 seconds.
Check to make sure the push pad is not stuck or catching on anything.
Ifmechanicalobstruction,remove&pushpaddownuntilbeepingstopstoreset.
Ifnoobstruction,thepadmayhavebeenpushedintoofarduringPTScalibration.
Recalibratewiththepadslightlyout.Ifproblempersists,verifythemagnetiswithin
1/4” of the sensor at the end of travel.
4 Beeps Failed Sensor Verifyall3sensorwiresareinstalledcorrectly.Replacesensorifproblempersists
by contacting CAT tech support.
Average Latch Retraction Current: 2 Amp
Average Holding Current: 250 mA
High Torque Mode
Average Latch Retraction Current: 1.3 amp
Average Holding Current: 215 mA
Standard Torque Mode
mm4 switches
on
on
off STANDARDTORQUE
High TORQUE
PTS Programing Lock
PTS PROGRAMING On
off
• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Direct wire run - no relays or
access control units in-between
power supply & module
1
2

Ceiling Tile
Legend
Standard Placement
Optional Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT
Recommended Power Supplies:
AllCommandAccessexitdevices&fieldinstallablekitshavebeenthoroughly
cycle tested with Command Access power supplies at our factory.
For more information, visit our website
Electrified Exit Device
Installation Example
USCUSTOMERSUPPORT1-888-622-2377|WWW.COMMANDACCESS.COM|CACUSTOMERSUPPORT1-855-823-3002

2
4
1
2
Note: For AHT4/5 & PD11’s purchased after 2015 only.
Installation Instructions
Remove HEAD COVER
1.
SLIDE PUSH PAD OFF DEVICE
3.
REMOVEBOTHSCREWSATTACHINGHEADASSEMBLYTOHOUSING
5.
REMOVEFRONTANDBACKENDCAPS
2.
REMOVEBASERAILASSEMBLYFIRSTBYREMOVING
4 SCREWS
4.
REMOVEDOGGINGASSEMBLYANDBACKACTIVATING
BRACKET SCREWS.
6.
USCUSTOMERSUPPORT1-888-622-2377|WWW.COMMANDACCESS.COM|CACUSTOMERSUPPORT1-855-823-3002

RemovepinfromconnectingrodforRIM.ForCVRskip
this step. CVR-Removeconnectingrodassemblybypulling
away from device housing.
RemoveASSEMBLYFROMBASERAILANDREMOVETOP
ROLLER PINS
7.
9.
REMOVEDOGGING ASSEMBLYFROMBASERAIL
8.
10.
Installation Instructions
11. Confirmwhichbackactivatingbracketyouhaveandfollowbelowguide.
• Cut down • Good!
3/4
Cut
USCUSTOMERSUPPORT1-888-622-2377|WWW.COMMANDACCESS.COM|CACUSTOMERSUPPORT1-855-823-3002

Removebottompinfrombackactivating
bracket. Removebackactivatingbracketfromconnectingrod.
REMOVEBACKBUMPERANDADDTOFRONTBUMPER
Installation Instructions
12.
14.
16.
13.
15.
17.
RE-INSERTPININTOBRACKETANDTHROUGHBOTHBUMPERS
ONCEYOURBRACKETSAREPUTBACKINLINE,IT’STIMETOLINEUP
YOURPD10-UL-MKIT.SLIDEKITINTOREAROFBAR. HOOKACTIVATINGARMOVERBOTTOMPINOFBACKACTIVATING BRACKET
INSTALLING THE KIT
USCUSTOMERSUPPORT1-888-622-2377|WWW.COMMANDACCESS.COM|CACUSTOMERSUPPORT1-855-823-3002

PULLKITBACK/LINEUPDOGGINGHOLESONBACKOF
DEVICE WITH MOUNTNG HOLES.
18.
20.
22.
19.
23.
Installation Instructions
INSTALLMOUNTINGSCREWS.TESTMECHANICALLY
MAKESUREFLAPISUPONACTIVATINGBRACKETIFRIGGING
OR BINDING REASSEMBLING THE DEVICE
RE-INSERT TOP PINS AND PUSH PAD
SLIDEPUSHPADONMAKINGSURETHATTHESIDESFITINTOTHE
CORRECT GROOVES
USCUSTOMERSUPPORT1-888-622-2377|WWW.COMMANDACCESS.COM|CACUSTOMERSUPPORT1-855-823-3002

24. 25.
Installation Instructions
RE-INSTALL END CAPS Connecttopower&SetthePushToSetbyFollowingthe
steps below.
USCUSTOMERSUPPORT1-888-622-2377|WWW.COMMANDACCESS.COM|CACUSTOMERSUPPORT1-855-823-3002
Selectyourpreferredtorquemode(shipsinstandardtorque)Pressthedevicepushpadtothe
desiredsetting.(Recommendtofullydepressandrelease5%,givingthedeviceroomforchangingdoor
conditions.)
Step 2- Whiledepressingthepushpad,applypower.(i.e.presentingthecredentialtothereader).
Step 3- Continuetokeeppaddepressed,thedevicewillbeep6times.Afterthebeepshavestopped,releasethepad
and now the adjustment is complete. If not to your liking repeat the 3 steps.
Step 4- Once you found the correct location, turn PTS switch to OFF position.
Setting PTS
**Important Info**
Make sure to set PTS before finishing installation
Step 1-
mm4 switches
on
on
off STANDARDTORQUE
High TORQUE
PTS Programing Lock
PTS PROGRAMING On
off
