Comtech EF Data CiM Series Operating and maintenance instructions

Copyright © Comtech EF Data, 2001. All rights reserved. Printed in the USA.
Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, [phone], FAX: [phone].
CiM
Quick-Start Guide
For IP Enabled Satellite Modems
Part Number CD/CIMQSTART.IOM
Rev. 1
Sept. 9, 2002

CiM Quick Start Guide Rev. 1
Preface CD/CIMQSTART.IOM
ii
CUSTOMER SUPPORT
Contact Comtech EF Data Customer Support for:
 Product support or training
 Information on upgrading or returning a product
A Customer Support representative may be reached at:
Comtech EF Data
Attention: Customer Support Department
2114 West 7th Street
Tempe, Arizona 85281 USA
[phone] (Main Comtech EF Data Number)
[phone] (Customer Support Desk)
[phone] FAX
or, E-Mail can be sent to the Customer Support Department at:
[email protected]
1. To return a Comtech EF Data product (in-warranty and out-of-warranty) for
repair or replacement:
2. Request a Return Material Authorization (RMA) number from the Comtech
EF Data Customer Support Department.
3. Be prepared to supply the Customer Support representative with the model
number, serial number, and a description of the problem.
4. To ensure that the product is not damaged during shipping, pack the product
in its original shipping carton/packaging.
5. Ship the product back to Comtech EF Data. (Shipping charges should be
prepaid.)

iii
Table of Contents
CHAPTER 1. GETTING STARTED ............................................................................. 1
1.1 Introduction............................................................................................................................. 1
1.2 Typpical Point-to-Point System Configuration.................................................................... 1
1.3 Equipment List........................................................................................................................ 2
1.4 Equipment Setup..................................................................................................................... 2
1.5 PC Configuration.................................................................................................................... 2
1.6 Transmit and Receive IF Configuration............................................................................... 3
1.7 Basic IP Configuration ........................................................................................................... 3
1.7.1 Main Menu......................................................................................................................... 4
1.7.2 Restoring factory Default Configuration ........................................................................... 4
1.7.3 CiM 1 Configuration.......................................................................................................... 5
1.7.4 CiM 2 Configuration.......................................................................................................... 6
1.7.5 Verification ........................................................................................................................ 7
1.8 Using Encryption .................................................................................................................... 8
1.8.1 CiM 1 Configuration.......................................................................................................... 8
1.8.2 Configuration ..................................................................................................................... 9
1.8.3 Verification ...................................................................................................................... 10
1.9 Other Configuration Items...................................................................................................11
1.9.1 User Names & Passwords................................................................................................ 11
1.9.2 Access Lists ..................................................................................................................... 11
1.9.3 Enabling/Disabling Telnet ............................................................................................... 13
Figures
Figure 1. Typical Point-to-Point System Configuration ................................................................ 1
Figure 2. Main Menu ..................................................................................................................... 4

CiM Quick Start Guide Rev. 1
Preface CD/CIMQSTART.IOM
iv
OVERVIEW OF CHANGES TO PREVIOUS EDITION
CD/CIMQSTART.IOM Rev. 1 replaces part number CD/CIMQSTART.IOM Rev. -.
A summary of the changes made for Rev. 1 includes:
Chapter 1 Changed addresses in Figure 1 and through out the procedure.
ABOUT THIS MANUAL
This manual provides installation and operation information for the Comtech EF Data
CiM-IP Enabled Modems. This is a technical document intended for earth station
engineers, technicians, and operators responsible for the operation and maintenance of
the CiM-IP Enabled Modems.
CONVENTIONS AND REFERENCES
CAUTIONS AND WARNINGS
IMPORTANT
Indicates information critical for proper equipment function.
CAUTION
Indicates a hazardous situation that, if not avoided, may result in minor or moderate
injury. CAUTION may also be used to indicate other unsafe practices or risks of
property damage.
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in
death or serious injury.
METRIC CONVERSION
Metric conversion information is located on the inside back cover of this manual. This
information is provided to assist the operator in cross-referencing English to Metric
conversions.

