QuickSpecs
Compaq MP1400 Microportable Projector
DA-10628 Canada — Version 6 — September 10, 2001 1
M ODELS
Compaq MP1400 Microportable Projector
174626-001 – North America
174626-011 – Australia, New Zealand
174626-021 – Europe
174626-AA1 – China
174626-031 – UK
174626 - B24 – International
Option Part Numbers
174963-001 – Multimedia Adapter & Remote Control Option Kit
189789-001 – Lamp

QuickSpecs
Compaq MP1400 Microportable Projector
DA-10628 Canada — Version 6 — September 10, 2001 2
A T A G LANCE
• Designed for mobile professionals
• The MP1400 projector comes in a small form factor
• Plug and Play device
• 16.7 million digitally correct colours
• Weighs 4.2 lbs (1.9 kg)
• Carries a two-year, worldwide limited warranty
S PECIFICATIONS
Brightness in Lumens (ANSI) 800
Display Resolution Displays SVGA (800 x 600), but will automatically scale up to XGA from VGA, SVGA, or XGA and scale down from
XGA to fill screen. Will also scale from Macintosh 832 x 624 compatible.
Image Quality Contrast 400:1 contrast full-on; 150:1 checkerboard
Colour SMPTE-C – 24 bit 16.7M
White Point 7400 degrees
Uniformity 90% or better
Plug and Play Yes
Lens Type Fixed Focal Length (adjustable focus)
Throw Ration (D/W) 1.75:1
Lens Height 6in/15.18 cm
Throw distance 3´ to 30´
Offset 125% of image above centerline
Focus Manual focus via focus ring around lens
Keystoning Digital keystone correction
Portability General Fits in existing Notebook carrying case along with notebook
computer. Additional projector bag also included.
Size/Volume (HxWxD) 8.25 x 2.5 x 9 in and 175 cubic in/ 20.9 x 6.25 x 22.84 cm and
2861 cubic cm
Weight 4.2 lbs/1.9 kg
Casing Magnesium
(Stronger than plastics; 30% lighter than aluminum)
Connectivity Signal Interface Standard analog VGA cable and DFP standard cable
User Interface Standard Compaq 3 button OSD (includes zoom and
keystone correction), Power and Resynch
Standards Supported VGA, DFP, DVI, and P&D
USB Capabilities Not included on projector. 8-pin to USB/RS-232 cable
included with Multimedia adapter for remote mouse functions
Graphics Supports VGA, SVGA, and XGA resolutions

QuickSpecs
Compaq MP1400 Microportable Projector
DA-10628 Canada — Version 6 — September 10, 2001 3
S PECIFICATIONS (continued)
Approvals/Certifications CE Yes
C.I.S.P.R. Yes
VDE / TUV Yes
UL Approval Yes
FCC Class B Approval Yes
On-Screen Controls Yes
Language Selection English Yes
German Yes
French Yes
Spanish Yes
Italian Yes
Brazilian Portuguese Yes
Dutch Yes
User Controls Brightness, Contrast Yes
Positioning Yes
Keystone Correction Yes
Digital Zoom Yes
Clock Yes
Clock Phase Yes
Colour Temperature Yes
Picture Control Yes
Picture-In-Picture Control Yes (When used with the optional Multimedia Adapter)
Menu Location Control Yes
Power Saver Yes
Lamp Hours Yes
Lamp Hours Reset Yes
Standby Lamp Delay Yes
Serial Number Yes
Master Reset Yes
Image Control (upside down, reverse, upside down
and reversed) Yes
Tilt Feature 10 degrees and up
Horizontal Frequency 15 to 69 kHz for analog signals and 15 to 60 kHz for digital signals
Vertical Frequency 48 to 85 kHz for analog signals and 48 to 75 kHz for digital signals
Power Consumption 65 Watts (standby)/185 Watts (full power)
Operating Temperature 50°to 104°F/10°to 40°C (sea level)
Operating Humidity 20% to 80%
Video Projector is capable of displaying video from a VGA or DFP source (ex. DVD on Portable PC). Video and S-Video
capability (from DVD, Camcorder, or VCR) through optical video adapter

QuickSpecs
Compaq MP1400 Microportable Projector
DA-10628 Canada — Version 6 — September 10, 2001 4
S PECIFICATIONS (continued)
Audio Laptop or external audio source, or the optional Multimedia adapter with integrated 8-watt Premier*Sound speaker
system will be used for audio support.
Power supply 90V to 255V Fully US and European compliant (auto switching): warm restrike after 45 seconds
Lamp/Module User Replaceable
Warranty The MP1400 projector comes with a two-year worldwide limited warranty. In Europe and Asia Pacific, the
Advanced Unit Replacement program offers a new or "like new" replacement of a defective unit in 48 hours during
the two-year warranty period. In North America and all other regions, a replacement is available by mail-in. There
is a 90-day standard bulb warranty. Within the bulb warranty period, defective bulbs will be replaced via overnight
shipment. Multimedia adapter comes with a two-year worldwide limited warranty. Compaq telephone hotline
support is available 7 x 24 (terms and conditions vary from region to region).
Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center for details. In Canada,
consult the Product Information Centre at 1-888-88-COMPAQ.
