COMPANION 10000053 User manual

AEROHEAT
LiTHIUM
TENT HEATER
OWNERS MANUAL
Part No. 10000053

2
IMPORTANT
This appliance is designed to be used with an ambient
air temperature of 15˚C or below.
The maximum outlet temperature from the appliance is
60˚C.
For safety the appliance is designed to shut off the
burner when the outlet air temperature exceeds 60˚C
+/- 2˚C (average).
The average run time for the appliance from a fully
charged battery is 3.5-4.5 hours before it will require
recharging.
The appliance can be operated whilst connected to AC or
DC. The battery will accept charge if it is less than 12V
whilst operating.
GENERAL WARNINGS
This appliance shall only be used with the regulator
supplied with the appliance. This appliance shall only be
used with a ULPG rellable cylinder certied to Standard
AS 2469 that has a 3/8” LH BSP inlet tting, or a non-
rellable 468g disposable Propane cartridge certied to
DOT-39, UN1075.
IT MAY BE HAZARDOUS TO ATTEMPT TO FIT OTHER
TYPES OF GAS CONTAINERS.
This appliance is to be stored in a dry and well ventilated
location free from direct sunlight. Do not store when still
connected to the cylinder. Make sure that the cylinder is
disconnected and is stored in a well ventilated area, free
from direct sunlight, heat and ignition sources. If being
stored indoors ensure that the location complies with the
standard AS/NZS1596.
This appliance must only be serviced by an authorised
service agent, return to your place of purchase for
service and repair or contact Customer Service
1300 362 921.
Ensure any transit protection is removed before the
appliance is used.
When using Rellable Gas Cylinder:
If there is a leak on your appliance (smell of gas),
immediately attempt to turn off the cylinder valve.
Remove the appliance to a well ventilated location away
from any ignition source. Check for leaks using soapy
water. Do not try to detect leaks using a ame.
When using Disposable Cartridge:
If there is a leak from your appliance (smell of gas) and
you cannot stop the gas ow, remove the appliance to a
well-ventilated location away from any ignition source.
Check for leaks using soapy water. Do not try to detect
leaks using a ame.
IMPORTANT: Read these instructions for use carefully. Familiarise yourself with the appliance before
connecting it to its gas container. Keep these instructions for future reference.
This appliance is intended for the supply of heated air for the purpose of heating only. Check and
confirm safe air temperature before using this appliance. Air from this appliance may be very hot.

3
AEROHEAT SHOWER OWNERS MANUAL
ONLY USE IN WELL-VENTILATED AREAS
CARBON MONOXIDE HAZARD
USING THIS APPLIANCE IN AN ENCLOSED SPACE MAY CAUSE DEATH.
DO NOT USE IN CARAVANS, TENTS, MARINE CRAFT, CARS, MOBILE HOMES
OR SIMILAR LOCATIONS.
WARNING! USE OUTDOORS ONLY. INDOOR USE MAY CAUSE DEATH!
CAUTION: Accessible parts may be very hot. Keep young children away.
SAFETY INFORMATION
This appliance is designed for outdoor use only.
Do not use the appliance if it is leaking, damaged or
does not operate properly.
Handle with care even after brief use, always pick up
using the handle.
It may be hazardous to attempt to t other types of gas
containers or cartridges.
Use only in well ventilated areas.
This appliance shall only be used in an above ground
open air situation with natural ventilation, without
stagnant areas, where gas leakage and products of
combustion are rapidly dispersed by wind and natural
convection.
DO NOT MODIFY THIS APPLIANCE.
Do not use adaptors. Do not modify appliance to t other
connectors or cylinders.
When using this appliance children must be supervised
by an adult at all times.
Never leave appliance unattended when operating.
Do not use as a cooking appliance or modify for any
other reason.
The appliance must be used outdoors only and is to be
operated no closer than 800 mm from the sides and
800 mm from above all combustible surfaces, fabrics
and ammable materials. Must only be used on solid and
stable horizontal surfaces made from non-combustible
or non-ammable materials and should be protected
from direct drafts and in a well ventilated place. The
appliance must be protected from rain & wind
If you smell gas immediately turn the gas off and move
the appliance and cartridge to a well ventilated area
outside, keeping well away from sources of heat such as
naked ames and pilot lights.
Do not attempt to move or relocate the appliance when
it is operating. Extinguish the burner and allow to cool,
disengage the gas cartridge or gas hose then move the
appliance.
Maximum Hose Length: 1500mm

