Contec BX-320-DC700000 User manual

IPC Series
BOX-PC
for BX-320 Series
User’s Manual
CONTEC CO., LTD.

BX-320 User’s manual i
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is complete. If you discover damaged or missing items,
contact your retailer.
Product Configuration List
BX-320-DCx00000
[Base Model]
BX-320-DCxxxxxx*1
[OS Pre-installed
Model]
Name
Pcs.
Pcs.
The main body
1
1
DIN rail attachment fittings set
1*2
1*2
F&eIT module mettal fittings
2
2
Rubber foot
4
4
Washer assembled screw (M3 x 7)
6
6
Countersunk screw (M3 x5)
3
3
Connector cover
1*2
1*2
CFast card removal prevention fitting
1
1
CFast card removal prevention fitting
(bottom face side)
1*2 1*2
Cable clamp
1
1
Power connector
1
1
Product guide (this sheet)
1
1
IPC Precaution List
1
1
Warranty Certificate
1
1
Serial number label
1
1
Royalty consent contract (OS)
-*3
1
Setup Procedure Document
-*3
1
Recovery Media
-*3
1
*1 Except for base model.
*2 It is attached the main body.
*3 It is not packed to the Base model.
* The User’s Guide of this product is offered as the PDF file in our web page. With it, since information such as a
setup of hardware, each component function and BIOS setup is indicated, please refer to it if needed.
* User’s manual or driver library for using F&eIT Series device module is not attached to this product. Downloading
them from the CONTEC Website is needed.

ii BX-320 User’s manual
Product Configuration Image
* See the Product Configuration List to check if all the components are included for the specified number of units.
Copyright
Copyright 2016 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document.
The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel, Intel Atom, Intel Core and Celeron are registered trademarks of Intel Corporation. MS, Microsoft
and Windows are trademarks of Microsoft Corporation. Other brand and product names are trademarks
of their respective holder.

BX-320 User’s manual iii
Table of Contents
Check your package..................................................................................................................................... i
Copyright .....................................................................................................................................................ii
Trademarks ..................................................................................................................................................ii
Table of Contents .......................................................................................................................................iii
1. INTRODUCTION 1
About the Product........................................................................................................................................ 1
Features................................................................................................................................................. 2
Supported OS ....................................................................................................................................... 3
Support Software.................................................................................................................................. 3
Customer Support........................................................................................................................................ 4
Web Site................................................................................................................................................ 4
Limited One-Year Warranty ...................................................................................................................... 4
How to Obtain Service................................................................................................................................ 4
Liability........................................................................................................................................................ 4
Safety Precautions....................................................................................................................................... 5
Safety Information............................................................................................................................... 5
Caution on the BX-320 Series............................................................................................................ 5
Security Warning......................................................................................................................................... 8
2. SYSTEM REFERENCE 9
Specifications............................................................................................................................................... 9
Power Management Features ...................................................................................................................11
Power Requirements.................................................................................................................................12
Power Consumption........................................................................................................................... 12
Physical Dimensions.................................................................................................................................13
3. HARDWARE SETUP 15
Before Using the Product for the First Time ..........................................................................................15
Hardware Setup ......................................................................................................................................... 16
Inserting an Embedded CFast Card..................................................................................................16
Installing a CFast card in slot CFast1 ..............................................................................................17
Mounting the Device Module........................................................................................................... 18
Removing the Module.......................................................................................................................18
Removing a DIN Rail Installation Metal Fittings...........................................................................19
Mounting on a DIN rail installation metal fittings..........................................................................20
Removing from a DIN Rail...............................................................................................................21
Securing the expansion connector cable and attaching the cover..................................................22
Installation Requirements.................................................................................................................. 23

