Compaq Armada 4100 Operating instructions

. . . . . . . . . . . . . . . . . . . . . . . . .
ttttt
Part Number: 235758-004 - Writer: Johnnie Abercrombie - Saved by: Rebecca Wiggins
Saved date: 11/05/97 11:12 AM- File Name: Noticesi.doc
Notice
The information in this guide is subject to change without notice.
COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE
FOR TECHNICAL OR EDITORIAL ERRORS OR OMISSIONS
CONTAINED HEREIN; NOR FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE
FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.
This guide contains information protected by copyright. No part of this
guide may be photocopied or reproduced in any form without prior written
consent from Compaq Computer Corporation.
1998 Compaq Computer Corporation.
All rights reserved. Printed in Singapore.
Compaq and LTE are registered in the U. S. Patent and Trademark Office.
Armada is a trademark of Compaq Computer Corporation.
Microsoft, MS-DOS, and Windows are registered trademarks of Microsoft Corporation.
The software described in this guide is furnished under a license agreement or
nondisclosure agreement. The software may be used or copied only in
accordance with the terms of the agreement.
Product names mentioned herein may be trademarks and/or registered
trademarks of their respective companies.
Compaq Mobile CD Expansion Unit
Installation and Operations Guide
Compaq Armada 4100 and 4200 Families of Personal Computers
Fourth Edition (January 1998)
First Edition (May 1996)
Part Number 235758-004
Compaq Computer Corporation

. . . . . . . . . . . . . . . . . . . . . . . . .
Contents ix
ttttt
Writer: Jim Williams - Saved by: Rebecca Wiggins - Saved date: 11/05/97
11:12 AM
Part Number: 235758-004 - File name: Toc.doc
CONTENTS
Preface
Using This Guide ........................................................................................ xi
Chapter 1
Introduction
Contents of Packing Box .............................................................1-2
For Further Information...............................................................1-2
Chapter 2
Attaching and Detaching Procedures ...........................................................
Attaching the Computer...............................................................2-2
Detaching the Computer..............................................................2-5
Docking the Computer and MCD................................................2-7
Undocking the Computer and MCD............................................2-9
Turning Equipment On and Off.................................................2-10
Turning On the Computer...................................................2-10
Initiating Suspend ...............................................................2-10
Turning Off the Computer ..................................................2-11
Chapter 3
Using The Compaq Mobile CD Expansion Unit .............................................
Identifying the Connectors...........................................................3-2
Using the Stereo Speakers ...........................................................3-4
Using the CD-ROM Drive...........................................................3-5
Ejecting a CD Manually ..............................................................3-6
Using the MIDI/Game Port..........................................................3-7
Connecting the AC Adapter.........................................................3-8
Removing and Inserting the Battery Pack .................................3-10
Charging a Battery Pack............................................................3-12

. . . . . . . . . . . . . . . . . . . . . . . . .
xContents
Writer: Jim Williams - Saved by: Rebecca Wiggins - Saved date: 11/05/97
11:12 AM
Part Number: 235758-004 - File name: Toc.doc
Appendix A
Troubleshooting .......................................................................................A-1
Appendix B
Specifications ..........................................................................................B-1
Appendix C
Regulatory Agency Identification Numbers ...........................................C-1

. . . . . . . . . . . . . . . . . . . . . . . . .
v
ttttt
Part Number: 235758-004 - Writer: Jim Williams - Saved by: Rebecca Wiggins
Saved date: 09/08/97 11:37 AM- File Name: Agenda.doc
Federal Communications
Commission Notice
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
■Reorient or relocate the receiving antenna.
■Increase the separation between the equipment and the receiver.
■Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
■Consult the dealer or an experienced radio or television
technician for help.
Modifications
The FCC requires the user to be notified that any changes or
modifications made to this device that are not expressly approved by
Compaq Computer Corporation may void the user's authority to
operate the equipment.
Cables
Connections to this device must be made with shielded cables with
metallic RFI/EMI connector hoods to maintain compliance with
FCC Rules and Regulations.

