Compaq Notebook 100 Series User manual

Contents v
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: JGilbert Saved by: JAbercrombie Saved date: 03/15/00 10:46 AM
Pages: 2 Template: c:\msoffice\templates\ref\ref-toc.dot
Part Number: 177845-001 File name: TOC.doc
CONTENTS
preface
Symbols .......................................................................................... ix
Technician Notes............................................................................. x
Serial Number.................................................................................. x
Locating Additional Information.................................................... x
chapter1
1.1 Computer Features and Models............................................1-1
1.2 System Memory Options.......................................................1-4
1.3 Power Management Functions..............................................1-5
1.4 Setup Configuration Utility (SCU).......................................1-6
1.5 Compaq Configuration Record Utility ...............................1-16
1.6 Gathering Information.........................................................1-17
1.7 Diagnostics..........................................................................1-19
1.8 Computer External Components.........................................1-20
1.9 Design Overview.................................................................1-24
chapter2
2.1 Service Considerations..........................................................2-1
2.2 Basic Troubleshooting Checklist..........................................2-1
2.2 Power-On Self Test (Post) ....................................................2-2
2.3 Solving Common Problems..................................................2-5
2.4 Test Errors.............................................................................2-7
chapter3
3.1 Serial Number Location........................................................3-1
3.2 Computer System Major Components..................................3-2
3.3 Miscellaneous Plastic Kit Components ................................3-4
3.4 Hardware Kit Components....................................................3-5
3.5 Cable Kit Components..........................................................3-6
3.6 Mass Storage Devices...........................................................3-7
3.7 Miscellaneous........................................................................3-8
chapter4
4.1 Tools Required......................................................................4-1
4.2 Service Considerations..........................................................4-1

vi Contents
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: JGilbert Saved by: JAbercrombie Saved date: 03/15/00 10:46 AM
Part Number: 177845-001 File name: TOC.doc
4.3 Preventing Damage to Removable Drives ........................... 4-2
4.4 Preventing Electrostatic Damage.......................................... 4-3
4.5 Packaging and Transporting Precautions............................. 4-4
4.6 Workstation Precautions....................................................... 4-4
4.7 Grounding Equipment and Methods .................................... 4-5
chapter5
5.1 Serial Number....................................................................... 5-1
5.2 Disassembly Reference Chart............................................... 5-2
5.3 Preparing the Computer for Disassembly ............................ 5-3
5.4 Battery Pack......................................................................... 5-4
5.5 Modem .................................................................................. 5-5
5.6 Fan Assembly........................................................................ 5-8
5.7 CD-ROM Drive................................................................... 5-10
5.8 Processor............................................................................. 5-12
5.9 Memory............................................................................... 5-15
5.10 Top Cover.......................................................................... 5-17
5.11 Hard Drive......................................................................... 5-19
5.12 Real Time Clock (RTC) Battery....................................... 5-20
5.13 Keyboard........................................................................... 5-21
5.14 EMI Shield........................................................................ 5-23
5.15 Touchpad........................................................................... 5-25
5.16 Speakers ............................................................................ 5-26
5.17 Display Assembly............................................................. 5-27
5.18 Speaker Housing............................................................... 5-32
5.19 System Board.................................................................... 5-34
5.20 Diskette Drive................................................................... 5-38
chapter 6
SPECIFICATIONS
appendix A
CONNECTOR PIN ASSIGNMENTS
appendix B
POWER CORD SET REQUIREMENTS
3-Conductor Power Cord Set.......................................................B-1
Country-Specific Requirements...................................................B-2
INDEX .......................................................................................................I-1

Product Description 1-1
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Pages: 24 Words: 3860 Template: c:\msoffice\templates\ref\ref.dot
Part Number: 177485-001 File name: CH01.doc
chapter 1
PRODUCT DESCRIPTION
1.1 Computer Features and Models
The Compaq Notebook 100 Series offers an AMD K6-2 475-MHz
processor, a 12.1-inch SVGA TFT or HPA display, a 5.0-GB hard drive,
and a 24X Max CD-ROM drive. The computer also comes equipped with
a TouchPad pointing device and 4 MB of video SDRAM.
Figure 1-1. Compaq Notebook 100 Series

