USER GUIDE
UGH050-0816
Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
www.conairgroup.com
ESE Series Central Chillers
ESE Series Scroll Central Chillers

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
It’s a good idea to record the model and serial number(s) of your equipment and the date you
received it in the User Guide. Our service department uses this information, along with the manual
number, to provide help for the specific equipment you installed.
Please keep this User Guide and all manuals, engineering prints and parts lists together for
documentation of your equipment.
Date:
Manual Number: UGH050-0816
Serial Number(s):
Model Number(s)
DISCLAIMER:Conair shall not be liable for errors contained in this User Guide or for incidental, consequential
damages in connection with the furnishing, performance or use of this information. Conair makes no warranty
of any kind with regard to this information, including, but not limited to the implied warranties of
merchantability and fitness for a particular purpose.
Copyright 2016 l Conair l All rights reserved
Please record your equipment’s
model and serial number(s) and
the date you received it in the
spaces provided.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
Page Intentionally Blank

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
Table of Contents
Foreword .............................................................................................................................................................................1
Safety Guidelines ...............................................................................................................................................................2
General Data .......................................................................................................................................................................3
Table 1 – ESEW Series Single-Circuit Water-Cooled Condenser Chiller General Data (60 Hz) ............................................3
Table 2 – ESEW Series Dual-Circuit Water-Cooled Condenser Chiller General Data (60 Hz)................................................4
Table 3 – ESER Series Single-Circuit Remote Air-Cooled Condenser Chiller General Data (60 Hz) ...................................5
Table 4 – ESER Series Dual-Circuit Remote Air-Cooled Condenser Chiller General Data (60 Hz).......................................6
Table 5 – Remote Air-Cooled Condenser General Data (60 Hz).......................................................................................................7
Pre-Installation...................................................................................................................................................................8
Receiving Inspection...............................................................................................................................................................................................8
Unit Storage...............................................................................................................................................................................................................8
Installation - Chiller Mechanical......................................................................................................................................9
Unit Location .............................................................................................................................................................................................................9
Rigging.........................................................................................................................................................................................................................9
Chilled Water Piping...............................................................................................................................................................................................9
Condenser Water Piping.......................................................................................................................................................................................9
Water Pressure Gauges .........................................................................................................................................................................................10
Master Temperature Sensor ................................................................................................................................................................................10
Figure 1 – Standard Flow Chiller Coolant Circuit Pressure Drop (10 through 30 Ton Single-Circuit Chillers) ...............11
Figure 2 – Standard Flow Chiller Coolant Circuit Pressure Drop (40 through 80 Ton Single-Circuit Chillers) ...............12
Figure 3 – Standard Flow Chiller Coolant Circuit Pressure Drop (20 through 160 ton Dual-Circuit Chillers).................13
Figure 4 – Standard Flow Chiller Coolant Circuit Pressure Drop (80 through 160 ton Dual-Circuit Chillers).................14
Figure 5 – High Flow Chiller Coolant Circuit Pressure Drop (10 through 25 ton Single-Circuit Chillers).........................15
Figure 6 – High Flow Chiller Coolant Pressure Drop (30 through 50 ton Single-Circuit Chillers) .......................................16
Figure 7 – High Flow Chiller Coolant Pressure Drop (20 through 50 ton Dual-Circuit Chillers) ..........................................17
Figure 8 – High Flow Chiller Coolant Pressure Drop (60 through 100 ton Dual-Circuit Chillers)........................................18
Figure 9 – Condenser Water Circuit Pressure Drop (10 through 30 ton Single-Circuit Chillers) .........................................19
Figure 10 – Condenser Water Circuit Pressure Drop (40 through 80 ton Single-Circuit Chillers).......................................20
Figure 11 – Condenser Water Circuit Pressure Drop (20 through 60 ton Dual-Circuit Chillers)..........................................21
Figure 12 – Condenser Water Circuit Pressure Drop (80 through 160 ton Dual-Circuit Chillers) .......................................22
Installation - Remote Air-Cooled Condenser ................................................................................................................23
Location .......................................................................................................................................................................................................................23
Mounted Legs and Lifting (10 ton Single-Circuit and 20-ton Dual-Circuit Units) .........................................................................24
Mounted Legs and Lifting (all except 10 ton Single-Circuit and 20-ton Dual-Circuit Units).....................................................25
Interconnecting Refrigerant Piping ..................................................................................................................................................................26
Refrigeration Piping Design ................................................................................................................................................................................26
Figure 13 – Condenser Located with No Elevation Difference..........................................................................................................27
Figure 14 – Condenser Located above Chiller Unit................................................................................................................................27
Figure 15 - Condenser Located Below Chiller Unit ................................................................................................................................28
Determining Equivalent Line Length................................................................................................................................................................28
Table 6 – Equivalent Lengths of Fittings.....................................................................................................................................................29
Liquid Line Sizing .....................................................................................................................................................................................................29
Table 7 – Liquid Line Sizes for R410A..........................................................................................................................................................30

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
Discharge (Hot Gas) Line Sizing.........................................................................................................................................................................32
Figure 16 – Vertical Riser Traps......................................................................................................................................................................32
Figure 17 - Double Discharge Riser..............................................................................................................................................................33
Table 8 – Discharge Line Sizes for Chiller (inches OD) .........................................................................................................................33
Table 9 - Upflow Discharge Line Sizes for R410A (inches OD)..........................................................................................................34
Calculating System Refrigerant and Oil Charge ..........................................................................................................................................34
Table 10 – Combined Chiller and Remote Condenser Summer Refrigerant Charge ...............................................................34
Table 11 - Field Piping R-410A Refrigerant Charge per 100 Feet of Run (Lbs.) .........................................................................34
Oil Charge Determination ....................................................................................................................................................................................35
Setting Condenser Fan Controls........................................................................................................................................................................35
Table 12 - Condenser Fan Pressure Settings (psig) ...............................................................................................................................35
Installation - Electrical ......................................................................................................................................................36
Table 13 – ESEW & ESER Single-Circuit Chiller Electrical Data (60 Hz) ..........................................................................................37
Table 14 – ESEW & ESER Single-Circuit Chiller with Standard Flow Pump Set Electrical Data (60 Hz).............................38
Table 15 – ESEW & ESER Single-Circuit Chiller with High Flow Pump Set 1 Electrical Data (60 Hz)..................................39
Table 16 – ESEW & ESER Single-Circuit Chiller with High Flow Pump Set 2 Electrical Data (60 Hz)..................................Error! Book
Table 17 – ESEW & ESER Dual-Circuit Chiller Electrical Data (60 Hz) .............................................................................................40
Table 18 – ESEW & ESER Dual-Circuit Chiller with Standard Flow Pump Set Electrical Data (60 Hz) ................................41
Table 19 – ESEW & ESER Dual-Circuit Chiller with High Flow Pump Set 1 Electrical Data (60 Hz).....................................42
Table 20 – ESEW & ESER Dual-Circuit Chiller with High Flow Pump Set 2 Electrical Data (60 Hz).....................................Error! Book
Table 21 – Single-Circuit Remote Condenser Electrical Data (60 Hz).............................................................................................43
Table 22 – Dual-Circuit Remote Condenser Electrical Data (60 Hz)................................................................................................44
General Control Operation ...............................................................................................................................................45
System Initialization................................................................................................................................................................................................45
Figure 18 – Start-Up Splash Screen..............................................................................................................................................................45
Home - System Overview .................................................................................................................................................46
System Overview......................................................................................................................................................................................................46
Figure 19 – ESEW System Overview .............................................................................................................................................................46
Figure 20 – ESER System Overview...............................................................................................................................................................46
Table 23 – System Overview Functions.......................................................................................................................................................46
Home – Full Screen ............................................................................................................................................................ 47
Figure 21 – Full Screen ......................................................................................................................................................................................47
Warnings .....................................................................................................................................................................................................................47