. . . . . . . . . . . . . . . . . . . . . . . . .
vi
Part Number; 235758-004 - Writer: Jim Williams - Saved by; Rebecca Wiggins
Saved date: 09/08/97 11:37 AM - File Name: Agenda.doc
Laser Safety
All Compaq systems, equipped with CD-ROM drives, comply with
appropriate safety standard including IEC 825. With specific regard
to the laser, the equipment complies with laser product performance
standards set by government agencies as a Class 1 laser product. It
does not emit hazardous light; the beam is totally enclosed during all
modes of customer operation and maintenance.
CDRH Regulations
The Center for Devices and Radiological Health (CDRH) of the
U.S. Food and Drug Administration implemented regulations for
laser products on August 2, 1976. These regulations apply to laser
products manufactured from August 1, 1976. Compliance is
mandatory for products marketed in the United States.
!WARNING: Use of controls or adjustments or performance of
procedures other than those specified herein or in the CD-ROM
procedure may result in hazardous radiation exposure.
This system is classified as
CLASS 1 LASER PRODUCT.
This label is located on the
outside of your system. A similar
label also appears on the internal
CD-ROM installed in your
system.

. . . . . . . . . . . . . . . . . . . . . . . . .
vii
Part Number: 235758-004 - Writer: Jim Williams - Saved by: Rebecca Wiggins
Saved date: 09/08/97 11:37 AM - File Name: Agenda.doc
Laser Info
Laser Type: Semiconductor GaAIAs
Wave Length: 780 +/- 35 nm
Divergence Angle: 53.5 Degree +/- 1.5 Degree
Output Power: 0.4 mW - 2.5 mW
Polarization: Circular
Numerical Aperture: 0.45 +/- 0.04
Only authorized technicians trained by Compaq should attempt to
repair this equipment. All troubleshooting and repair procedures are
detailed to allow only subassembly/module level repair. Because of
the complexity of the individual boards and subassemblies, no one
should attempt to make repairs at the component level or to make
modifications to any printed wiring board. Improper repairs can
create a safety hazard.

. . . . . . . . . . . . . . . . . . . . . . . . .
viii
Part Number; 235758-004 - Writer: Jim Williams - Saved by; Rebecca Wiggins
Saved date: 09/08/97 11:37 AM - File Name: Agenda.doc
European Notice
Products with the CE Marking comply with both the EMC Directive
(89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued
by the Commission of the European Community.
Compliance with these directives implies conformity to the
following European Norms:
■EN55022 (CISPR 22)-Radio Frequency Interference
■EN50082-1(IEC801-2, IEC801-3, IEC801-4)-Electromagnetic
Immunity
■EN60950 (IEC950)-Product Safety
Canadian Notice
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Avis Canadien
Cet appareil numérique de la classe B respecte toutes les exigences
du Règlement sur le matériel brouilleur du Canada.
Japanese Notice

. . . . . . . . . . . . . . . . . . . . . . . . .
Preface
Preface xi
ttttt
Part Number: 235758-004 - Writer: Jim Williams - Saved by: Rebecca Wiggins
Saved date: 11/05/97 11:13 AM- File Name: Preface.doc
Using This Guide
The following format conventions distinguish elements of the text
throughout this guide:
■ Key names appear in a boldfaced type looking very much the
way they appear on the keyboard. For example, Home, End,
Backspace, Tab.
■ When keys must be pressed at the same time, the action is
represented by the key names and the plus (+) symbol. For
example, Ctrl+Alt+Delete.
■ Drive letters that are not in command lines are presented in
uppercase type as shown here: drive A.
■ Directory names that are not in command lines are presented in
uppercase type as shown here: DIRECTORY.
■ The file names are presented in uppercase italic type
as shown here: FILENAME.
■ The names of commands are presented in lowercase, bold type as
shown here: install, or a:\install. Commands that are to be
entered at the system prompt may be shown on a separate line.
■ When you need to type information without pressing the Enter
key, you are directed to "type" the information.
■ When you need to type information and press the Enter key, you
are directed to "enter" the information.
The following words and symbols mark special messages
throughout this guide:
!WARNING: Text set off in this manner indicates that failure to
follow directions could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to
follow directions in the caution could result in damage to
equipment or loss of information.
IMPORTANT: Text set off in this manner presents clarifying
information or specific instructions.
NOTE: Text set off in this manner presents commentary, sidelights,
or interesting points of information.

. . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1
Introduction 1-1
ttttt
Part Number: 235758-004 - Writer: Jim Williams - Saved by: Rebecca Wiggins
Saved date: 11/05/97 11:14 AM- File Name: Ch01.doc
Introduction
The Compaq Mobile CD Expansion Unit (MCD) provides
multimedia capabilities for your Compaq portable computer. The
MCD includes a dedicated battery compartment, a CD-ROM drive,
dual stereo speakers, and a game port with a Musical Instrument
Digital Interface (MIDI).
To expand the multimedia functions and give you full desktop
capabilities, you can dock the computer and MCD to the optional
convenience base.
This guide provides information for attaching and detaching the
computer to and from the MCD. Instructions are also provided for
docking and undocking the computer and MCD to the optional
convenience base, as well as procedures for using the MCD.
The Compaq Mobile CD Expansion Unit (MCD)

. . . . . . . . . . . . . . . . . . . . . . . . .
1-2 Introduction
Part Number; 235758-004 - Writer: Jim Williams - Saved by; Rebecca Wiggins
Saved date: 11/05/97 11:14 AM - File Name: Ch01.doc
Contents of Packing Box
Before you begin, ensure that you have removed everything from
the packing box. In addition to this guide, you should have the
following items in the packing box:
■Compaq Mobile CD Expansion Unit (MCD)
■Warranty and service information
NOTE: The modular battery pack (Part No. 217935-001) is sold
separately. If external power is required, use the AC adapter that
comes with your computer for external power source.
For Further Information
For additional information on using the computer, refer to the online
and hardcopy Reference Guide included with the computer.
!WARNING: Misuse of your personal computer or failure to
establish a safe and comfortable workstation may result in
discomfort or serious injury. Refer to your
Safety & Comfort Guide
for more information on choosing a workspace and creating a safe
and comfortable work environment.

. . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2
Attaching and Detaching Procedures 2-1
ttttt
Part Number: 235758-004 - Writer: Johnnie Abercrombie - Saved by: Rebecca Wiggins
Saved date: 11/05/97 1:36 PM- File Name: Ch02.doc
Attaching and
Detaching Procedures
This chapter provides procedures for attaching and detaching the
computer to and from the Compaq Mobile CD Expansion Unit
(MCD) as well as for docking and undocking the computer and
MCD to and from the optional convenience base. The following
information is included:
■Attaching the computer to the MCD
■Detaching the computer from the MCD
■Docking the computer and MCD to the convenience base
■Undocking the computer and MCD from the convenience base
■Turning equipment on and off

. . . . . . . . . . . . . . . . . . . . . . . . .
2-2 Attaching and Detaching Procedures
Part Number; 235758-004 - Writer: Johnnie Abercrombie - Saved by; Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
Attaching the Computer
To attach the computer to the MCD, follow these steps:
1. Turn off and disconnect all external devices connected to the
computer (such as the AC adapter).
2. Turn off the computer.
3. Close the computer display. Ensure that the handle is in the up
position, unless it has been removed from the computer.
4. Slide the computer expansion slot cover on the bottom of the
computer to the open position.
Opening the Expansion Slot Cover

. . . . . . . . . . . . . . . . . . . . . . . . .
Attaching and Detaching Procedures 2-3
Part Number: 235758-004 - Writer: Johnnie Abercrombie - Saved by: Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
5. Tilt the computer at an angle to line up the two guide hooks 1
with the two tabs on the right side of the MCD.
Attaching the Computer to the MCD
6. Lower the computer 2until it snaps into place. Be sure that the
expansion connector slot on the bottom of the computer is
aligned with the connector posts on top of the MCD.

. . . . . . . . . . . . . . . . . . . . . . . . .
2-4 Attaching and Detaching Procedures
Part Number; 235758-004 - Writer: Johnnie Abercrombie - Saved by; Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
7. Turn the computer and MCD over, bottom side up.
8. Turn the two thumbscrews clockwise to securely attach the
MCD to the computer.
!WARNING:Failure to secure the thumbscrews to the MCD can
result in damage to the computer. Secure the thumbscrews each
time you attach the computer to the MCD.
Thumbscrew Locations
9. Turn the computer and MCD over, top side up.
10. Reconnect all external devices to the computer and MCD.
11. Turn on the computer.

. . . . . . . . . . . . . . . . . . . . . . . . .
Attaching and Detaching Procedures 2-5
Part Number: 235758-004 - Writer: Johnnie Abercrombie - Saved by: Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
Detaching the Computer
To detach the computer from the MCD, follow these steps:
1. Turn off the computer.
2. Turn off and disconnect all external devices connected to the
computer and MCD (such as the AC Adapter).
3. Close the computer display and ensure that the handle is in the up
position, unless it has been removed from the computer.
4. Turn the computer and MCD bottom side up.
5. Turn the two thumbscrews on the bottom of the MCD
counterclockwise to loosen the MCD from the computer.
6. Pull down the eject lever on the back of the MCD.
Pulling Down the Eject Lever
7. Remove the MCD from the computer.

