QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 1
Overview
What's New
• 2.5 lb/1.13 kg Ultraportable
• Ultra Low VoltageMobile Intel

Pentium

III processor
• Intel 440MX chipset with 100-
MHz bus
• Optional Mobile Expansion Unit
(MEU)
• Microsoft

Windows

XP
Professional
• Support for two batteries in the
system
• Easy Access Internet Buttons
• Enhanced Industrial and
ergonomic design
At A Glance
• Ultra Low Voltage Mobile Intel
Pentium III 700 MHz-M
• 10.4-inch XGAdisplay
• 2.5 lb/1.13 kg weight with one
battery
• 0.83 in/2.11 cm thin
• 192 MB SDRAM standard
(100 MHz)
• 20 GB user removable SMART
hard drives
• Integrated Mini PCI modem/NIC
combo
• 90% keyboard
• Microsoft Windows XP
Professional Edition or, Microsoft
Windows 2000
• Includesa One-year,Worldwide
Warranty—Certain restrictions
and exclusions apply. Consult
the Compaq Customer Support
Center for details.
What’s Special
• Ultra Thin and lightweight design
• Ultra Low Voltage Processor
• Magnesium system enclosure
• Common MultiBay with optional
MEU
• Dual batterysupport
• Exceptionalbatterylife
• Ease of connectivity

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 2
Standard Features
Processor and Panel 700 MHz-M on Ultra low voltage Mobile Intel Pentium III processor with 512 KB L2 cache
10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
NOTE: Mobile Intel Pentium III processors support enhanced Intel SpeedStep™ technology.
Memory Standard/Maximum 192 MB 100-MHz SDRAM (128-MB SODIMM in slot 1 and 64 MB on board)
NOTE:Due to the non-industry standard nature of some third-party memory modules, we recommend Compaq
branded memory to ensure compatibility.
Communications Type III Mini PCI 56K (V.90) modem plus 10/100 NIC Combo
Optional Compaq 56 K (V.90) Modem plus Intel PRO/100+ NIC with IPSec (Internet Protocol Security)
NOTE: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download
transmission rates currently do not reach 56 KB/s, and will vary with line conditions.
NOTE: Modem availability is subject to country regulatory approval.
Keyboard 90% 102-key compatible keyboard with isolated, inverted-T cursor control keys, and right-control key, special
feature hotkeys for instant access to power conservation, QuickLock/QuickBlank (ex: FN+F6), toggle between
internal and external, or simultaneous displays, battery gauge, speaker volume control and brightness.
NOTE: Key pitch is 16 mm vertical and 17 mm horizontal, and key stroke is 2 mm.
Easy Access Internet
Buttons The Evo™ Notebook N200 comes with four Easy Access Buttons designed to increase customer productivity by providing one-touch access to helpful Compaq information, favorite Internet destinations, files, or applications.
Pointing Device Touchpad
PC Card Slots One Type II PC Card Slot which support both 32-bit CardBus and 16-bit PC Cards
Storage Diskette Drives*Optional Floppy Drive
Optical Drives*DVD/CD-RW combo Drive
CD-RW Drive
DVD-ROM Drive
CD-ROM Drive
Hard Drives 20-GB SMART Hard Drive
NOTE: * = Requires optional Mobile Expansion Unit (MEU).