1-2 Product Description
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Part Number: 177485-001 File name: CH01.doc
Models
The Compaq Notebook 100 Series is available in the models shown in
Table 1-1. The computer serial number is located on a bar code on the
bottom of the computer and identifies the model’sfeatures.
Table 1-1
Compaq Notebook 100
Model Naming Convention
Example: serial number N10 K2 475 T1S 5 M 64 98
Key
A K2 475 T2S 5 M 64 98
1 2345678
KEY DESCRIPTION OPTIONS
1 Brand designator A = Notebook 100
2 Processor K2 = AMD k6-2
3 Processor speed 475 = 475-MHz
4 Display T2S = 12.1”, CTFT, SVGA H2S = 12.1”, HPA, SVGA
5 Hard drive size (MB) 5 = 5.0 MB
6 Integrated
communication
M = Modem 0 = None
7 RAM (in MB) 64 = 64 MB 32 = 32 MB
8 Operating system 98 = Microsoft
Windows 98
2 = Microsoft Word
2000
SB = Microsoft Small
Business
Table 1-2
Compaq Notebook 100 Models
12345678 SKU#
Config.
Code
A K2 475 T2S 5 M 64 98/2 175844-XX4 FFG1
A K2 475 T2S 5 M 64 98 180641-XX4 FFG2
A K2 475 T2S 5 M 64 98 180641-XX5 FFG2
A K2 475 T2S 5 0 64 98/2 180097-XX4 FFG3
A K2 475 T2S 5 M 64 98/SB 175599-XX4 FFG4
A K2 475 H2S 5 M 32 98/2 175843-XX4 FFF1
A K2 475 H2S 5 M 32 98 180640-XX4 FFF2
A K2 475 H2S 5 M 32 98 180640-XX5 FFF2
A K2 475 H2S 5 0 32 98/2 180096-XX4 FFF3
A K2 475 H2S 5 M 32 98/SB 175598-XX4 FFF4
A K2 475 H2S 5 M 64 98/2 180095-XX4 FFF5
A K2 475 H2S 5 M 64 98/SB 180094-XX4 FFF6

Product Description 1-3
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Part Number: 177485-001 File name: CH01.doc
Features
The Compaq Notebook 100 Personal Computer has the following
features:
■ AMD K6-2 475-MHz processor with 512 KB integrated L2 cache.
■ 64-MB 100-MHz SDRAM, expandable to 192 MB, or 32-MB
100-MHz SDRAM, expandable to 160 MB, varying by computer
model. The Compaq Notebook 100 also features a SODIMM
memory expansion slot, capable of accepting a memory expansion
board of 32-, 64-, or 128-MB.
■ Primary memory cache is 64 KB; secondary memory cache is
512 KB.
■ 12.1-inch SVGA TFT or HPA (800 × 600) color display, varying by
computer model. These display feature:
■ over 16.8 million colors.
■ integrated Trident CyberBlade AGP2 controller bus.
The computer also features external monitor support with 4G color
(640 × 480, 800 ×600, 1024 ×768, 1280 ×1024), with up to 60-, 75-,
or 85-Hz refresh rate.
■ Microsoft Windows 98, professional or standard edition,
preinstalled.
■ Keyboard with TouchPad pointing device.
■ 56-Kbps AC97 modem (not supported in DOS mode).
■ External AC adapter with 6-foot power cord.
■ A 9-cell NiMH battery pack is standard equipment on the Compaq
Notebook 100 Personal Computer. An 8-cell Li ion battery pack is
available as an option.
■ One Type II PC Card slot with support for both 32-bit CardBus and
16-bit PC Cards.
■ Mass storage devices include a 5.0-GB hard drive, 3.5-inch,
1.44-MB diskette drive, and 24X Max CD-ROM drive.
■ Connectors for parallel, serial, audio in/out, external monitor,
universal serial bus, external keyboard, and AC power. An infrared
port is also available.

1-4 Product Description
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Part Number: 177485-001 File name: CH01.doc
1.2 System Memory Options
Depending on the computer model, the main memory subsystem supports
a minimum of 32 or 64 megabytes of Synchronous SDRAM, expandable
to 160 or 192 megabytes. The minimum standard Synchronous SDRAM
is integrated on the system board. The upgrade SDRAM is accomplished
with memory expansion boards that are available on 128-, 64-, and 32-
megabytes.
The memory expansion slot is located underneath the fan/CPU cover.
Refer to Chapter 5, “Removal and Replacement Procedures,” for
information on installing and removing memory expansion boards.
System memory can be upgraded as shown in Table 1-3.
Table 1-13
Memory Upgrade
Base Memory on System Board Memory Expansion Board Total Memory
32 MB 32 MB 64 MB
32 MB 64 MB 96 MB
32 MB 128 MB 160 MB
64 MB 32 MB 96 MB
64 MB 64 MB 128 MB
64 MB 128 MB 192 MB

