Comprehensive CDA-HD18018G User manual

VER 1.0
CDA-HD18018G
1x8 HDMI Full UHD 4K60 18Gb Splitter (YUV:444)

Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully
before connecting, operating or adjusting this product. Please keep this manual
for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shock, lighting strikes, etc. Use of surge
protection systems is highly recommended in order to protect and extend the
life of your equipment.
Table of Contents
1. Introduction...........................................................................................
2. Features.................................................................................................
3. Package Contents...............................................................................
4. Specifications.......................................................................................
5. Operation Controls and Functions.....................................................
6. Application Example...........................................................................
7. FAQ........................................................................................................
1
1
1
2
3
4
4

1. Introduction
2. Features
3. Package Contents
①1× 18Gbps 1×8 HDMI Splitter
②1× 12V/1A DC Locking Power Adapter
③1× User Manual
18Gbps 1x8 HDMI Splitter is an advanced solution for splitting single HDMI
signal to 8 HDMI outputs synchronously. It supports up to 18Gbps bandwidth,
HDMI 2.0b/HDCP 2.2 content up to 4K@60Hz 4:4:4. It can be set the COPY/
AUTO EDID configuration. Supporting the latest features you can be assured
of reliable and high quality HDMI distribution.
1/4
☆HDMI 2.0b, HDCP 2.2 compliant
☆Supports 18Gbps bandwidth
☆Supports resolution up to 4K@60Hz 4:4:4
☆Supports HDR function
☆Supports COPY/AUTO EDID control via dialling the dip switch
☆Compact design for easy and flexible installation

4. Specifications
243mm (W) × 102mm (D) × 16mm (H)
480i ~1080p50/60Hz, 4Kx2K@24/30Hz, 4k2k@60Hz
2/4
Human body model—±8kV (Air-gap discharge) &
±4kV (Contact discharge)
Power Supply
Dimensions
Weight 572g
Housing Metal Enclosure
Silkscreen Color Black
Operation
Temperature -10°C ~ 50°C / 14°F ~ 122°F
Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity 20~90% RH (non-condensing)
Power Consumption 6.15W
ESD Protection
Technical
Video Bandwidth 594MHz/18Gbps
Input Ports 1×HDMI Type A (19-pin female)
1×SERVICE (Micro USB, Update port)
Output Ports 8×HDMI Type A (19-pin female）
Mechanical
Input: AC100 - 240V 50/60Hz, Output: DC 12V/1A
(US/EU standards, CE/FCC/UL certified)
Video Resolution
HDMI Audio Formats
PCM 2CH, LPCM 7.1/5.1CH, Dolby Digital, DTS 5.1,
Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio,
Dolby Atmos and DTS:X
Connections
HDMI Compliance HDMI 2.0b
HDCP Compliance HDCP 2.2

5. Operation Controls and Functions
34
5
EDID COPY
6
EDID AUTO
HDMI OUT 1~8
7 HDMI IN
8 DC 12V Plug the DC 12V power supply into the unit and
connect the adaptor to an AC outlet.
1/5
COPY AUTO
1234 5
678
Number Name Function description
1 POWER LED This blue LED will illuminate when the device
connects power supply.
2 IN LED This blue LED will illuminate when HDMI IN port
connects an active source device.
3 OUT LED These blue LEDs will illuminate when HDMI OUT
ports connects an active display device.
4 SERVICE Firmware update use only.
When dial switch is dialled the ‘COPY’ position,
the unit will read the EDID setting of the HDMI
OUT 1 display device to source deveice, the source
deveice will send again matching the OUT 1 display
device signal to all HDMI outputs. If no HDMI OUT
1 capable EDID is detected then the unit will read
the EDID setting of the HDMI OUT 2 display device
to source device...etc. The priority order is OUT 1 to
OUT 8.
When dial switch is dialled the ‘AUTO’ position,
the unit will compare the EDID setting of the HDMI
OUT 1~8 port displays device then send the best
EDID signal to source device, the source device
will send again matching the display device signal
to all outputs.
Connect to the HDMI source device such as
DVD player or set-top box with an HDMI cable.
Connect to the HDMI display devices such as
TVs or Monitors with an HDMI cable.
3/4

6. Application Example
4/4
UHDTV DVD or Blu-ray Player
Power Supply
UHDTV
7. FAQ
1. Q: Where is this product usually used?
A: It can be used in many place such as Entertainment Room / Home Theater / Lecture
Room / Hall Presentation / Show Room / Demo Room / Public Commercial Display
etc.
2. Q: Which input source and output devices can this product connect to?A: Input
source devices such as Blu-ray / DVD / PS3 / PS4 player or Set-Top-Box or any 6G with
HDCP2.2 source etc. Output with 6G HDMI TV / Display or audio amplifier etc.
Note: To achieve 6G performance will need to collocation with particular HDMI cable to
get the better quality.
3. Q: Does this product require an HDMI line length for the connection interface?A:
According to HDMI line length test, 4K2K@60Hz / 8 bit YUV 4:4:4 is the longest line
length up to 3m, 4K2K@30Hz / 8-bit is the longest line length up to 10m, 1080p@60Hz /
8-bit is the longest line length up to 15m.
The use of “Premium High Speed HDMI” cable is highly recommended.
80 Little Falls Road, Fairfield, NJ 07004
[email protected] l 800.526.0242 l www.ComprehensiveCo.com
