Condair MD Series Technical manual

2600800-A EN 2011
Humidication and Evaporative Cooling
PLANNING MANUAL
Condair HumiLife – the efficient ERV solution
Condair MD
MD-EL-H
MD-FB-H
MD-WW-H
MD-HW-H

Proprietary rights
This document and the information disclosed herein are proprietary data of Condair Group AG. These operating
instructions (including extracts hereof) may not be reproduced or passed on, nor may the contents thereof be used
or passed on to any third party without the written permission of the manufacturer. Any infringements are punish-
able and entail a liability for damages.
Liability
Condair Group AG is not liable for any damages incurred as a result of poorly executed installation, improper
operation or the use of components or equipment not approved by Condair Group AG.
Copyright notice
© Condair Group AG, all rights reserved
Technical modication rights reserved.

3Table of Contents
Table of Contents
1 Introduction 5
1.1 First things rst! 5
1.2 Notes on the planning manual 5
2 For your safety 7
3 Product overview 8
3.1 Model overview 8
3.2 System description 9
3.3 Installation overviews 10
3.3.1 Condair MD MD-EL-H variant installation overview 10
3.3.2 Condair MD MD-HW-H variant installation overview 11
3.3.3 Condair MD MD-FB-H variant installation overview 12
3.3.4 Condair MD MD-WW-H variant installation overview 13
3.4 Scope of delivery 14
3.5 Options 15
3.6 Accessories 16
4 Planning a Condair MD system 17
4.1 Requirements for the installation room 17
4.2 Humidier unit selection and positioning 17
4.2.1 Humidier unit pre-assembly kit 17
4.2.2 Instructions for positioning the humidier unit 18
4.3 Selection and positioning of the hydraulic unit 21
4.3.1 Determining the hydraulic unit variant 21
4.3.2 Instructions for positioning the hydraulic unit 22
4.4 Positioning sensors 23
5 Media requirements 24
5.1 Fresh water connection requirements 24
5.1.1 Fresh water supply quality requirements 24
5.1.2 When is a water treatment device required? 25
5.1.3 Fresh water installation 26
5.2 Water drain requirements 28
5.3 Power supply requirements 29
5.3.1 Hydraulic unit power supply 29
5.3.2 Sensor power supply 29
5.4 Requirements for the ventilation system 29
5.5 Heating circuit requirements (MD-HW-H variant) 30
5.6 Heating circuit requirements (MD-FB-H) 32
5.7 Requirements for the hot water circuit (MD-WW-H) 34

4Table of Contents
6 Productspecications 36
6.1 Technical data of the hydraulic unit 36
6.2 Technical data of humidier unit 37
6.3 CE Declaration of Conformity 38
7 Appendix 39
7.1 Dimensional drawing of humidier unit 39
7.2 Dimensional drawings of adapters 39
7.3 Dimensional drawing of hydraulic unit 40
7.4 Condair MD wiring diagram for external connections 41

5Introduction
1 Introduction
1.1 Firstthingsrst!
Thank you for choosing the Condair MD.
The Condair MD has been built using state-of-the-art technology and in accordance with the latest safety
regulations. However, improper use of the Condair MD may put users and/or third parties at risk and/or
may also cause damage to material assets.
Please observe and comply with all information and safety instructions in this documentation and in the
instructions to the components built into the humidier system to ensure safe, proper and cost-efcient
operation of the Condair MD.
Should you have any questions after reading these instructions, please contact your local Condair rep-
resentative. We will be happy to assist.
1.2 Notes on the planning manual
Delimitations
This planning manual deals with the different variants of the Condair MD. Options and accessories
are only described insofar as is necessary for proper operation. Please see the relevant instructions for
additional information on the options and accessories.
The information in this manual is limited to the planning of the Condair MD and is aimed at correspond-
inglytrainedandadequatelyqualiedgroupsofpersons.
This planning manual is accompanied by various separate documents which are included with delivery.
Where necessary, these instructions may refer to these publications.