4
CHECKING FOR GAS LEAKS
Check that all connections are tight and that the gas
connection has been leak tested before you turn the
appliance on.
Never check for leaks with a ame or pilot light.
Using soapy water coat all connections, if bubbles
appear retighten the cartridge before re-testing.
This appliance must only be serviced by an authorised
person.
Inspect the appliance regularly for signs of wear, leaks
or incorrect operation. If symptoms such as aring of
the burners, issues with lighting, damages connections
or leaks from seals or gas controls are identied do not
attempt to repair, contact Customer Service on
1300 362 921.
To check if gas remains in the cartridge, disconnect
from the appliance and hold the cartridge in a vertical
position then shake from side to side. If there is a sound
or a feel of liquid movement inside the cartridge, the
cartridge contains gas.
When changing gas cartridge ensure this is conducted
outside in a well ventilated location free from people,
animals and ignition sources such as naked ames, pilot
lights and electrical equipment with heaters or elements.
Check the seals are in place & gas hose is tight before
checking for leaks (if using gas hose to cylinder).
Check that the seals between the appliance and the
gas cartridge are in place and in good condition before
connecting the gas container.
Do not use the appliance if it has damaged or worn
seals.
Do not use this appliance if it is leaking, damaged or
does not operate properly.
IMPORTANT
This appliance is designed to be used with an ambient
air temperature of 15˚C or below, if the temperature of
the outlet air exceeds 60˚C +/- 2˚C the burners will shut
off and will only relight once the unit temp drops below
60 degrees & the unit is manually re-lit.
This appliance is designed to raise the outlet air
temperature by a maximum (average) of 25˚C to 30˚C
above the ambient air temperature and can be adjusted
by the fan speed. During operation ensure that all air
inlets and exhausts are kept free from obstructions,
closure and blockage.
SAFETY FEATURES
This appliance is equipped with the following safety
features:
Over temperature sensor
The appliance will not allow the burner to remain in
operation once the outlet air temperature reaches 60˚C
+/- 2˚C.
Outlet Hose Adaptor Microswitch
The outlet hose adaptor & hose must be attached to the
heater correctly to activate the safety microswitch.
Tilt switch
In the event that the appliance is moved during operation or
is being operated on an unstable or non-solid surface the
appliance will shut down and must be switched off until a
suitable surface is located.
O2 Sensor info
The Oxygen depletion sensor is tted to prevent the use of
the product in an indoor environment - the sensor will turn
the unit off if it senses a low oxygen level.

5
AEROHEAT SHOWER OWNERS MANUAL
Fuse protection
Fuses are located in the cigarette lighter tting of the DC
lead & power inlet socket of the appliance.
Replacement fuse
5A 250V (5 mm x 20 mm)
SAFE LOCATIONS
This appliance shall only be used in an above ground
open air situation with natural ventilation, without
stagnant areas, where gas leakage and products of
combustion are rapidly dispersed by wind and natural
convection.
Any enclosure in which the appliance is used shall
comply with one of the following:
An enclosure with walls on all sides, but with no
overhead cover (see example 1).
Within a partial enclosure that includes an overhead
cover and no more than two walls (see examples 2 & 3)
Within a partial enclosure that includes an overhead
cover and more than two walls, the following shall apply:
at least 25% of the total wall area is completely open.
30% or more in total of the remaining wall side, back
and front wall areas is open and unrestricted
(see examples 4 & 5).
In the case of balconies, 20% or more of the total wall
area shall remain open and unrestricted.
DIAGRAMMATIC REPRESENTATION OF OUTDOOR AREAS
The following examples are diagrammatic
representations of outdoor areas. Rectangular areas
have been used in these examples - the same principles
apply to any other shaped area.
Example 1
Example 2
Example 3
Example 4
Example 5
Both ends open
Open side at least 25% of total wall area.
30% or more in total of the remaining wall area is open and unrestricted.
Open side at least 25% of total wall area.
30% or more in total of the remaining wall area is open and unrestricted.

