QUICKSPECS
1DA-10629-02-003 — 03.15.2001
Compaq MP1800
Microportable Projector
MODELS
Compaq MP1800
Microportable Projector
Models
180226-001 – North America
180226-011 – Australia, New
Zealand
180226-021 – Europe
180226-AA1 – China
180226-031 – UK
180226 - B24 – International
Options Part numbers
189789-001 - Lamp
1. Handle
2. Onscreen display (OSD) menu buttons
3. Multimedia Adapter with integrated 8 Watt
Premier•Sound speaker
4. Full features remote control with remote mouse
5. Power On/Off and VGA/DFP cable connectors
6. Rugged magnesium casing
7. Stability Foot
8. Easily removable lamp housing
9. Integrated zoom lens
10. Focus Adjustment

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
2DA-10629-02-003 — 03.15.2001
Compaq MP1800
Microportable Projector
SPECIFICATIONS
Brightness in Lumens(ANSI) 800
Display Resolution Displays native XGA (1024 x 768), but will automatically scale up to XGA from
VGA, SVGA, to XGA or scale down from SXGA to fill screen. Will also scale
from Macintosh 832 x 624 compatible.
Image Quality
Contrast 400:1 contrast full-on; 150:1 checkerboard
Colour SMPTE-C, 24 bit, 16.7M
White Point 7400 degrees
Uniformity 90% or better
Plug and Play Yes
Lens
Type Adjustable Focal Length Zoom lens (1.3x) and manual adjustable focus
Throw Ration (D/W) 2:22 – 2.87:1
Lens Height 6in/15.18 cm
Throw distance 3´ to 30´
Offset 123% of image above centerline
Focus Manual focus via focus ring around lens
Keystoning Digital keystone correction
Portability
General Fits in existing Notebook carrying case along with notebook computer.
Additional dual projector/portable bag also included.
Size/Volume (HxWxD) 8.25 x 2.5 x 9 in and 175 cubic in/ 20.9 x 6.25 x 22.84 cm and 2,861 cubic cm
Weight 4.6 lbs/2.09 kg
Casing Magnesium (Stronger than plastics; 30% lighter than aluminum)
Connectivity
Signal Interface Standard analog VGA, digital DFP, DVI, S-Video, RCA Video, and audio cables
User Interface Standard Compaq 3 button OSD (includes zoom and keystone correction),
Power and Resynch
Standards Supported VGA, DFP, DVI, and P&D
USB Capabilities Not included on projector. 8-pin to USB/RS-232 cable included with Multimedia
adapter for remote mouse functions
Graphics Supports VGA, SVGA, XGA and SXGA resolutions
Approvals/Certifications
CE Yes
C.I.S.P.R. Yes
VDE / TUV Yes
UL Approval Yes
FCC Class B Approval Yes
On-Screen Controls Yes
Language Selection
English Yes
German Yes
French Yes
Spanish Yes
Italian Yes
Brazilian Portuguese Yes
Dutch Yes
AT A
G
LANCE
Compaq MP1800
Microportable Projector
•Designed for mobile professionals
•The MP1800 projectorcomesin a
small form factor
•Plug and Playdevice
•16.7 million digitally correct
colours
•Weighs4.2 lbs (1.9 kg)
•Carriesa two-year, worldwide
limited warranty

.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
QUICKSPECS
3DA-10629-02-003 — 03.15.2001
Compaq MP1800
Microportable Projector
SPECIFICATIONS (continued)
User Controls
Brightness, Contrast Yes
Positioning Yes
Keystone Correction Yes
Digital Zoom Yes
Clock Yes
Clock Phase Yes
Colour Temperature Yes
Picture Control Yes
Picture-In-Picture Control Yes
Menu Location Control Yes
Power Saver Yes
Lamp Hours Yes
Lamp Hours Reset Yes
Standby Lamp Delay Yes
Serial Number Yes
Master Reset Yes
Image Control (upside down,
reverse, upside down and
reversed)
Yes
Tilt Feature 10 degrees and up
Horizontal Frequency 15 to 69 kHz for analog signals and 15 to 60 kHz for digital signals
Vertical Frequency 48 to 85 kHz for analog signals and 48 to 75 kHz for digital signals
Power Consumption 65 Watts (standby)/185 Watts (full power)
Operating Temperature 50°to 104°F/10°to 40°C
Operating Humidity 20% to 80%
Video Projector is capable of displaying video from a VGA or DFP source (example:
DVD on Portable PC). Video and S-Video capability (from DVD, Camcorder, or
VCR) through the included multimedia adapter
Audio Multimedia adapter has integrated 8W (maximum) speaker system.
Power supply 90V to 255V Fully US and European compliant (auto switching): warm restrike
after 45 seconds
Lamp/Module User Replaceable
Warranty The MP1800 comes with a two-year worldwide limited warranty. Advanced Unit
Replacement program (North America and Europe) offers a new or “like new”
replacement of a defective unit in 24 hours (U.S.), 48 hours (ROW) during the
two year warranty period. There is a 90-day or 1,000 hour (whichever comes
first) standard bulb warranty. Within the bulb warranty period, defective bulbs
will be replaced via overnight shipment. Multimedia adapters carry the same
warranty as the projector. Compaq’s toll-free, telephone hotline support is
available 7 x 24 (terms and conditions vary from region to region).
Certain restrictions and exclusions apply. Consult the Compaq Customer
Support Center for details. In Canada, consult the Product Information Centre
at 1-888-88-COMPAQ.