6Introduction
Symbols used in this manual
CAUTION!
The signal word “CAUTION” together with the hazard symbol in a circle indicates information provided
in this documentation which, if ignored, could lead to damage and/or the failure of the device or
other equipment.
WARNING!
The signal word "WARNING", together with the general hazard symbol, indicates safety and hazard
information given in this documentation which, if ignored, could lead to injury to people.
DANGER!
The signal word "DANGER", together with the general hazard symbol, indicates safety and hazard
information given in this documentation which, if ignored, could lead to serious injury or even death
to people.
Storage
Keep this documentation in a safe place for further use. If these instructions are lost or if you are unsure
whether this documentation is still up to date, please contact your Condair representative.
Language versions
This documentation is available in various languages. For more information, please contact your Condair
representative.

7For your safety
2 For your safety
Personnelqualications
All work described in this documentation may onlybecarriedoutbytrainedandsuitablyqualied
specialist staff authorised by the operator.
Furthermore, for safety and warranty reasons, interventions may only be undertaken by specialist per-
sonnel authorised by Condair.
It is assumed that all persons entrusted to work on the Condair MD are familiar with and abide by the
regulations on occupational health and safety and accident prevention.
Intended use
The Condair MD is exclusivelyintendedforductairhumidicationtogetherwithEnergyRecovery
Ventilation(ERV)withinthespeciedoperatingconditions (see Section 6.1 and Section 6.2). Any
other use without the written permission of Condair is deemed to be improper use and can render the
Condair MD hazardous.
Intended use also includes compliance with all information contained in this documentation as
well as the installation and commissioning instructions as well as the operating instructions
(particularly all safety and hazard information).
Hazards that may arise from the Condair MD:
DANGER!
Risk of electrocution
The hydraulic unit of the Condair MD operates using mains voltage. If the hydraulic unit is open,
users may come into contact with live parts. Touching live parts may cause severe injury or death.
For this reason: Before starting work on the hydraulic unit, disconnect it from the mains power
supply (remove plug from socket).
CAUTION!
Leaking or defective water pipes/connections may lead to water damage.
For this reason: If possible, the hydraulic unit and the humidier unit must be installed in a utility room
with a oor drain connected to the on-site wastewater pipe. If this is not possible, we recommend using
the optional leakage monitoring.
Unauthorisedmodicationstothedevice
No additions or modications must be made to the Condair MD without the written permission of
Condair.
When replacing any defective components on the unit, use only genuine accessories and spare parts
provided by your Condair representative.

8Product overview
3 Product overview
3.1 Model overview
The Condair MD is available in four different variants with a humidication output of 2 kg/h for installation
in horizontal ventilation ducts (H).
– EL: heating up the humidication water with integrated, electrical heating.
– HW: heating up the humidication water using the integrated heat exchanger connected to a hot
water system of a heating system.
– FB: heating up the humidication water using the integrated heat exchanger connected to a oor/
wall-based heating or a convection circuit.
– WW: heating up the humidication water using the integrated heat exchanger connected to the hot
water system (heated drinking water or heated waste water).
Variants Humidicationoutput1) Heating type
MD-EL-H
2 kg/h 1)
Electrical heating element integrated into the water
tank of the hydraulic unit
MD-HW-H Heating water circuit (35°C to 60°C) without recir-
culation pump
MD-FB-H Floor/wall-based heating circuit or convection circuit
(29°C to 60°C) with recirculation pump
MD-WW-H Hot water circuit (45°C to 60°C) without recircula-
tion pump
1) The stated humidication output is the maximum value, measured at an air throughput rate of 180
m3/h. The effective humidication output depends on the heating source output, the condition of the
supply air and the adjusted humidity setpoint. The output has been veried by Fraunhofer Institute
for Solar Energy Systems (ISE), Freiburg, Germany.
The functionality of all basic models can be enhanced using various options. Different accessories and
consumables are also available.

