Compcooler COMP-QRB-15 User manual

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
Quick Release Single Chamber
ICE Bladder
Model: COMP-QRB-15/20/30
Rev. A
Operation Manual
Compcooler Technology
Jan. 2021

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
COMPCOOLER Introduction:
Compcooler Technology specializes in working for personal cooling & heating systems for harsh
conditions. Compcooler has established its resume as a manufacturer for Military, Electronic,
Medical cooling equipment. The employees at Compcooler’s state of the art manufacturing facility
have been producing liquid heating & cooling systems over 15 years. Quality system: ISO9001 and
AS9100 registered facility. Certifications for major items: CE, FCC, UL, PSE, CB, FDA.
Product Categories
1. Personal ICE Water Circulation Systems
2. Micro Refrigeration Chiller Units
3. Liquid Heating & Cooling Chiller
4. Liquid Cooling & Heating Garment
5. Industrial Chiller Unit Module
6. Customized Cooling Systems
Certifications for major items
Quality System for facility

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
BACKGROUND OF PERSONAL COOLING SYSTEM
In conditions of extreme heat, people may be at risk of heat stress where body under stress from
overheating. Heat stress is not only a serious condition for workers, but it can result in occupational
illnesses and injuries, heat related discomforts and illnesses include heat exhaustion, heat cramps,
heat rash or even heat stroke. Symptoms can range from profuse sweating to dizziness, cessation
of sweating and collapse. At greatest risk of heat stroke are the elderly, children and people with
medical conditions, however, even young and healthy individuals can succumb to heat if they
participate in strenuous physical activities during hot weather. It will need immediate action to cool
the person until help arrives.
LIQUID CIRCULATION COOLING SYSTEM
Liquid circulation cooling system is an active cooling solution, it can cool the body temperature fast
to decrease incidence of thermal stress and heat stroke while increase comfort, safety, focus and
endurance. Liquid circulation system includes a liquid circulation unit and a cooling garment. Mini
pump circulates cold water from chiller or ICE bladder to cooling channels embedded on the
cooling garment, and continuously flow around the body, it will keep the user’s body temperature at
a comfort and safety range.
BENEFITS OF LIQUID COOLING SYSTEM
Reduction in body core temperature, increased duration.
Reduction in skin temperature, decrease in hydration need
Reduction in heart rate, improve mental acuity
Reduction in sweat rate, maintain physical performance
COMPCOOLER Personal ICE Water Circulation Cooling System (PICS)
PICS includes a liquid circulation unit and liquid cooling garment. Mini pump circulates the cold ICE
water from bladder to micro-tubing cooling channel embedded on the liner of garment, it
continuously flows around the body to reduce body core temperature and keep user at a
comfortable cool range in hot conditions.
Detachable Bladder: 1.5L, 2.0L, 3.0L and 4.0L (Hydration)
Cooler Unit: 6L, 25L Cooler
Pump Control Unit:
ON/OFF mode: cold water circulation only
Flow control mode: 3 levels water flow control
Temp control mode: precise temp control for circulation liquid
Liquid Temperature range: 2°C-10°C (36 °F -50 °F )
Cooling time:
1-3 hours for 1.5L frozen bladder
3-6 hours for 3.0L frozen bladder
4-8 hours for 6L ICE Cooler
8-12 hours for 25L ICE Cooler
Operation Ambient: 10°C-65°C (36 °F -148 °F )

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
Quick Release Single Chamber
ICE Bladder
Model: COMP-QRB-30
Introduction:
COMPCOOLER quick released single chamber ICE Bladder was designed for personal
ICE water cooling systems, user may freeze the bladder or start quick cooling by ice
cubes.
Bladder Size and Applications
•1.5L/2.0L Single Chamber ICE Bladder:
Waistpack ICE Water Cooling Systems
•3.0L Single Chamber ICE Bladder:
Backpack ICE Water Cooling Systems
UniVest ICE Water Cooling Systems
Cooling Features:
•ICE Block Water Circulation
•ICE Cubes Water Circulation

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
Preparation: Unit Connection and Primary Circulation
Bladder Connection:
Fill water into Roll-Top, do not fill above overfill line.
Connect the bladder Outlet/Inlet with backpack unit.
Checking: bladder no leaks, quick fittings connection is fine,
Vest Connection:
Connect backpack unit with cooling vest, once you hear a click, it’s in position.
Checking: Vest no leaks, quick fittings connection is fine.
Start circulation:
Press On/Off switch, Pump circulates water from bladder into micro tubing cooling
channels of cooling vest, then flow back to bladder. User may see the water flow back to
bladder from Inlet fitting.
Checking: Battery works fine, pump works fine.

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
Mode A
Cold Water Circulation
Temp Range: 2℃-5℃(36℉-41℉)
Frozen Bladder
Step I：Bladder Freeze
Fill water into Roll-Top to Fill Line, do not fill
above the Overfill Line.
Water must be below fill line to create an air
packet. After freezing, the air bubble fills with
circulation water for pump.
Step II: Circulation Water
After bladder is frozen, fill small amount
circulation water into the roll top.
Step III: Bladder Connection
Connect the frozen bladder Outlet/Inlet quick
fitting with backpack unit
Step Ⅳ: Start circulation
Press On/Off Switch or temp controller,
pump starts to circulation, user may feel the cooling in 60 seconds
Cooling Performance
Cooling time: 1-2 hours by 1.5L Bladder
2-4 hours by 3.0L Bladder
Temp Range: 2℃-5℃(36℉-41℉)
Hydration: Not Available

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
Mode B：
Quick Cold Water Circulation
Temp Range: 4℃-6℃(39℉-43℉)
ICE Cubes
Step I：Bladder Freeze
Fill ICE Cubes to full from Roll-Top.
Step II: Circulation Water
Fill small amount circulation water from Roll-Top
Step III: Bladder Connection
Connect the bladder Outlet/Inlet quick fitting with backpack unit
Step Ⅳ: Start circulation
Press On/Off Switch or temp controller, pump starts to circulation, user may feel the
cooling in 60 seconds
Cooling Performance
Cooling time: 0.5-1.5hours by 1.5L Bladder
1-2 hours by 3.0L Bladder
Temp Range: 4℃-6℃(39℉-43℉)
Hydration: Not Available

Personal Thermal Technology
_______________________________________________________________________________________
COMPCOOLER
Personal Thermal Technology
Add: A1 HenChangRong Tech Zone, Huaning West Road, Dalang, Longhua, Shenzhen, China
www.compcooler.com
[email protected]
Safety:
It is important to become thoroughly familiar with the manual and operating characteristics
of the unit. It is the owner’s responsibility to assure proper operator training, installation,
operation and maintenance of the unit. Observe all warning can result in injury to the
operator and severe mechanical damage to the unit.
Warranty:
Compcooler Warrants to the original Purchaser that products sold shall be free from
defects material and workmanship for warranty period not exceed one year from the date
of shipment. Compcooler agrees to correct for the original user of this product, either by
repair, or at the manufacturer’s election by replacement. This warranty shall not apply if
the defect or malfunction was caused by accident, neglect, unreasonable use, improper
service, or other causes not arising out of defects in material or workmanship. The
manufacturer’s sole obligation under this warranty is limited to the repair or replacement of
a defective product and shall not in any event be liable for any incidental or consequential
damages of any kind resulting from use or possession of this product.