Figure 22 – Warning Screen ............................................................................................................................................................................47
Home – Pump Control (Optional) ...................................................................................................................................48
Pump Control Screen (Optional) .......................................................................................................................................................................48
Figure 23 – Pump Control Screen .................................................................................................................................................................48
Pump VFD Control Screen (Optional)..............................................................................................................................................................48
Figure 24 – Pump VFD Control Screen .......................................................................................................................................................48
Menu 1 - Overview ............................................................................................................................................................49
Figure 25 – Menu 1 Screen ..............................................................................................................................................................................49
Table 24 – Menu 1 Functions..........................................................................................................................................................................50
Menu 1 - Alarms.................................................................................................................................................................51
Alarms Active.............................................................................................................................................................................................................51
Figure 26 – HMI Alarm Handler .....................................................................................................................................................................51
Alarm History.............................................................................................................................................................................................................51

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
Figure 27 – Alarm History.................................................................................................................................................................................51
Alarm Setup ...............................................................................................................................................................................................................52
Figure 28 – Alarm Setup ...................................................................................................................................................................................52
Alarm Glycol...............................................................................................................................................................................................................52
Figure 29 – Alarm Setup ...................................................................................................................................................................................52
Menu 1 – Metric Units/Imperial Units ............................................................................................................................53
Menu 1 - Compressor Data ..............................................................................................................................................53
Compressor Data Screen ......................................................................................................................................................................................53
Figure 30 – Circuit Data Screen (Water-Cooled Condenser Chiller)................................................................................................53
Figure 31 – Circuit Data Screen (Remote Air-Cooled Condenser Chiller) .....................................................................................54
Compressor Data Screen – Interlocks..............................................................................................................................................................54
Figure 32 – Interlocks.........................................................................................................................................................................................54
Figure 33 – Critical Interlocks..........................................................................................................................................................................55
Figure 34 – Refrigeration Interlocks.............................................................................................................................................................55
Menu 1 – Modbus/BAS ..................................................................................................................................................... 56
Modbus RTU/BAS Setup Screen ........................................................................................................................................................................56
Figure 35 – Modbus Setup Screen................................................................................................................................................................56
Figure 36 – Modbus Word Data Screen .....................................................................................................................................................56
Figure 37 – Modbus Bit Data Screen ...........................................................................................................................................................56
Menu 1 – EXV1 Expansion Valve Setup ..........................................................................................................................57
EXV1 Expansion Valve Setup Screen ................................................................................................................................................................57
Figure 38 – EXV1 Expansion Valve Setup Screen....................................................................................................................................57
Table 25 – EXV1 Setup Parameters...............................................................................................................................................................57
Menu 1 – EXV2 Hot Gas Bypass Setup............................................................................................................................58
EXV2 Hot Gas Bypass Setup Screen (Optional)............................................................................................................................................58
Figure 39 – EXV2 Hot Gas Bypass Screen ..................................................................................................................................................58
Table 26 – EXV2 Setup Parameters...............................................................................................................................................................58
Menu 1 – Water Regulating Valve (WRV) Setup ..........................................................................................................59
WRV Water Regulating Valve Setup Screen .................................................................................................................................................59
Figure 40 – WRV Setup Screen.......................................................................................................................................................................59
Table 27 – WRV Setup Parameters ...............................................................................................................................................................59
Menu 1 – Compressor Staging/PID.................................................................................................................................60
Compressor Staging Setup Screen ...................................................................................................................................................................60
Figure 41 – Compressor Staging Setup Screen .......................................................................................................................................60
Table 28 – Compressor Staging Setup Parameters................................................................................................................................60
Compressor Staging Graph Screen ..................................................................................................................................................................61
Figure 42 – Compressor Staging Graph Screen ......................................................................................................................................61
Table 29 – Compressor Staging Graph Parameters...............................................................................................................................61
Compressor Staging Local Screen ....................................................................................................................................................................62
Figure 43 – Compressor Staging Local Screen ........................................................................................................................................62
Table 30 – Compressor Staging Local Parameters.................................................................................................................................62
Menu 1 – Inputs/Outputs .................................................................................................................................................63
Inputs / Outputs Screens......................................................................................................................................................................................63
Figure 44 – Digital Inputs Screen ..................................................................................................................................................................63
Figure 45 – Digital Outputs Screen ..............................................................................................................................................................63
Figure 46 – Analog Inputs Screen .................................................................................................................................................................63

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
Figure 47 – Analog Outputs Screen .............................................................................................................................................................63
Menu 1 – Temperature Offsets........................................................................................................................................64
RTD Temperature Offset Adjustment ..............................................................................................................................................................64
Figure 48 – RTD Temperature Offsets Screen ..........................................................................................................................................64
Menu 1 – Process Control................................................................................................................................................. 65
Leaving/Entering Sensor Selection ...................................................................................................................................................................65
Figure 49 – Process Control Screen..............................................................................................................................................................65
Menu 1 – Pumps Setup .....................................................................................................................................................66
Pump Setup Screen.................................................................................................................................................................................................66
Figure 50 – Pump Setup Screen.....................................................................................................................................................................66
Table 31 – Pump Setup Parameters .............................................................................................................................................................66
Menu 1 – Tank Setup.........................................................................................................................................................67
Tank Setup Screen...................................................................................................................................................................................................67
Figure 51 – Tank Setup Screen.......................................................................................................................................................................67
Menu 1 – Counters.............................................................................................................................................................68
Counters Screens .....................................................................................................................................................................................................68
Figure 52 – Counters 1 Screen .......................................................................................................................................................................68
