Commodity Axis Poly-Reactor ViaAqua PR 20/20 Installation and operation manual

PR 20/20
WARNING
Buyer/User assumes all responsability for safety and proper
use not in accordance with the directions and sately labels.
• Equippedreadytouse
• Variableowwaterpump
• Intakeandoutputtubing
• Easytwistofftopwithrecessed
o-ring
• Usein-sumporhangontank
• Sedimentdischargelter
• Upowltration

FEATURES
ViaAqua® Poly ReactorTM is built with high quality acrylic and an easy to remove lid
with a recessed o-ring. The reverse water ow design eliminates water channeling
through the lter media thus efciently utilizing ltering media. ViaAqua® Poly
ReactorTM comes complete and ready to run with a pump and all plumbing parts.
ViaAqua® Poly ReactorTM is designed to be installed either in-sump or hang on the
tank.
WARNING AND SAFEGUARD
WARNING
»This product may contain chemicals known to the State of California to
cause cancer and/or birth defects or other reproductive harm. Wash you
hand after handling the product.
»It is your sole responsability to verify that the plug and receptacle are
clean/free of moisture and salt build up at all times. The receptacle must
be free of water, salt, calcium, and magnesium. Failure to do so may cause
re and/or loss of life.
»Do not plug into an extension cord or power strip.
»A drip loop must be used when plug into any electrical devices. A drip
loop is part of the cord hanging below the receptacle.
»The national code requires all aquarium equipment to be plugged into
a G.F.C.I. (Ground Fault Circuit Interrupter) electrical outlet. If you do
not have a G.F.C.I., have an electrician install one prior to operating any
aquarium components.
• Read and follow all instructions before using the ViaAqua® Poly ReactorTM to
ensure proper use and application.
• Use this product for its intended use only.
• Do not operate ViaAqua® Poly ReactorTM without
water. Doing so can cause permanent damage to the
pump.
• You must verify that the receptacle is clean and
free of water, moisture, and salt build up at all
times. Failure to do so may cause electrical arching
resulting in re or electrical shock.
• Prior to maintenance on any electrical aquarium
appliance or aquarium, you must disconnect all
Drip loop
1

APPLICATION
ViaAqua® Poly ReactorTM is used for a number of
different applications: phosphate resins, phosphate
sponge, activated carbon, nitrate sponge and other
resin ltering medias. When the ViaAqua® Poly
ReactorTM is used with activated carbon, a higher ow
pump can be used.
PART LIST
1. Reaction chamber
2. Down tube
3. Intake tube
4. Sediment discharge lter
5. Barbed tting
6. Lock nut
7. Lid
8. O-ring
9. Media sponge
10. Media strainer
11. Hanger
12. Suction cup bracket
13. Control valve
14. Pump
15. Tubing
electrical aquarium devices.
• Routine maintenance is required to ensure the maximum
performance and the longevity of the ViaAqua® Poly
ReactorTM. See maintenance guidelines.
• The use of a surge suppressor is strongly recommended.
Drip
Loop
GFCI
ONLY
2

INSTALLATION
1. Choose a desired location for the ViaAqua® Poly ReactorTM.
2. Connect the intake tube to the middle barbed tting of the ViaAqua® Poly
ReactorTM. Secure the tube to the lock nut.
3. Connect a small piece of tubing from the bottom of the intake tube to the water
pump.
4. Connect the output tube to the output barbed tting of the ViaAqua® Poly
ReactorTM. Secure the tube to the lock nut.
5. Connect the sediment discharge lter to the end of the output tubing.
6. Remove the lid by twisting counter clockwise.
7. Add desired media to the reaction chamber: phosphate resin, activated carbon,
and other resin ltering medias. Follow manufacture guidelines for media
requirements for a given aquarium size, ow rates and precautions.
8. Place media sponges and media strainers below and above desired media.
9. Place the lid back by twisting clockwise.
10. Plug the water pump into a GFCI (Ground Fault Circuit Interrupter) outlet.
SETUP DIAGRAM
A) HANG ON TANK
Media
(not included)
Pump
Intake tube
Output tube
Aquarium
3

