User Guide
Concrete Forklift Kibble

User Guide - Concrete Forkli Kibble
Product Information
Overview
The Conquip Concrete Forkli Kibble is a kibble designed to be aached to a
forkli for quick and easy manoeuvring and pouring of concrete. The geared
opening aids easy ow and control of concrete pouring.
Key Benets
• The low overall height of the kibble enables it to be lled from a site concrete
mixer.
• Geared opening for easy concrete ow.

3
Product Information
Specication
Item Product Code
Concrete Forkli Kibble 500 CS214-00500
Concrete Forkli Kibble 1000 CS214-01000
Product Code Height Width Length Weight WLL1Capacity
CS214-00500 1350mm 1350mm 850mm 245kg 1500kg 500 litre
CS214-01000 1780mm 1530mm 1210mm 360kg 3000kg 1000 litre
1Working Load Limit

User Guide - Concrete Forkli Kibble
Item Number Descripon Quanty
1Gate Wheel 2
2Locking Pin 1
35.5mm Linch Pin 1
4Heel Pin Assembly 4
5 Heel Pin 4
6 R Clip 4
Product Information
Parts Diagram
Concrete Forkli Kibble
NOTE: These parts are for this model, they may differ for previous versions. Please contact Conquip with any queries.

5
Original Working Instructions
Usage Instructions
Important Usage Notes
• The Concrete Forkli Kibble is supplied with heel pins; these must be ed
correctly before use.
• It is recommended that you apply kibble wax to the kibble to assist cleaning.
This is available from Conquip.
Usage Instrucons
1. To aach the Concrete Forkli Kibble to a forkli, rst release the heel pins by
removing the linch pins and pulling from the aachment. Set the machine’s
forks to the correct width for the Concrete Forkli Kibble fork pockets. Make
sure that they are equidistant from the centre.
2. Drive the forkli to the kibble, aligning the forks with the kibble’s fork
pockets.
3. Double check that all is correctly aligned, then move the forkli forward unl
the forks are fully inserted into the fork pockets.
4. Apply the park brake and switch o the forkli engine.
5. Insert the heel pins ensuring they pass behind the heel of the forks, use the
linch pins to lock the heel pins in place.
6. Ensure the kibble’s ow gate is fully closed. The wheel should be turned
clockwise to ensure it is fully closed and aach the safety chain to the wheel
to prevent the gate opening during a li.
7. Once prepared and ready to ll with concrete, manoeuvre the kibble to the
lling locaon and posion the kibble on the ground.
8. Fill the kibble with concrete, taking care that the load is level. Do not overll.
The kibble can now be raised and moved to where it is required.
9. Carefully raise the kibble just o the round and check for balance and
security.
10. Carefully move the load to its required posion. Move slowly and carefully;
do not jolt the load.
11. When in posion, lower the kibble unl the load is suspended above the
discharge point.
12. Carefully open the gate by either depressing the lever or releasing the safety

User Guide - Concrete Forkli Kibble
chain and turning the release wheel anclockwise.
13. Only open the gate suciently to allow the load to empty.
14. When discharge is complete, close the gate fully and move the kibble back to
the ground.
15. Aer use ensure the kibble is thoroughly washed out (see cleaning
instrucons below).
16. With the kibble empty and clean, lower it to the ground and disconnect from
the forkli. Disconnect the safety chain, remove the linch pins and heel pins
and reverse the forkli backward and clear of the kibble. Replace the heel
pins and linch pins to prevent loss.
Cleaning Instrucons
1. The kibble must be cleaned of all remaining concrete at the end of each work
session, or more frequently if required. There can be no excuse for the unit to
fail because of hard concrete residue.
2. Thorough cleaning can be achieved if the gate control spring is disconnected,
this will allow you to open the gate fully for hosing down. Always take
extreme cauon when releasing the gate control. Do not e the gate control
lever in the open posion.
3. Once thoroughly cleaned, the spring must be re-ed to keep the gate
closed. If you do not, concrete residue may set in the gate blade channels
that will foul its operaon.
Original Working Instructions
Usage Instructions
Connued

7

User Guide - Concrete Forkli Kibble
Original Working Instructions
Safety Instructions
Basic Safety
A site-specic Risk Assessment, and li plan where applicable, must be completed by the responsible person
before using this equipment to control risks, produce a safe system of work and ensure safety for you, your
colleagues and others. Your risk assessment will determine the correct Personal Protecve Equipment (PPE)
for the task you are doing. You must use it. Conquip recommends that you should wear:
• Suitable clothing
• Gloves
• Hard hat
• Protecve footwear (steel toecaps)
• Safety glasses
Important Safety Notes
• Read these instrucons before using this equipment. If there is anything you do not understand
or if you have any concerns do not use this equipment. Contact your supervisor or Conquip
Engineering Group for advice.
• You must check that you have considered all the safety requirements for the task you are doing
and that this equipment is suitable.
• You must protect bystanders and the general public by prevenng access to the working area.
• Do not use this equipment if you are red, unwell or under the inuence of alcohol or drugs. If
you are taking any medicine or undergoing treatment you should inform your supervisor.