CiM Quick Start Guide Rev. 1
Preface CD/CIMQSTART.IOM
v
RECOMMENDED STANDARD DESIGNATIONS
Recommended Standard (RS) Designations have been superseded by the new designation
of the Electronic Industries Association (EIA). References to the old designations are
shown only when depicting actual text displayed on the screen of the unit (RS-232, RS-
485, etc.). All other references in the manual will be shown with the EIA designations
(EIA-232, EIA-485, etc.) only.
TRADEMARKS
All product names mentioned in this manual may be trademarks or registered trademarks
of their respective companies and are hereby acknowledged.
REPORTING COMMENTS OR SUGGESTIONS CONCERNING THIS MANUAL
Comments and suggestions regarding the content and design of this manual will be
appreciated. To submit comments, please contact the Comtech EF Data Customer
Support Department.
EMC COMPLIANCE
This is a Class A product. In a domestic environment, it may cause radio interference that
requires the user to take adequate protection measures.
EN55022 COMPLIANCE
This equipment meets the radio disturbance characteristic specifications for information
technology equipment as defined in EN55022.
EN50082-1 COMPLIANCE
This equipment meets the electromagnetic compatibility/generic immunity standard as
defined in EN50082-1.
FEDERAL COMMUNICATIONS COMMISSION (FCC)
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment.

CiM Quick Start Guide Rev. 1
Preface CD/CIMQSTART.IOM
vi
This equipment generates, uses, and can radiate radio frequency energy. If not installed
and used in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference; in which case, users are required to correct the interference at their
own expense.
Note: To ensure compliance, properly shielded cables for DATA I/O shall be used. More
specifically, these cables shall be shielded from end to end, ensuring a continuous shield.

CiM Quick Start Guide Rev. 1
Preface CD/CIMQSTART.IOM
vii
SAFETY COMPLIANCE
EN 60950
Applicable testing is routinely performed as a condition of manufacturing on all units to
ensure compliance with safety requirements of EN60950.
This equipment meets the Safety of Information Technology Equipment specification as
defined in EN60950.
LOW VOLTAGE DIRECTIVE (LVD)
The following information is applicable for the European Low Voltage Directive
(EN60950):
<HAR> Type of power cord required for use in the European Community.
!
CAUTION: Double-pole/Neutral Fusing.
ACHTUNG: Zweipolige bzw. Neutralleiter-Sicherung.
International Symbols:
Symbol Definition Symbol Definition
Alternating Current. Protective Earth.
Fuse. Chassis Ground.
Note: For additional symbols, refer to “Cautions” listed earlier in this preface.

CiM Quick Start Guide Rev. 1
Preface CD/CIMQSTART.IOM
viii
WARRANTY POLICY
This Comtech EF Data product is warranted against defects in material and workmanship
for a period of two years from the date of shipment. During the warranty period, Comtech
EF Data will, at its option, repair or replace products that prove to be defective.
For equipment under warranty, the customer is responsible for freight to Comtech EF
Data and all related custom, taxes, tariffs, insurance, etc. Comtech EF Data is responsible
for the freight charges only for return of the equipment from the factory to the customer.
Comtech EF Data will return the equipment by the same method (i.e., Air, Express,
Surface) as the equipment was sent to Comtech EF Data.
LIMITATIONS OF WARRANTY
The foregoing warranty shall not apply to defects resulting from improper installation or
maintenance, abuse, unauthorized modification, or operation outside of environmental
specifications for the product, or, for damages that occur due to improper repackaging of
equipment for return to Comtech EF Data.
No other warranty is expressed or implied. Comtech EF Data specifically disclaims the
implied warranties of merchantability and fitness for particular purpose.
EXCLUSIVE REMEDIES
The remedies provided herein are the buyer's sole and exclusive remedies. Comtech EF
Data shall not be liable for any direct, indirect, special, incidental, or consequential
damages, whether based on contract, tort, or any other legal theory.
DISCLAIMER
Comtech EF Data has reviewed this manual thoroughly in order that it will be an easy-to-
use guide to your equipment. All statements, technical information, and
recommendations in this manual and in any guides or related documents are believed
reliable, but the accuracy and completeness thereof are not guaranteed or warranted, and
they are not intended to be, nor should they be understood to be, representations or
warranties concerning the products described. Further, Comtech EF Data reserves the
right to make changes in the specifications of the products described in this manual at any
time without notice and without obligation to notify any person of such changes.
If you have any questions regarding the equipment or the information in this manual,
please contact the Comtech EF Data Customer Support Department

