Connex FALCON CP100 User manual

INSTRUCTION MANUAL
Please read and retain these instructions for future reference.
CP100
FALCON
PC Projector With Wi-Fi Connectivity

2
HIGHLIGHTS
• 1500 Lumens
• Up to 1080P
• Wi-Fi Screen Share / Multi-Screen
• USB/SD/HDMI/VGA/AV
• Build-in Speakers
• Good Picture Quality
• Universal Compatibility
• Connex Falcon Projector
• Power Supply
• AV Cable
• Remote Control
• User Manual
• Projection system : TFT LCD
• Projector Resolution : 800 x 480 (720P, 1080P)
• Brightness : 1500 Lumens
• Image ip : Up/down/mirror ip
• Projection : Forward/Back Projection/Drop
• Focusing method : Manual
• Contrast ratio : 1000: 1
• Perspective ratio : 16:9 & 4:3
• Bulb type : LED
• Projection size : 40” - 150”
• Keystone correction : +- 15-degree Manual
• Projection distance : 1 - 4 m
• Total power : 60W
• Input ports : USB/HDMI/AV/VGA/SD
PACKAGE CONTENTS
SPECIFICATIONS

3
IDENTIFYING PARTS
2
1. Signal Source
2. Menu
3. OK Button
4. Arrow Keys
5. Back
6. Power
7. SD Input
8. Video HD Input
9. Video Input
10. Earphones/3.5 mm
AUDIO OUT
11. 5 V Out put
12. USB Input
13. Lens Focus
14. Keystone Correction
15. Lens
16. Power Input (110 - 240 V)
17. VGA Input
18. Lens Cap
1. Mute Button:
2. Zoom Button
3. Power Button
4. Flip Button (Horizontal)
5. Flip Button (Vertical)
6. Listen Button
7. Volume Up Button
8. Rewind Button
9. Fast Forward Button
10. Volume Down Button
11. Previous Button
12. Next Button
13. Play / Pause button
14. Menu Selection Arrow Key (Up)
15. Source Button (Media)
16. Menu Selection Arrow Key (Left)
17. OK Button: Conrm Menu Selections
18. Menu Selection Arrow Key (Right)
19.Menu Button
20. Menu Selection Arrow Key (Down)
21. Exit Button
Projector Back
Remote
FREEZE
FREEZE
Freezes the screen when playing video.(This key is invalid )
3

4
OPERATING INSTRUCTIONS
GETTING STARTED
Connect the power cord to the power input slot located on the side of the projector,
and then plug the cord into the plug outlet. The LED Indicator will light up red when
power is connected to projector.
SWITCHING ON / OFF
To switch on the Falcon, press the power button on the Projector or the remote.
The Projector will play a boot sequence on its screen. To switch off the Falcon, press
the power button on the Projector or the remote.
STANDALONE STREAMING
The projector can be used as a standalone device to share content from a variety
of devices with a wired HDMI connection or wireless connection or from USB ash
drive.
START-UP / MULTI-MEDIA INTERFACE
When projector is turned on, you will be entered in to multi-media screen, as seen
below.
MULTI-MEDIA FORMATS
Note: The projector is now in standby mode.
File Support format Filename extension Internal decoding format
JPEG .jpg ---
BMP .bmp ---
PNG .png ---

5
KEYSTONE CORRECTION / LENS FOCUS
Use the keystone correction turn dial to adjust the angle of the projector, and the
lens focus turn dial to adjust image focus to make picture clear.
MULTIMEDIA CONNECTION
To connect to the USB drive or SD card select the media source “USB” then navigate
to the le type that you want (movie, photo, music or text). Select the le you would
like to view by pressing the play / pause button on the remote of the OK button on
the projector.
AV VIDEO CONNECTION
Connect the 3-in-1 Cable (included) to the Video Input on the back of the projector.
Navigate to the AV Media Source and press either the OK Button on the Remote
Control or the OK Button on the Projector.
music
WMA .wma ---
MP3 .MP3 ---
AC3 / WAV .ac3 / wav ---
movies
RM / RMVB .rm / .rmvb RV8 / 9 / 10
AVI .avi ---
ASF .wmv / .asf ---
MP4 .mp4 / .mov / .3gp ---
H264 .mov MPEG 1, 2, 4
MKV .mkv ---
FLV .v H.264
PS .mpg / .mpeg / .vro / vob vc1
TS .Others(ts) H.264

6
HDMI CONNECTION
Connect an HDMI cable to the HDMI Input on the back of the projector. Navigate to
the HDMI media source and press either the OK Button on the Remote Control or
the OK Button on the Projector.
VGA CONNECTION
Connect a VGA cable to the VGA Input on the back of the Projector. Navigate to the
VGA media source and press either the “OK” Button on the Remote Control or the
“OK” Button on the Projector.
AUDIO CONNECTION
Connect a VGA cable to the VGA Input on the back of the Projector. Navigate to the
VGA media source and press either the “OK” Button on the Remote Control or the
“OK” Button on the Projector.
OTHER CONNECTIONS
The falcon projector can be used as a charging output as well for any device that
used a 5 V changing input.