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 3
Standard Features
Multimedia Integrated 16-bit Stereo Sound
Integrated mono speaker and microphone
Headphone-out
Microphone in
Software MPEG1 support, MPEG2 and DVD
CD-RW Drive (optional, with MEU only)
8X DVD-ROM Drive with movie playback software (optional, with MEU only)
24X CD-ROM Drive (optional, with MEU only)
PCI Graphics support
4MB SGRAM
Interfaces
PC Card USB 1 (Type II) 2
DC Power 1
RJ-45 (NIC) 1
RJ-11 (modem)
Headphone/Line-out
Microphone in
1
1
1
MEU Connector
LED status indicators
VGA/External Monitor
Infrared Port
1
6
1
1 (4 Mb/s support)
(IrDA 4 MB compliant. IR performance will vary depending on performance of IR
peripherals and application used.)
Graphics ATI Mobility L with 4 MB SGRAM
Display (External) Supports 1280 x 1024 @ 100 Hz refresh for single display mode operation.
Display (Internal) 10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
Operating System Microsoft Windows XP Professional Edition*or Microsoft Windows 2000 preinstalled
NOTE: * = Available December ’01 on select models.
Software Fax Central for Microsoft Windows 2000
Diagnostics for Microsoft Windows 2000
DVD Playback Software (with optional MEU)
Safety and Comfort Guide
Reference Guide
System Recovery Each unit is shipped with a CD kit for quick recovery (erases hard disk and restores manufacturer installed image)
and software recovery (installs only selected standard software)
Security Configuration Control Hardware
Set-up Password
Power-On Password
DriveLock
Support for PC Card SmartCard and Biometric options
Power Supply External AC adapter, 6-foot/1.8-meter power cord included. Total length including External AC adapter is 12-
feet/3.66-meter

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 4
Standard Features
Battery The Evo Notebook N200 provides 2.5 hours of battery life using the standard 6-cell Lithium-Ion polymer battery.
With the additional 4-cell external battery installed, battery life may be increased to 6.5 hours.
NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 2:30
(hr:min) were achieved running the eTesting Labs Inc.'s BatteryMarkTest version 4.0.1 on a N200 with
an Ultra Low Voltage Intel Pentium III 700 MHz-M CPU, 10.4-inch XGA panel, 192 MB RAM, 20-GB
HDD, 6-cell Li-polymer battery, and combination NIC/modem. System parameters were set according to
eTesting Labs’ recommendations: panel brightness 50%, hard drive standby and video idle time three
minutes, Intel SpeedStep battery optimized mode.
NOTE: This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc. makes
no representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff Davis
Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.
Power Conservation Support enhanced Intel SpeedStep Technology (Allows a Battery Optimized Mode, Maximum Performance Mode,
or Automatic mode)
Hibernation
Instant-on via Standby
One custom level of power conservation
ACPI compliant
MultiBay Devices MultiBay devices may be swapped in the system docked to the MEU powered on (hot) or in suspend mode
(warm) under Microsoft Windows 2000 (except MultiBay Zip drive or MultiBay secondary hard drive). MultiBay
devices can be swapped with system power off under any supported operating system.
Service and Support Compaq Services includes a One-year, Worldwide Limited Warranty, pick-up or carry-in, upgrade to on-site
warranty or additional Two-year warranty available, and toll-free 7 x 24 hardware technical phone support.
NOTE: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details.

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 5
Standard Features
Naming Convention The Etymology of a Model name:

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 6
Standard Features
Models
Display 10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
Processor 700 MHz-M on Intel Ultra Low Voltage Mobile Pentium III processor
Cache Memory 512 KB, L2 Cache
N2P700X020C19T2P
P/N
Memory Standard/Maximum 192 MB SDRAM
Optical Drive N/A
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.90) modem plus 10/100 NIC Combo
Graphics ATI Mobility L, with 4 MB SGRAM
Audio 16-bit SoundBlaster Pro compatible
Operating System Microsoft Windows 2000
Pointing Device Touchpad
Display 10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
Processor 700 MHz-M on Intel Ultra Low Voltage Mobile Pentium III processor
Cache Memory 512 KB, L2 Cache
N2P700X020C19ToP
P/N
Memory Standard/Maximum 192 MB SDRAM
Optical Drive N/A
Hard Drive 20-GB SMART
Communications Type III Mini PCI 56K (V.90) modem plus 10/100 NIC Combo
Graphics ATI Mobility L, with 4 MB SGRAM
Audio 16-bit SoundBlaster Pro compatible
Operating System Microsoft Windows XP Pro/Microsoft Windows 2000
Pointing Device Touchpad