1
Chapter 1. Getting Started
Introduction 1
Sample Configuration 1
Equipment List 1
Equipment Setup 2
PC Configuration 2
Transmit and Receive IF Configuration 3
Basic IP Configuration 3
Using Encryption 8
Using QoS 11
Other Configuration Items 11
1.1 INTRODUCTION
This quick start guide will allow a user to configure a pair of CiM-550 or CiM-300L
(referred to CiM in rest of the document) from beginning (i.e. starting from factory
default settings) and be able to pass traffic within minutes. It is assumed that the user is
familiar with the configuration of the base satellite modem.
1.2 TYPICAL POINT-TO-POINT SYSTEM CONFIGURATION
The steps in this guide will lead to following configuration:
IP Address:
Mask:
GW:
172.16.10.100
255.255.255.0
172.16.10.10
PC 1
Satellite IP Modem (CiM 1)
Ethernet Interface (fei0)
IP Address:
Mask:
172.16.10.10
255.255.255.0
HDLC Interfacce (hdl1)
IP Address:
Mask:
10.1.1.1
255.255.255.0
10/100 BaseT
Etherneet Hub
RF or IF
IP Address:
Mask:
GW:
172.17.10.100
255.255.255.0
172.17.10.10
PC 2
Satellite IP Modem (CiM 2)
10/100 BaseT
Etherneet Hub
Ethernet Interface (fei0)
IP Address:
Mask:
172.17.10.10
255.255.255.0
HDLC Interfacce (hdl1)
IP Address:
Mask:
10.1.1.2
255.255.255.0
Figure 1. Typical Point-to-Point System Configuration

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
2
1.3 EQUIPMENT LIST
Following equipment is required:
Item Equipment Quantity Comments
1 CiM-550 Modem 2
2 10/100baseT Ethernet Hub 2 Provided by customer
3 PC with NIC and a terminal
emulation program
2 Provided by customer
4 Console cable (DB-9 to RJ-11) 1 Can be procured from Comtech EF Data
5 Ethernet cables 4 Provided by customer
6 IF cables 2 Provided by customer
(For IF loopback only. Additional
equipment required for RF connectivity.)
7 Traffic Generator such as
SmartBits
1 Provided by customer
1.4 EQUIPMENT SETUP
Step Description
1 Connect each CiM to the PC via the Ethernet Hub.
2 Connect the TX IF on CiM 1 to RX IF of CiM 2 and vice-versa.
3 Connect the DB-9 end of the console cable to the COM1 or COM2 port of the PC and
the RJ-11 end to the console port at the back of CiM 1.
4 Connect CiM 1 and CiM 2 to suitable power supply and turn them ON.
1.5 PC CONFIGURATION
Step Description
1 Set the IP address on PC 1 to 172.16.10.100, mask to 255.255.255.0 and gateway to
172.16.10.10.
2 Set the IP address on PC 2 to 172.17.10.100, mask to 255.255.255.0 and gateway to
172.17.10.10.
Reboot the PCs (if required).

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
3
1.6 TRANSMIT AND RECEIVE IF CONFIGURATION
Step Description
1 Configure the transmit and receive IF parameters on CiM 1 and CiM 2 via the front panel.
Note: The IF parameters can also be set via console menu, Telnet, web interface and SNMP -
but for this exercise, it is recommended that the front panel be used.
2 Set the TxPower to minimum level.
3 Before proceeding to next step, make sure that each CiM is locked to the other CiM.
1.7 BASIC IP CONFIGURATION
Step Description
1 Launch the terminal emulation program - such as HyperTerminal on Microsoft Windows.
2 Select the appropriate COM port (to which the DB-9 end of the console cable is
connected) and configure it for:
 38,400 bps
 8 data bits
 no parity
 1 stop bit
 no hardware flow control
3 Press return and to bring up the Main menu.

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
4
1.7.1 MAIN MENU
Figure 2. Main Menu
To use this onterface, select the appropriate sub-menu or the entry by pressing the
character indicated at the right. Enter xto return to the previous menu.
1.7.2 RESTORING FACTORY DEFAULT CONFIGURATION
The following sections in this guide assume that the CiM is still in factory default
configuration for IP. If that’s not the case, the factory default configuration can be
restored from the menu:
Step Description
1 From the Main Menu, select Administration sub-menu.
2 From the Administration menu, select Operations and Maintenance sub-menu.
3 From the Operations and Maintenance menu, select Database Operations sub-menu
4 From the Database Operations menu, select Restore Factory Default option
5 Confirm when prompted.
This will erase any user configuration and restore the CiM to factory default
configuration.

