Introduction
Package contents
1. Airtop computer
2. Power supply: input 115-230VAC 50/60Hz, 250W output 19VDC 13.15A
3. AC Cord ( North American)
4. HDMI to DVI adapter
5. WiFi 2.4GHz/5GHz band 2 antennas
6. Mini-serial to DB9-male adapter cable
7. M3 screw for HDD x16
8. Airtop decorative vane
Note: For more information about Airtop packagecontent please consult www.airtop-pc.com Specifications
To use Airtop you will need:
Display with DisplayPort or HDMI/DVI input + DVI/HDMI cable adapter if needed
USB keyboard and mouse
For Barebone models –compatibleRAM modules and storage devices with installed operating system
Note: Local resellers may supply Airtop with other AC cord types.

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 6of 25 Airtop owner’s manual
Quick Start Guide
Several Airtop models are sold “Barebone” – without RAM and storage. To install RAM and storage please consult
“Installation and Service” below.
Connecting Airtop
Turn off the display and connect it to Airtop DisplayPort or HDMI connector (use the HDMI to DVI adapter if
needed)
Connect the USB keyboard and mouse to USB2.0 connectors
Plug the Ethernet cable into the Ethernet connector
Mount WiFi antennas on the SMAconnector by turning it clockwise repeatedly until the antenna holds firm
Insert the DC plug into Airtop main DC-in jack
Plug the speakers into the line-out jack
Connect the power supply to the AC cord and plug the cord into AC outlet
WARNING: Operating Airtop in horizontal position will reduce itscooling efficiency.
Booting Windows 7
Upon first power-up, you will be guided through the Windows Welcome procedure which is self-explanatory. The
Windows 7 serial number is printed on the Windows 7 label.
Booting Linux
Linux loads automatically on power up. Upon boot you will be guided through the Linux Mint first-boot setup
procedure.
Installing an operating system
To install Windows please visit: http://fit-pc.com/wiki/index.php/Installing_Windows_7_on_Airtop
Drivers can be found at: http://fit-pc.com/wiki/index.php/Airtop_Software
To install Linux please visit: http://fit-pc.com/wiki/index.php/Airtop:_Installing_Linux_Mint_17
Drivers can be found at: http://www.fit-pc.com/wiki/index.php/Airtop_Software

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 7of 25 Airtop owner’s manual
Hardware specifications
Model
Name
Airtop
Current HW Revision
1.1
Long Term Availability
2022
Processor
Type
Intel 5th Gen Xeon E3-1285L v4
Intel 5th Gen Core i7-5775C
Intel 4th Gen Core i5-4690S
Socket
FCLGA1150
Cores
64-bit quad core
Intel Hyper-Threading Technology
Clock speed
3.4 GHz (turbo boost upto 3.8 GHz)
3.3 GHz (turbo boost upto 3.7 GHz)
3.2 GHz (turbo boost up to3.9 GHz)
TDP
65W
Chipset
Intel C226 Chipset (Lynx Point)
Memory
Supported
2x DIMM 240-pin DDR3 SDRAM memory slots
Up to 32GB (2x 16GB) ECC/Non-ECC DDR3-1866 (referto specific model specs)
Storage
Supported
All SATA3.0 ports (up to 6 Gbps)
4x 2.5” HDD/SSD in disks cartridge
1x M.2 2280 M-key slot
1x mSATA slot
RAID
Intel Rapid Storage Technology
RAID 0/1/5/10 support
Integrated Graphics
GPU
Intel Iris Pro Graphics 6300/ 6200
Up to 7x displays supported (refer to specific model specs)
Display I/F 1
DisplayPort1.2 up to 3840 x 2160 @ 60 Hz
Display I/F 2
HDMI 1.4a upto 4096 x2304 @24 Hz
Display I/F 3
HDMI 1.4a upto 4096 x2304 @24 Hz

