Pivit Frame Conference Table Assembly Instructions
96in Table …………………………………………………………………………………. Page 2
120in Table ……………………………………………………………………………….. Page 3
144in Table ……………………………………………………………………………….Page 4
1

PART QTY TOOLS YOU'LL NEED:
36" Shared Leg 2 -Drill with Phillips head bit
30" Shared Leg 1 -Allen wrench
Mending Plate 2 -Tape measure
End section top 2
A
ssembl
y
Instructions
TIPS:
●Assemble table on a carpeted area or on cardboard, close to the area where the table will be in use.
●Never drag the assembled table across the floor. Pick up and lift.
●2 people needed for assembly, and a 3rd person needed to help turn over table in the last step.
Step 1.
Assemblyofthelegs
Assemblethelegbracketstothelegframeandusetheflatheadmachinescrewstofastenthebracketontothelegframe.Twoscrewsperbracket.
Usethesocketheadmachinescrewsonthesideofthelegbracket(asillustratedbelow)andtighten.Twoscrewsperbracket.
Assembletheglidestothebottomoflegwiththesuppliedthreadedglides.
Flatheadscrew
Socketheadscrew
Glide
Step 2.
Installationofthetops
Carefully lay table tops finished side down on carpet or cardboard.
PLEASE NOTE: The table tops DO NOT have pre-drilled pilot holes for mounting the legs.
① Lay the two table tops consecutively as shown on the table bottom view reference.
(Make sure the two unfinished edges from each top are joined together)
②
Measure and position the legs as illustrated below on the bottom view reference. 36" legs on ends and 30" leg inside.
③ Using a power drill, fasten the legs onto the table tops by using the work surface screws.
④ Install the two flat brackets with the included screws between the seams of tops as shown on the bottom view reference.
www.compeloffice.com
PARTS LIST
Pivit 96 OF Conference Table
61/2"fromedgeof legtoedgeoftop.
61/2"
12" 30"Leg
2

PART QTY TOOLS YOU'LL NEED:
36" Shared Leg 2 -Drill with Phillips head bit
30" Shared Leg 1 -Allen wrench
Mending Plate 2 -Tape measure
End section top 2
A
ssembl
y
Instructions
TIPS:
●Assemble table on a carpeted area or on cardboard, close to the area where the table will be in use.
●Never drag the assembled table across the floor. Pick up and lift.
●2 people needed for assembly, and a 3rd person needed to help turn over table in the last step.
Step 1.
Assemblyofthelegs
Assemblethelegbracketstothelegframeandusetheflatheadmachinescrewstofastenthebracketontothelegframe.Twoscrewsperbracket.
Usethesocketheadmachinescrewsonthesideofthelegbracket(asillustratedbelow)andtighten.Twoscrewsperbracket.
Assembletheglidestothebottomoflegwiththesuppliedthreadedglides.
Flatheadscrew
Socketheadscrew
Glide
Step 2.
Installationofthetops
Carefully lay table tops finished side down on carpet or cardboard.
PLEASE NOTE: The table tops DO NOT have pre-drilled pilot holes for mounting the legs.
① Lay the two table tops consecutively as shown on the table bottom view reference.
(Make sure the two unfinished edges from each top are joined together)
②
Measure and position the legs as illustrated below on the bottom view reference. 36" legs on ends and 30" leg inside.
③ Using a power drill, fasten the legs onto the table tops by using the work surface screws.
④ Install the two flat brackets with the included screws between the seams of tops as shown on the bottom view reference.
www.compeloffice.com
PARTS LIST
Pivit 120 OF Conference Table
61/2"fromedgeof legtoedgeoftop.
61/2"
12" 30"Leg
3

PART QTY TOOLS YOU'LL NEED:
36" Shared Leg 2 -Drill with Phillips head bit
30" Shared Leg 2 -Allen wrench
Mending Plate 4 -Tape measure
End section top 2
Middle section top 1
TIPS:
●Assemble table on a carpeted area or on cardboard, close to the area where the table will be in use.
●Never drag the assembled table across the floor. Pick up and lift.
●2 people needed for assembly, and a 3rd person needed to help turn over table in the last step.
Step 1.
Assemblyofthelegs
Assemblethelegbracketstothelegframeandusetheflatheadmachinescrewstofastenthebracketontothelegframe.Twoscrewsperbracket.
Usethesocketheadmachinescrewsonthesideofthelegbracket(asillustratedbelow)andtighten.Twoscrewsperbracket.
Assembletheglidestothebottomoflegwiththesuppliedthreadedglides.
Flatheadscrew
Socketheadscrew
Glide
Step 2.
Installationofthetops
Carefully lay table tops finished side down on carpet or cardboard.
PLEASE NOTE: The table tops DO NOT have pre-drilled pilot holes for mounting the legs.
① Lay the three table tops consecutively as shown on the table bottom view reference.
(The middle top will have unfinshed edges on two sides / The end tops will have unfinished edge on one side)
②
Measure and position the legs as illustrated below on the bottom view reference. 36" legs on ends and 30" legs inside.
③ Using a power drill, fasten the legs onto the table tops by using the work surface screws.
④ Install the four flat brackets with the included screws between the seams of tops as shown on the bottom view reference.
www.compeloffice.com
PARTS LIST
Pivit 144 Conference Table
61/2"fromedgeof legtoedgeoftop.
61/2"
12"
30"Legs
4
