Compel PIV-LAT-TS-35 User manual

PIVIT STORAGE & FILING CREDENZA ASSEMBLY
Table of Contents
NOTE: These instructions are used to assemble the dual ling cabinet credenza, the
dual storage cabinet credenza, and the storage/ling combo credenza congurations.
PART 1
Assemble the Credenza Shell
PART 2
Assemble the Top Supporting Lateral File Cabinet
PART 3
Assemble the Top Supporting Storage Cabinet

Pivit Round 72” x 24” Credenza Shell
Assembly Instructions
compelofce.com | 773.253.4758
NOTES
Place all laminated parts on a cleand and smooth surface such as a rug or carpet to avoid the parts from being scratched.
Check to be sure that you have all parts and hardware.
Remove all wrapping materials, including staples and packing straps before you start to assemble.
Keep all hardware parts out of reach of children.




     