iv BX-320 User’s manual
4. BIOS SETUP 27
Introduction................................................................................................................................................ 27
Starting Setup ............................................................................................................................................ 27
Using Setup................................................................................................................................................ 28
An attention when using Windows 10............................................................................................. 28
Getting Help....................................................................................................................................... 28
In Case of Problems........................................................................................................................... 28
A Final Note About Setup................................................................................................................. 28
Main Menu................................................................................................................................................. 29
Setup Items......................................................................................................................................... 29
Main............................................................................................................................................................ 30
Advanced ................................................................................................................................................... 31
ACPI Settings..................................................................................................................................... 32
Super IO Configuration..................................................................................................................... 33
H/W Monitor...................................................................................................................................... 35
CPU Configuration............................................................................................................................ 36
PPM Configuration............................................................................................................................ 37
SATA Configuration......................................................................................................................... 38
CSM Configuration ........................................................................................................................... 39
Chipset........................................................................................................................................................ 40
North Bridge....................................................................................................................................... 41
Intel IGD Configuration.................................................................................................................... 42
South Bridge Configuration.............................................................................................................. 44
Azalia HD Audio Configuration....................................................................................................... 45
Security...................................................................................................................................................... 48
Secure Boot menu.............................................................................................................................. 50
Boot Configuration ................................................................................................................................... 51
Save & Exit................................................................................................................................................ 53
5. EACH COMPONENT FUNCTION 55
Component Name...................................................................................................................................... 55
Front View.......................................................................................................................................... 55
System Configuration............................................................................................................................... 56
Component Function................................................................................................................................. 57
LED: POWER, ACCESS, L1, L2 .................................................................................................... 57
DC Power Input Connector: DC-IN................................................................................................. 57
POWER SW: POWER-SW .............................................................................................................. 58
User Programmable Switch: uSW.................................................................................................... 58
User Programmable Switch: uSW.................................................................................................... 58
Line out Interface: LINE OUT ......................................................................................................... 58
Microphone input Interface: MIC .................................................................................................... 58
Analog RGB Interface: A-RGB ....................................................................................................... 59

BX-320 User’s manual v
USB3.0 Port: USB3.0........................................................................................................................ 60
USB2.0 Port: USB2.0........................................................................................................................ 60
Giga bit-Ethernet: LAN A, B............................................................................................................61
CFast Card Connector: CFast1 .........................................................................................................62
Serial Port Interface: SERIAL A, B..............................................................................................63
BUS EXPANDER (PCIe).................................................................................................................64
F&IT I/F.............................................................................................................................................. 65
6. APPENDIX 71
POST Codes............................................................................................................................................... 71
Interrupt Level List ................................................................................................................................... 74
SERIAL I/O Address and Register Function.......................................................................................... 75
Watch-Dog-Timer .....................................................................................................................................81
Battery........................................................................................................................................................ 86
Life of CF................................................................................................................................................... 87
7. LIST OF OPTIONS 89

vi BX-320 User’s manual

1. Introduction
BX-320 User’s manual 1
1. Introduction
About the Product
This product is a small, fanless PC for embedding with a palm-size body that can be mounted on a 35mm
DIN rail.
This product is the successor to the previous BX-300 microcontroller products and it meets the needs of
replacing the BX-300 in systems. The exterior of this product has the same dimensions. The functionality
of this product can also be expanded in ways such as adding digital I/O by connecting F&eIT Series
device modules.* This product utilizes the Intel®Atom™ Processor E3845 for the CPU. This product is
equipped with an external expansion connector that can be connected by cable to an expansion chassis for
PCI/PCI Express expansion boards.
* Windows Embedded Standard 7 32bit only
This product is available in the following 3 models:
- Base model with Intel Atom Processor E3845 1.91GHz
BX-320-DC700000 (Memory 4GB, ECC, without OS, without CFast)
- OS-installed model with Intel Atom Processor E3845 1.91GHz
BX-320-DC731314 (Memory 4GB, ECC, Windows Embedded Standard 7 32bit (Japanese, English,
Chinese, Korean), CFast Card (SLC) 16GB)
BX-320-DC781724 (Memory 4GB, ECC, Windows10 IoT Enterprise LTSB 2016 64bit (Japanese,
English, Chinese, Korean), CFast Card (Q-MLC) 32GB)

