Chapter 1. INTRODUCTION
1.1 INTRODUCTION
Phase combining is a traditional technique to cost effectively increase the available
output power of an amplifier system. The PCB 4000 (1+1 version), together with 2
SSPAs, form a complete 1+1 phase combined system that doubles the available output
power. The PCB 4000 (1+1) also features a “soft fail” configuration, such that if one
SSPA experiences a failure, the total output power will only be reduced by 3dB, rather
than 6dB.
Figure 1-1. PCB-4000, Phase Combiner Control Box (PCCB)

PCB-4000 Phase Combiner Revision 0
Introduction MN/PCB4000.IOM
1–2
1.2 DESCRIPTION
Figure 1-2 is a block diagram that shows the major components of the phase combined
system.
The Phase Combiner Control Box (PCCB) contains a microprocessor based M&C circuit
board to control the system. The PCCB communicates with each SSPA via control
cables that are attached from the PCCB (J2, J3) to each SSPA. It is also through this
connection that the PCCB receives it prime power to operate. A +24V signal from each
SSPA is diode OR’ed to provide redundant operating power for the PCCB. Control of
the waveguide switches is accomplished via a “Y” cable (J5). The user communicates
with the control box via the System Comm. Connection (J1). (In order to avoid
ambiguities, all communication to each SSPA is also accomplished via the control box
M&C.)
The PCCB provides a weatherized housing for the necessary input RF components. An
input RF redundancy switch selects which RF path is directed to the output. It is
controlled via J6. The output RF signal is fed into an in-phase divider, which equally
splits the signal in phase and amplitude to SSPA #1 and SSPA#2 outputs (J9, J10). The
RF path to SSPA #1 (J9) contains a manually adjustable phase shifter. This phase shifter
is used to equalize the phase difference of each SSPA signal path to achieve maximum
system output power. It is accessible via a small cover panel. This critical component is
factory set and should only be adjusted if needs arise by carefully following an
appropriate alignment procedure. (See sections on alignment and operation). The path to
SSPA #2 (J10) contains a length of coaxial cable that is factory manufactured to provide
equal phase length paths from the RF input to each PCCB output when the adjustable
phase shifter is set to its midpoint. This provides a maximum adjustable phase range.
There are also several isolators inside the PCCB that maintain good system VSWR. The
user should not alter any RF cable inside (or outside) this box that is part of the RF signal
path.
The RF signals from the PCCB are fed to the RF input of the respective SSPA via a set of
phase matched cables. Again, the phase length (and matching) of these cables is essential
to system operation and no substitutes should be used. The routing should not be such to
cause extreme bends.
The output waveguide combining system consists of balanced waveguide lengths, 2
waveguide transfer switches, a “magic-tee” combiner with termination, and couplers for
test and alignment.

PCB-4000 Phase Combiner Revision 0
Introduction MN/PCB4000.IOM
1
–
3
Figure 1-2. Block Diagram

PCB-4000 Phase Combiner Revision 0
Introduction MN/PCB4000.IOM
1–4
This page intentionally left blank.

PCB-4000 Phase Combiner Revision 0
Introduction MN/PCB4000.IOM
1
–
5
.88
R
.13
R.25
7.30
12.70
.45
.43
4X KEY HOLE4X KEY HOLE
1.3 DIMENSIONAL ENVELOPE
Note: All dimensions are in English units; metric units are in the parentheses.
Figure 1-3. Dimensional Envelope
SUM
SSPA1 SSPA2
STATUS

PCB-4000 Phase Combiner Revision 0
Introduction MN/PCB4000.IOM
1–6
This page intentionally left blank.

2
-
1
Chapter 2. CONNECTOR PINOUTS
2.1 EXTERNAL CONNECTORS
Figure 2-1. External Connectors
Table 2-1. External Connectors
Name Ref Des Mating Connector Type Function
System Com J1 ITT Cannon MS3116J14-19P
CEFD CN/MS3116J14-19P Customer RS 232/485 and discrete
interface
SSPA Com 1 J2 ITT Cannon MS3116J14-19P
CEFD CN/MS3116J14-19P Connects to SSPA 1
SSPA Com 2 J3 ITT Cannon MS3116J14-19P
CEFD CN/MS3116J14-19P Connects to SSPA 2
SSPA Com 3(only for 1:2
systems) J4 ITT Cannon MS3116J14-19P
CEFD CN/MS3116J14-19P Connects to SSPA 3(only for 1:2
systems)
SSPA SW OUT J5 ITT Cannon MS3116J14-19P
CEFD CN/MS3116J14-19P Connects to both waveguide switches
RF INPUT SWITCH J6 ITT Cannon MS3116J10-6S
CEFD CN/MS3116J10-6S Drive input, selects either RF IN 1 or 2
RF IN 1 J7 Type N RF input 1
RF IN 2 J8 Type N RF input 2
SSPA OUT 1 J9 Type N RF output to SSPA 1
SSPA OUT 2 J10 Type N RF output to SSPA 2
RF IN 1
J7
SSPA
SW OUT
J5
SSPA
COM 1
J2
SYSTEM
COM
J1
RF IN 2
J8
SSPA
COM2
J3
RF INPUT
SWITCH
J6
SSPA
OUT 2
J10
SSPA
OUT 1
J9

PCB-4000 Phase Combiner Revision 0
Connector Pinouts MN/PCB4000.IOM
2-2
IMPORTANT
To maintain compliance with the European EMC Directive (EN55022,
EN50082-1) properly shielded cables are required for data I/O.
2.1.1 SYSTEM COMM CONNECTOR, J1
Table 2-2. System Comm Connector Pin Assignments, J1
Pin
#Signal Function Signal Name
ARS485_+RX Customer communications interface
BRS485_-RX Customer communications interface
CRS485_+TX Customer communications interface
DRS485_-TX Customer communications interface
ERS232_RD Customer communications interface
FSpare Reserved for future use
GRS232_TD Customer communications interface
HSystem Fault NO When there is a summary fault in the PCB-4000, this pin (NO) will be tied
to the Fault Common pin.
JSystem Fault NC When there is not a summary fault in the PCB-4000, this pin (NC) will be
tied to the Fault Common pin.
KFault Common
LSSPA 1 Fault
NO When there is a fault with SSPA 1, this pin (NO) will be tied to the Fault Common pin.
MSSPA 1 Fault
NC When there is not a fault with SSPA 1, this pin (NC) will be tied to the Fault Common pin.
NGround
PSSPA2Fault
NO When there is a fault with SSPA 2, this pin (NO) will be tied to the Fault
Common pin.
RSSPA2Fault
NC When there is not a fault with SSPA 2, this pin (NC) will be tied to the
Fault Common pin.
SSystem Mute SSPA will be muted if this pin is grounded
TSSPA3Fault
NO When there is a fault with SSPA 3, this pin (NO) will be tied to the Fault
Common pin. (Only for 1:2 systems)
USSPA3Fault
NC When there is not a fault with SSPA 3, this pin (NC) will be tied to the
Fault Common pin. (Only for 1:2 systems)
VGround GND