9Product overview
3.2 System description
System design
A Condair MD consists of the hydraulic unit and the humidier unit.
– Humidierunit(humidicationoutput2kg/h)
The humidier unit is installed at minimum 300 mm above the hydraulic unit with the adapters in the
central supply air line upstream of the distributor and downstream of any silencer.
The humidier unit can be mounted to the ceiling or wall with 4 M8 threaded rods (standard) or two
pipe clamps.
– Hydraulic unit
The hydraulic unit is mounted to the wall at minimum 300 mm below the humidier unit with the
supplied mounting rails.
The hydraulic unit is available in four different variants:
– EL: heating up the humidication water with integrated, electrical heating.
– FB: Heating up humidier water using a heat exchanger connected to an underoor/wall heating
circuit or a convector circuit with circulation pump.
– HW: Heating up humidier water using a heat exchanger connected to the heating water system
of a heating system without a circulation pump.
– WW: Heating up humidier water using a heat exchanger connected to the hot water system
(heated drinking water) without circulation pump.
Power supply
The hydraulic unit requires a 3-pin 230V/1~/50Hz mains socket. The mains socket must be installed in
accordance with local regulations and protected by a separate, on-site RCD switch (max. 30 mA) and
a separate automatic circuit breaker (min. 10 A, slow-blow).
The control and monitoring devices (humidity and temperature sensor, max. humidistat and air ow
monitor) are supplied with 24 VDC by the hydraulic unit.
Supply water
– Water quality: drinking water with max. 100 cfu/ml
– Water inlet pressure: 150 to 500 kPa (1.5 to 5 bar)
– Water hardness: 1 to 30 °dH
– pH value: 6.5 to 9.0
Water drain
The water drain of the hydraulic unit is connected to the wastewater pipe on site using an open drain
funnel with siphon.
Heating water supply and return or hot water supply and return
The hot water supply and return (for MD-HW-H and MD-FB-H variants) as well as the hot water supply
and return (for MD-WW-H variant) are connected to the corresponding connections on the underside
of the hydraulic unit.

10 Product overview
3.3 Installation overviews
3.3.1 Condair MD MD-EL-H variant installation overview
Fig. 1: Condair MD MD-EL-H variant installation overview
Max. humidistat
Humidity and temperature sensor
Air ow monitor
Service uid connection JG ø10 mm
Humidier unit return connection JG ø10 mm
Humidier unit supply connection JG ø10 mm
Drain connection ø40 mm
Drain funnel with
siphon
Supply connection G 3/4"(AG)
Drain pipe ø40 mm (min. slope 15%)
by others
by others
Mains socket
(230V/50Hz,
10 A slow-blow, FI 30 mA)
Minimum distance for service
liquid lling
min. 300 mm
300 mm
288 mm
610 mm
425 mm
min. 200 mm min. 300 mm
Free access: at min. 800 mm
Free access: at min. 800 mm
min. 200 mm
min. 350 mm
Extract air
Supply air
Shut-off valve
1.5 to 5.0 bar
8 to 30 °C
Max. hose length 3 m
(hoses with a continuous slope of at
min. 15% routed to the hydraulic unit)
Max. cable length 5 m
Water treatment (optional)
Condair RO-HS
reverse osmosis system
Decarboniser
50% scaled
50% scaled

11Product overview
Fig. 2: Condair MD MD-HW-H variant installation overview
3.3.2 Condair MD MD-HW-H variant installation overview
Existing heating system
(e.g. buffer storage) with
a supply temperature of
35°C to at max. 60°C
Max. humidistat
Humidity and temperature sensor
Air ow monitor
Service uid connection JG ø10 mm
Humidier unit return connection JG ø10 mm
Humidier unit supply connection JG ø10 mm
Drain connection ø40 mm
Drain funnel with
siphon
Supply connection G 3/4"(AG)
Drain pipe ø40 mm (min. slope 15%)
by others
by others
Mains socket
(230V/50Hz,
10 A slow-blow, FI 30 mA)
Minimum distance for service
liquid lling
min. 300 mm
300 mm
288 mm
610 mm
425 mm
min. 200 mm min. 300 mm
Free access: at min. 800 mm
Free access: at min. 800 mm
min. 200 mm
min. 350 mm
Extract air
Supply air
Shut-off valve
1.5 to 5.0 bar
8 to 30 °C
Shut-off/check valve,
supply
Shut-off valve
return
Heating water return
Heating water supply (1.5 to 4 bar, 35°C to 60°C)
Supply connection G 1/2" (IG)
Return connection G 1/2"(IG)
Hot water installation
(on-site)
Max. hose length 3 m
(hoses with a continuous slope of at
min. 15% routed to the hydraulic unit)
Max. cable length 5 m
Water treatment (optional)
Condair RO-HS
Reverse Osmosis System
Decarboniser
50% scaled
50% scaled