1. Introduction
2BX-320 User’s manual
Features
- Contributes to reducing running costs and energy efficiency
While inheriting the basic functionality of the previous BX-300 Series, this product achieves further
decreases in power usage and increases in speed while maintaining sufficient performance by employing
a low power platform featuring the Intel® Atom™ Processor E3845 for the CPU
- Contributes to equipment miniaturization. PC functionality and expandability concentrated into a
small form (94.0 (W) x 120.0 (D) x 74.7 (H))
The small chassis (94.0 (W) x 120.0 (D) x 74.7 (H)) is equipped with a variety of interfaces including
VGA, USB3.0 x 1, USB 2.0 x 3, RS-232C x 2, LAN x 2 (1000BASE-T, 100BASE-TX), Audio, and the
F&eIT I/F (for F&eIT Series device modules). This product is also equipped with a PCIe connector that
can be connected to an external expansion chassis. This product has the same dimensions as the previous
BX-300 Series products, so it can be swapped into existing systems.
- Fanless design reduces maintenance and inspection work
This product features a completely spindle-free design that eliminates the CPU fan and uses a CFast card
for storage. The use of components that deteriorate with age has been held down as much as possible,
which greatly reduces the burden of maintenance and inspection work.
- Remote power management functions that save operational labor
This product supports Wake On LAN to externally start the PC via the network and Power On by Ring to
start the PC by the modem receiving a call. This makes it capable of providing large operational labor
savings.
- Freely expandable peripherals. Twin CFast card slots and other abundant interfaces
This product is equipped with expandable interfaces including 1000BASE-T x 2, USB 3.0 x 1, USB 2.0 x
3, and serial interfaces (RS-232C) x 2.It is also equipped with two CFast card slots (one slot isinternal)
so the data and operating system can be separated. This is very convenient for forms of operation such as
using one slot to run the system and one slot for maintenance, or using one slot to take home system logs
and sampled data.
- Usable as a controller for F&eIT Series measurement, control, and communication devices *1
This product can be used as a controller for F&eIT Series measurement, control, and communication
devices. Device modules including digital I/O, analog I/O, and serial communication can be used as
measurement, control, and communication devices.
- Up to eight F&eIT Series device modules can be connected to the F&eIT I/F *1
The F&eIT I/F can accommodate up to eight F&eIT Series device modules (maximum total current of
each module is 3A or less).
*1 WindowsEmbedded Standard 7 32bit only
- Expandable with PCI boards and/or PCI Express boards
With a single separately sold cable, this product can connect to a PCI Express Cable expansion chassis
which enables expansion by PCI/PCI Express boards.
- Possibly installed in 35mmDIN rail
A detachable metal installation part for attaching the main unit to a 35mm DIN rail is bundled by default,
which can be used according to the installation conditions. The system features a unique configuration for
its connection to a module on the side in a stacking manner, which allows you to configure the system
simply and elegantly without using backplanes and other connecting devices.

1. Introduction
BX-320 User’s manual 3
- Safety design required for embedded applications
For Windows Embedded Standard installed model or Windows10 IoT Enterprise LTSB 2016 64bit
installed model, it is possible to use the WF *2 function of OS. It is designed for safety required for
embedding purpose, for example, prohibiting unwanted writing to the CFast card with EWF function will
relieve the concern about the writing limits to the CFast card and prevent an unintentional system
alteration.
*2 EWF (Enhanced Write Filter) is a function of Windows Embedded Standard.
UWF(Unified Write Filter) is a function of Windows 10 IoT Enterprise LTSB 2016.
They protect the disk from being actually written by redirecting the writing to RAM.
- A wide range of power supplies (10.8 - 31.2VDC) supported
As the product supports a wide range of power (10.8 - 31.2VDC), it can be used in a variety of power
environments.
Supported OS
- Windows Embedded Standard 7 32bit (Japanese, English, Chinese, Korean)
- Windows 10 IoT Enterprise LTSB 2016 64bit (Japanese, English, Chinese, Korean)
2.10 or more than it of a main-frame BIOS version is an operating conditions of Windows 10.
Support Software
You should use CONTEC support software according to your purpose and development environment.
Driver library API-SBP(W32)
(Available for downloading (free of charge) from the CONTEC web site.)
It is the Windows version driver library software that provides stack-connected commands to F&eIT
series measurement/control/ communication device module in the form of Win32 API functions (DLL).
Various programming languages such as Visual Basic and Visual C++ can be used to create high-speed
application software which maximizes the features of the F&eIT module. In addition, a diagnostic
program, which is useful for operation verification, is also provided.
< Operating environment >
OS Windows Embedded Standard 2009
Adaptation language Visual C++, Visual Basic, etc.
You can download the updated version from the CONTEC’s Web site (https://www.contec.com/). For
more details on the supported OS, applicable language and new information, please visit the CONTEC’s
Web site.
* API-SBP(W32) and API-PAC(98/PC) cannot be used at the same time. Use the WDM driver of
API-PAC.
CAUTION

1. Introduction
4BX-320 User’s manual
Customer Support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
Web Site
Japanese http: //www.contec.co.jp/
English http: //www.contec.com/
Chinese http: //www.contec.com.cn/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One-Year Warranty
CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in material and
workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office, from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
original products. The warranty is not applicable if the device has been tampered with or damaged
through abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in
which case repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization number (RMA) from the CONTEC group office where you
purchased before returning any product.
* No product will be accepted by CONTEC group without the RMA number.15B
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be
liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.