Figure 53 – Counters 2 Screen .......................................................................................................................................................................68
Figure 54 – Counters 3 Screen .......................................................................................................................................................................68
Menu 2 - Overview ............................................................................................................................................................69
Figure 55 – Menu 2.............................................................................................................................................................................................69
Table 32 – Menu 2 Functions..........................................................................................................................................................................69
Menu 2 – Hardware Options Selected ............................................................................................................................70
Hardware Options Screen ....................................................................................................................................................................................70
Figure 56 – Hardware Options Screen ........................................................................................................................................................70
Menu 2 - Date/Time ..........................................................................................................................................................71
Menu 2 – System Menu ....................................................................................................................................................71
Menu 2 – Defaults..............................................................................................................................................................71
Figure 57 – Restore Factory Settings ...........................................................................................................................................................71
Figure 58 – Factory Settings Restored ........................................................................................................................................................72
Menu 2 – Remote Setpoint Setup ...................................................................................................................................72
Figure 59 – Remote Setpoint Setup Screen ..............................................................................................................................................72
Menu 2 – Remove SD Storage .........................................................................................................................................73
Menu 2 – Trending ............................................................................................................................................................73
Figure 60 – Trending Screen ...........................................................................................................................................................................73
Menu 2 – Remote Mode ...................................................................................................................................................73
Menu 2 – PLC Link Setup ..................................................................................................................................................74
PLC Link (Master/Slave) Setup Screen.............................................................................................................................................................74
Figure 61 – PLC Link Setup Screen ...............................................................................................................................................................74
Figure 62 – PLC Link Word Data Screen .....................................................................................................................................................74
Figure 63 – PLC Link Bit Data Screen ...........................................................................................................................................................74
Menu 2 – Touch Calibration .............................................................................................................................................75

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
Start-Up............................................................................................................................................................................... 75
Step 1 - Connect Main Power.............................................................................................................................................................................75
Step 2 - Fill Coolant Circuit ..................................................................................................................................................................................76
System Fill Water Chemistry Requirements ..............................................................................................................................................76
Table 33 – Fill Water Chemistry Requirements........................................................................................................................................77
Table 34 - Recommended Glycol Solutions..............................................................................................................................................77
Step 3 - Check Condenser....................................................................................................................................................................................77
Water-Cooled Condenser Check...................................................................................................................................................................77
Remote Air-Cooled Condenser Check ........................................................................................................................................................77
Step 4 – Check Refrigerant Valves ....................................................................................................................................................................77
Step 5 – Verify Freezestat Setting .....................................................................................................................................................................78
Step 6 – Turn On Control Power........................................................................................................................................................................78
Step 7 – Establish Coolant Flow.........................................................................................................................................................................78
Step 8 – Intial Unit Operation .............................................................................................................................................................................78
Low-Ambient Start-Up (Remote Condensers) .........................................................................................................................................78
Preventive Maintenance ...................................................................................................................................................79
Once a Week .............................................................................................................................................................................................................79
Once a Month ...........................................................................................................................................................................................................80
Once Every Three Months ....................................................................................................................................................................................80
Once a Year ................................................................................................................................................................................................................80
Cleaning the Operator Interface......................................................................................................................................81
General Troubleshooting..................................................................................................................................................82
Preventive Maintenance Checklist .................................................................................................................................. 83
Drawings .............................................................................................................................................................................83
Warranty Information.......................................................................................................................................................84

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
Page Intentionally Blank

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
1
Foreword
The central chiller contains on or more refrigeration
circuits intended to chiller or cool a process fluid. As
an option, a process fluid reservoir and pumping
system is available to create a complete packaged
chiller system.
The intent of this manual is to serve as a guide for
placing our central chiller in service and operating
and maintaining it properly. Improper installation
can lead to poor equipment performance or severe
equipment damage. Failure to follow the installation
instructions may result in damage not covered by
your warranty. It is extremely important that a
qualified refrigeration installation contractor perform
all installation line sizing and piping. Please supply
these instructions to your authorized refrigeration
contractor. This manual is for our standard product
line with supplements as required to accommodate
any special items provided for a specific application.
The written information contained in this manual, as
well as various drawings, are intended to be general
in nature. Unit specific drawings are included with
the equipment for troubleshooting and servicing of
the unit. Additional copies of drawings are available
upon request. We strive to maintain an accurate
record of all equipment during the course of its
useful life.
Due to the ever-changing nature of applicable
codes, ordinances, and other local laws pertaining to
the use and operation of this equipment we do not
reference them in this manual. There is no substitute
for common sense and good operating practices
when placing any mechanical equipment into
operation. We encourage all personnel to familiarize
themselves with this manual's contents. Failure to do
so may unnecessarily prolong equipment down time.
The chiller uses chemical refrigerants for heat
transfer purposes. This chemical is sealed and tested
in a pressurized system containing ASME coded
vessels; however, a system failure will release it.
Refrigerant gas can cause toxic fumes if exposed to
fire. Place these units in a well-ventilated area,
especially if open flames are present.
Failure to follow these instructions could result in a
hazardous condition. The standard refrigerant used
in these units is a hydro fluorocarbon (HFC) trade
named R-410A. We strongly recommend a
refrigerant management program be implemented
which includes a survey of all equipment to
document the type and quantity of refrigerant in
each machine. In addition, we recommend only
licensed and EPA certified service technicians work
on our refrigeration circuits. Follow good piping
practices and the information in this manual to
ensure successful installation and operation of this
equipment. We are not responsible for liabilities
created by substandard piping methods and
installation practices external to the chiller.
We trust your equipment will have a long and useful
life. If you should have any questions, please contact
the Conair Service Department specifying the serial
number and model number of the unit as indicated
on the nameplate.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
2
Safety Guidelines
Observe all safety precautions during installation,
start-up, and service of this equipment. The
following is a list of symbols used in this manual and
their meaning.
General Warning
High Voltage Warning
Sharp Element Warning
Hot Surface Warning
Flammable Material Warning
Explosive Material Warning
General Mandatory Action
Wear Eye Protection
Wear Protection Gloves
Wear Ear Protection
Disconnect Before Carrying Out Maintenance or
Repair
Connect an Earth Terminal to Ground
Only qualified personnel should install, start-up, and
service this equipment. When working on this
equipment, observe precautions in literature, and on
tags, stickers, and labels located on the equipment.
WARNING: Any use or misuse of this equipment
outside of the design intent may cause injury or
harm.
WARNING: Vent all refrigerant relief valves in
accordance to ANSI/ASHRAE Standard 15, Safety
Code for Mechanical Refrigeration. This
equipment should be located within a well-
ventilated area. Inhalation of refrigerant can be
hazardous to your health and the accumulation
of refrigerant within an enclosed space can
displace oxygen and cause suffocation.
WARNING: This equipment contains hazardous
voltages that can cause severe injury or death.
WARNING: This equipment contains refrigerant
under pressure. Accidental release of refrigerant
under pressure can cause personal injury and or
property damage.
WARNING: This equipment may contain fan
blades or other sharp edges. Make sure all fan
guards and other protective shields are securely
in place.
WARNING: The exposed surfaces of motors,
refrigerant piping, and other fluid circuit
components can be very hot and can cause burns
if touched with unprotected hands.