6
UNDERSTANDING YOUR APPLIANCE
IMPORTANT: During operation ensure that all air inlets and exhausts are kept free from obstructions
and closure.
CARRY HANDLE
VENTING
RUBBER FEET
AIR OUTLET BUILT IN GAS REGULATOR
BATTERY CHARGE
INLET SOCKET

7
AEROHEAT SHOWER OWNERS MANUAL
SETTING UP
Step 1. Remove all components from the storage bag
and place the appliance on a solid, non-combustible
surface and straighten out all hoses to remove any kinks
or twists.
Step 2a. Screw the gas cartridge (clockwise direction)
onto the gas regulator and tighten securely. Check for
leaks with soapy water.
Step 2b. Screw the gas hose (clockwise direction) onto
the gas regulator securely. Check for leaks with soapy
water.
Step 3. Connect the air outlet tting & air outlet hose to
the front of the unit ensuring it locks into place properly
- There are 3 retaining notches that can only line up
one way
- Line them up and rotate about 10mm to locate

8
OPERATING THE HEATER
Step 1. Press the power button and the unit will
switch on.
Step 2. Check the battery charge level to see if
sufcient power is available, if not connect to the AC or
DC adaptor. Refer to page 11 for Appliance Power and
Charging.
Step 3. Setup the appliance in a suitable outdoor
location & press the POWER button to turn unit on.
Step 4. Press the FAN button once to turn the fan on.
Press the FAN button a second time to get the heater to
ignite.
Step 5. Adjust the fan speed by pressing the + or -
buttons on the display
NOTE - Increased fan speed will move the air further but
slightly decrease the air temp exiting the heater outlet
Step 6. To turn the heating off but leave the fan on press
the FAN button once. To completely turn the unit off
press the POWER button once.
WHEN USING REFILLABLE GAS CYLINDER:
After use, turn the gas cylinder valve off, wait for the
ame to go out, then turn the appliance off.
OPERATING THE HEATER VIA BLUETOOTH
APP
Step 1. Download the Aeroheat
Bluetooth APP via APPSTORE or
GOOGLE PLAYSTORE
Step 2. Turn unit power on &
ensure you are within bluetooth
operating range
Step 3. Pair device via smart
device & ensure connection is
made
Step 4. Open the previously downloaded AEROHEAT APP
Step 5. Start using the AEROHEAT via the APP
NOTE - The AEROHEAT can only be connected to one
device at a time
The APP will only connect when the tentheater is
powered on already

9
AEROHEAT SHOWER OWNERS MANUAL
The APP can only adjust the fan speed & turn the unit off
- it cannot turn it back on that must be done manually
The APP cannot be used to override any errors - they
must be investigated at the main unit
Main Interface
This is the only UI of this app.
It shows the Bluetooth
connection status, battery
status, fan status and heating
status.
The picture shows when the app
loads and automatically searches
for the device for connectivity
Automatic Connection
It takes seconds to nish the automatic connection to
the heater.
The rst-time connection is automatic pairing to the
closest device. The device can be changed
Change Device
If the connected device is not your heater, please press
the Bluetooth icon to search the available device nearby.
It will pop out the list of device that can be connected.
Connected
This is the screen connected,
with no operation.
Fan Control
Hit the FAN ON button to turn on
the fan, and drag the colored dot
to adjust the fan speed.
Hit the FAN ON button again
to turn off the fan, the fan cannot
be deactivated when HEAT ON is
activated.
Heating Conrm
When hitting the HEAT ON
button, it will pop out
conrmation box to check if it is
false operation.
HEAT ON BUTTON can only be
activated when FAN
ON is activated
Heating Control
This is the heating screen. When
the HEAT ON button is activated,
the ame icon turns red.
Deactivate the HEAT ON, the fan
will still be working.
Turn Off
Touch the TURN OFF button, it pops out the conrmation
box to double check whether it is false operation.
When the heater is turned off from heating, the fan
will work for another 90 seconds for cooling down the
system.