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 7
Standard Features
Pentium III-700 MHz-M ULV
10.4-inch TFT
192 MB
20-GB
Combo
Microsoft Windows 2000
Pentium III-700 MHz-M ULV
10.4-inch TFT
192 MB
20-GB
Combo
Microsoft Windows XP Pro/Microsoft
Windows 2000
NORTH AMERICA
US N2P700X020C19T2P 470019-385
N2P700X020C19ToP 470026-715
Fr Canada N2P700X020C19T2P 470019-386
N2P700X020C19ToP 470026-718
EUROPE/MIDDLE EAST/AFRICA
Belgium-FR/NL/US N2P700X020C19T2P 470019-387
Czech Republic N2P700X020C19T2P 470019-388
Denmark N2P700X020C19T2P 470019-389
Euro N2P700X020C19T2P 470019-390
N2P700X020C19ToP 470026-719
France N2P700X020C19T2P 470019-391
N2P700X020C19ToP 470026-720
Germany N2P700X020C19T2P 470019-393
N2P700X020C19ToP 470026-721
Greece/Poland N2P700X020C19T2P 470019-514
Hungary N2P700X020C19T2P 470019-394
Israel N2P700X020C19T2P 470019-395
Italy N2P700X020C19T2P 470019-396
N2P700X020C19ToP 470026-722
Middle East N2P700X020C19T2P 470019-397
Netherlands N2P700X020C19T2P 470019-398
Norway N2P700X020C19T2P 470019-399
Portugal N2P700X020C19T2P 470019-400
Russian N2P700X020C19T2P 470019-402
Slovak, Slovenian N2P700X020C19T2P 470019-404
Spain N2P700X020C19T2P 470019-401
N2P700X020C19ToP 470026-723
Sweden/Finland N2P700X020C19T2P 470019-403
Swiss 1-FR/GR/US N2P700X020C19T2P 470019-405
N2P700X020C19ToP 470026-752
Swiss 2-FR/GR/IT N2P700X020C19T2P 470019-406
N2P700X020C19ToP 470026-753
Turkey N2P700X020C19T2P 470019-409
UK N2P700X020C19T2P 470019-410
N2P700X020C19ToP 470026-724
CKK
Japan-Jpn N2P700X020C19T2P 470019-412
N2P700X020C19ToP 470026-725
Japan-Eng N2P700X020C19T2P 470019-413
N2P700X020C19ToP 470026-726

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 8
Standard Features
Pentium III-700 MHz-M ULV
10.4-inch TFT
192 MB
20-GB
Combo
Microsoft Windows 2000
Pentium III-700 MHz-M ULV
10.4-inch TFT
192 MB
20-GB
Combo
Microsoft Windows XP Pro
LATIN AMERICA
LTNA N2P700X020C19T2P 470019-415
N2P700X020C19ToP 470026-727
BRAZIL N2P700X020C19T2P 470019-417
ASIA PACIFIC
APD N2P700X020C19T2P 470019-418
N2P700X020C19ToP 470026-728
APD - THAI N2P700X020C19T2P
Australia N2P700X020C19T2P 470019-420
N2P700X020C19ToP 470026-729
GREATER CHINA
PRC N2P700X020C19T2P 470019-531
Taiwan N2P700X020C19T2P 470019-422
Hong Kong N2P700X020C19T2P 470019-424
Korea N2P700X020C19T2P 470019-429