12 Product overview
3.3.3 Condair MD MD-FB-H variant installation overview
Fig. 3: Condair MD MD-FB-H variant installation overview
Max. humidistat
Humidity and temperature sensor
Air ow monitor
Service uid connection JG ø10 mm
Humidier unit return connection JG ø10 mm
Humidier unit supply connection JG ø10 mm
Drain connection ø40 mm
Drain funnel with
siphon
Supply connection G 3/4"(AG)
Drain pipe ø40 mm (min. slope 15%)
by others
by others
Mains socket
(230V/50Hz,
10 A slow-blow, FI 30 mA)
Minimum distance for service
liquid lling
min. 300 mm
300 mm
288 mm
610 mm
425 mm
min. 200 mm min. 300 mm
Free access: at min. 800 mm
Free access: at min. 800 mm
min. 200 mm
min. 350 mm
Extract air
Supply air
Shut-off valve
1.5 to 5.0 bar
8 to 30 °C
Shut-off/check valve,
supply
Shut-off valve
return
Heating water return Heating water supply (1.5 to 4 bar, 29°C to 60°C)
Supply connection G 1/2" (IG)
Return connection G 1/2"(IG)
Hot water installation
(on-site)
Existing underoor/wall
heating or convector circuit
with a supply temperature
of 29°C to at max. 60°C
Max. hose length 3 m
(hoses with a continuous slope of at
min. 15% routed to the hydraulic unit)
Max. cable length 5 m
Water treatment (optional)
Condair RO-HS
Reverse Osmosis System
Decarboniser
50% scaled
50% scaled

13Product overview
3.3.4 Condair MD MD-WW-H variant installation overview
Fig. 4: Condair MD MD-WW-H variant installation overview
Max. humidistat
Humidity and temperature sensor
Air ow monitor
Service uid connection JG ø10 mm
Humidier unit return connection JG ø10 mm
Humidier unit supply connection JG ø10 mm
Drain connection ø40 mm
Drain funnel with
siphon
Supply connection G 3/4"(AG)
Drain pipe ø40 mm (min. slope 15%)
by others
by others
Mains socket
(230V/50Hz,
10 A slow-blow, FI 30 mA)
Minimum distance for service
liquid lling
min. 300 mm
300 mm
288 mm
610 mm
425 mm
min. 200 mm min. 300 mm
Free access: at min. 800 mm
Free access: at min. 800 mm
min. 200 mm
min. 350 mm
Extract air
Supply air
Shut-off valve
1.5 to 5.0 bar
8 to 30 °C
Shut-off/check valve,
supply
Shut-off valve
return
Heating water return Hot water supply (1.5 to 5 bar, 45°C to 60°C)
Supply connection G 1/2" (IG)
Return connection G 1/2"(IG)
Existing hot water tank
with a supply temperature
of 45°C to at max. 60°C
Hot water installation
(on-site)
Max. hose length 3 m
(hoses with a continuous slope of at
min. 15% routed to the hydraulic unit)
Max. cable length 5 m
Water treatment (optional)
Condair RO-HS
Reverse Osmosis System
Decarboniser
50% scaled
50% scaled