. . . . . . . . . . . . . . . . . . . . . . . . .
2-6 Attaching and Detaching Procedures
Part Number; 235758-004 - Writer: Johnnie Abercrombie - Saved by; Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
8. Close the expansion slot cover on the bottom of the computer.
Closing the Expansion Slot Cover
9. Turn the computer top side up.
10. Reconnect all external devices to the computer and MCD.
11. Turn on the computer.

. . . . . . . . . . . . . . . . . . . . . . . . .
Attaching and Detaching Procedures 2-7
Part Number: 235758-004 - Writer: Johnnie Abercrombie - Saved by: Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
Docking the Computer and MCD
This section describes the procedures for docking the computer and
MCD to the convenience base. For information on using the
convenience base, refer to the Installation and Operations guide that
comes with the convenience base.
1. If attached, remove the convenience base adapter from the
convenience base by firmly holding both units and pulling them
apart.
NOTE: The convenience base adapter is not used when the
computer is attached to the MCD.
Removing the Convenience Base Adapter
2. Ensure that all external equipment is connected to the
convenience base.
IMPORTANT: If you are setting up the convenience base for the
first time, connect all external devices before docking the
computer. Refer to Chapter 3 for additional information on
connecting external devices.
NOTE: You may leave external equipment turned on while
docking the computer.

. . . . . . . . . . . . . . . . . . . . . . . . .
2-8 Attaching and Detaching Procedures
Part Number; 235758-004 - Writer: Johnnie Abercrombie - Saved by; Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
3. Turn off the computer or initiate Suspend.
CAUTION:Before docking or undocking, turn off the computer or
initiate Suspend to prevent damage to the computer. To prevent loss of
information, ensure that the battery pack is inserted into the computer
before initiating Suspend and undocking the computer.
4. Close the computer display. Make sure that the handle is in the
up position, unless it has been removed from the computer.
5. Slide the computer and MCD onto the convenience base so that
the expansion connector on the rear of the MCD and the
expansion connector posts on top of the convenience base are
aligned.
6. Slide the computer back until it stops.
Docking the Computer and MCD
7. Open the computer display.
8. Turn on the computer or exit Suspend to resume work.

. . . . . . . . . . . . . . . . . . . . . . . . .
Attaching and Detaching Procedures 2-9
Part Number: 235758-004 - Writer: Johnnie Abercrombie - Saved by: Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
Undocking the Computer and MCD
To remove the computer and MCD from the convenience base,
follow these steps:
CAUTION:Before docking or undocking, turn off the computer or
initiate Suspend to prevent damage to the computer. To prevent
loss of information, ensure that the battery pack is inserted into
the computer before initiating Suspend and undocking the
computer.
1. Turn off the computer or initiate Suspend.
2. Close the computer display.
3. Pull the docking lever on the right side of the convenience base
toward the front of the base. This releases the computer and
MCD from the convenience base.
Undocking the Computer and MCD
4. Slide the computer and MCD forward until it clears the
convenience base.
5. Turn on the computer or exit Suspend to resume work.

. . . . . . . . . . . . . . . . . . . . . . . . .
2-10 Attaching and Detaching Procedures
Part Number; 235758-004 - Writer: Johnnie Abercrombie - Saved by; Rebecca Wiggins
Saved date: 11/05/97 1:36 PM - File Name: Ch02.doc
Turning Equipment On and Off
When the computer is attached to the MCD or when the computer
and MCD are docked to the convenience base, use these procedures
for turning the computer on, initiating Suspend, and turning off the
computer. These procedures may be necessary when docking and
undocking the computer and MCD to and from the convenience
base.
Turning On the Computer
Use this procedure for turning on the computer and MCD when they
are docked to the convenience base:
1. Make sure that the AC adapter is plugged into an outlet and
connected to the convenience base.
2. Turn on all external devices connected to the convenience base.
3. Press the power button on the computer.
The power/suspend light on the computer will illuminate.
Initiating Suspend
Before docking the computer and MCD to the convenience base,
place the computer in Suspend. Suspend enables you to place the
computer in a reduced-power condition without having to save your
work or exit applications.
CAUTION: To prevent loss of information when undocking, ensure that
a battery pack is inserted in the computer before initiating Suspend and
undocking the computer.
To initiate Suspend, press the suspend button on the computer or
click Suspend from the Windows 95 Start menu. The suspend light
on the computer blinks to indicate the computer is in Suspend.
To exit Suspend, press the suspend button on the computer. The
power/suspend light on the computer will stop blinking and
remain on.