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
5
1.7.3 CIM 1 CONFIGURATION
CiM has 2 data interfaces - a LAN interface and a WAN interface. The LAN interface is
a 10/100baseT Ethernet port (fei0). The WAN interface is the serial synchronous HDLC
interface (hdl0). The Ethernet MAC address is factory assigned and cannot be changed.
1.7.3.1 SETTING IP ADDRESS(ES)
Step Description
1 From the Main Menu select Interface Configuration sub-menu.
2 From the Interface Configuration Menu select Ethernet Interface (fei0)
3 Set IP Address to 172.16.10.10
4 Set Subnet Prefix Length to 24
5 From the Interface Configuration Menu select Satellite/HDLC Interface (hdl0).
6 Set IP Address to 10.1.1.1
7 Set Subnet Prefix Length to 24
8 Set RX – Enable/Disable and TX – Enable/Disable to Enable.
9 From Receive HDLC Channel Address menu set HDLC Addr 1 to 1 (0x0001)
The other parameters can be left to their factory default settings.
At this point you should be able to ping CiM 1 from PC 1:
10 ping 172.16.10.10
11 ping 10.1.1.1
1.7.3.2 ROUTE TABLE
Step Description
1 From Main Menu, select Route Table sub-menu.
2 Enter 1to configure the first route
3 Enter a suitable name
4 Set IP Address to 172.17.10.0
5 Set Number of Subnet Bits to 24
6 Enter the next hop IP address which is CiM 2’s HDLC IP Address, 10.1.1.2
1.7.3.3 SAVE CONFIGURATION
Save parameters to permanent storage.

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
6
1.7.4 CIM 2 CONFIGURATION
Disconnect RJ-11 end of the console cable from CiM 1 and connect it to CiM 2.
1.7.4.1 SETTING IP ADDRESS(ES)
Step Description
1 From the Main Menu select Network Configuration sub-menu.
2 Set Ethernet IP Address to 172.17.10.10.
3 Set Subnet Prefix Length to 24.
4 Set HDLC IP Address to 10.1.1.2.
The other parameters can be left to their factory default settings.
At this point you should be able to ping CiM 2 from PC 2:
5 ping 172.17.10.10
6 ping 10.1.1.2
1.7.4.2 ROUTE TABLE
Step Description
1 From Transmitter Configuration, sub-menu select Route Table sub-menu.
2 Enter 1to configure the first route
3 Enter a suitable name
4 Set IP Address to 172.16.10.0
5 Set Number of Subnet Bits to 24
6 Enter the next hop IP address which is CiM 1’s HDLC IP Address, 10.1.1.1
1.7.4.3 SAVE CONFIGURATION
Save parameters to permanent storage.

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
7
1.7.5 VERIFICATION
At this point the basic configuration is over and you should be able to:
 Ping PC 1 from PC 2 and vice versa
 Ping CiM 2 from PC 1 and vice versa
 Pass any other data between the 2 PCs

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
8
1.8 USING ENCRYPTION
CiM supports optional DES 56 encryption and decryption for additional security over the
satellite link. Each CiM supports 2 user configurable keys for encryption and 2 user
configurable keys for decryption. Each route can be assigned to be encrypted by Key 1 or
Key 2 or Random (i.e. CiM selects Key 1 or Key 2 randomly on a per IP datagram basis)
or transmitted in Clear (i.e. no encryption).
1.8.1 CIM 1 CONFIGURATION
1.8.1.1 DES CONFIGURATION
Step Description
1 From the Main Menu select Administration sub-menu
2 From the Administration Menu, select the Feature Configuration sub-menu
3 Enable Transmit DES Encryption by pressing T
4 Enable Receive DES Dencryption by pressing R
5 From the Administration Menu, select the DES Configuration sub-menu
6 Set Transmit Key 1 to 0123456789ABCDEF1
7 Set Transmit Key 2 to FEDCBA98765432102
8 Set Receive Key 1 to ABCDEF0123456789
9 Set Receive Key 2 to FEDCBA0123456789
10 From Main Menu, select Route Table sub-menu
11 Select QOS/DES sub-menu
12 Select first route by pressing 1
13 Press Enter for Minimum and Maximum Bandwidth
14 Set DES Key to 2 (i.e. Key 2 - FEDCBA9876543210 will be used to encrypt all
datagrams on this route)
1Customer may select another 16 hex digit key. This key must match the receive Key 1 on the other CiM.
2Customer may select another 16 hex digit key. This key must match the receive Key 2 on the other CiM.