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 9
Options
Expansion Mobile Expansion Unit – CD 231492-B21
Mobile Expansion Unit – DVD 231493-B21
Mobile Expansion Unit – CD-RW 231494-B21
Monitors TFT8030 Flat Panel Color 18-inch (carbon/silver) 243362-xxx
TFT7020 Flat Panel Color 17-inch with integrated speakers (carbon/silver) 253217-xxx
TFT5015 Flat Panel Color 15-inch (carbon/silver) 234044-xxx
TFT5030 Flat Panel Color 15-inch (carbon/silver) 228134-xxx
V720 17-inch CRT (carbon/silver) 232944-001
S720 17-inch CRT (carbon/silver) 239287-001
V570 15-inch CRT (carbon/silver) 228113-001
MultiBay Hard Drives 30-GB SMART Hard Drive 212791-B25
20-GB SMART Hard Drive 212790-B25
MultiBay Storage Devices DVD/CD-RW Combo Drive 237184-B25
(Optional MEU Required) CD-RW Drive 136186-B25
8X DVD-ROM Drive 138320-B25
24X CD-ROM Drive 298452-B25
Floppy Drive 226935-B25
Iomega Zip 250 Drive 217387-B25
Other Storage Devices IBM 1GB Microdrive (PC card Device) 217390-B25
USB Disk-on-Key 249552-B25
USB Floppy drive 230330-B25
Connectivity Compaq M420 56K Global Modem 317900-001
10/100 TX PC Card UTP Controller 335506-B21
56K V.90 modem and 10/100 NIC IPSEC 225638-001
Wireless Connectivity Compaq WL100 11 Mbps Wireless LAN PC Card 233814-xx1
Compaq WL400 11 Mbps Wireless LAN Hardware Access Point 146927-001
Compaq WL Software Access Point 11Mbps 158603-001
NOTE: For more information on Compaq WLAN Wireless LAN solutions visit:
http://www.compaq.com/products/wlan/wl100-specifications.html
NOTE: This website is available in English only.
Power Primary Battery 258940-B25
External Battery (4-cells) 244389-B25
Common Power Solutions ArmadaE500, Armada M300 and Evo Notebook N200, Evo Notebook N400c, and
Evo Notebook N600c
AC Adapter 50W 120765-xx1
Auto Power Adapter/Charger 401043-B25
Aircraft Power Adapter 386504-B21
AC Line Cord (10 ft/3.1 m) 217932-xx2

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 10
Options
Input Devices External Enhanced III Keyboard (carbon – PS/2)*118003-008
Compaq 2 Button Mouse (carbon – PS/2)*103180-B21
USB 2 Button Scroll Mouse (carbon) 195255-B25
External 10-Key Numeric Keypad (carbon – PS/2)*294317-B21
USB EZ Access Keyboard 222726-xx8
NOTE: * = Item requires optional MEU.
Security Security Cable Lock 294316-B21
Compaq Smart Card PC Card Reader 135646-B25
Biometrics PC Card 146805-B25
Useful Accessories MP1400 Microportable Projector 174626-xx1
MP1800 Microportable Projector 180226-xx1
MP2800 Microportable Projector 180228-xx1
MP1600 Video Adapter 116298-001
MP1600 Lamp replacement kit 118052-001
MP1800/1400 Lamp replacement kit 189789-001
MP2800 Lamp replacement kit 215464-001
Carrying Cases Evo Notebook N200 specific
Compaq Evo Notebook N200 Portfolio Case 259396-B25
Compaq Value Case 294266-B21
Compaq Workstation Case 294267-B21
Compaq Global Case 294268-B21
Compaq Professional Case (nylon) 401366-B21
Compaq Professional Case (leather) 401367-B21
Armada M300, Evo Notebook N600c and Evo Notebook N400c specific
Compaq M Series Portfolio Case 167337-B21
Compaq Ultralight Case 167336-B21
NOTE: For additional Compaq Brand cases, visit http://www.compaq.com/products/notebooks/.

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 11
Memory
Compaq Evo Notebook N200
S TANDARD M EMORY
Memory onboard Slot 1 Total
64 MB 128 MB 192 MB

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 12
Storage
1. User Removable Hard Drive
D
RIVE S UPPORT
System Drive Support Quantity Supported Drive Bay Supported
20-GB SMART Hard Drive 1 Dedicated hard drive bay

