Compel HiLo User manual

HiLo Assembly
Instructions
2-Stage Base

HiLo Assembly Instructions
2-Stage Base
Parts Diagram
NOTE: Part 5 (HAT Channel) is only applicable on
tables 60”w and larger

HiLo Assembly Instructions
2-Stage Base
Assembly Instructions
Overview
1. Fasten the top support onto the table top
2. Assemble the beam and column to the top support
3. Assemble the foot to the column
4. Fasten the table frame onto the table top
5. Fasten the control box and handswitch to the table top
6. Connect the motor cables to the control box
7. Connect the handswitch (HS) cable to the control box
8. Connect the supplied power cord (AC) to the control box
9. Attach all cables to the table frame or on the underside of the table top

HiLo Assembly Instructions
2-Stage Base
Assembly Instructions

HiLo Assembly Instructions
2-Stage Base
Assembly Instructions

HiLo Assembly Instructions
2-Stage Base
Assembly Instructions

HiLo Assembly Instructions
2-Stage Base
Assembly Instructions

HiLo Assembly Instructions
2-Stage Base
Operation Information
INITIALIZATION/RESET
The desk must be initialized/reset after any of the following:
- After assembly
- After disconnection from the power supply
- After any impact on the table top.
To initialize/reset, move the table to the lowest position by pressing the DOWN button on the
handswitch until the columns reach the lowest position. Press the DOWN button again until the ta-
ble moves slightly down to the machine zero point and back up to the operation zero point. Re-
lease the DOWN button. If the button is released too soon, the table legs will not move up. Repeat
the reset process. The control box is programmed with a parameter file which controls the table
legs' lower and upper travel limits. Under no circumstance should a control box from one table be
moved to another.
NORMAL HANDSWITCH OPERATION (for all handswitch types)
By pressing the UP or DOWN buttons, the table will move up or down to the desired position. Once
the desired position is reached, let go of the UP or DOWN button. The table legs will stop once they
reach the lower or upper height limits.
PROGRAMMABLE HANDSWITCH OPERATION (optional)
This programmable handswitch is equipped with a display for showing the current table height in
centimeters or inches. The handswitch also will display an error code if an error is detected by the
control box. When an error is detected, the display will show an error code “EXX,” instead of the cur-
rent table height. To resolve the error, see the Troubleshooting Section. The programmable
handswitch also has the ability to save up to four different height positions.
Continued on next page….

HiLo Assembly Instructions
2-Stage Base
Operation Information
PROGRAMMABLE HANDSWITCH OPERATION (continued)
CHANGE THE HEIGHT UNIT (inches or centimeters)
The handswitch can display the table height in either centimeters or inches. With the help of the
S5-menus, the unit of measure can be changed. To change the unit of measure,:
1. Press and hold the 1, 2, and UP buttons until the display shows “S 5”.
2. Confirm by pressing the “S” button. Now the display will have changed. To exit the menu without
making a selection, wait until the height display appears again.
CHANGE THE HEIGHT DISPLAY
If the displayed value does not match the actual height of the table top, the display can be cor-
rected as follows:
1. Press and release the “S” button.
2. Press and hold the DOWN button until the display starts to flash.
3. Change the height shown on the handswitch by pressing the UP or DOWN button to the desired
height. Confirm by pressing the “S” button. To exit the menu without making a selection, wait until
the height display appears again.
SAVE MEMORY POSITION
1. Move the table up or down to the desired height.
2. Press the “S” button (in the display “S -” is shown.)
3. Select a position by pressing one of the four number buttons, 1-4, (the display will show the set-
ting as “S1”).
4. The saved position is confirmed by a double click sound from the control box. The display shows
the current table height. Repeat steps to save a maximum of four different positions.
RECALL MEMORY POSITION
Press and hold the desired memory button (1, 2, 3 or 4) the table moves from the current position
into the saved position. The button must be pressed until the position is reached. If the button is
released, the table will stop short of the desired height.

HiLo Assembly Instructions
2-Stage Base
Troubleshooting Guide

HiLo Assembly Instructions
2-Stage Base
Troubleshooting Guide
Handswitch Display
If it is not possible to resolve an error as described, disconnect the power cord, wait a few minutes and reset the table
again. If the error still occurs, remove the table from the power source and contact customer service.

HiLo Assembly Instructions
2-Stage Base
Safety Information
IMPORTANT SAFETY INSTRUCTIONS. Save these instructions.
DANGER To reduce the risk of electric shock: Always unplug this furnishing from the electrical outlet
before cleaning.
BE CAREFUL WHEN ADJUSTING DESK HEIGHT
Body parts and property can be caught between the moving work surface and an immobile ob-
stacle (such as shelves, furniture, window sills, or walls). Keep at least one inch of clearance
around desk and make sure nothing is in table’s path for its entire range of motion.
BEFORE RAISING OR LOWERING:
• Check surroundings on all sides of desk are clear
• Make sure corded objects will not be pulled off table or cause other objects to fall
• Make sure desk power cord moves freely as desk moves up and down
DO NOT OVERLOAD DESK
To prevent table from tipping or collapsing, make sure
the desk frame is not overloaded by the weight
of tabletop and objects on table. Evenly distribute
load; excess loads near edges can reduce stability
and lead to tip over.
• Do not exceed maximum load (including weight of
desktop) of 200 lb. (91Kg) for two-leg configuration,
• Do not exceed edge load of 25 lb. when positioning
monitors or mounting accessories.
• Do not sit or stand on table

HiLo Assembly Instructions
2-Stage Base
Safety Information
IMPORTANT SAFETY INSTRUCTIONS. Save these instructions.
USE CARE WHEN MOVING DESK
• Clear objects and equipment from table before moving to reduce the risk of tipping over.
• Adjust the desk to its lowest height before moving
• To disconnect, remove plug from outlet
• Do not move a loaded desk
DO NOT OPEN ELECTRICAL COMPONENTS
Do not attempt to service table components. There are no user-serviceable parts inside the mo-
tor control units or table legs. If your table needs service, contact customer service. Never operate
this workstation if it has a damaged cord or plug.
KEEP TABLE FRAME DRY
Keep all electrical components away from water and high humidity. Clean only with a dry or
slightly damp cloth. Do not spray cleaning solutions directly onto table system.
GROUNDING INSTRUCTIONS
This product is equipped with a cord having an equipment-grounding conductor and a ground-
ing plug. Use only the cord provided. Make sure that the product is connected to an outlet having
the same configuration as the plug (as shown in Illustration A) that is properly installed and
grounded in accordance with all local codes and ordinances. Do not modify the plug provided
with the product –if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
No adapters are to be used with this product.
Keep cord away from heated surfaces.

HiLo Assembly Instructions
2-Stage Base
Standards & Certifications
The drive system is tested according to the following standards:
UL 962
Issued: 2014/11/07 Ed: 4 Household and Commercial Furnishings
CSA C22.2#68
Issued: 2009/09/01 Ed: 7 (R2014)
Motor-Operated Appliances (Household and Commercial)
Meets BIFMA X5.5 2014.
compeloffice.com | 773.253.4758 Contact Compel for specification and pricing.