Product Description 1-5
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Part Number: 177485-001 File name: CH01.doc
1.3 Power Management Functions
Power Management functions of the computer are designed to conserve
power. All Power Management functions can be configured from the
Setup Configuration Utility (SCU), described later in this chapter.
Automatic Power Management
Automatic Power Management operates at two levels as described in the
following paragraphs.
Local Power Management
Local Power Management controls computer subsystems. When a
subsystem is inactive for a period of time, it is automatically shut down
or slowed to reduce power consumption. The subsystem returns to an
active state when it is accessed.
Subsystems under Power Management include:
■ Hard disk drive
■ Diskette drive
■ CD-ROM drive
■ LCD display panel
Global Power Management
Global Power Management automatically puts the computer into Suspend
mode when the computer is inactive for a period of time. The computer
wakes up whenever activity resumes.
The time-out settings for Suspend mode are set up in the SCU program.
The computer uses Suspend-to-RAM (Standby) or Suspend-to-Disk
(Hibernation) depending on the Suspend Data To setting in the SCU
program.
Manual Power Management
Suspend mode can be initiated at any time in one of two ways:
■ By pressing Fn + F12.
■ By closing the top cover, if the Cover Close option is set to Suspend
in the SCU program.

1-6 Product Description
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Part Number: 177485-001 File name: CH01.doc
Suspend-to-Disk (Hibernation)
When the computer suspends to disk, the system preserves all the running
application programs as a file in a Suspend-to-Disk partition on the hard
disk. The computer then turns off automatically. When the computer is
powered on, the system reads the file from the Suspend-to-Disk partition
back into memory, returning the computer to the state it was in before it
was suspended.
If there is no Suspend-to-Disk partition on the hard disk, use the
HIBERNAT utility to create the partition, in order to be able to use the
Suspend-to-Disk feature.
Suspend-to-RAM (Standby)
When the computer suspends to RAM, several subsystems enter standby
or power-off mode to conserve power. The system wakes up when any
key is pressed. Resume Timer and Ring Resume options also wake the
system from Suspend-to-RAM.
1.4 Setup Configuration Utility (SCU)
The system comes with a Setup Configuration Utility (SCU). This utility
configures BIOS settings via menu-driven utilities. Settings are stored in
the CMOS RAM.
The SCU must be used when:
■ An error message indicates that the SCU should be run.
■ Factory default settings need to be restored (after BIOS upgrades).
■ Specific settings must be modified.
Starting the SCU
The SCU resides on the system ROM chip. Start the utility by pressing
F10 during initial power up.

Product Description 1-7
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Part Number: 177485-001 File name: CH01.doc
Main SCU Screen
The SCU main screen is divided into three areas:
Menu area –lists the available menu titles, across the top of the screen.
Each menu title provides a pull-down menu of item settings.
Display area –displays current system settings. This section also
displays submenus for items that provide multiple options.
Information and navigation area –provides keyboard/mouse
instructions for moving around and making decisions.
You can select items using either the keyboard or theTouchPad/mouse.

1-8 Product Description
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Writer: David Calvert Saved by: David Calvert Saved date: 03/28/00 9:32 AM
Part Number: 177485-001 File name: CH01.doc
Startup Menu
The Startup pull-down menu contains basic system configuration
settings.
Startup Menu
Item Function Default
Date and
Time Sets the system date and time. N/A
Fast Boot When enabled, speeds up the booting
procedure by bypassing the memory test. This
option does not include a sub-menu. A check
mark indicates Enabled. An underline
indicates Disabled.
Enabled
Boot
Device Sets the boot device sequence. If all booting options are set to the same device, the
computer tries to boot only from that device.
Diskette A
Hard Drive C
CD-ROM Drive
Set Admin
password Allows the creation of an administrator-level password. This controls whether a non-
administrator can boot the system or enter the
SCU utility.
Set User
password Sets up a user-level password. This controls booting, running the SCU, or resuming the
system.
■ An Administrator password must be set up prior to attempting to set
up a User password.
■ The Administrator password must be used to make changes in the
SCU. The User password only allows browsing.