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 8of 25 Airtop owner’s manual
Discrete Graphics
GPU
NVIDIA GeForce GTX 950 Graphics Card (refer to specific model)
NVIDIA Quadro M4000 Graphics Card (refer to specific model)
Display I/F 1
DisplayPort1.2 up to 4096×2160 @ 60 Hz
Display I/F 2
DisplayPort1.2 up to 4096×2160 @ 60 Hz
Display I/F 3
DisplayPort1.2 up to 4096×2160 @ 60 Hz
Display I/F 4
HDMI 2.0 / DisplayPort 1.2 up to 4096×2160 @ 60 Hz (refer to specific model)
Audio
Codec
Realtek ALC886 HD audio codec
Audio Output
Digital 5.1-ch TOSLINK output
Analog 2-ch stereo output
3.5mm jack
Audio Input
Analog microphone input
3.5mm jack
Networking
LAN
2x GbE LAN ports (by option additional 4x GbE)
LAN1: Intel I218 GbE PHY (MAC integrated into the chipset) (RJ-45)
LAN2: Intel I210 GbE controller (RJ-45)
LAN3-6: Intel 82574 GbE Controller (RJ-45) (in server models only)
Wireless
WLAN
WLAN 802.11ac (2.4/5GHz dual band Intel 7260HMW)
Bluetooth
Bluetooth 4.0
Cellular
2x micro SIMslot (6 pins)
Connectivity
USB3
4x USB 3.0 (back)
USB2
2x USB 2.0 (back)
4x USB 2.0 (front)
Serial
3x Serial communication ports
COM0: Full RS232 viamini serial connector
COM1: 2-wire RS232 via mini serial connector
COM3: 2-wire RS232 via mini serial connector

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 9of 25 Airtop owner’s manual
Expansion
PCI Express
1x 16 PCIe 3.0 (up to8 Gbps) Graphics Card, Full-height
Mini PCIe 1
Intel 7260HMW WLAN/BT module
Mini PCIe 2
Full-size slot available
FACE Module
4x USB2.0
Advanced Technologies
vPRO/AMT
Yes (N/A in Broadwell desktop processors SKUs)
CPU Virtualization
Yes
AES
Yes
Special Functionality
Auto-On, Wake-on-LAN, Wake-on-Timer, PXE Boot, Watchdog
I3M –Integrated Interactive Information Monitor
BIOS
Vendor
Phoenix
Features
BIOS Legacy mode
UEFI 2.3.1
Secure Boot
Operating System
Supported
Windows 7/8/10; Windows Server 2012 R2
Linux Mint
Operating Conditions
Input Voltage
Unregulated 15 –20VDC input
Dual power input for redundancy
Power Consumption
10W –200W
Operating Temperature
Standard: 0°C to 45°C
Extended: -20°C to 70°C
Industrial: -40°C to 70°C
Relative Humidity
5% to 95% (non-condensing)
MTTF
> 100,000 hours
Enclosure
Material
All Aluminum
Cooling
Passive Zero-FansNatural Airflow (NAF) cooling
Dimensions
10 cm (W) x 30 cm (H) x 25.5 cm (D)
4” (W) x 12” (H) x 10” (D)
Weight
5 kg –5.8 kg

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 10 of 25 Airtop owner’s manual
Airtop features
Airtop I/O
4x DisplayPort
(external graphics)
HDMI 1
HDMI 2
DisplayPort
USB2.0 ports
LAN 1
Kensington
lock
Power input
main/backup
RS232
serial
ports
LAN 2
SMA antenna
ports
Locking
knob
USB3.0
USB2.0
TOSLink
Mic In
Audio out
I3M
monitor
Power
button
NAV
buttons
Top bar
Figure 1 - Airtop I/O ports

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 11 of 25 Airtop owner’s manual
Airtop Motherboard
2x DIMM-240
memoryslots
FACE Module
Mini PCIe
#1 Mini PCIe #2
Micro SIM #2
Micro SIM #1
mSATA slot
M.2 slot
CMOS/RTC
battery 2032
Disks
Cartridge
conn
Figure 2 - Airtop motherboard features

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 12 of 25 Airtop owner’s manual
CPU
Airtop is designed to be used withLGA1150 Intel processors.
Among them Xeon E3-1285L v4, Core i7-5775C and others.
Figure 3 - Intel LGA1150 socketed CPU

