Compel Pivit Perch User manual

Pivit Perch Assembly Instructions
NOTES
Check to be sure that you have all parts and hardware.
Remove all wrapping materials, including staples, and packing straps before you start to assemble.
Keep all hardware parts out of reach of children. compeloffice.com | 773.253.4758
Product Information
• Two sizes (Length - 60in, 18in)
• Easy assembly
• Knock-down shipping
•Base available in three colors
STANDARDS & CERTIFICATIONS
Meets 2014 BIFMA X5.4 standards.
WARRANTY
Contact your sales representative for
warranty information.
PARTS DIAGRAM
1. End O-Frame
2. Connecting Beams
3. Mid Support (48in & 60in only)
4. Tube Connectors (48in & 60in only)
5. M6-1.00 X14MM Self Thread Screws
6. #10-12 X 0.50IN Wood Screws
QTY
2
2
1
2
8
8-16
Safety Information
Maximum load for seating unit is 1 3/8 lbs/in^2.
If you are unsure if your preferred seating surface
meets specifications, contact customer service.
USE CARE WHEN MOVING SEATING
SYSTEM
• Remove all objects before moving
• Clear objects and equipment before moving to
reduce risk of tipping over
ASSEMBLY INSTRUCTIONS
The assembly of the seating system to be made in
accordance with this manual. Changes to the seating
system’s frame or improper use may aect the safety,
function, and life of your product.
OVERVIEW
1.Assemble the mid support run (when applicable)
2. Join outer beams with mid support
3. Mount end frame
4. Install the frame to seating surface

Pivit Perch Assembly Instructions
Check to be sure that you have all parts and hardware.
Remove all wrapping materials, including staples, and packing straps before you start to assemble.
Keep all hardware parts out of reach of children. compeloffice.com | 773.253.4758
1.
ASSEMBLE THE MID SUPPORT RUN
(WHEN APPLICABLE)
Latch tube connectors with mid support. Use rubber
mallet and appropriate force for flush alignment.
2.
JOINT OUTER BEAMS WITH MID
SUPPORT
Joint outer beams of the bench with the mid support
assembly. Use rubber mallet and appropriate force
to ensure proper alignment.
NOTES

Pivit Perch Assembly Instructions
NOTES
Check to be sure that you have all parts and hardware.
Remove all wrapping materials, including staples, and packing straps before you start to assemble.
Keep all hardware parts out of reach of children. compeloffice.com | 773.253.4758
MOUNT END FRAME
Mount the connecting beam to the o-frame using
the M6 self-threading screws.
3.
4.
INSTALL THE FRAME TO THE
SEATING SURFACE
Center the table frame and keep edges ush with
the frame of the bench. Use a Phillips head bit to
fasten the frame to seating surface. Adjust glides/
levelers accordingly after frame is fully installed
and ipped up-right.