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 13
Technical Specifications
System Unit Dimensions (Hx W x D) 10.4-inch TFT panel display 0.83 x 9.9 x 7.83 in/2.11 x 25.15 x 19.88 cm
Weight 10.4-inch LCD, HDD, SODIMM,
Battery 2.5 lb/1.13 kg
Stand-Alone Power
Requirements Nominal Operating Voltage
(Li-Ion Polymer) 11.1V (6-cell)
Average Operating Power 10W
Peak Operating Power 25W
Power in suspend mode 290 Milliwatts
Power in hibernation mode 8.32 Milliwatts
Power Supply Rated Input Voltage 90 to 264 VAC (auto-switching)
Rated Input Current 1.5 A RMS
Rated Frequency 47 to 63 Hz
Temperature Operating 50° to 95°F/10° to 35°C
Non-operating –4° to 140°F/–20° to 60°C
Relative Humidity Operating 10% to 90% relative humidity, non-condensing
Non-operating 5% to 95% relative humidity, 101.6°F/38.7°C
Maximum wetbulb temperature
Shock Operating 10 G, 11 ms, half-sine
Non-operating 60 G, 11 ms, half-sine
Vibration Operating 0.5 G zero-to-peak, 10 to 500 Hz, 0.25 oct/min
sweep rate
Non-operating 1.0 G, zero-to-peak, 10 to 500 Hz, 0.5 oct/min
sweep rate
Operating 0 to 10,000 ft (0 to 3,048 m)
Maximum Altitude
(unpressurized) Non-operating 0 to 30,000 ft (0 to 9,144 m)
Dimensions (H x W)9.29 x 6.82 in/23.6 x 17.3 cm
Diagonal Size 10.4 in/26.41 cm
10.4-Inch Color TFT XGA Display
Mounting Internal Panel Supports, Flange Mounted
Number of Colors Up to 16.8M
Contrast Ratio 150:1
Brightness 120nt typ
Pixel Resolution Pitch 0.264 x 0.264 mm
Format 1024 x 768
Configuration RGB stripe
Backlight Edge Lit
Character Display 80 x 25
Total Power Consumption 3.75W

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 14
Technical Specifications
Hard Drives
MultiBay Drive Adapter Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.15 lb/70g
Drive Weight 0.21 lb/95 g
Capacity 20 GB
Height 0.374 in/0.95 cm /1.25 cm
20 GB
Width 2.75 in/7 cm
Interface ATA-5
Transfer Rate Synchronous (maximum) 33MB/s
Security ATA Security
Single Track 2.5 ms
Seek Time
(typical reads, including settling) Average 12 ms
Maximum 23 ms
Rotational Speed 4200 rpm
Logical Blocks ~ 39,070,080
Operating Temperature 41° to 131°F/5° to 55°C
External AC Adapter Dimensions (Hx W x D) 1.10 x 1.57 x 3.70 in/2.8 x 4.0 x 9.4 cm
Weight 0.39 lb/0.18 kg
Power Supply (Input) Operating Voltage 90 to 260 VAC RMS
Operating Current 1.5 A RMS
Operating Frequency Range 47 to 63 Hz AC
Maximum Transient 4/50 kV
Dimensions (H x W x D) 5.73 x 3.85 x 0.57 in/14.5 x 9.7 x 1.4 cm
Li-Ion Polymer Battery Pack
(6-cell) Weight 0.39 lb/0.18 kg
Energy Nominal Voltage 11.1 V
Amp-hour capacity 1.6 Ah
Watt-hour capacity 17.2Wh
Temperature Operating 32° to 107.6°F/0° to 42°C
Non-operating –4° to 107.6°F/–20° to 60°C
Battery Re-Charge Time System in OFF mode or Standby 2:10 hours HH:MM
System ON (depending of
system power consumption) 2:10 hours HH:MM