CAUTION: Disconnect and lock out incoming
power before installing, servicing, or
maintaining the equipment. Connecting power to
the main terminal block energizes the entire
electric circuitry of the unit. A power supply
provides 24 VDC control power. Electric power at
the main disconnect should be shut off before
opening access panels for repair or maintenance.
CAUTION: Wear eye protection when installing,
maintaining, or repairing the equipment to
protect against any sparks, debris, or fluid leaks.
CAUTION: The chiller will exceed 70 dBA sound
pressure at 1 meter distance and 1 meter
elevation when operating. Wear ear protection
as required for personnel comfort when
operating or working in close proximity to the
chiller.
CAUTION: Wear protective gloves when
installing, maintaining, or repairing the
equipment to protect against any sparks, debris,
or fluid leaks.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
3
General Data
Table 1 – ESEW Series Single-Circuit Water-Cooled Condenser Chiller General Data (60 Hz)
Model
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
010S
015S
020S
025S
030S
040S
050S
060S
080S
General
Cooling Capacity tons1
10.9 16.1 22.1 27.3 32.6 42.2 53.3 68.4 86.2
Set Point Range °F
20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80
Process In/Out (in.)-Standard
1½ 1½ 2 2 2½ 2½ 3 3 4
Process In/Out (in.)-High Flow
2 2½ 2½ 3 3 4 4 4 N/A
Condenser Water In/Out (in.)
1½ 2 2 2½ 2½ 3 3 4 4
Refrigerant Charge (lbs of
R410A)
10 30 30 35 40 50 70 80 100
Min Unloaded Capacity ton
5.5 8.1 11.1 13.7 16.2 21.0 25.9 33.9 42.6
with HGBP Option ton
2.7 4.0 5.5 6.8 8.1 10.5 13.0 17.0 21.3
Dimensions, Weights, Amps (Chiller Only)
A - Length inches {mm}
68 {1727}
68 {1727}
68 {1727}
68 {1727}
72 {1829}
100 {2540}
100 {2540}
100 {2540}
105 {2667}
B - Width inches {mm}
24 {610}
24 {610}
24 {610}
24 {610}
24 {610}
24 {610}
30 {762}
30 {762}
30 {762}
C- Height inches {mm}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
Ship Weight lbs {kg}
1200 {544}
1300 {590}
1400 {635}
1500 {680}
1600 {726}
1800 {816}
2000 {907}
2200 {998}
2400 {1089}
Operating Weight lbs {kg}
1400 {635}
1500 {680}
1600 {726}
1700 {771}
1800 {816}
2000 {907}
2200 {998}
2400 {1089}
2600 {1179}
MCA @ 460/3/60 amps2
22
34
42
53
62
71
86
124
165
Dimensions, Weights, Amps (Chiller with Standard Flow Reservoir Option , 10°F ∆T Process, 10°F ∆T Chiller)
Reservoir Capacity gal {l}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
450 {1703}
450 {1703}
Pump Models
(Process/Chiller)
5D/1.5A
5D/1.5A
5D/1.5A
5D/1.5A
7.5D/2A
10D/2A
10D/3A
10D/3A
15D/3A
Process Connection Size inch
1½
1½
2
2
2½
2½
3
3
4
D - Length inches {mm}
84 {2134}
84 {2134}
84 {2134}
96 {2438}
96 {2438}
96 {2438}
96 {2438}
108 {2743}
108 {2743}
E - Width inches {mm}
72 {1829}
72 {1829}
76 {1930}
76 {1930}
76 {1930}
92 {2337}
92 {2337}
95 {2413}
100 {2540}
F - Height inches {mm}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
Ship Weight lbs {kg}
2600 {1179} 2700 {1225} 2900 {1315} 3200 {1451} 3900 {1769} 4100 {1860} 4700 {2132} 5100 {2313} 5400 {2449}
Operating Weight lbs {kg}
4900 {2223} 5000 {2268} 5100 {2313} 5500 {2495} 6200 {2812} 6400 {2903} 7000 {3175} 7400 {3357} 7800 {3538}
MCA @ 460/3/60 amps2
32 43 50 62 75 86 104 141 188
Dimensions, Weights, Amps (Chiller with High Flow Reservoir Option 1, 5°F ∆T Process, 10°F ∆T Chiller)
Reservoir Capacity gal {l}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
650 {2461}
650 {2461}
Pump Models
(Process/Chiller)
5D/1.5A
7.5D/1.5A
10D/1.5A
10D/1.5A
10D/2A
15D/2A
15D/3A
20D/3A
25D/3A
Process Connection Size
inches
2
2½
2½
3
3
4
4
4
6
D - Length inches {mm}
84 {2134}
84 {2134}
84 {2134}
84 {2134}
120 {3048}
132 {3353}
132 {3353}
132 {3353}
132 {3353}
E - Width inches {mm}
72 {1829}
72 {1829}
72 {1829}
76 {1930}
76 {1930}
92 {2337}
92 {2337}
92 {2337}
92 {2337}
F - Height inches {mm}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
Ship Weight lbs {kg} 2800 {1270} 2900 {1315} 3100 {1406} 3400 {1542} 4100 {1860} 4300 {1950}
4900 {2223} 5350 {2427} 5650 {2563}
Operating Weight lbs {kg}
5960 {2699} 6050 {2744} 6150 {2790} 6550 {2971} 7250 {3289} 7450 {3379} 8050 {3651} 9050 {4105} 9450 {4286}
MCA @ 460/3/60 amps2
32 46 57 68 78 91 109 153 201
1Cooling capacity when cooling water with 50°F {10°C} set point, 60°F {16°C} return, 85°F {29°C} condenser water, R-410A
refrigerant.
