QuickSpecs
Compaq MP2800 Microportable Projector
DA-10728 Canada — Version 8 — July 24, 2001 1
M ODELS
Compaq MP2800 Microportable Projector
180228-001
Option Part Numbers
215464-001 – Lamp

QuickSpecs
Compaq MP2800 Microportable Projector
DA-10728 Canada — Version 8 — July 24, 2001 2
A T A G LANCE
• 3 lbs (1.4 kg)/118 cubic inches (1937 cubic centimetres)
• 1100 ANSI, 1500 peak lumens
• Texas Instruments DLP technology
• Native XGA resolution
• Integrated zoom lens
• Multimedia adapter and remote control
• Two-year worldwide limited warranty
S PECIFICATIONS
Brightness 1100 ANSI, 1500 peak lumens
Portability General Fits in existing notebook carrying case along with notebook
computer. Additional traveling case also included.
Size/Volume (HxWxD) 7.11 x 2.71 x 8.71 in and 118 cubic in/ 18.06 x 6.89 x 22.13
cm and 1937 cubic cm
Weight 3 lbs/1.36 kg
Casing Magnesium (Stronger than plastics; 30%lighter than
aluminum)
Display Resolution Displays native XGA (1024 x 768) resolution but will automatically scale up from VGA and SVGA or down from SXGA to fill
screen. Will also scale from Macintosh 832 x 624 compatible.
Image Quality Technology Texas Instruments Digital Light Processing (DLP) technology
Contrast 400:1 contrast full-on; 150:1 checkerboard
Colour SMPTE-C, 24 bit, 16.7M
White Point 8000° Kelvin
Uniformity 70%
Plug and Play Yes
Lens Type Adjustable Focal Length Zoom lens (1.2x) and manual
adjustable focus
Throw Ration (D/W) 2.0:1 – 2.4:1
Lens Height 6in/15.18 cm
Throw distance 3.74 to 32.8 feet/114 to 1000 cm
Offset 128% of image above centreline
Focus Manual focus via focus ring around lens
Keystoning Digital keystone correction
Connectivity Signal Interface Standard analog VGA, DVI, S-Video, RCA Video, and audio
cables
User Interface Standard Compaq 3 button OSD (includes zoom and
keystone correction), Power and Re-synch
Standards Supported VGA and DVI
USB Capabilities 8-pin to USB/RS-232 cable included with Multimedia Adapter
for remote mouse functions
Supports VGA, SVGA, XGA and SXGA resolutions
Approvals/Certifications CE Yes
C.I.S.P.R. Yes
VDE / TUV Yes
UL Approval Yes
FCC Class B Approval Yes
Multimedia Adapter Yes
Remote Control Yes
On-Screen Controls Yes

QuickSpecs
Compaq MP2800 Microportable Projector
DA-10728 Canada — Version 8 — July 24, 2001 3
S PECIFICATIONS (continued)
Language Selection English Yes
German Yes
French Yes
Spanish Yes
Italian Yes
Dutch Yes
Japanese
Chinese Yes Yes
User Controls Brightness, Contrast Yes
Positioning Yes
Keystone Correction Yes
Digital Zoom Yes
Clock Yes
Clock Phase Yes
Colour Temperature Yes
Picture Control Yes
HDTV Settings Yes
Menu Location Control Yes
Power Saver Yes
Lamp Hours Yes
Lamp Hours Reset Yes
Standby Lamp Delay Yes
Serial Number Yes
Master Reset Yes
Image Control (upside down, reverse, upside down and
reversed) Yes
Tilt Feature Up to 10 degrees
Horizontal Frequency 31.5 to 80 kHz for analog signals and 31.5 to 60 kHz for digital signals
Vertical Frequency 48 to 85 Hz for analog signals and 48 to 85 Hz for digital signals
Power Consumption 5 Watts (standby)/185 Watts (full power)
Operating Temperature 50°to 104°F/10°to 40°C
Operating Humidity 20% to 80%
Video Projector is capable of displaying video from a VGA or DVI source (example: DVD on Portable PC). Video and S-Video
capability (from DVD, Camcorder, or VCR) through the included multimedia adapter
HDTV Support 720p, 1080i
Audio Multimedia adapter has integrated 8-watt Premier•Sound speaker system.
Power supply 90V to 255V (auto switching): warm restrike after 45 seconds
Lamp/Module User Replaceable
Warranty The MP2800 projector comes with a two-year worldwide limited warranty. In North America, Europe and Asia Pacific, the
Advanced Unit Replacement program offers a new or "like new" replacement of a defective unit in 48 hours during the two-
year warranty period. In all other regions, a replacement is available by mail-in. There is a 90-day standard bulb warranty.
Within the bulb warranty period, defective bulbs will be replaced via overnight shipment. Multimedia adapter comes with a
two-year worldwide limited warranty. Compaq telephone hotline support is available 7 x 24 (terms and conditions vary from
region to region).
Note: Certain restrictions and exclusions apply. For details, consult the Product Information Centre at 1-888-88-COMPAQ.