10
STORING THE APPLIANCE
Step 1. Press the power button and turn the
appliance off.
Step 2. Disconnect outlet hose & tting and store in a
safe place.
Step 3. Unscrew and remove gas cartridge or gas hose
from the appliance.
Step 5. Store unit in a safe dry place.

11
AEROHEAT SHOWER OWNERS MANUAL
APPLIANCE POWER AND CHARGING
The charging system is designed so it will allow the
battery to be recharged whilst the unit is in operation.
The recharge times will increase by 50% if the unit is
operating whilst it is being charged..
Step 1. The appliance is tted with a 12V battery
pack and can be recharged from the DC charge lead
included (or the AC adaptor sold separately part number
COMP825-10s)
Step 2. To recharge the appliance from either an AC or
DC power source, the unit must be switched on and the
battery charge level must be illuminated.
Step 3. Connect to the DC input socket (red) at the rear
of the appliance and the battery charge level will start
to ash and move from red to green conrming that the
battery is now charging.
Note: When the battery is fully charged, the red,
orange and green battery levels will stop ashing
and remain illuminated.
Step 4. AC: Connect the three (3) pin plug to a suitable
outlet then connect to the appliance and switch on the
AC outlet. (Adaptor sold seperately)
Step 5. DC: Connect the adaptor to the appliance and
then connect to a suitable outlet via the cigarette lighter
tting.
*AC Adaptor sold seperately
P/N: COMP825-10S

12
Important:
Do not use AC to DC converters or modify the adaptors
supplied with the appliance.
If the appliance is not being used or is stored
it must be recharged every three months to guarantee
the battery life expectancy, failure to do so may result in
battery failure.
Charge time to recharge the battery from either power
source can be reached in:
25% - 1 hour
50% - 2 hours
100% - 4 to 5 hours
To maintain battery life and condition it is recommended
that the unit is allowed to be charged to 100%
CARE INSTRUCTIONS
Using warm soapy water with a mild detergent wipe
down all surfaces and areas of the appliance, taking care
not to allow water to enter the burner outlets.
Do not submerge the appliance in a sink or bowl.
Do not use abrasive cleaners or bleach.
SPECIFICATIONS
Part no. 10000053
Model no. Aeroheat Tentheater
Ignition Automatic
Inlet voltage 12V DC - 5A
Gas type Propane
468g BOM cartridge (not included)
Gas consumption 2.2 Mj/h / 43.7 g/h
Injector size 0.4 mm
Max. temperature 60°C
DC power cord length 2 m
Outlet hose length 1 m (Fully Extended)
Dimensions 442L x 163W x 380H mm
Weight 8kg (including accessories)
Certification AGA 8863 G
AUSTRALIA AND NEW ZEALAND
GAS SAFETY CERTIFICATION
®

13
AEROHEAT SHOWER OWNERS MANUAL
TROUBLESHOOTING
This guide should be followed in case of failure of the
appliance to operate correctly.
If symptoms persist contact Customer Service on
1300 362 921.
Do not attempt to repair or modify the appliance.
ABNORMAL OPERATION
Unit will not operate
Check that appliance is switched on
Check thre outlet hose & tting are
correctly connected to the appliance
Check that fuse is not blown
Check that adequate DC power is available
Check DC fuse in cigarette lighter tting
Unit will not switch on
- display will not
illuminate
Check DC fuse in cigarette lighter tting
Check that adequate AC/DC power is
available
Check if battery requires recharging
Burner will not light
Check that gas cylinder is turned on and
that there is gas in cylinder
Check that outlet hose & tting are
correctly connected
Check there are no error messages on
the display
Turn fan speed down
Check there is sufcient gas
Air is too hot Turn fan up to MAX
Turn burner off & only operate fan
ERROR CODES
The appliance is tted with a number of operational and
safety features that can be identied by the following
error codes. In the event that the unit will not operate
refer to the Troubleshooting Guide:
E1: Outlet hose tting not connected or not connected
correctly
E2: Tilt switch activated – place on level surface and
re-start appliance
E3: No ame / burner not lit – Check gas cylinder &
connections
E6: Over temperature shut off – Once activated this will
take at least 5 minutes to cool down - the only way to
restart is to wait 5 minutes & turn off/on then attempt
restart
Appliance cutting out due to air temperature
too hot:
If E6 Over temperature shut off.
1. Allow heater to cool down for approximately 5 minutes
to clear over temp error
Try using heater again - If overtemp error appears again
it may be too warm to use the heater, the unit is only
suitable for use in ambient temperatures under 15˚c