1. Introduction
BX-320 User’s manual 5
Safety Precautions
Understand the following definitions and precautions to use the product safely.
Safety Information
This document provides safety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels
to operate the equipment safely.
DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury or in property damage.
Caution on the BX-320 Series
Handling Precautions
- Always check that the power supply is turned off before connecting or disconnecting power cables.
- Do not modify the product.
- Always turn off the power before inserting or removing circuit boards or cables.
- This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other
applications that require a very high level of reliability. Do not use the product in such applications.
- If using this product in applications where safety is critical such as in railways, automotive, or
disaster prevention or security systems, please contact your retailer.
- Do not attempt to replace the battery as inappropriate battery replacement poses a risk of explosion.
- For battery replacement, contact your retailer as it must be performed as a process of repair.
- When disposing of a used battery, follow the disposal procedures stipulated under the relevant laws
and municipal ordinances. For details on replacing the battery, refer to the appendix.
DANGER
WARNING
CAUTION
WARNING

1. Introduction
6BX-320 User’s manual
- Do not use or store this product in a location exposed to high or low temperature that exceedsrange
of specification or susceptible to rapid temperature changes.
Example: - Exposure to direct sun
- In the vicinity of a heat source
- Do not use this product in extremely humid or dusty locations. It is extremely dangerous to use this
product with its interior penetrated by water or any other fluid or conductive dust. If this product
must be used in such an environment, install it on a dust-proof control panel, for example.
- Avoid using or storing this product in locations subject to shock or vibration that exceeds range of
specification.
- Do not use this product in the vicinity of devices that generate strong magnetic force or noise. Such
products will cause this product to malfunction.
- Do not use or store this product in the presence of chemicals.
- To clean this product, wipe it gently with a soft cloth dampened with either water or mild detergent.
Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing or
discoloration of the paint.
- This product’s case may become hot. To avoid being burned, do not touch that section while this
product is in operation or immediately after turning off the power. Avoid installation in a location
where people may come into contact with that section.
- CONTEC does not provide any guarantee for the integrity of data on CFast.
- Always remove the power cable from the power outlet before mounting or removing an expansion
board and before connecting or disconnecting a connector.
- Always remove the power cable from the power outlet before connecting or disconnecting a
connector.
- To prevent corruption of files, always shutdown the OS before turning off this product.
- CONTEC reserves the right to refuse to service a product modified by the user.
- In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power
cord immediately and contact your retailer.
- To connect with peripherals, use a grounded, shielded cable.
- The CFast card connector doesn't support hot plug. The pulling out opening of the CFast card cannot
be donein the state of power supply ON. Please neither pulling out opening of CFast in the state of
power supply ON of this product nor come in contact with CFast. This product may malfunction or
cause a failure.
- If you use any other CFast than our CFast, we can not guarantee this product’s specification. When
you newly select CFast for this product, you should read “Chapter 7” at first. If you select
unpreferable CFast, the system may work out of order.
- Component Life:
(1) Battery---The internal calendar clock and CMOS RAM are backed by a Lithium primary battery.
The backup time at a temperature of 25°C with the power disconnected is 10 years or
more.
(2) CFast --- Window installed model uses a CFast card in the OS storage area.
The estimated failure rate is 1 every 60,000 rewrites for SLC models and 1 every 2000
rewrites for MLC models and 1 every 20,000 rewrites for Q-MLC models.
* Replacement of expendables is handled as a repair (there will be a charge).
* The service life for consumable parts are reference values and are not guaranteed values.
* This product's specifications allow the device to be rebooted from the BIOS screen during startup.
This has no effect on operation after the OS boots
CAUTION

1. Introduction
BX-320 User’s manual 7
FCC PART15 Class A Notice
This equipment has been tested and found to comply with the limits for a ClassA digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
NOTE
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.