14 Product overview
3.4 Scope of delivery
Condair MD is supplied with:
Material Condair scope of delivery By others
EL-H FB-H HW-H WW-H
Humidierunit
Humidier housing 2 kg/h x x x x
Humidier insert 2 kg/h x x x x
Adapters ventilation duct incl. seals, screws and nuts x x x x
Screws and wall plugs for wall installation x x x x
Ceiling attachment (threaded rods, etc.) x
Hydraulic unit
Hydraulic unit 2 kg/h with power cable and ø40/
ø32 mm reduction screw connection for water drain
connection
xxxx
Control Components
Humidity/temperature sensor for duct installation incl.
connecting cable
xxxx
Max. humidistat for duct installation incl. connecting
cable
xxxx
Air ow monitor for duct installation incl. connecting
cable
xxxx
Connecting cable leakage sensor humidier unit x x x x
Fresh water pipe + ttings x
Heating or hot water installation
Heating water supply/return + ttings (MD-HW-H and
MD-FB-H variants)
x
Hot water/cold water pipes + ttings (MD-WW-H variant) x
Installation set
“Large" installation set (all necessary hoses, insula-
tion hoses, hose connectors, etc.) for establishing the
hydraulic connections between the hydraulic unit and
humidier unit
xxxx
Note: All material not supplied by Condair must be procured by the installer according to the conditions
on site.

15Product overview
3.5 Options
The following options are available for Condair MD:
Option Description
Remote operation and fault signalling PCB (RFI)
Remote operation and fault signalling PCB for
installation in the hydraulic unit. The remote opera-
tion and fault signalling PCB has four potential-free
relay contacts for the remote display of the following
operating states: “Device switched on", "Device
humidied", "Service due" and "Error".
Leakage monitoring room Leakage monitoring for rooms without oor drain
consisting of oor sensor and connection cable.
Heating element (for MD-FB-H variant only)
Heating element with cable for installation in the
water tank of the hydraulic unit for the MD-FB-H
unit variant at supply temperatures below 29°C.
Note: The minimum supply temperature when using
the additional heating element must be at minimum
27°C. If you have any questions, please contact
your Condair representative.
Humidier unit lter Air lter for installation in the humidier unit.
Condair RO-HS reverse osmosis system External reverse osmosis system for supplying
reverse osmosis water to the Condair MD.
Decarboniser
Decarboniser (resin lter) for removing the miner-
als dissolved in the water for supplying water with
reduced mineral content to the Condair MD.

16 Product overview
3.6 Accessories
The following accessories are available for the Condair MD:
Accessories Description
Adapters ventilation duct
Adapters for humidier unit incl. seal. The adapters
are available with different connection diameters:
DN125, DN160 or DN180.
Service kit
Service kit for descaling/disinfection of Condair
MD. The service kit includes: A dosing bottle with
quick coupling, a funnel, a container with descaler
granules and a bottle with 1 l disinfectant.

17Planning a Condair MD system
4 Planning a Condair MD system
4.1 Requirements for the installation room
The humidier unit and the hydraulic unit have been designed for installation in protected indoor spaces.
Please note the following regarding the requirements for the installation site:
– The humidier unit must be installed together with the hydraulic unit in a utility room that has been
protected against unauthorised access.
– The installation room must have a oordrainconnected to the on-site wastewater pipe.
Note: If there is no oor drain, the installation of the optional "leakage monitoring" is recommended.
– The room temperature must be between +7°C and +30°C all year round and the humidity between
15% rH and 50% rH (non-condensing) and the room must be ventilated.
– There must be a sufciently large, free ceiling or wall surface at the installation location for mounting
the humidier unit and a sufciently large, free wall surface for mounting the hydraulic unit.
4.2 Humidierunitselectionandpositioning
4.2.1 Humidierunitpre-assemblykit
To take into account any subsequent installation of the Condair MD when planning a new ventilation
system, a pre-assembly kit can be ordered. The pre-assembly kit includes:
– Humidier housing 2 kg/h
– Two adapters incl. seal for installation in ventilation ducts with DN125, DN160 and DN180.
Note: No adapters are required for ventilation ducts with DN200.
When selecting the pre-assembly set, the nominal diameter of the adapters as well as the type of instal-
lation (ceiling or wall) must be dened.
Please observe and follow the instructions for positioning the humidier unit when determining the instal-
lation location (see Section 4.2.2).