2MCA is Minimum Circuit Amps (for wire sizing), complie with NEC, Section 430-24.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
4
Table 2 – ESEW Series Dual-Circuit Water-Cooled Condenser Chiller General Data (60 Hz)
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
ESEW-
020D
030D
040D
050D
060D
080D
0100D
0120D
0160D
General
Cooling Capacity tons1
21.7 32.1 44.3 54.7 65.2 84.5 106.7 136.9 172.5
Set Point Range °F
20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80
Process In/Out (in.)-Standard
2 2½ 2½ 3 3 4 4 4 6
Process In/Out (in.)-High Flow
2½ 3 4 4 4 6 6 6 N/A
Condenser Water In/Out
inches
2 2½ 3 3 4 4 4 6 6
Refrig Charge/Cir (lbs of R410A)
10 30 30 35 40 50 70 80 100
Mini Unloaded Capacity ton
5.5 8.0 11.1 13.7 16.2 20.9 25.9 33.9 42.6
with HGBP Option ton 2.7 4.0 5.5 6.8 8.1 10.5 13.0 16.9 21.3
Dimensions, Weights, Amps (Chiller Only)
A - Length inches {mm}
75 {1905}
75 {1905}
80 {2032}
80 {2032}
85 {2159}
115 {2921}
115 {2921}
118 {2997}
125 {3175}
B - Width inches {mm}
56 {1422}
56 {1422}
56 {1422}
56 {1422}
56 {1422}
56 {1422}
56 {1422}
56 {1422}
56 {1422}
C- Height inches {mm}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
Ship Weight lbs {kg}
2500 {1134}
2600 {1179}
2800 {1270}
3000 {1361}
3200 {1451}
3600 {1633}
4000 {1814}
4400 {1996}
4800 {2177}
Operating Weight lbs {kg}
2700 {1225}
2800 {1270}
3000 {1361}
3200 {1451}
3400 {1542}
3800 {1724}
4200 {1905}
4600 {2087}
5000 {2268}
MCA @ 460/3/60 amps2
42
63
76
99
115
131
161
232
311
Dimensions, Weights, Amps (Chiller with Standard Flow Reservoir Option , 10°F ∆T Process, 10°F ∆T Chiller)
Reservoir Size gal {l}
275 {1041} 275 {1041} 275 {1041} 275 {1041} 450 {1703} 450 {1703} 700 {2650} 700 {2650} 1000 {3785}
Pump Models (Process/Chiller)
5D/1.5A 7.5D/2A 10D/2A 10D/3A 10D/3A 15D/3A 15D/5A 20D/7.5F 25D/10E
Process Connection Size inch
2 2½ 2½ 3 3 4 4 4 6
D - Length inches {mm} 108 {2743} 108 {2743} 108 {2743} 120 {3048} 132 {3353} 132 {3353} 132 {3353} 144 {3658} 144 {3658}
E - Width inches {mm}
78 {1981}
78 {1981}
78 {1981}
90 {2286}
90 {2286}
1053
{26746}
1103
{28016}
1103
{28016}
1103
{28016}
F - Height inches {mm}
75 {1905} 75 {1905} 75 {1905} 75 {1905} 75 {1905}} 75 {1905} 75 {1905} 75 {1905} 90 {2286}
Ship Weight lbs {kg}
4100 {1860} 4300 {1950} 4400 {1996} 4700 {2132} 5400 {2449} 5600 {2540} 6200 {2812} 6600 {2994} 7000 {3175}
Operating Weight lbs {kg} 6400 {2903} 6600 {2994} 6700 {3039} 7000 {3175} 7700 {3493} 7900 {3583} 8500 {3856} 8900 {4037}
10450
{4740}
MCA @ 460/3/60 amps2
51 76 93 117 133 154 187 269 356
Dimensions, Weights, Amps (Chiller with High Flow Reservoir Option 1, 5°F ∆T Process, 10°F ∆T Chiller)
Reservoir Size gal {l}
400 {1514} 400 {1514} 400 {1514} 400 {1514} 650 {2461} 650 {2461} 1000 {3785} 1000 {3785} 1000 {3785}
Pump Models (Process/Chiller)
10D/1.5A
10D/2A 15D/2A 15D/3A 20D/3A 25D/3A 30D/5A 40D/7.5F 40D/10E
Process Connection Size inch
2½ 3 4 4 4 6 6 6 6
D - Length inches {mm} 108 {2743} 108 {2743} 108 {2743} 120 {3048} 132 {3353} 132 {3353} 144 {3658} 144 {3658} 144 {3658}
E - Width inches {mm}
78 {1981}
78 {1981}
78 {1981}
90 {2286}
90 {2286}
1053
{26746}
1103
{28016}
1103
{28016}
1103
{28016}
F - Height inches {mm}
76 {1930}
76 {1930}
76 {1930}}
76 {1930}
76 {1930}
90 {2286}
90 {2286}
90 {2286}
90 {2286}
Ship Weight lbs {kg} 4300 {1950} 4500 {2041} 4600 {2087} 4900 {2223} 5650 {2563} 5850 {2654} 6500 {2948} 6900 {3130} 7300 {3311}
Operating Weight lbs {kg}
7450 {3379}
7650 {3470}
7750 {3515}
8050 {3651}
9350 {4241}
9500 {4332}
11000
{4990}
11400
{5171}
11800
{5352}
MCA @ 460/3/60 amps2
59 79 98 122 145 168 207 294 375
1Cooling capacity when cooling water with 50°F {10°C} set point, 60°F {16°C} return, 85°F {29°C} condenser water, R-410A
refrigerant.
2MCA is Minimum Circuit Amps (for wire sizing), complies with NEC, Section 430-24
3To keep the shipping dimensions within a 102” width for standard flatbed shipping, the condenser inlet manifold is removed
for shipment.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
5
Table 3 – ESER Series Single-Circuit Remote Air-Cooled Condenser Chiller General Data (60 Hz)
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
010S
015S
020S
025S
030S
040S
050S
060S
080S
General
Cooling Capacity tons1
10 14.9 20.4 25.2 30.1 38.9 48.9 63.6 78.7
Set Point Range °F
20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80
Process In/Out (in.)-Standard
1½ 1½ 2 2 2½ 2½ 3 3 4
Process In/Out (in.)-High Flow
2 2½ 2½ 3 3 4 4 4 N/A
Refrigerant Discharge Line inch
⅞1⅛1⅛1⅜ 1⅜1⅝1⅝1⅝2⅛
Refrigerant Liquid Line inch
⅝⅞⅞1⅛ 1⅛1⅛1⅛1⅜1⅝
Refrigerant Charge (lbs of
R410A)
Varies based on refrigerant system piping
Min Unloaded Capacity ton 5.0 7.4 10.0 12.5
14.8 19.1 23.6 30.9 38.5
with HGBP Option ton
2.5 3.7 5.0 6.2 7.4 9.6 11.8 15.5 19.3
Dimensions, Weights, Amps (Chiller Only)
A - Length inches {mm}
68 {1727}
68 {1727}
68 {1727}
68 {1727}
72 {1829}
102 {2591}
102 {2591}
102 {2591}
105 {2667}
B - Width inches {mm}
24 {610}
24 {610}
24 {610}
24 {610}
24 {610}
24 {610}
30 {762}
30 {762}
30 {762}
C- Height inches {mm}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
Ship Weight lbs {kg}
1200 {544}
1300 {590}
1400 {635}
1500 {680}
1600 {726}
1800 {816}
2000 {907}
2200 {998}
2400 {1089}
Operating Weight lbs {kg}
1300 {590}
1400 {635}
1500 {680}
1600 {726}
1700 {771}
1900 {862}
2100 {953}
2300 {1043}
2500 {1134}
MCA @ 460/3/60 amps2
22
34
42
53
62
71
86
124
165
Dimensions, Weights, Amps (Chiller with Standard Flow Reservoir Option , 10°F ∆T Process, 10°F ∆T Chiller)
Reservoir Capacity gal {l}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
275 {1041}
450 {1703}
450 {1703}
