CompuLab fit-PC2i User manual

fit-PC2i
Owner’s Manual

2
fit-PC2i Owner’s Manual
21-Dec-2010
Introduction
Package contents
Hardware specifications
fit-PC2i features
Quick start guide
Connecting fit-PC2i
Booting Linux (applies to fit-PC2i Linux)
Booting Windows 7 (applies to fit-PC2i Win7)
Maintenance
Affixing rubber feet
Installing Hard Disk
BIOS Setup Utility
BIOS Setup Utility Sections
Warranty and RMA
Warranty
RMA
Tips for saving power
General
In BIOS
In Operating System
For more information and to obtain the latest revision of this document, please visit
www.fit-pc.com

3
Introduction
Package contents
1. fit-PC2i computer
2. 12V DC power supply
3. AC cord with North American or localized standard plug
4. HDMI to DVI adapter
5. 3.5mm to RCA cable
6. 2 mini-USB to USB-A adapters
7. Mini serial to DB-9 cable
8. 4 Rubber feet
9. WiFi antenna (in some models)
To use fit-PC2, you will need:
A display with DVI or HDMI input + DVI or HDMI cable
USB keyboard and mouse
Hardware specifications
CPU
Intel Atom Z510/Z530/Z550 *
Chipset
Intel US15W
RAM
1GB / 2GB DDR2-533 *
Storage
160GB Hard Disk *
Display
DVI up to 1920x1200
Audio
S/PDIF 5.1 channels
Stereo line-out, line-in / mic
WiFi
802.11b/g*
Ethernet
2x 1000BaseT RJ45
USB
4 ports USB 2.0 Hi-Speed 480Mbps
Serial
RS232 full UART
Power
12V DC
__________________
*Depending on model

4
fit-PC2i features
USB
There are 4 USB ports –2 USB A ports on the back and 2 mini-USB on the front. All ports support High-
speed USB 2.0 - 480 Mbps.
Ports on the back are upside down –note when connecting USB plugs.
Serial port
The RS232 serial port is placed on the front panel. Use the provided mini-serial to DB9 cable to connect
to standard serial devices.
DVI
Display interface is DVI-D over HDMI connector.
To connect fit-PC2i to a DVI display
Use the provided HDMI to DVI adapter. Use a DVI cable to connect the adapter to the display.
To connect fit-PC2i to a flat-screen TV
Use an HDMI cable between the HDMI connector and HDMI input of the TV.
Note: Audio should be connected separately.
miniSD
The miniSD socket supports miniSD cards, including SDIO and SDHC.
Audio
There are 2 standard 3.5mm jacks on the back.
left:
S/PDIF using provided cable
Stereo line-out
Right:
Microphone
Stereo line-in

5
LAN
fit-PC2i has 2 10/100/1000BaseT Ethernet ports using a standard RJ45 connectors. Use a standard
Ethernet cable to connect.
The connector has built-in LEDs that are lit when a connection is detected.
WLAN
A WLAN antenna is supplied in models with integrated WiFi and should be screwed into the standard
SMA connector.
Power button
fit-PC2i has a tactile power push-button. It is used for turning on/off the fit-PC and for standby/resume
when supported by the operating system.
A push of at least 5 seconds will always turn off the fit-PC2i.
Note: fit-PC2i supports auto-on. When connected to power it will power-up automatically.
LEDs
fit-PC2i has 3 indicator LEDs.
From left to right –
HDD activity
WLAN enabled / activity
Power
Quick start guide
Connecting fit-PC2i
Turn off the display and connect it to the fit-PC2i HDMI connector (use the HDMI to DVI
adapter if needed).
Connect the USB keyboard and mouse to USB connectors.
Plug the speakers into the line-out jack.
Plug the Ethernet cable into the Ethernet connector.
In fit-PC2i models with WiFi: Mount the WiFi Antenna on the SMA connector by turning it
clockwise repeatedly until the antenna holds firm.
Insert the DC plug into the fit-PC2i DC in jack.
It is recommended to secure the power plug using the adjacent screw.
Connect the power supply to the AC cord and plug the cord into AC outlet. The power LED
should light up as the fit-PC2i boots.

6
Booting Linux (applies to fit-PC2i Linux)
Linux loads automatically on power up.
Login: Username: fit
Password: 111111
Booting Windows 7 (applies to fit-PC2i Win7)
Upon first power-up, you will be guided through the Windows Welcome procedure which is self-
explanatory. The Windows 7 serial number is printed on the Windows 7 label on the bottom of your fit-
PC2i.
Maintenance
The fit-PC2i requires no maintenance. You should not take the fit-PC2i apart - this will void its warranty.
The following operations can be conducted by the user:
Affixing rubber feet
You should stick the rubber feet to the bottom of the fit-PC2i to protect the supporting surface.
Recommended rubber feet placement is shown below:

7
Installing Hard Disk
1. Open the two HDD screws on the HD door as indicated below and remove it.
2. Release spacers using a 5.5mm nut-driver and remove with attached screw.
3. Slide-in HDD.

