Connex E-LUMINATE CP101 User manual

INSTRUCTION MANUAL
Please read and retain these instructions for future reference.
CP101
E-LUMINATE

2
HIGHLIGHTS
• 3500 Lumens
• Up to 200″Screen Projection
• 2 x USB / 2 x HDMI / VGA / AV
• Built-in Speakers
• Good Picture Quality
• Universal Compatibility
• Connex E-Luminate Projector
• Carry Bag
• Remote Control
• Power Cable
• HDMI Cable
• VGA Cable
• 3-in-1 AV Cable
• User Manual
• Projection System: TFT LCD
• Projector Resolution: 1280 x 800, Supports 720p / 1080p
• Brightness: 3500 Lumens
• Image Flip: Up / Down / Mirror Flip
• Projection: Forward / Back Projection / Drop
• Focusing Method: Manual
• Contrast Ratio: 1500:1
• Perspective Ratio: 16:9 & 4:3
• Bulb Type: LED
• Projection Size: 50″- 200″
• Keystone Correction: ± 15° Manual
• Projection Distance: 1.5 - 4 m
• Total Power: 120 W
• Input Ports: HDMI x 2 / USB x 2 / VGA / AV
PACKAGE CONTENTS
SPECIFICATIONS

3
Remote Control
IDENTIFYING PARTS
3
54
2
1
6
7
98
10
11
12
13
14
15
16
17
19
18
21 20
23 22
24
26
27
25
28
29
30
31
1 - Power On / Off
2 - Picture Mode
3 - Information
4 - AB Repeat
5 - Repeat
6 - Stop
7 - Play / Pause
8 - Fast Forward
9 - Fast Backward
10 - Source
11 - Direction Buttons
12 - Menu
13 - Flip (360° Image)
14 - Volume Buttons
15 - Freeze Image
16 - Channel Buttons
17 - Channel Input
18 - Mute / Unmute
19 - Audio Mode
20 - Zoom
21 - Audio Tracks
22 - Subtitle
23 - Go to Timeframe
24 - USB Mode
25 - Previous Track
26 - Next Track
27 - Aspect Ratio
28 - OK / Conrm
29 - Exit
30 - Channel Buttons
31 - Repeat

4
Projector Back
Projector Top
1 - VGA Input
2 - Power Switch
3 - Power Input
4 - USB Inputs
5 - HDMI 1 Input
6 - HDMI 2 Input
1
2
3
45 7 86
15
16
13
11
14
12
10
9
7 - Audio (Aux)
8 - AV Input
9 - Power Button
10 - OK Button
11 - Menu Button
12 - Source Button
13 - Direction Buttons
14 - LED Indicator
15 - Lens Correction Dial
16 - Keystone Correction Dial

5
OPERATING INSTRUCTIONS
GETTING STARTED
Connect the Power Cord to the Power Input slot located on the back
of the Projector, and then plug the other end of the cord into a plug
outlet. The LED Indicator will light up red when power is connected
to projector.
SWITCHING ON / OFF
To switch on the E-Luminate Projector, press the power button on
either the Projector or the Remote. The Projector will play a boot
sequence on its screen. To switch off the E-Luminate, press the
power button on either the projector or the remote.
STANDALONE STREAMING
The Projector can be used as a standalone device to share content
from a variety of devices with a wired connection or from a USB ash
drive.
KEYSTONE CORRECTION / LENS FOCUS
Use the Keystone Correction Turn Dial to adjust the angle of the
Projector. Use the Lens Focus Turn Dial to adjust image focus to make
picture clear.
MULTIMEDIA CONNECTION
To connect to the USB drive select the source “Multimedia” or press
the USB Button on the remote. Then navigate to the le type
that you want (movie, photo, music or text) using the
directional keys. Select the le you would like to view by pressing the
Play / Pause button or the OK button on the remote or the
OK button on the projector.
Note:
The projector is now in standby mode.

6
AV VIDEO CONNECTION
Connect the 3-in-1 Cable (included) to the Video Input on the back of
the projector.
Navigate to the AV Media Source and press either the OK Button
on the Remote Control or the OK Button on the Projector.
HDMI CONNECTION
Connect an HDMI cable to the HDMI Input on the back of the
projector. Navigate to the HDMI media source and press either
the OK Button on the Remote Control or the OK Button on
the Projector.
VGA CONNECTION
Connect a VGA cable to the VGA Input on the back of the Projector.
Navigate to the VGA media source and press either the OK
Button on the Remote Control or the OK Button on the Projector.
AUDIO CONNECTION
Connect a 3.5 mm jack cable to the 3.5 Output on the back of the
projector.

7
SAFETY PRECAUTIONS
• Never use your projector near water or in areas where it can come
into contact with water. Never handle the projector if it was
dropped in water or any other liquid. If the product comes into
contact with water while switched off, but still plugged in it is a
safety hazard.
• Always make sure your hands are dry before touching the plug or
power connections.
• Do not operate the product with a damaged cord or plug, or after
it malfunctions, has been dropped, or damaged in any manner.
• The E-Luminate is intended for personal use only. Commercial use
invalidates the warranty and the supplier cannot be held
responsible for injury or damage caused when using the device for
any other purpose than that which it was intended for.
• This projector is not intended for use by children, or persons with
reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the device by a
person responsible for their safety. Extreme caution must be
exercised.
• Children should be supervised to ensure that they do not play
with the Projector. Packaging must never be left within reach of
children, as it is potentially dangerous.
• Do not cover the vents of the projector as this may lead to
excessive heating of the E-Luminate’s components. Always leave a
minimum distance of 10 cm around the unit to ensure sufcient
ventilation.

• Before Cleaning: Ensure that your E-Luminate is not plugged into
any device or power source before cleaning or maintaining it.
• Cleaning: Wipe down the surface of your E-Luminate using a
soft, slightly damp cloth. To clean the lens, use a dry microber
cloth and gently wipe until it is clean.
• Do not use any harsh or abrasive cleaning chemicals or materials
on your E-Luminate as doing so may damage or scratch the surface
nish or the lens.
• Do not expose your E-Luminate to direct sunlight or high
temperatures for extended periods of time.
• Do not store in temperatures over 60° C.
8
CLEANING & CARE INSTRUCTIONS
ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities. Contact
your local government for information regarding the
collection systems available. If electrical appliances are
disposed of in landlls or dumps, hazardous substances
can leak into the groundwater and get into the food chain,
damaging your health and well-being.
All product and company names are trademarks™ or registered®
trademarks of their respective holders. Use of them does not imply
any afliation with or endorsement by them.
The terms HDMI and HDMI High-Denition Multimedia Interface,
and the HDMI logo are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
DISCLAIMER

This E-Luminate Series Projector comes with a standard 12 month
limited warranty against manufacturing defects and faults. Should
your E-Luminate projector be unboxed with any faulty parts, poor
nishing or visible damage, or fail to perform due to a manufacturing
defect or poor workmanship, please return it with your proof of
purchase (till slip or invoice) to the store of purchase for an exchange,
or repair, depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your
warranty period.
NOTE:
The warranty does not apply to a product that:
a.) Has failed due to excessive wear and tear beyond what is
considered to be reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by acts of God including re
and ooding.
d.) Has been used or operated contrary to operating or maintenance
instructions outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products
that have not been returned in accordance to this warranty or which
does not follow their own Returns Policy. Please refer to the Store of
Purchase / Sellers Returns Policy for details.
Should you require any further assistance or have any questions on
your warranty, please contact the store of purchase.
WARRANTY