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 13 of 25 Airtop owner’s manual
RAM
Airtop motherboard features two DIMM slots 240-pin suitablefor DDR3 SDRAM memory modules. Airtop supports up
to 32 GB in 2x16 GBconfiguration.Intel Core CPUsmemory controllercan operateup to 1600 MT/s,while Intel Server
CPUs can operate up to 1866 MT/s.
Both, ECC and Non-ECC RAM is supported, specific CPU/RAM compatibility is shown in Airtop model specification.
Storage
Airtop has 6 independent SATA3.0 ports, which allow users to install up to 6 storage devices inside Airtop. Four 2.5’’
HDD/SSD drives arranged and mounted in a special disks cartridge for convenient installation and maintenance. Two
additional SATA locations are onboardM.2 2280 and mSATA slotsfor SSD devices in corresponding form factors.
Disks Cartridge
Disk cartridge is a unique storage compartment that allows to store up to four 2.5’’ form factor HDD (hard drives) or
SSD (solid state drives). It is designed to support up to 15mm drives.
Users can install into the disks cartridge up to two 15mm height drives (while the two others can be 7mm or 9.5mm
height), or up to four 7mm and 9.5mm height drives in any arrangement.
For YouTube video please visit:
https://www.youtube.com/watch?v=p7ANwEd14Wk
Figure 4 - Disks cartridge top view
Figure 5 - Disks cartridge side view

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 14 of 25 Airtop owner’s manual
The following images show disks cartridge removal and storage drive replacement in 4simple steps:
Figure 6 –Press top-bar to open left lid
Figure 7 –Unscrew disks-cartridge’s two thumb screws
Figure 8 –Pull out the disk cartridge
Figure 9 –Install disks and assemble in reverse order
RAID
The Intel® RapidStorage Technology (Intel RST®) supports RAID levels 0/1/5/10.
For more information please refer to Airtop wiki: http://fit-pc.com/wiki/index.php/RAID_on_Airtop
mSATA
Airtop features single mSATA slot suitable for connecting standard mSATA SSD modules.
M.2
Airtop featuressingle M.2slot suitable for M.2 2280 SATAonly modules.

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 15 of 25 Airtop owner’s manual
Display
Airtop can drive up to 7 independent 4K displays. Based on the model in use, it features integrated graphicsand
external discrete graphics card.
Integrated Graphics
Intel 5th generation of Core and Xeon processors integrates Intel® Iris™ Pro Graphics 6x00 with three digital display
interfaces (DDI),all with Audio support:
1x DisplayPort 1.2
2x HDMI port 1.4a
To connect Airtop to a DVIdisplay, use the included HDMI to DVI-D adapter. Use a DVI cable to connect the adapter to
the display.
External Graphics
Several Airtop models come with external discrete graphics cards. Both support upto four independent digital display
outputs with Audio support.
NVIDIA GeForce GTX 950 Graphics Card:
3x DisplayPort 1.2
HDMI 2.0
NVIDIA Quadro M4000 Graphics Card:
4x DisplayPort 1.2
Audio
Airtop back panel offers 2 standard 3.5mm jacks for analog audio,and one TOSLink output fordigital audio.
Stereo analog audio output using standard 3.5mm plug
5.1-channels digital audio output using TOSLINK cable
Stereo microphone input using standard 3.5mm plug
Connectivity
USB
Airtop models feature 4x USB 3.0 ports(5 Gbps) and 6x USB 2.0 ports, when all USB3.0 ports and two of USB2.0 ports
are located on the back panel. Four additional combined USB2.0 ports are located on Airtop front when ordered with
FM4U.
Each USB pair is capable of supplying up to 2.5A.
Serial
Airtop features three RS232 serial ports via mini-serial connectors:
1x Full signal set
2x Tx/Rx signals only
One mini-serial to DB9 adapter to connect to standard serial devices is included. Additional adapters can be ordered
from Compulab.

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 16 of 25 Airtop owner’s manual
Networking
LAN
Airtop features two 10/100/1000BaseT Ethernet portsusing standard RJ45 connectors. Use astandard Ethernet
cables to connect. Four additional GbE LAN ports can be installed using FM-LANE4U4 FACE Module.
Wireless Communications
WLAN & Bluetooth
Standard Airtop models ship with WLAN/Bluetooth module - Intel 7260HMW which supports 802.11ac WLAN and
BT4.0. Two antennas are included and should be screwed into the SMA connectors on the back panel.
Cellular
Airtopprovidestheoptionforcellularcommunication.Dedicated3rd partycommunicationmodemcardcanbeinstalled
in one of two mini PCI express onboard slots, while the USIM card is connected to onboard respective micro SIMslots.
Mini PCIe #1 and#2 corresponds to micro SIM slot #1 and #2 respectively as shown in Figure 2.
I3M –Integrated Interactive Information Monitor
The integrated interactive information monitor (I3M) is a GUI system integrated in the front panelof Airtop.
I3M has the followingmajor components:
1. An OLED display
2. Navigation keys
3. Programmable micro-controller
4. Interfaces to power and temperature sensors on the motherboard
5. Serial interfaces for communication with BIOS and operating system
The user can navigate through menus between multiple screens of the I3M that display system information,
temperatures, power consumption and notifications.
I3M firmware can be upgraded.
Options
By navigating I3M screen the following basic information can be displayed:
-Power consumption
-Temperature (CPU/GPU)
-Airtop Part Number (PN)
-Airtop Serial Number (SN)
-MAC addresses of the LAN ports
-Additional parameters can be added by programming new I3M firmware

