Comprehensive CDA-VGA108A User manual

VGA SPLITTER 1 8 with audio
!
USER MANUAL
Table of Contents
1.0 Introduction……………………………………………………..2
2.0 Specifications…………………………………….………..……2
3.0 Package Contents………………………………………….…..3
4.0 Panel Descriptions…………………………………….…….…3
5.0 Connection and Operation..................................................3
CDA-VGA108A
Cable and Connectivity Com p a n y

VGA SPLITTER 1 8 with audio
"
VGA SPLITTER 1 8 with audio
Dear Customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
1.0 INTRODUCTION
This product is an VGA splitter 1x8 with audio. It distributes the input of the VGA
signal and stereo audio signal into the eight identical outputs simultaneously.This
product has the ability of buffering and amplifying. Each amplifier splitter’s output
can achieve long distance transmission of VGA signal of more than 15 meters.
This VGA Splitter offers solutions for monitors or projectors retail and show site,
and Projector factory, noise, space and security concerns, data center control,
information distribution, conference room presentation, school and corporate
training environments.
1.1 FEATURES
This VGA Splitter has many features that enable it to perform in a superior
manner. Among those features you will find:
Easy to Use: Install in seconds, no need of setting.
Connects VGA source to eight VGA displays at the time.
Connects stereo audio source to eight audio receivers at the time.
Supports highest video resolution up to 1920 x 1200 and 1080p
Supports highest video Amplifier Bandwidth to 500MHz
2.0 SPECIFICATIONS
Signal Inputs/Output
Input video Signal 1.2 volts p-p
Maximum Single Link Range 1920X1200,1080p
Operating Frequency
Vertical Frequency Range30-170 Hz
Video Amplifier Bandwidth 500MHz
Input/Output connector
Input VGA 15pin male
Output VGA 15pin female
Mechanical
Size(L-W-H) 267x115x45MM
Weight(Net) 810g
Warranty
Limited Warranty 2 Years Parts and Labor
Environmental

VGASPLITTER1 8withaudio
３
Operating Temperature 0℃to+70℃
Operating Humidity 10% to85% RH (nocondensation)
Storage Temperature -10℃to+80℃
Storage Humidity 5% to90% RH (no condensation)
PowerRequirement
ExternalPower Supply 5V DC@2A
Powerconsumption (Max) 5W(max)
RegulatoryApprovals
ConverterUnit FCC,CE,UL
PowerSupply UL,CE,FCC
AccessoriesAdapter
ACPower Adapter USstandard, UKstandard andsoon
UserManual
Note:Specificationsaresubjectto changewithout notice.
3.0PACKAGECONTENTS
Before attemptingtousethisunit, pleasecheck the packagingand makesurethe
followingitemsare containedinthe shippingcarton:
1) Mainunit
2) 6feetVGA cable(M-F)
3) 5V/2A DC Power Supply.
4) UsersManual.
4.0PANELDESCRIPTIONS
5.0CONNECTIONAND OPERATION
1) Connectthe supplied VGAcable(M-F)fromVGA deviceintoVGAinputofthe
mainunit.
2) Connectstereoaudiocable(M-M)fromaudiodeviceintothe audioinputof the
mainunit.

VGA SPLITTER 1 8 with audio
3) Connect the VGA cable(M-M) from your displays into the VGA output of the
main unit
4) Connect stereo audio cable(M-M) from audio receiver into the audio output of
the main unit.
5) Insert the DC side of 5v power supply into the main unit and then connect the
AC side of the power supply into the wall outlet.
*please refer to the connection diagram section.
Attention: Insert / Extract cable gently.
5.1 CONNECTION DIAGRAM
4