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 15
Technical Specifications
Dimensions (Hx W x D) 10.49 x 1.49 x 0.95 in/26.6 x 3.8 x 2.4 cm
Secondary Lithium Ion Battery
Pack (4-cell) Weight 0.5 lb/0.23 kg
Cells 4 Lithium Ion
Energy Voltage 14.4 V
Amp-hour capacity 1.96Ah
Watt-hour capacity 28.2 Wh
Temperature Operating 32° to 107.6°F/0° to 42°C
Non-operating –4° to 107.6°F/–20° to 60°C
MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
MultiBay DVD/CD-RW Combo
Drive Weight 0.55 lb/250 g
Center Hole Diameter 15 mm
Disk Diameter 12 cm, 8 cm
Disk Thickness 1.2 mm
Track Pitch 1.6 µm
Random CD < 120 ms
Access Times
(typical reads, including settling) Full-Stroke CD < 175 ms
Disk Diameter Random DVD < 140 ms
Disk Thickness Full-Stroke DVD < 225 ms
Audio Output Level 8X CLV minimum CD-ROM, CD-R, CD-RW Read
Cache Buffer 2 Mbytes (minimum)
Data Transfer Rate
(typical, including settling) CD-ROM, CD-R Read Speed 3600 KB/second
Audio Output Level DVD-ROM Read Speed 8100 KB/second
Cache Buffer CD-R, CD-RW Write Speeds Sustained 600KB/s (4X CLV)
Start-up Time Single < 7 seconds (typical)
Multi-Session < 30 seconds (typical)
Stop Time < 3 seconds (typical)

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 16
Technical Specifications
MultiBay CD-RW Drive MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.74 lb/335 g
Center Hole Diameter 0.59 in/1.5 cm
Disk Diameter 12 cm/8 cm
Disk Thickness 0.047 in/1.2 mm
Track Pitch 0.74 µm
Random < 150 ms
Access Times
(typical reads, including settling) Full-Stroke < 225 ms
Audio Output Level Line-out 0.7 Vrms
Cache Buffer 128 KB/s (minimum)
Sustained (16X) 150 KB/s
Sustained 4X CD-RW 5,520 KB/s
Data Transfer Rate
(typical, including settling)
Normal PIO Mode 4
(single burst) 16.6 MB/s
Start-up Time < 15 seconds
Stop Time < 6 seconds
MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.66 lb/300 g
Center Hole Diameter 0.59 in/1.5 cm
MultiBay DVD-ROM Drive
Disc Diameter 12 cm/8 cm
Disc Thickness 1.2 mm
Track Pitch 0.74 µm
Random (typical) < 180 ms DVD Media
Access Times
(typical reads, including settling) Full-Stroke (typical) < 300 ms DVD Media
Random (typical) < 120 ms CD Media
Full-Stroke (typical) < 200 ms CD Media
Cache Buffer 512 KB/s (minimum)
Max 24X CD 3600 KB/s (150 KB/s at 1X CD rate)
Data Transfer Rate
(typical, including settling) Max 8X DVD 10,800 KB/s (1352 KB/s at 1X DVD rate)
Normal PIO Mode 4
(single burst) 16.6 MB/s
Start-up Time < 12 seconds
Stop Time < 3 seconds

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 17
Technical Specifications
MultiBay 24X CD-ROM Drive MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.50 lb/225 g
Applicable Disk CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready
(Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multi-
session), CD-Extra, Video CD, CD-WO (fixed packets only), CD-Bridge
Center Hole Diameter 0.59 in/15 mm
Disk Diameter 12 cm, 8 cm
Disk Thickness 1.2 mm
Track Pitch 1.6 µm
Random < 150 ms
Access Times
(typical reads, including settling) Full-Stroke < 300 ms
Audio Output Level Line-out 0.7 Vrms
Cache Buffer 128 KB
Sustained (16X) 150 KB/s (sustained 1X)
Data Transfer Rate
(typical, including settling) Variable 1500 to 3600 KB/s (10X to 24X)
Normal PIO Mode 4 (single
burst) 16.66 MB/s
Start-up Time < 8 seconds
Stop Time < 4 secconds
MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.51 lb/230 g
Diskette Size 3.5 in
Activity Indicator On system
MultiBay Diskette Drive
Height 0.5 in/12.7 mm
Bytes per Sector 512
Sectors per track High density 18 (1.44 MB)/15 (1.2 MB)
Low density 9
Tracks per side High density 80 (1.44 MB)/80 (1.2 MB)
Low density 80
Read/Write heads 2
Access Times Track-to track (high/low) 3 ms/6 ms
Average (high/low) 94 ms/174 ms
Settling time 15 ms
Latency average 100 ms