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 17 of 25 Airtop owner’s manual
Expansion
PCI Express
Airtop allows installing a full-height single slot PCI Express card 2x/4x/8x/16x up to PCIe
gen 3.0 (8 Gbps). The most common use case is an installation of discrete external
graphics card. Airtop-G model features NVIDIA GeForce GTX 950 graphics card, and
Airtop-W/S have NVIDIA Quadro M4000 graphics card installed.
Alternatively other PCI Express cards can be installed, such as Ethernet NIC, professional audio card, Fire-wire or
Thunderbolt extenders, etc.
Notes:
1. Compulab ships some Airtop models with the graphics cards selected and adapted to Airtop. Users cannot
install another graphics card.
2. For installing another PCIecard please consult Compulab technical support: [email protected]
Mini PCI Express
Airtop motherboard has two full-size mini-PCI express slots. One of the slots is normally used for WLAN/BT module.
Half-size modules can be installed with half-to-full size adapter bracket available from Compulab.
Note: When removing the WLAN module make sure to isolate the tips of antenna-cables to avoid short-circuits to the
motherboard.
FACE Module
FACE Modules are extension boards that integrate seamlessly into Airtop to provide custom functionality and I/O
extension. FACE Module is connected to the PC motherboard with a board-to-board mezzanine connector featuring
standard PC interfaces such as PCI Express, USB and serial interfaces.
Compulab offers a catalog of ready-made FACE Modules with various functions. The FACE Module interface is fully
documented and supported to allow 3rd parties to designtheir own FACE Modules.
For more information please visit http://fit-pc.com/wiki/index.php/Fit-PC_Product_Line:FACE_Modules

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 18 of 25 Airtop owner’s manual
Kensington Security Lock
Airtop Kensington lock can be found on the upper sideof its rear panel.
Make sure to set the locking knob to locked state before using Kensington lock. This will prevent opening the case.
Kensington Lock
Locking knob
Figure 10 - Kensington lock and locking knob
Figure 11 - Airtop in locked position

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 19 of 25 Airtop owner’s manual
Operating Conditions and Environmental Characteristics
Power Input
Airtop is powered from unregulated DC voltage in therange between15V –20V, with nominal value of 19V.
19V @ 13.15A power supply is included.
For redundancy purposes Airtop incorporates two power inputs. Airtop can be powered from single power supply, or
from both power inputs simultaneously.
Backup power input
Main power input
Figure 12 - Power inputs
Environmental Characteristics
Airtop is operational underrelative non-condensing humidity in the range 5% to95%, and available in threeoperating
temperature grades, with ambient temperatures as follows:
Standard: 0°C to 45°C
Extended: -20°C to 70°C
Industrial: -40°C to 70°C
Notes:
1. Please consider the temperature ratings of storage devices andextension cards ifyou intend to operate Airtop
at extreme conditions.
2. You may consult Compulab technical support: [email protected]

HaYetsira St. 17, Yokneam, Israel
Tel:
[phone]
Fax:
[phone]
www.airtop-pc.com
www.airtop-pc.com Page 20 of 25 Airtop owner’s manual
Installation and Service
Maintenance
Airtoprequiresnomaintenance.Youshouldnottake Airtopapartotherthanopeningtheclamshelldoorandinstalling.
Taking Airtop apart will void its warranty.
For your convenience Airtop video available: https://www.youtube.com/watch?v=p7ANwEd14Wk
Access Airtop Motherboard
In order to access Airtop mother board follow the steps below:
1. Shut down the computer and disconnect PSU
2. Move locking knob on the rear panel to open position
3. Press the top-bar
4. Open the clamshell door
Figure 13 –Move locking knob to open position
Figure 14 –Press the top-bar
Figure 15 - Airtop from inside