18 Planning a Condair MD system
4.2.2 Instructionsforpositioningthehumidierunit
Please observe and follow the instructions for positioning the humidier unit:
– The ceiling/wall on which the humidier unit or the hydraulic unit is mounted must have sufcient
load-bearing capacity and be suitable for fastening (see Fig. 5, Fig. 6 and Fig. 7).
Ceiling mounting with threaded rods
Ventilation pipe
Ventilation pipe
Adapter
DN125 (L= 90 mm)
DN160 (L= 73 mm)
DN180 (L= 63 mm)
Adapter
DN125 (L= 90 mm)
DN160 (L= 73 mm)
DN180 (L= 63 mm)
Installation length: 549 mm (DN200)
Installation length: 729 mm (DN125)/695 mm (DN160)/675 mm (DN180)
563 mm
620 mm
L
170 mm
288 mm
Operating weight, humidier unit: approx. 18 kg
Fig. 5: Dimsensions ceiling mounting with threaded rods

19Planning a Condair MD system
Alternative ceiling mounting with pipe clamps
Ventilation pipe
Ventilation pipe
Adapter
DN125 (L= 90 mm)
DN160 (L= 73 mm)
DN180 (L= 63 mm)
Adapter
DN125 (L= 90 mm)
DN160 (L= 73 mm)
DN180 (L= 63 mm)
577 mm
620 mm
L
288 mm
Operating weight, humidier unit: approx. 18 kg
Installation length: 549 mm (DN200)
Installation length: 729 mm (DN125)/695 mm (DN160)/675 mm (DN180)
Fig. 6: Dimsensions ceiling mounting with pipe clamps
Wall mounting
Ventilation pipe
Ventilation pipe
Adapter
DN125 (L= 90 mm)
DN160 (L= 73 mm)
DN180 (L= 63 mm)
Adapter
DN125 (L= 90 mm)
DN160 (L= 73 mm)
DN180 (L= 63 mm)
620 mm
L
288 mm
Operating weight, humidier unit: approx. 18 kg
Installation length: 549 mm (DN200)
Installation length: 729 mm (DN125)/695 mm (DN160)/675 mm (DN180)
Fig. 7: Dimsensions wall mounting

20 Planning a Condair MD system
– The installation site must not be exposed to direct sunlight and must be sufciently far away from
other heat sources.
– The humidier unit must be installed at minimum 0.3 m and at maximum 3.0 m above the hydraulic
unit in the supply air duct of the ERV. The pipe lengths between the humidier unit and the hydraulic
unit must not exceed 3 m. In order to avoid standing water in the pipes, it must be taken into account
that the pipes between the humidier unit and the hydraulic unit must be routed with a constant
slope.
– A lter with a minimum neness of G4 (recommendation F7) must be installed in the supply air of the
ERV and regularly serviced to ensure hygienic operation. This lter reliably protects the humidier
insert from contamination by dust particles and thus extends the service life of the humidier insert.
– Position the humidier unit in such a way that it is easily accessible and has sufcient space for ser-
vicing. Minimum distances according to the installation overviews in Section 3.3 must be observed.
– The humidier unit is installed with the enclosed adapters in the central supply air line upstream of
the distributor and downstream of any silencer.
Ceiling mounting with threaded rods: The humidier unit is fastened to the ceiling with four
threaded rods and nuts (see Fig. 5). The fastening material is not included in the scope of delivery.
Alternative ceiling mounting with pipe clamps: The humidier unit is fastened to the ceiling with
two ø200 mm pipe clamps (see Fig. 6). The fastening material is not included in the scope of delivery.
Wall mounting: The humidier unit is attached to the wall with 4 dowel pins and screws (enclosed)
(see Fig. 7).
The total installation length is:
– When using DN125 adapters: 729 mm
– When using DN160 adapters: 695 mm
– When using DN180 adapters: 675 mm
– Without adapters (DN200): 549 mm
– The ceiling or wall on which the humidier unit is mounted must have sufcient load-bearing capacity
as well as stability and be suitable for fastening. The operating weight of the humidier unit is approx.
18 kg.
– To ensure correct operation of the air ow monitor and the max. humidistat, a straight duct section
with a minimum length of 550 mm must be provided upstream of the humidier unit and a straight
duct section with a minimum length of 300 mm downstream of the humidier unit must be provided
for the integration of the air ow monitor and the max. humidistat.