Pump Models (Process/Chiller)
5D/1.5A
5D/1.5A
5D/1.5A
5D/1.5A
7.5D/2A
10D/2A
10D/3A
10D/3A
15D/3A
Process Connection Size inch
1½
1½
2
2
2½
2½
3
3
4
D - Length inches {mm}
84 {2134}
84 {2134}
84 {2134}
96 {2438}
96 {2438}
96 {2438}
96 {2438}
108 {2743}
108 {2743}
E - Width inches {mm}
64 {1626}
64 {1626}
64 {1626}
76 {1930}
76 {1930}
92 {2337}
92 {2337}
96 {2438}
98 {2489}
F - Height inches {mm}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
Ship Weight lbs {kg}
2600 {1179} 2700 {1225} 2900 {1315} 3200 {1451} 3900 {1769} 4100 {1860} 4700 {2132} 5100 {2313} 5400 {2449}
Operating Weight lbs {kg}
4900 {2223} 5000 {2268} 5100 {2313} 5500 {2495} 6200 {2812} 6400 {2903} 7000 {3175} 7400 {3357} 7800 {3538}
MCA @ 460/3/60 amps2
32 43 50 62 75 86 104 141 188
Dimensions, Weights, Amps (Chiller with High Flow Reservoir Option 1, 5°F ∆T Process, 10°F ∆T Chiller)
Reservoir Capacity gal {l}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
650 {2460}
650 {2460}
Pump Models (Process/Chiller)
5D/1.5A
7.5D/1.5A
10D/1.5A
10D/1.5A
10D/2A
15D/2A
15D/3A
20D/3A
25D/3A
Process Connection Size inch
2
2½
2½
3
3
4
4
4
6
D - Length inches {mm}
84 {2134}
84 {2134}
84 {2134}
96 {2438}
96 {2438}
96 {2438}
96 {2438}
108 {2743}
108 {2743}
E - Width inches {mm}
64 {1626}
64 {1626}
64 {1626}
76 {1930}
92 {2337}
92 {2337}
92 {2337}
96 {2438}
98 {2489}
F - Height inches {mm}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
Ship Weight lbs {kg}
2800 {1270} 2900 {1315} 3100 {1406} 3400 {1542} 4100 {1860} 4300 {1950} 4900 {2223} 5350 {2427} 5650 {2563}
Operating Weight lbs {kg}
5950 {2699} 6050 {2744} 6150 {2790} 6550 {2971} 7250 {3289} 7450 {3379} 8050 {3651} 9050 {4105} 9450 {4286}
MCA @ 460/3/60 amps2
32 46 57 68 78 91 109 153 201
1Cooling capacity when cooling water with 50°F {10°C} set point, 60°F {16°C} return, 95°F {35°C} condenser air, R-410A
refrigerant.
2MCA is Minimum Circuit Amps (for wire sizing).

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
6
Table 4 – ESER Series Dual-Circuit Remote Air-Cooled Condenser Chiller General Data (60 Hz)
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
ESER-
020D
030D
040D
050D
060D
080D
0100D
0120D
0160D
General
Cooling Capacity tons1
20.4 29.9 40.7 50.5 60.2 77.8 97.7 127.2 157.5
Set Point Range °F
20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80 20 to 80
Process In/Out (in.)-Standard
2 2½ 2½ 3 3 4 4 4 6
Process In/Out (in.)-High Flow
2½ 3 4 4 4 6 6 6 N/A
Refrig Discharge Line/Circuit
inches
⅞1⅛1⅛1⅜1⅜1⅝1⅝1⅝2⅛
Refrig Liquid Line/Circuit
inches
⅝⅞⅞1⅛1⅛1⅛1⅛1⅜1⅝
Refrig Charge/Cir (lbs of
R410A)
Varies based on refrigeration system piping
Min Unloaded Capacity ton
5.0 7.3 10.0 12.5 14.7 19.1 23.6 30.9 38.5
with HGBP Option ton
2.5 3.7 5.0 6.2 7.4 9.6 11.8 15.5 19.3
Dimensions, Weights, Amps (Chiller Only)
A - Length inches {mm}
75 {1905}
75 {1905}
80 {2032}
80 {2032}
89 {2261}
105 {2667}
105 {2667}
110 {2794}
125 {3175}
B - Width inches {mm}
48 {1219}
48 {1219}
48 {1219}
48 {1219}
48 {1219}
48 {1219}
48 {1219}
48 {1219}
52 {1321}
C- Height inches {mm}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
69 {1753}
Ship Weight lbs {kg}
2500 {1134}
2600 {1179}
2800 {1270}
3000 {1361}
3200 {1451}
3600 {1633}
4000 {1814}
4400 {1996}
4800 {2177}
Operating Weight lbs {kg}
2700 {1225}
2800 {1270}
3000 {1361}
3200 {1451}
3400 {1542}
3800 {1724}
4200 {1905}
4600 {2087}
5000 {2268}
MCA @ 460/3/60 amps2
42
63
76
99
115
131
161
232
311
Dimensions, Weights, Amps (Chiller with Standard Flow Reservoir Option , 10°F ∆T Process, 10°F ∆T Chiller)
Reservoir Size gal {l}
275 [1041}
275 {1041}
275 {1041}
275 {1041}
450 {1703}
450 {1703}
700 {2650}
700 {2650}
1000 {3785}
Pump Models
(Process/Chiller)
5D/1.5A
7.5D/2A
10D/2A
10D/3A
10D/3A
15D/3A
15D/5A
20D/7.5F
20D/10E
Process Connection Size inch
2 2½ 2½ 3 3 4 4 4
6
D - Length inches {mm}
108 {2743}
108 {2743}
108 {2743}
120 {3048}
132 {3353}
132 {3353}
132 {3353}
144 {3658}
144 {3658}
E - Width inches {mm}
74 {1880}
74 {1880}
74 {1880}
74 {1880}
74 {1880}
92 {2337}
102 {2591}
102 {2591}
102 {2591}
F - Height inches {mm}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
75 {1905}
Ship Weight lbs {kg}
3900 {1769} 4000 {1814} 4200 {1905} 4500 {2041} 5200 {2359} 5400 {2449} 6000 {2722} 6400 {2903}
6800 {3084}
Operating Weight lbs {kg}
6200 {2812} 6300 {2858} 6400 {2903} 6800 {3084} 7500 {3402} 7700 {3493} 8300 {3765} 8700 {3946}
9100 {4128}
MCA @ 460/3/60 amps2
51 76 93 117 133 154 187 269
356
Dimensions, Weights, Amps (Chiller with High Flow Reservoir Option 1, 5°F ∆T Process, 10°F ∆T Chiller)
Reservoir Size gal {l}
400 {1514}
400 {1514}
400 {1514}
400 {1514}
650 {2461}
650 {2461}
1000 {3785}
1000 {3785}
1000 {3785}
Pump Models
(Process/Chiller)
10D/1.5A
10D/2A
15D/2A
15D/3A
20D/3A
25D/3A
30D/5A
40D/7.5F
40D/10E
Process Connection Size inch 2½ 3 4 4 4 6 6 6 6
D - Length inches {mm}
108 {2743}
108 {2743}
108 {2743}
120 {3048}
132 {3353}
132 {3353}
132 {3353}
144 {3658}
144 {3658}
E - Width inches {mm}
74 {1880}
74 {1880}
74 {1880}
74 {1880}
74 {1880}
92 {2337}
102 {2591}
102 {2591}
102 {2591}
F - Height inches {mm}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
76 {1930}
90 {2286}
90 {2286}
90 {2286}
90 {2286}
Ship Weight lbs {kg} 4100 {1860} 4200 {1905} 4400 {1996} 4700 {2132} 5450 {2472} 5650 {2563} 6300 {2858} 6700 {3039} 7100 {3221}
Operating Weight lbs {kg}
7250 {3289}
7350 {3334}
7450 {3379}
7850 {3561}
9150 {4150}
9350 {4241}
10800
{4899}
11200
{5080}
11160
{5262}
MCA @ 460/3/60 amps2
59 79 98 122 145 168 207 294 375
1Cooling capacity when cooling water with 50°F{10°C} set point, 60°F {16°C} return, 95°F {35°C} condenser air, R-410A
refrigerant.