8
4. Tighten the four HDD screws indicated below.
Removing Hard Disk
1. Open the two HDD screws on base
2. Push out the HDD cover as indicated below. Hard disk will slide out.

9
BIOS Setup Utility
Entering BIOS Setup Utility
Turn off the fit-PC2i.
Turn on while holding down the F2 key.
Screen Layout
Menu is on the top.
The left pane shows configuration items. When an item is highlighted, the right pane displays help for
this item.
Navigation keys are detailed on the bottom.
Restoring BIOS Defaults
Select Exit  Load Setup Defaults and Exit Saving Changes
Booting over LAN (PXE)
Select Chipset Control Sub-Menu Gigabit LAN Enable
Select Chipset Control Sub-Menu LAN PXE BOOT Enable
Save settings and reboot
BIOS Setup Utility Sections
Main
Setting date and time
Large Disk Access Mode [DOS | Other] –select DOS for Windows XP and Linux
Primary Master –hard disk identification. If on-board flash is present it will be automatically
detected.
Primary Slave - Usually automatically detects an installed hard disk
Memory Cache –should be enabled
BIOS Date –indicates when BIOS was generated, useful if you consider BIOS update
Advanced
Installed O/S –select WinXP for Windows and Linux
Keyboard Features - standard keyboard settings
Summary Screen –displays system configuration on boot
QuickBoot mode –perform fewer tests during boot for a quicker boot
Watchdog Timer –enable or disable watchdog timer which reboots on hang
Watchdog Timer Value [sec] –set watchdog delay (31 to 255 seconds)
Start Etherlink - start Etherlink utility for updating BIOS over LAN
Load and run APCC code –used for custom pre-boot chipset configuration

10
Intel
CPU Control Sub-Menu
oHyperthreading –enable or disable hyperthreading
oProcessor Full Speed –select power management policy
oNo Execute –enable or disable NX bit virus protection
oIntel Virtualization –enable or disable virtualization support
Chipset Control Sub-Menu
oAudio –enable or disable audio
oSDIO –enable or disable SD socket
oPCI Express –Root Port 1 –enable or disable PCIe port of Ethernet 1
oPCI Express –Root Port 2 –enable or disable PCIe port of Ethernet 2
Video (Intel IGD) Control Sub-Menu
oGraphic Memory Aperture Size –[256MB | 128MB] Select how much memory to
allocate for graphics. Main memory available is reduced by the amount chosen
Security
This section allows the setting of:
Supervisor password for protecting setup utility
User password for protecting fit-PC2i boot
If you wish to clear a password, set a new, blank password.
Boot
Select a boot sequence between the built-in HDD, built-in flash disk, USB thumb drive (USB key), USB
CDROM, USB HDD, USB Floppy (FDC) and SD.
Booting over LAN (PXE) is enabled separately (see above).
Exit
Standard options for saving/discarding BIOS changes or reloading BIOS defaults.

11
Warranty and RMA
Warranty
CompuLab guarantees products against defects in workmanship and material for a period of
24 months from the date of shipment.
Your sole remedy and CompuLab’s sole liability shall be for CompuLab, at its sole discretion,
to either repair or replace the defective product at no charge.
This warranty is void if the product has been altered or damaged by accident, misuse or
abuse.
RMA
Keep the original package for shipping in case of hardware failure.
In case of HW failure of a fit-PC2i under warranty, please contact the seller of that fit- PC2i.
Please provide the following required information:
fit-PC2i serial number
Name of purchaser
Address
Problem description
If the fit-PC2i was purchased directly from CompuLab, please email [e-mail].
Tips for saving power
General
Working without a connected display automatically disables the graphics controller –saving
up to 20% power.
Disconnect external USB devices when not in use.
In BIOS
Enable CPU C-States (Intel / CPU Control)
If devices are unused –disable them (Intel / Chipset Control)
oAudio
oSDIO
oPCI Express Ports
In Operating System
Use power scheme as follows
Turn of monitor after several minutes not in use
Turn off hard disk after several minutes not in use
System standby after an hour not in use

12
fit-PC2i
Manufacturer: CompuLab Ltd.
This device complies with Part 15 of the
FCC Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
Statement
Changes or modifications to this
equipment not expressly approved by
the party responsible for compliance
(CompuLab Ltd.) could void the user’s
authority to operate the equipment.
Statement
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV
technician for help.