MAINTENANCE
1. Routine maintenance is required to ensure the maximum performance and the
longevity of the ViaAqua®water pump.
2. For proper operation of the water pump: clean the pump, impeller and intake
strainers every three weeks. Failure to do so will cause premature failure of the
pump.
3. Basic maintenance of the ViaAqua® pump:
a) Disconnect the water pump from the power supply prior removing the pump
from the aquarium.
b) Remove either the prelter or intake lter strainer. Rinse out prelter sponge of
all debris.
c) Remove the impeller cover.
d) Once the impeller cover is removed, slide both the impeller and shaft out of
the main body of the pump and clean well. Do not use any soap or detergents
during cleaning.
e) After the impeller and shaft are cleaned, use a small brush to clean inside of the
motor housing .
f) Reassemble above parts and your ViaAqua® pump is ready to use. Make sure
the bushing is reassembled properly. Failure to do so will cause permanent
damage to the pump.
Sump
Pump
Intake tube
Output tube
Media
(not included)
B) SUMP
4

Replacement Parts Part list no. UPC# 0069037
VA-230 pump 14 2929 1
O-ring for the lid 8 2930 7
Control valve 13 2931 4
Media sponges - 2 pk 9 2922 2
1. Reaction chamber
2. Down tube
3. Intake tube
4. Sediment discharge lter
5. Barbed tting (2)
6. Lock nut (2)
7. Lid
8. O-ring
9. Media sponge (2)
10. Media strainer (2)
11. Hanger
12. Suction cup bracket
13. Control valve
14. Pump
15. Tubing
5
PART LIST:

LIMITED WARRANTY
Commodity Axis, Inc.®warrants that the ViaAqua® Poly ReactorTM is free from
defects for a period of one year from the initial date of purchase shown on the original
cash register receipt. Commodity Axis, Inc.® disclaim all other warranties, express or
implied, including but not limited to any implied warranties of merchantability and/
or tness for a particular purpose. Although this limited warranty gives you specic
rights, you may have other rights which vary from state to state. This warranty is
void if the failure is due to misuse, tampering, negligence, abuse, accident and/or
submersion, a failure to properly install, maintain, clean, prelter, reassemble, and/
or use the ViaAqua® Poly ReactorTM with a Ground Fault Circuit Interrupter (GFCI).
CONSUMER REMEDIES
Commodity Axis, Inc.’s entire liability and your sole and exclusive remedy shall
be either repair or replacement of the ViaAqua®Poly ReactorTM only if you return
the defective unit directly to Commodity Axis, Inc.®with the original receipt in its
original box along with fteen dollars ($15.00) for shipping and handling. Do not
send the ViaAqua®Poly ReactorTM by insured mail. You may send your returns or
replacements by UPS if requiring a signature upon arrival. Any replaced unit will be
warranted for the remaining time of the original warranty period. In no event shall
any shipping charges be reimbursed. In no event will Commodity Axis, Inc.®be liable
for any consequential or incidental damages, including but not limited to lost sea life,
personal injury, property damage, equipment damage, lost prots, lost wages, lost
savings, lost income, etc., arising out of the use of the ViaAqua®Poly ReactorTM.
Some states do not allow for the limitation or exclusion of liability for incidental or
consequential damages, so the above exclusion may not apply to you.
6

Name Date
Address
City State Zip Code
Country Home Phone
Cell Phone Email
Date of Purchase Seller (Retail Name)
Seller’s Location Phone
*Afx a copy of your original purchase receipt here.Please mail warranty card and proof of
purchase within 15 days of purchase to:
Commodity Axis® Inc., 300 South Lewis Rd. Unit J. Camarillo CA 93012
IMPORTANT: Please make a copy of this warranty card and retain it for your records. Warranty
policy is subject to change without notice.
