Commando AirONE AP750 User manual

COMMANDO AirONE AP750 Indoor Wireless Access Points
Configuration Guide

OVERVIEW
COMMANDO AirONE AP750 is Indoor AP which enables communication between
wireless and wired computers/laptops and mobile devices in the network. It complies IEEE
802.11ac/b/g/n standard and comes with dual band 2.4GHz+5GHz with Separate
10/100Mbps WAN and LAN ports with Dual power input facility with either IEEE 802.3at
PoE+ input or DC IN 12V, 1.5A.
Fig 1. Physical port on AirONE AP750
Table 1. Physical port on AirONE AP750 Description.
Physical Port Description
Reset Reset Button, makes AP revert to default
settings after pressing for 15sec.
WAN/PoE WAN Port, connect with PoE+ Switch or
internet gateway.
LAN LAN Port to end users Switch or PC for
Accessing device via WEBGUI.
LED Upper LED for WAN port and Lower LED for LAN port ( Green and Blinking to show
ACT/Link connection).
DC DC input power 12V, 1.5 A.

Fig 2. Access information on AirONE AP750
Table 2. COMMANDO AirONE AP750 LED indication
LED Indicator LED Status
Power Red Blinking: Power ON Indication Green and Blinking: Wi-Fi indication that
SSID now available for use.
WAN Upper LED WAN: Connect with Gateway or PoE devices and Green Blinking show
activity on WAN port.
LAN Lower LED LAN:Connect to end users
and Green ON shows activity on LAN port.
It is 4 in 1 mode Access Point with Gateway, Repeater, WISP and AP mode (Default
Mode) with range up to 91 meters (300feets) and above in all directions with up to 300mW
input Power. It is industrial grade Wall/Ceiling Indoor Access Point with speed up to
300Mbps. It equipped with separate Gigabit WAN & LAN port which enhances the sharing
of files, photo, audio, video and gaming experience over wireless network. It can also be
used as DHCP server and works as layer 3 device when configured in gateway mode. It
supports (IEEE 802.3at) PoE+, which helps in easy installation by eliminating the need of a
dedicated power source and need of a power adapter. It can identify and determine the
correct transmission speed and half/full duplex mode of the attached devices. It also
supports standard Auto-MDI/MDI-X that can detect the type of connection to any Ethernet
device without requiring special straight or crossover cables, Store-and-Forward
forwarding scheme to ensure low latency and high data integrity.
You can access and manage AirONE AP750 using the Web based GUI (Graphical User
Interface) , also called WEB-GUI interface.

INTRODUCTION
COMMANDO AirONE AP750 Indoor AP are WEB GUI based easy to use and manage
device. It requires minimal configuration, so setup is simple and hassle-free. Auto-
negotiation senses the link speed of a network device in wired 10 or 100Mbps and also for
wireless clients. It intelligently adjusts for compatibility and optimal performance by DFS
and setting channel bandwidth 20/40MHz wireless band and also can check free channels
available with inbuilt Wi-Fi analysis. Its compact size makes it ideal for Indoor
desktops/wall/ceiling with limited space. Dynamic LED lights provide real-time work status
display and basic fault diagnosis. Easy Plug-and-play installation with no configuration
required. It operates quietly, making it ideal for use in virtually any room or office. Perfect
for noise sensitive environments. It has Dual power options with DC input power and PoE
power input which protect from power failures and increases life of device. With Inbuilt
security features protect your business by losing network sensitive information and data of
wireless users/surveillance cameras connected to them.
It supports energy-efficient Ethernet that can save power. It automatically adjusts power
consumption according to the link status to limit the carbon footprint of your network. It also
complies with RoHS, CE, FC prohibiting the use of certain hazardous materials. Besides
that most of the packaging material can be recycled and reused.
It has State of art quality product that can serve on real time high-speed Performance with
dual input power, cost effective, highly reliable, conformance to international open
standards, durable, serviceable, aesthetics, perceived quality, enhanced performance
leads to value to money.
Hardware Highlights
Solid performance with non-blocking architecture
• Up to 16 MB Flash, 128MB RAM
• LAN and WAN ports capable of Fast Ethernet speed with (Auto-Negotiation/Auto
MDI/MDIX).
• Solid performance with non-blocking architecture.
Physical Ports and Networking Interfaces
• Up to 2 x 10/100 Mbps Rj45 Ethernet Ports with combined IEEE 802.3at PoE+ with WAN
and separate LAN port
• LED Indicators: Power, LAN/WAN (Link/Act)
• Reset Button
Extra Long operational life
• Dual input Power Either DC 12V/1.5A or IEEE 802.3at PoE+ via WAN port.