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
9
1.8.2 CONFIGURATION
1.8.2.1 DES CONFIGURATION
Step Description
1 From the Main Menu select Administration sub-menu
2 From the Administration Menu select the Feature Configuration sub-menu
3 Enable Transmit DES Encryption by pressing T
4 Enable Receive DES Dencryption by pressing R
5 From the Administration Menu select the DES Configuration sub-menu
6 Set Transmit Key 1 to ABCDEF01234567893
7 Set Transmit Key 2 to FEDCBA01234567894
8 Set Receive Key 1 to 0123456789ABCDEF
9 Set Receive Key 2 to FEDCBA9876543210
10 From Main Menu select Route Table sub-menu
11 Select QOS/DES sub-menu
12 Select first route by pressing 1
13 Press Enter for Minimum and Maximum Bandwidth
14 Set DES Key to 1 (i.e. Key 2 – ABCDEF0123456789 will be used to encrypt all
datagrams on this route)
1.8.2.2 SAVE CONFIGURATION
Save parameters to permanent storage.
3Customer may select another 16 hex digit key. This key must match the receive Key 1 on the other CiM.
4Customer may select another 16 hex digit key. This key must match the receive Key 2 on the other CiM.

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
10
1.8.3 VERIFICATION
At this point all IP datagrams using route 1 on CiM 1 or CiM 2 are encrypted.
Step Description
1 First verify connectivity by:
 Pinging PC 1 from PC 2 and vice versa
 Pinging CiM 2 from PC 1 and vice versa
 Passing any other data between the 2 PCs
2 Setup a continuous ping from PC 1 to PC 2 (ping 172.17.10.100 -t)
3 Disable decryption (Main Menu -> Administration -> DES Configuration -> Disable
Decryption) on CiM 1 and the ping will start timing out.
4 Enable decryption and the ping will resume.
5 Alternatively disable encryption (Main Menu -> Administration -> DES Configuration -
> Disable Encryption) on CiM 2 and the ping will resume

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
11
1.9 OTHER CONFIGURATION ITEMS
1.9.1 USER NAMES & PASSWORDS
Step Description
1 From the Main Menu select Administration sub-menu.
2 Select Name/Password Configuration sub-menu.
1.9.2 ACCESS LISTS
Access lists can be used to regulate access to CiM to one or more devices or networks. If
access list enforcement is enabled, only devices with IP address within the configured
range are allowed access with:
 ICMP ping
 Telnet
 FTP
 SNMP
 HTML
If enabled, access list restrictions apply to both Ethernet and HDLC interface.
1.9.2.1 CIM 1 CONFIGURATION
Step Description
1 From the Main Menu select Administration sub-menu.
2 Select Access Lists sub-menu
3 Set AccessClient1
a Set IP Address to 172.16.10.0
b Set Number of subnet bits to 24
c Set Access List Enforcement to Enabled
Now CiM 1 can only be pinged from PC 1 (and any other device on network
172.16.10.0/24) or accessed via Telnet or FTP or web interface. PC 2 will not be able to
ping CiM 1 or access via any other means. To allow PC 2 access to CiM 1:

CiM Quick Start Guide Rev. 1
Operation CD/CIMQSTART.IOM
12
4 Set AccessClient2
a Set IP Address to 172.17.10.0
b Number of subnet bits to 24
Now PC 2 (and any other device on network 172.17.10.0/24) will be able to ping CiM 1
or access CiM 1 via Telnet or FTP or web interface.
1.9.2.2 CIM 2 CONFIGURATION
Step Description
1 From the Main Menu select Administration sub-menu.
2 From the Administration menu, select Access Lists sub-menu
3 Set AccessClient1
a Set IP Address to 172.16.10.0
b Set Number of subnet bits to 24
c Set Access List Enforcement to Enabled
Now CiM 2 can only be pinged from PC 1 (and any other device on network
172.16.10.0/24) or accessed via Telnet or FTP or web interface. PC 2 will not be able to
ping CiM 2 or access via any other means. To allow PC 2 access to CiM 2:
3 Set AccessClient2
a Set IP Address to 172.17.10.0
b Set Number of subnet bits to 24
Now PC 2 (and any other device on network 172.17.10.0/24) will be able to ping CiM 2
or access CiM 2 via Telnet or FTP or web interface.