2MCA is Minimum Circuit Amps (for wire sizing), complies with NEC, Section 430-24.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
7
Table 5 – Remote Air-Cooled Condenser General Data (60 Hz)
Model
Chiller
Model
Used
With1
Dimensions inches {mm}
Weights lbs {kg}
Total
Air
Flow
(cfm)
Sound
Pressure
Level
(dBA)2
MCA @
460/3/60
(amps)3
Refrig Lines
(in)
L W H Ship Oper
Inlet
Per
Circuit
Outlet
Per
Circuit
Single-Circuit
KCM014
ESER-010S 83 {2108} 43 {1092} 48 {1219} 415 {188}
Operating weight varies base on system refrigeration charge
and operating conditions
14,400
53
2.6 1
⅜
1
⅛
KCL023
ESER-015S 113 {2870} 45 {1143} 54 {1372} 670 {304}
24,000
63
7.0 2
⅛
1
⅜
KCL030
ESER-020S 113 {2870} 45 {1143} 54 {1372} 720 {327}
22,600
63
7.0 2⅛1⅝
KCL037
ESER-025S 113 {2870} 45 {1143} 54 {1372} 800 {363}
20,600
63
7.0 2
⅛
1
⅝
KCL045
ESER-030S 168 {4267} 45 {1143} 54 {1372} 1075 {488}
33,900
64
10.1 2⅝1⅝
KCL056
ESER-040S 168 {4267} 45 {1143} 54 {1372} 1200 {544}
30,900
64
10.1 2
⅝
2
⅛
KCL068
ESER-050S 223 {5664} 45 {1143} 54 {1372} 1475 {669}
42,400
65
16.0 2⅝2⅛
KCL095
ESER-060S 278 {7061} 45 {1143} 54 {1372} 1950 {885}
51,800
66
16.0 3
⅛
2
⅝
KCL110
ESER-080S 333 {8458} 45 {1143} 54 {1372} 2300 {1043}
62,100
67
21.0 3⅛2⅝
Dual-Circuit
KCM034
ESER-020D 83 {2108} 83 {2108} 48 {1219} 830 {376}
28,400
55
4.9 1
⅝
1
⅛
KCL047
ESER-030D 113 {2870} 87 {2210} 54 {1372} 1275 {578}
47,900
65
16.0 2
⅛
1
⅜
KCL060
ESER-040D 113 {2870} 87 {2210} 54 {1372} 1350 {612}
45,200
65
16.0 2
⅛
1
⅝
KCL074
ESER-050D 113 {2870} 87 {2210} 54 {1372} 1525 {692}
41,200
65
16.0 2
⅛
1
⅝
KCL090
ESER-060D 168 {4267} 87 {2210} 54 {1372} 2050 {930}
67,800
67
21.0 2
⅝
1
⅝
KCL112
ESER-080D 168 {4267} 87 {2210} 54 {1372} 2275 {1032}
61,800
67
21.0 2
⅝
2
⅛
KCL137
ESER-0100D 223 {5664} 87 {2210} 54 {1372} 2800 {1270}
84,800
68
24.8 2
⅝
2
⅛
KCL190
ESER-0120D 278 {7061} 87 {2210} 54 {1372} 3700 {1678}
103,500
69
36.0 3
⅛
2
⅝
KCL224
ESER-0160D 333 {8458} 87 {2210} 54 {1372} 4400 {1996}
124,200
70
46.0 3⅛2⅝
1One condenser is required per chiller; dual-circuit chillers use one remote condenser that has two refrigeration circuits.
2Sound pressure level at 30 feet.
3MCA is Minimum Circuit Amps (for wire sizing) as provided by the remote condenser manufacturer.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
8
Pre-Installation
Receiving Inspection
When the unit arrives, verify it is the correct unit by
comparing the information that appears on the unit
nameplate with that which appears on the order
acknowledgement and shipping papers. Inspect the
equipment condition for any visible damage and
verify all items shown on the bill of lading are
present. If damage is evident, properly document it
on the delivery receipt and clearly mark any item
with damage as “unit damage” and notify the carrier.
In addition, make note of the specific damage and
notify Conair’s Service Department.
Shipping damage is the responsibility of the carrier.
To protect against possible loss due to damage
incurred during shipping and to expedite payment
for damages, it is important to follow proper
procedures and keep records. Photographs of
damaged equipment are excellent documentation
for your records.
Start unpacking the unit, inspect for concealed
damages, and take photos of any damages found.
Once received, equipment owners have the
responsibility to provide reasonable evidence that
the damage did not occur after delivery. Photos of
the equipment damage while the equipment is still
partially packed will help in this regard. Refrigerant
lines can be susceptible to damage in transit. Check
for broken lines, oil leaks, damaged controls, or any
other major component torn loose from its
mounting point.
Record any signs of concealed damage and file a
shipping damage claim immediately with the
shipping company. Most carriers require concealed
damages be reported within 15 days of receipt of
the equipment. In addition to notifying the carrier,
notify Conair’s Service Department.
Water-cooled chillers ship with a full refrigerant
charge while remote condenser chillers ship with a
nitrogen holding charge. Remote air-cooled
condensers ship separately with a 350-psi dry
nitrogen gas charge. Check the remote condenser
for signs of leaks prior to rigging. This will ensure no
coil damage has occurred after the unit left the
factory. The condenser ships with the legs removed.
Mount the legs to the condenser using the provided
nuts, bolts, and washers.