• High Quality PCB Circuit Board and PCB Surface Treatment Using Gold Sinking Process.
• Support temperature range 0° C to 50° C
• Desktop and Wall mount design that enables to mounts Which enables horizontal and
vertical wall mounting.
• Comes with one-year default warranty – optionally extendable up to 3 years.
Noise-free Operation
• The ports support reduced power modes for silent operation. Perfect for noise
sensitive environments.
Software Highlights
• Multiple Operational Modes like Gateway, Repeater, WISP and AP mode (Default mode).
• Multiple SSID with Up to 8 SSIDs with VAP.
• Supports IEEE 802.11ac/b/g/n 2.4GHz and 5GHz with Antenna RF input Power of
27dBm.
• Support wireless RF power adjustable as per user movements from AP.
• Access end users up to 128 max, with concurrent 90 end users.
• Support MAC ACL, DHCP Server, Static DHCP, URL Mapping, URL/IP/MAC Filter, DMZ,
Time reboot, Flow Control and DDNS.
• Support tag VLAN and VLAN management.
• Supports intelligent load balance based on users.
• Support seamless roaming and low rate terminal access.
• Support inbuilt WI-FI channel analysis.
• Internal Antenna enabling maximum client density deployments with no interference.
• Supports Wi-Fi client distance 91 meters (300 feet) and above in all directions depending
on surrounding conditions.
• Support Open or encryption like WPA/WPA2PSK_TKIPAES.
How to take access of COMMANDO AirONE AP750?
1.Wired access Via LAN port connected to PC.
Power ON AirONE AP750.
Connect LAN port of AirONE AP750 to PC via RJ-45 cable.
Open Network and sharing center.
Go to Change adapter settings.
Double click on Local Area Connection. Go to Properties. Double click on Internet Protocol
Version 4 (TCP/IPv4) option and set any IP address from 192.168.188.1 to 252 and
Gateway of PC to be set as 192.168.188.253 to as shown below.

Fig 3. IP setting in PC connected to AirONE AP750
2. Wireless access Via SSID connected to PC.
Power ON AirONE AP750.
Connect Default SSID named “COMMANDO AIR-AP750 2.4G” or “COMMANDO AIR-

AP750 5.8G” with the help of default Wi-Fi Password “commando” or “66666666”.
Click on properties of connected SSID “COMMANDO AIR-AP750 2.4G” or “COMMANDO
AIR-AP750 5.8G”.
Edit IP setting from DHCP to Manual and set any IP address from 192.168.188.1 to 252
and Gateway of PC to be set as 192.168.188.253 to as shown below.
Note:
All Default SSID and password can be changed as per user requirement.

Fig 4. Default SSID of AirONE AP750
Fig 5. Properties of SSID COMMANDO AIR-AP750 2.4G

Fig 6. Edit IP setting from DHCP to Manual as shown for COMMANDO AIR-AP750
2.4G
Open any web browser like Chrome/Firefox/Internet Explorer/Opera etc. and enter default
IP address 192.168.188.253 in address field.
Caution:
If you have already taken any Other COMMANDO wireless device access. Then before
taking access of this device, you are required to clean the browser history to avoid catch
pages issue.

Fig 7. Login page for AirONE AP750
Default Password: admin
Note:
Password can be changed as per user choice. Default password is written on backside of
device.
After giving proper password Home page is displayed giving device information like CPU
usage, memory usage, LAN Information like IP Mode Get IP From AC/Gateway/Static,
Status with 2G Wi-Fi Clients Status with information like SSID, Channel, Bandwidth,
Encrypt, MAC Address, Operation Mode configure like AP/ Fat AP Mode with Uptime, Flow
in bps for AP downstream and AP Upstream

Fig 8. Home page after login AirONE AP750

HOME
After login, home page will be showed. This page will show device Information like CPU
Usage, Memory Usage, LAN/WAN Information like IP Mode Get IP From
AC/Gateway/Static, Status with 2G/5G Wi-Fi Clients Status with information like SSID,
Channel, Bandwidth, Encrypt, MAC Address, Operation Mode configure like AP/ Fat AP
Mode with Uptime, Flow in bps for AP downstream and AP Up stream. All information can
help to troubleshoot network issue, if any very easily.
Fig 1.1 Home page Components of AirONE AP750
1.1 Device Information
In Device Information, Current CPU Usage percentage and Memory Usage percentage of
the AP is shown.

Fig 1.1.1 Home page Components of AirONE AP750

Fig 1.1.2 Device Description of AirONE AP750
In Device Description you can add the APs description by clicking on Click Settings

Fig 1.1.3 Changing Device Description of AirONE AP750
Fig 1.1.4 New Device Description of AirONE AP750
1.2 LAN/WAN Information
In LAN Information you can find the IP Mode, LAN IP, Subnet, Gateway and MAC
Address. In WAN Information like WAN IP address, Gateway, DNS and MAC Address.

Fig 1.2.1 LAN/WAN information of AirONE AP750
1.3 Wi-Fi Information
In Wi-Fi Information, Status along with number of clients connected to AP, SSID, Channel
used, Encryption and MAC Address of AP is shown.
Fig 1.3.1 Wi-Fi Information of 2G Wi-Fi AirONE AP750

Fig 1.3.2 Wi-Fi Information of 5G Wi-Fi AirONE AP750
1.4 Clients List
Clients list along with number of clients connected to AP, MAC address of clients
connected, Signal strength of clients’ connection along with connection time is shown. We
can learn about users in network with all vital information.

Fig 1.4.1 Clients list of 2G Wi-Fi AirONE AP750
Fig 1.4.2 Clients list of 5G Wi-Fi AirONE AP750
1.5 Operation Mode configuration

Default operation is Fat AP where it integrates the WLAN physical layer functions, service
data encryption, user authentication, QoS, network management, roaming technologies,
and application layer functions. It can provide wireless access independently. Each AP is
an independent node. The channels and power on each AP are configured independently.
All APs work independently and support advanced and independent security policy.
A Fit AP has only select IP mode along with reset and reboot options.
Fig 1.5.1 Fat AP mode of AirONE AP750
