Pivit Open Frame Desk Installation Guide
What You Received:
-Worksurface(s)
-30”/36”/24” Legs
-Worksurface Support Bar
-Wood Screws
-Mending Plates
Tools You’ll Need:
-Drill with Phillips head bit
-Tape measure

Pivit Desk Installation Guide
1. Lay your worksurfaces out and place the 24"/30”/36” legs on
both ends. The outside corners of the surface should be
flush with the outside corner of the leg.
2A. Attach work surface support bar 1/3rd of the way from
the front of the worksurface. Expand outside portion of
each side of the hat channel to fit in the gap between
surface and leg. Tighten down center bolts.
2B. If two worksurface support bars were received, position
an equal distance 1/3 of the way from the back.
3. Carefully flip desk over. 2 people may be required.

Pivit L-Shaped Desk Installation Guide
3A. Assemble desk as show in 1 & 2. Do not flip desk over yet.
3B. Attached Mending plates to main surface on the right or
left side of desk. Space mending plates evenly.
5. Flip return rightside up and rest free end of return
against and under mending plates. Align with outside
corner and attached top to open side of mending plates.
4. Attach single 24" Open frame leg to end of the return.
Plan view from bottom.

compel0
6. Screw in mending plates. Once attached, carefully flip desk
and return over, onto legs. 2 people may be required.