9
Usage & Transportaon
• Never unevenly load this equipment.
• The weight of the equipment, together with its aachments, must be added to the weight of the load
when calculang the total load that will be imposed on the liing apparatus / operang machine.
• This equipment must be used in conjuncon with the load rangs of the liing apparatus / operang
machine. (Refer to the manufacturers’ load rangs and original working instrucons).
• Make sure you know how to use this equipment and understand all aspects of its operaon in case of
emergency.
• This equipment weighs more than 25kg. Do not li or manhandle without machine assistance.
• Do not operate this equipment near overhead power lines.
• Take care in conned spaces, near ceilings or similar hazards. This equipment was designed for vercal
liing. Do not drag, or swing.
• Before operang this equipment, check that you have enough space for you to work safely and make
sure that the working area is clear of hazards, obstrucons and personnel.
• Before lowering equipment make sure that the landing zone is clear and capable of accepng the size
and weight of the load.
• Crush Risk. Keep hands and feet clear of the equipment at all mes to avoid injury.
• Do not exceed the maximum Working Load Limit (WLL) shown on the serial plate. Ensure that the WLL
on the individual li points is not exceeded.
• Before liing, check that the load is secured, balanced and stable. Allow space for the equipment to
move if the load shis.
• Manoeuvre loaded or raised equipment carefully. Travel and turn slowly to avoid unit becoming
unstable.
Personnel
• All personnel must wear relevant personal protective equipment.
• Do not wear loose clothing or jewellery and tie back long hair to avoid becoming tangled or trapped in
this equipment. You must make everyone in the work area aware of what you are doing.
• All personnel involved in the lifting operation must be competent to do so and must have been briefed
in conjunction with this User Guide available from Conquip Engineering Group, the manufacturer.
Equipment Maintenance & Cleaning
• It is mandatory that the equipment is thoroughly examined regularly, by a qualied engineer, to ensure
compliance with relevant regulaon/s. (Conquip recommend to carry out thorough examinaon every
six months).
• This product may incorporate various loose and detachable items of liing gear. Refer to the separate
requirements for the safe use of those items.
• When not being used, store the unit in a clean, upright condion and in a safe place where it will be
protected from thieves and unauthorised users.
• This equipment must be inspected by the responsible person before each use and then regularly, as
determined by your risk assessment or working pracce. If you have any concerns about condion or
suitability do not use.

User Guide - Concrete Forkli Kibble

11
Disclaimer
Warranty
The products supplied by Conquip Engineering Group are all guaranteed by a 12 month warranty.
Apart from where excepons apply, Conquip Engineering Group promises to repair or replace any fault which
the Company considers to be due to defecve material or workmanship within 12 months of the date of sale,
at no addional cost.
• Faults arising from unauthorised alteraons (see modicaons secon below for full details).
• Damage caused by abuse, neglect, misuse or falling.
• Damage caused because of failure to follow transportaon, storage, loading, cleaning or
operang instrucons.
• Replacement or repair of components due to fair wear and tear.
• Any consequenal damage or wear arising from the use or ng of addional or non-standard
parts.
Modicaons
If any third-party modicaons or alteraons, involving drilling, welding, cung or distoron of materials in
any form, are to be carried out on the product, Conquip Engineering Group must provide full wrien approval
prior to the work being carried out.
Alteraons, modicaons, addions or repairs must be carried out by Conquip Engineering Group’s
recognised distributors, if they are not carrying out the work themselves.
Conquip Engineering Group operate a connuous improvement policy and therefore reserve the right to alter
technical specicaons and user guide details at any point without noce.
Conquip Engineering Group will not cover or reimburse any transportaon and/or shipment costs to and
from their premises or their recognised agents, or any material and/or labour costs for repair, replacement or
assessment against a warranty claim.
Conquip Engineering Group and/or their directors, employees, insurers or recognised agents will not be held
liable for consequenal damages, losses or expenses relang to the inability to use the product correctly for
its purpose.

Important Notes
• This User Guide is for this Conquip product only.
• Any movements of the product must be thoroughly planned before the work commences to idenfy
potenal hazards and assess risk.
• All personnel involved in liing and transportaon of this product must have read this User Guide and
must be properly briefed.
• You must be competent, alert and medically t when using this equipment. If you have a medical
condion, a mental or physical disability, you must seek advice from a medical professional before using
this equipment.