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 18
Technical Specifications
Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
MultiBay SuperDisk 2X LS-120
Drive MultiBay
Weight 0.61 lb/276 g
Maximum Transfer Rate From Disk 896 KB/s
Sustained: 375 to 900 KB/s
120 MB Physical Format Number of Heads: 2
Bytes per Sector: 512
Sectors per Track: 51 to 92
Zones/Side: 55
Data Tracks per Side: 1736
Servo Tracks: 900
Sector Interleave: 1:1
Track–to–track: 20 ms
Access Times
(including setting) Average: 70 ms
Latency Average: 41.67
Operating Conditions Temperature: 41° to 131°F/5° to 55°C
Humidity: 10% to 80% RH
Operating System Support Microsoft Windows 95, Microsoft Windows NT 4.0
Option Kit Contents LS-120 Drive, 17 mm MultiBay Adapter, Software, Documentation
NOTE: Drivers for the LS-120 Drive are standard in Microsoft Windows 95/OSR2, Microsoft Windows NT
3.51/SP5, and Microsoft Windows NT 4.0. Use the LS-120 Option Support Diskette (included in option
kit) with earlier releases of Microsoft Windows 95 and NT 3.51.
Dimensions (H x W x D) 5.26 x 5.24 x 5.71 in/13.35 x 13.3 x 14.5 cm
MultiBay Iomega Zip 250 Drive MultiBay
Weight 9.8 oz/278 g or Xg
Transfer Rates 250 Media: 1200 to 2400 KB/s
100 Media: 138 to 1400 KB/s
Track–to–track: 5 ms
Access Times
(including setting) Average: 40 ms
Latency Average: 10 ms
Maximum: 70 ms
Operating Conditions Temperature: 41° to 124.7°F/5° to 51.5°C
Humidity: 10% to 80% RH
Operating System Support Microsoft Windows 95, 98, Microsoft Windows NT 4.0, Microsoft Windows 2000,
Microsoft Windows Me
Option Kit Contents Zip 250 Drive, Documentation

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 19
Technical Specifications
Form Factor Mini-PCI Type 1B per Specification
Type III Mini PCI 56K (V.90)
modem plus 10/100 NIC Combo OS Support
(with all released Service Packs)Microsoft Windows 95 (OSR2.x), Microsoft Windows 98 SE (Gold, SE)
Microsoft Windows NT4.0, Microsoft Windows 2000, DOS Application Support
under Microsoft Windows
Power Management Support APM Revision 1.2, ACPI, Compaq Power Management Extensions for Microsoft
Windows NT
Approvals/Certifications UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15
Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark,
Other Countries
Modem Device Driver Name Compaq 56K (V.90) Mini PCI
Data Mode Capabilities V.90 (a-law, mu-law)
K56flex (a-law, mu-law)
V.8bis
V.80
V42.bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
V.34 (file date: 10/96)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
Fax Mode Capabilities TIA-578-S (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2

QuickSpecs
Compaq Evo Notebook N200
DA-10921 World Wide — Version 5 — March 4,2002 20
Technical Specifications
Type III Mini PCI 56K (V.90)
modem plus 10/100 NIC Combo
(continued)
Command Set V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, + Iirr
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
Compaq PCs use genuine Microsoft

Windows

www.microsoft.com\piracy\howtotell
©2002 Compaq Information Technologies Group, L.P. All rights reserved. Compaq, the Compaq logo, Evo, and Armada are trademarks of Compaq
Information Technologies Group, L.P. in the U.S. and/or other countries. Windows NT is a trademark of Microsoft Corporation in the U.S. and/or other
countries. Pentium, the Intel Inside Logo, and SpeedStep are trademarks of Intel Corporation in the U.S. and/or other countries.BatteryMark is a trademark of
Ziff Davis Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries. All other product names mentioned herein may be
trademarks of their respective companies. The information in this publication is subject to change without notice.