7
WIRELESS CONNECTION
The projector can be connected to some smart phones and tablets via a
wireless connection.
To access this in the projector please select “Wi-Fi Display” on start-up screen.
ANDROID DEVICES
SYSTEM REQUIREMENTS:
Phone : Android 4.2 with at least 1GB RAM
Resolution : WVGA~1080P
Storage : At least 40MB free Space
CONNECTING DEVICES WIRELESSLY.
After selecting “Wi-Fi Display” Select “Miracast” then press OK.
Find Multi-Screen / Miracast Settings / Software on your device, select and connect
to the SSID shown on the projector interface. Once connected, device screen will be
duplicated on to the Projector.
Note: Please refer to device instructions to access Wi-Fi sharing options.

8
IOS DEVICES
SYSTEM REQUIREMENTS:
Operating system : IOS 7 and above.
Resolution support : Iphone 480*320 ~ 1139*640
Ipad 1024*768 ~ 2048*1536
Storage : At least 40MB free space
Device connection.
After selecting “Wi-Fi Display” Select “ISO Airplay” then press OK.
CONNECTING DEVICES WIRELESSLY.
Connect both IOS device and projector to the same Wi-Fi network. To connect
projector to a Wi-Fi network, go to settings then function select wireless setup the
search for correct network, once network is selected enter password if needed.

9
CONNECTING DEVICE WITH A CABLE
DEVICE CONNECTION.
After selecting “Wi-Fi Display” Select “ISO Cablecast” then press OK.
Using an original iPhone USB cable connect phone to projector, then click trust on
“Trust” when dialog box shows up. Then click “Allow” to start sharing screen.
MENU SETTING
Picture Menu
Picture Mode Standard / Warm / User / Dynamic
Colour temperature Standard / Warm / Cool
Aspect Auto / 4:3 / 16:9
Noise Reduction OFF / LOW / MID / HIGH
Flip Horizontal OFF / ON
Flip Vertical OFF / ON
Sound Menu
Sound Mode Music / Movie / Sport / User / Standard
Balance (-50 ~ 50)
Auto-volume OFF / ON
Surround Sound OFF / Surround
Balance 120/500 / 1.5 K / 5 K / 1 OK) Hz 50
Sound Menu
Sound Mode Music / Movie / Sport / User / Standard
Balance (-50 ~ 50)
Auto-volume OFF / ON
Surround Sound OFF / Surround
Balance 120/500 / 1.5 K / 5 K / 1 OK) Hz 50

10
SAFETY PRECAUTIONS
• Never use your projector near water or in areas where it can come into contact
with water. Never handle the projector if it was dropped in water or any other
liquid. If the product comes into contact with water while switched off, but still
plugged in it is a safety hazard.
• Always make sure your hands are dry before touching the plug or
power connections.
• Do not operate the product with a damaged cord or plug, or after it malfunctions,
has been dropped, or damaged in any manner.
• The Falcon is intended for personal use only. Commercial use invalidates the
warranty and the supplier cannot be held responsible for injury or damage
caused when using the device for any other purpose than that which it was
intended for.
• This projector is not intended for use by children, or persons with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
device by a person responsible for their safety. Extreme caution must
be exercised.
• Children should be supervised to ensure that they do not play with the Projector.
Packaging must never be left within reach of children, as it is
potentially dangerous.
• Do not cover the vents of the projector as this may lead to excessive heating of
the Falcon’s components.
• Always leave a minimum distance of 10 cm around the unit to ensure
sufcient ventilation.

• Before Cleaning: Ensure that your Falcon is not plugged into any
device or power
source before cleaning or maintaining it.
• Cleaning: Wipe down the surface of your Falcon using a soft,
slightly damp cloth.
To clean the lens, use a dry microber cloth and gently wipe until it is clean.
• Do not use any harsh or abrasive cleaning chemicals or materials on your Falcon
as doing so may damage or scratch the surface nish or the lens.
• Do not expose your Falcon to direct sunlight or high temperatures for extended
periods of time.
• Do not store in temperatures over 60° C.
CLEANING & CARE INSTRUCTIONS
ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact your local government for information regarding the
collection systems available. If electrical appliances are disposed of in landlls or
dumps, hazardous substances can leak into the groundwater and get into the food
chain, damaging your health and well-being.
11
All product and company names are trademarks™ or registered® trademarks
of their respective holders. Use of them does not imply any afliation with or
endorsement by them.
The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the United
States and other countries.
DISCLAIMER

This Falcon Series Projector comes with a standard 12 limited month warranty
against manufacturing defects and faults. Should your Falcon projector be unboxed
with any faulty parts, poor nishing or visible damage, or fail to perform due to a
manufacturing defect or poor workmanship, please return it with your proof of
purchase (till slip or invoice) to the store of purchase for an exchange, or repair,
depending on the store’s returns policy.
This warranty commences from the date of purchase.
Kindly retain your proof of purchase as well as the packaging for your warranty
period.
NOTE:
The warranty does not apply to a product that:
a.) Has failed due to excessive wear and tear beyond what is
considered to be reasonable.
b.) Has been misused or neglected.
c.) Has been damaged accidentally or by acts of God including re
and ooding.
d.) Has been used or operated contrary to operating or maintenance
instructions outlined in this manual.
The Store of Purchase / Seller cannot accept any returned products that have not
been returned in accordance to this warranty or which does not follow their own
Returns Policy. Please refer to the Store of Purchase / Sellers Returns Policy for
details.
Should you require any further assistance or have any questions on your warranty,
please contact the store of purchase.
WARRANTY
12
