Comprehensive CDA-HD12018G User manual

CDA-HD12018G
1x2 HDMI Full UHD 4K60 18Gb Splitter (YUV:444)
User manual
V1.0C

1
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or adjusting this product. Please keep this
manual for future reference.
I. Introduction
This 1 x 2 HDMI UHD Splitter with HDCP 2.2 is an advanced solution for splitting a single
HDMI input to two HDMI outputs. It provides high performance audio and video output through
HDMI cables up to 4K2K@60Hz (YUV444) resolution and is capable of receiving and transmitting
up to 18Gbps of bandwidth with no data loss.
II. Features
1.Compliant with HDMI2.0, HDCP2.2 and DVI 1.0
2.Supports video format up to 4k2k@30Hz with 24bit RGB/YcbCR 4:4:4/YCBCR 4:2:2,and up to
4k2k@60Hz with 12bit YCBCR 4:4:4

2
3.Supports 3D frame sequential video format up to 1080p@60
4.Supports high resolution VESA mode video format up to QSXGA@60Hz
5.Supports LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio
6.Supports smart EDID control
III. Package Contents
1. UHD 1x2 HDMI Splitter ------------------------------------------------------------------ 1pc
2. 5V1A DC Power adapter ----------------------------------------------------------------- 1pc
3. Operation Manual ------------------------------------------------------------------------- 1pc
IV. Specifications
1.Video Bandwidth600MHz/18Gbps
2.Input Ports1 × HDMI (Female)
3.Output Ports2 × HDMI (Female)
4.Output Resolution480i ~1080p50/60, 4Kx2K@24/30, 4k2k@60Hz

3
5.ESD ProtectionHuman Body model:±8 kV (air-gap discharge)
±4 kV (contact discharge)
5V/1A DC (US/EU standards, CE/FCC/UL certified)
56 mm (W) × 100 mm (D) × 16 mm (H)
165 g
8. Power Supply
9. Dimensions
10. Weight
11. Chassis Material Metal
0 °C~40 °C/ 32 °F~104 °F12. Operating Temperature
13. Storage Temperature −20 °C ~ 60 °C/−4 °F ~140 °F
14. Relative Humidity20~90 % RH (non-condensing)
15. Power Consumption (Max) 5W

4
V. Operation controls and Functions
Front Panel & Rear Panel
1. POWER: A blue LED will illuminate when the device is connected to the power supply
2. OUT 1, OUT 2: The blue LEDs will light up to indicate which HDMI outputs are connected

5
to an active TV/display/monitor.
3. IN:A blue LED will illuminate when the source is connected to the device.
4. EDID STD: When in “STD” mode, the unit will use its own built-in EDID settings. In this
mode, the video output will be set to 1080p@60Hz and the audio output at LPCM 2CH
Stereo. NOTE: Use this mode if there are display problems in TV Mode.
5. EDID TV: When in “TV” mode, the unit will read the EDID settings of the display device
connected to HDMI OUT 1. If it detects a 4K2K capable EDID setting it will transmit the
signal in that format to all outputs. If no 4K2K capable EDID is detected then the unit will
output the best resolution that all displays can support.
6. HDMI OUT 1~2: Connect each of the HDMI outputs to an HDMI display for simultaneous
HDMI distribution, or cascade the output to another transmitter.
7. HDMI IN: Connect the input port to the HDMI or DVI (adapter not included) output of your
source device.

6
8. DC 5V: Plug the 5V DC power supply into the unit and connect the adaptor to an AC outlet.
VI. Application Example
