Compcooler COMP-GHV-7450 User manual

Compcooler, keep your body cool and comfortable in harsh conditions.
1
Graphene Heating Garment
Graphene Heating Vest
Model: COMP-GHV-7450
Graphene Heating Jacket
Model COMP-GHV-7450
Rev: A
Operation Manual

Compcooler, keep your body cool and comfortable in harsh conditions.
2
COMPCOOLER Introduction:
Compcooler Technology specializes in working for personal cooling & heating systems for harsh
conditions. Compcooler has established its resume as a manufacturer for Military, Electronic,
Medical cooling equipment. The employees at Compcooler’s state of the art manufacturing facility
have been producing liquid heating & cooling systems over 15 years. Quality system: ISO9001 and
AS9100 registered facility. Certifications for major items: CE, FCC, UL, PSE, CB, FDA.
Product Categories
1. ICE Water Circulation Systems
2. Micro Refrigeration Chiller Units
3. Liquid Heating Systems
4. Liquid Cooling & Heating Garment and Pad
5. Customized Cooling Systems
6. Industrial Chiller or Cooling Module
Certifications for major items
Quality System for facility

Compcooler, keep your body cool and comfortable in harsh conditions.
3
Graphene Heating Garment
Description:
Compcooler Graphene Heating Garment used high efficiency graphene heating pads to warm the
body. Graphene heating vest used 5pcs heating pads with 3 levels temperature controller, two pcs
for front pockets, two pcs for back, and one pc for collar. Graphene heating jacket added two extra
pads for arm warming. One touch intelligent controller automatically reduces the power once it
reaches its operating temperature, 7.4V 5A rechargeable battery provides 4-8 hours body
warming. Front zipper design with Modal cotton scuba stretch material, soft mesh liner, easy don
and comfortable warm feeling, 15W and 25W heating capacity, ergonomics vest design, free your
body movements.
Key features
High efficiency Graphene Heating pads generate more heat
One touch intelligent temperature 3 levels controller
Modal Cotton scuba stretch fabric with soft mesh liner
Ergonomics design, easy don and comfort to wear
35W rechargeable battery provides long heating time

Compcooler, keep your body cool and comfortable in harsh conditions.
4
Model-GHV-7450
Components List:
Item
Part number
Description
Quantity
1
COMP-GHV-XX
Graphene Heating Vest
1
2
COMP-RB7450
Rechargeable battery 7.4V 5.0A
1
3
COMP-BC-74
Battery Charger for 7.4V battery
1
4
COMP-PA-1274
Power Adapter 12V to 7.4V
Optional
5
Operation Manual
1
Model: COMP-GHV-1274
Components List:
Item
Part number
Description
Quantity
1
COMP-GHV-XX
Graphene Heating Vest
1
2
COMP-RB7450
Rechargeable battery 7.4V 5.0A
Optional
3
COMP-BC-74
Battery Charger for 7.4V battery
Optional
4
COMP-PA-1274
Power Adapter 12V to 7.4V
1
5
Operation Manual
1
Technical Datasheet for Graphene Heating Garment
Item
Graphene Heating Vest
Graphene Heating Jacket
COMP-GHV-7450
COMP-GHJ-7450
Heating Capacity
20W
28W
Heating Pads
5pcs
7pcs
Voltage Range
5-12V
5-12V
Rated Voltage
7.4V
7.4V
Temp Controller
3 Levels
3 Levels
Battery
7.4V 5A
7.4V 5A
Heating Temp Range
38-70℃(100-158℉)
38-70℃(100-158℉)
Working time
4-8 hours
3-7 hours
Operation Ambient
-20 to 50℃
-20 to 50℃
Storage
-40 to 60℃
-40 to 60℃
Color
Black
Black
Weight
1kg
1.2kg

Compcooler, keep your body cool and comfortable in harsh conditions.
5
Specification
Graphene Heating Garment
Fabric Material: Modal Cotton wrinkle free Scuba
85% Poly 15%Spandex
Color: Black
Liner: stretch mesh
Zipper: YKK Nylon zipper
Heating Unit: water proof Graphene heating pads
Power connection: 4017 male
Controller: 3 levels temperature
Weight:1kg
Size: XS/S, M/L, XL/2XL, 3XL/4XL
Garment Size:
Item
XS/S
M/L
XL/XXL
3XL/4XL
Chest
84
100
108
126
Waist
76
92
100
118
Length
64
68
70
73
Sleeve Length
58
59
60
61
Collar Length
46
48
50
52
Collar Height
4.5
4.5
4.5
4.5
Preparation
1. Battery Charging:
Connect battery with charger plug, red light means charging, green light mean charge
completed.
2. Battery Capacity Checking:
Press the button “battery capacity remaining”, 3 lights mean 80-100%, 2 lights mean 50-70%, 1
light means 40% or less.

Compcooler, keep your body cool and comfortable in harsh conditions.
6
Operation Processes
3. Battery connection: plug the power cord (right pocket) into battery
4. Start Heating:
press the ON/OFF switch over 2 seconds to start heating.
5. Temp level setting:
Short press switch, temp levels changes with 3 colors
Low level: Green color, 38℃100℉
Medium level: Blue color，50℃122℉
High Level: Red color,65℃150℉
6. Stop heating:
Press power switch over 2 seconds, unit turns off.
Clean and Maintenance
Liquid Heating Garment:
Prefer to clean by hand wash then hang dry.
Machine wash with laundry bag, using a front-loading wash machine with cold water on a
gentle/delicate cycle, laundry bag to minimize risk of damaging heating pads connection.
Note: DO NOT BLEACH, NO IRON, NO DRYER, TUMBLE DRY ON LOW

Compcooler, keep your body cool and comfortable in harsh conditions.
7
Garment Storage:
Disconnect the battery, clean the garment, pack the unit for storage.
Battery Storage
1. Shall be in the clean and dry ventilation room at temperature 0℃-35℃(32℉-95℉)
2. Shall keep out of fire or heat and avoid touching corrosion elements
3. Shall be charged every 6 months during storage
4. Keep the battery out of children’s reach
Please STOP using the battery if any abnormal be found!
Safety:
It is important to become thoroughly familiar with the manual and operating characteristics of the
unit. It is the owner’s responsibility to assure proper operator training, installation, operation and
maintenance of the unit. Observe all warning can result in injury to the operator and severe
mechanical damage to the unit.
Warranty:
Compcooler Warrants to the original Purchaser that products sold shall be free from defects
material and workmanship for warranty period not exceed one year from the date of shipment.
Compcooler agrees to correct for the original user of this product, either by repair, or at the
manufacturer’s election by replacement. This warranty shall not apply if the defect or malfunction
was caused by accident, neglect, unreasonable use, improper service, or other causes not arising
out of defects in material or workmanship. The manufacturer’s sole obligation under this warranty
is limited to the repair or replacement of a defective product and shall not in any event be liable for
any incidental or consequential damages of any kind resulting from use or possession of this
product.