14
STORAGE AND MAINTENANCE
This appliance is to be stored in a dry and well ventilated
location free from direct sunlight.
Do not store when still connected to the cartridge. Make
sure that the cartridge is disconnected and is stored in a
well ventilated area, free from direct sunlight, heat and
ignition sources. If being stored indoors ensure that the
location complies with the standard AS/NZS1596.
This appliance must only be serviced by an authorised
service agent. Please contact 1300 362 921 or
[e-mail] for further
information.

15
AEROHEAT SHOWER OWNERS MANUAL
NOTES

WARRANTY POLICY
WARRANTY - For details see www.companionleisure.com.au/warranty
Companion
®
is a registered trademark of
Primus Australia Pty Ltd
Designed & Imported by:
Adventure Trading Australia Pty Ltd
71 Charles Ulm Place,
Eagle Farm, QLD 4009
AUSTRALIA Made in China
1. Products distributed by Adventure Operations Australia Pty Ltd and any of our subsidiaries come with guarantees
that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major
failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the
goods repaired or replaced if products fail to be of acceptable quality and the failure does not amount to a
major failure.
2. In addition, we warrant that this product will be free from defects in materials and workmanship under normal use
as described in the published product documentation for 36 months & the integrated powerpack for 12 months from
the date of original purchase (Limited Warranty). This Limited Warranty is only valid and enforceable in Australia and
will apply only if you have purchased the product from us or our authorised resellers.
3. To the extent permitted by the Australian Consumer Law and any applicable local law:
(a) our obligations under this Limited Warranty are limited to the repair, replacement or refund of covered parts
that prove defective under normal use during the Limited Warranty and does not extend to any claim for
damages that you or any other person may have for any loss (including without limitation consequential
damages or loss of prot, freight/shipping or travel costs), or damage howsoever caused whether or not
such loss or damage arises as a result of any defect in the product or from the failure or omission on
our part to comply with any obligation at law;
(b) in replacing a defective product under the Limited Warranty, we may, at its discretion, substitute a model of
equivalent nature where the exact model is unavailable;
(c) this Limited Warranty does not apply to damage caused by failure and damage caused by improper use and
abuse, fair wear and tear, accidents, misuse (including failure to follow instructions regarding
care and maintenance of the product), neglect, disassembly, alterations or external causes such
as, but not limited to, water damage, exposure to sharp objects, exposure to excessive force, anomalies in the
electrical current supplied to the product (if applicable), and extreme thermal or environmental conditions;
(d) we may elect, at our discretion and as an alternative to repairing or replacing a defective part to refund the
cost of the relevant product upon it being returned to us; and
(e) this Limited Warranty does not extend to any products acquired for the purposes of re-supply, or for use in a
manufacturing, or repair processes.
4. This warranty may be claimed by:
returning the product to its place of purchase, with a detailed proof-of-purchase clearly showing the date
and detail of the purchase;
5. If you have any questions concerning this warranty policy, you may contact us in writing:
Adventure Operations, 71 Charles Ulm Place, Eagle Farm, 4009 QLD, or by email: [e-mail]
or visit our website: www.adventureoperations.com
TO THE EXTENT PERMITTED BY LAW, ADVENTURE OPERATIONS AUSTRALIA PTY LTD, ITS SUBSIDIARIES AND ITS
VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OR
ANY SIMILAR STANDARD IMPOSED BY APPLICABLE LEGISLATION AND ADVENTURE OPERATIONS AUSTRALIA PTY LTD
AND ITS SUBSIDIARIES’ RESPONSIBILITY TO REPAIR, REPLACE, OR OFFER A REFUND FOR DEFECTIVE PRODUCTS IS THE
SOLE AND EXCLUSIVE REMEDY PROVIDED TO ITS CUSTOMERS UNDER THIS DOCUMENT.