Unit Storage
If the chiller is stored prior to installation, it is
important to protect it from damage. Blow out any
water or fluid from the evaporator and water-cooled
condenser circuits to protect the unit from damage
from freezing. Close any open refrigerant valves.
Cover the equipment to keep dirt and debris from
accumulating on it. Units charged with refrigerant
should not be stored in areas warmer than
145°F (62.8°C).

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
9
Installation - Chiller
Mechanical
Unit Location
The chiller is available in many different
configurations to meet various environments. Please
refer to the proposal and order acknowledgement
for this equipment to verify the specific
environmental design conditions for your chiller.
Allow a minimum of 48 inches (1219mm) of
clearance between the remote condenser and any
walls or obstructions. For installations with multiple
condensers, allow a minimum of 96 inches (2438mm)
between condensers placed side-by-side or 48
inches (1219mm) for condensers placed end-to-end.
In all cases, install the equipment on a rigid surface
suitable to support the full operating weight of the
unit. Level all equipment to ensure proper operation.
When installed the equipment must be level within
¼ inch over its length and width.
Serviceability is an important factor to consider when
deciding on the location of the chiller. Do not
compromise this feature by locating it in an
inaccessible area. When locating the chiller it is
important to consider accessibility to the
components to allow for proper maintenance and
servicing of the unit. In general, allow a minimum of
36 inches (914mm) of clearance around all sides and
above the unit. There should be no piping or conduit
located over the unit. This will ensure easy access
with an overhead crane or lift for heavier
components should they need to be replaced or
serviced.
Proper ventilation is another important
consideration when locating the unit. Locate the unit
is an area that will not rise above 110°F (43.3°C).
In addition, ensure the condenser and evaporator
refrigerant pressure relief valves can vent in
accordance with all local and national codes.
Rigging
The chiller has a structural steel frame with forklift
slots to facilitate easy movement and positioning.
Follow proper rigging methods to prevent damage
to components. Avoid impact loading caused by
sudden jerking when lifting or lowering the chiller.
Use pads where abrasive surface contact may occur.
Use the frame supporting the unit for positioning it
with a crane or a forklift.
Chilled Water Piping
Proper insulation of chilled water piping is crucial to
prevent condensation. The formation of
condensation on chiller water piping, the state
change of the water from gas to liquid, adds a
substantial heat load to the system and becomes an
additional burden for the chiller.
The importance of properly sized piping between
the chiller and process cannot be overemphasized.
Reference the current edition of the ASHRAE
Fundamentals Handbook or other suitable design
guide for proper pipe sizing. In general, run full size
piping out to the process and then reduce the pipe
size to match the connections on the process
equipment. One of the most common causes of
unsatisfactory chiller performance is poor piping
system design. Avoid long lengths of hoses, quick
disconnect fittings, and manifolds wherever possible
as they offer high resistance to water flow. When
manifolds are required, install them as close to the
use point as possible. Provide flow-balancing valves
at each machine to assure adequate water
distribution in the entire system.
Condenser Water Piping
(Water-Cooled Condenser Chillers Only)
The performance of a condenser is dependent on
maintaining the proper flow and temperature of
water through the heat exchanger. Insufficient water
flow or high condenser water supply temperature
will result in the reduction of cooling capacity of the
chiller. Extreme conditions will eventually result in
the chiller shutting down due to high refrigerant
pressure. Allowing the condenser to plug up from
contaminants in the condenser water stream
adversely affects performance. In order to reduce
maintenance costs and chiller downtime, a water
treatment program is highly recommended for the
condenser cooling water. Contact our Customer
Service Department for assistance in the proper
procedure for cleaning out any plugged condenser.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
10
The nominal chiller design is for 85°F (38.6°C)
condenser cooling water supply. Under normal
operation under full load there will be about a 10°F
(4.5°C) rise through the condenser resulting in 95°F
(43.1°C) exiting water temperature from the
condenser. To ensure proper water flow through the
condenser, the condenser water pump should
provide at least 25 psi (1.7 bar).
Each condenser has a two-way condenser water-
regulating valve. Under varying loads and condenser
inlet water temperatures the amount of cooling
water needed varies. The condenser water-
regulating valve controls the amount of water
allowed to pass through the condenser in order to
maintain proper refrigeration pressures in the circuit.
To prevent damage to the condenser or regulating
valve, the condenser water pressure should not
exceed 150 psig (10.3 bar). The condenser water-
regulating valve controls the condenser water flow in
order to maintain the pressure set point. The chiller
load, condenser-water inlet temperature, and
pressure set point determine the actual flow.
Water Pressure Gauges
It is highly recommended to install pressure gauges
or taps in the inlet and outlet of both the condenser
and evaporator chilled water piping. The ability to
read the pressure drop across the chiller is important
and will aid in preventive maintenance and in
troubleshooting the chiller performance.
Master Temperature Sensor
This section only applies to installations where
multiple chillers are in a common system where one
chiller will be the master with the other chillers
serving as slaves. In those situations, a field-installed
master fluid-temperature sensor is required to be
field installed in the common chilled water supply
and return piping. The sensor ships loose from the
factory. The supply sensor should be installed
downstream of all individual chilled water supply
streams. Position the sensor to read the mixed
supply temperature. The supply sensor will normally
be the control sensor for the chilled water set point
and will determine the loading/unloading of the
compressors of the system.
Mount the sensor in a ½” NPT coupling in a
minimum pipe size of 3”. The probe sheath is ¼” OD
x 3” in length and is equipped with a ½” NPT male
fitting for direct mounting in a coupling. The sensor
is to be direct immersion for the most accurate
reading and quickest response time. If direct
immersion mounting is not possible, mount the
sensor inside a thermowell to aid in maintenance
and or repair of the sensor if opening of the process
piping is not possible. Use a suitable heat transfer
compound with a thermowell. The sensor is
equipped with a NEMA-4 sensor head with an
integral temperature transmitter. Wiring must be
field provided from the sensor head to the chiller
electrical enclosure and landed at the designated
terminal blocks within the enclosure. Please see the
chiller electrical schematic provided for further
detail.

Corporate Office: 724.584.5500 Instant Access 24/7 (Parts and Service): 800.458.1960 Parts and Service: 814.437.6861
11
Figure 1 – Standard Flow Chiller Coolant Circuit Pressure Drop (10 through 30 Ton Single-Circuit Chillers)
0
5
10
15
20
25
30
35
40
020 40 60 80 100 120 140 160
Pressure Loss (psi)
Flow (gpm)
Standard Flow Chiller Coolant Circuit Pressure Drop
(Water at 50°F)
TSEW15S
& TSER15S
TSEW20S
& TSER20S
TSEW25S
& TSER25S
TSEW30S
& TSER30S
TSEW10S
& TSER10S
ESEW-015S
ESER-015S
ESEW-010S
ESER-010S
ESEW-020S
ESER-020S
ESEW-025S
ESER-025S
ESEW-030S
ESER-030S