1. Introduction
8BX-320 User’s manual
Security Warning
When connecting to the network, be aware of security-related problems. See the examples of Security
measures below and set up the product properly along with the network devices.
[Information security risks]
- Unauthorized access from the outside through a network could cause the system halt, data damage, or
exposure to malware *1.
- Invaded and used as a stepping stone, a device might attack the others through networks.
(a victim becomes an assailant)
- Information might leak without realizing due to the connection to the network.
- Secondary damages such as harmful rumors, liability in damages, social credibility fall, and opportunity
loss are expected led by the troubles described above.
*1… Malware (Malicious Software) is software that brings harm to a computer system and performs unintended operations.
[Security measures - e.g.]
- Do not keep using the default password. (Refer to the product manual for the password setting).
- Set a strong password.
⇒Combined with upper and lowercase letters, and numbers so that it cannot be easily analogized
by others.
- Change the password periodically.
- Disable unnecessary network services and functions.
- Restrict access to the network with network devices. *2
- Restrict ports to be released on the network with network devices.
- Create a closed network connection using such as dedicated network or VPN*3.
*2…Inquire for setting procedureto manufacturers.
*3…VPN (Virtual Private Network): a secured network that wards off unauthorized access by protecting thecommunication path with
authentication and encryption.
Unfortunately, there are no perfect ways to avert unauthorized access or close a security hole that are
endlessly found day and night. Please understand that risks are always involved with the Internet
connection, and we strongly recommend a user should constantly update information security measures.

2. System Reference
BX-320 User’s manual 9
2. System Reference
Specifications
Table 2.1. Functional Specifications < 1 / 2 >
Model
BX-320-DC7xxxxx
CPU Intel® Atom™ Processor E3845 1.91GHz
BIOS
BIOS (mfd. by AMI)
Memory
4GB, 204pin SO-DIMM socket x 1, PC3-10600(DDR3L 1333) ECC
Graphic Intel® HD Graphics (built-in CPU)
System
resolution Analog RGB
640x480, 800x600, 1,024x768, 1,152x864, 1,280x600, 1,280x720, 1,280x768,
1,280x800, 1,280x960, 1,280x1,024, 1,360x768, 1,366x768, 1,400x1,050, 1,440x900,
1,600x900, 1,680x1,050, 1,920x1,080, 1,920x1,200 (16,770,000 colors)
Audio
HD Audio compliant, LINE OUT x 1, MIC IN x 1
CFast card slot
2 slot, CFast CARD Type I x 2 bootable
BX-320-DC73131x: Built-in CFast card slot (SLC) (16GB, 1 partition) *1
BX-320-DC781724: Built-in CFast card slot (Q-MLC) (32GB, 1 partition) *1
Other models: none
LAN *2 Intel I210IT Controller
1000BASE-T/100BASE-TX/10BASE-T 2 port (Wake On LAN support)
USB USB 3.0 compliant 1 port
USB 2.0 compliant 3 port
Serial I/F RS-232C (general-purpose) : 2port (SERIAL PORTA, B), 9pin D-SUB connector (male)
Baud rate : 50 - 115,200bps
Watchdog timer
Software programmable, 255 level (1sec - 255 sec) Causes a reset upon time-out.
General-purpose I/O Photocoupler insulation inputs/outputs (3 of each)
(However, one output can be switched to WDT external output.)
Hardware monitoring
Monitoring CPU temperature, power voltage
RTC/CMOS Lithium backup battery life: 10 years or more.
The real-time clock is accurate within ±3 minutes (at 25°C) per month
Power Management Power management setup via BIOS, Power On by Ring / Wake On LAN,
Supports PC98/PC99 ACPI Power management
F&eIT I/F *3
It can be accommodated up to 8 F&eIT series device modules.(Max.3A)
BUS EXPANDER(PCIe)
PCI Express 1.0a (x1) compliant PCI Express cable port
*1: The capacity of CFast is a value when 1GB is calculated by 1 billion bytes. The capacity that can be recognized from
OS might be displayed fewer than an actual value.

2. System Reference
10 BX-320 User’s manual
Table 2.1. Functional Specifications < 2 / 2 >
Model
BX-320-DC7xxxxx
Interface
Display
Analog RGB x 1 (15pin D-SUB connector)
Audio LINE OUT : 3.5φ Stereo mini jack, Full-scale output level 1.4Vrms(Typ.)
MIC IN : 3.5φ Stereo mini jack, Full-scale input level 1.4Vrms(Typ.)
CFast card slot
2 slot, CFast CARD Type I x 2, bootable
BX-320-DC700000:-
BX-320-DC73131x:Built-in CFast card slot contains a CFast card (SLC) .
(16GB, 1 partition)*1
BX-320-DC781724:Built-in CFast card slot contains a CFast card (Q-MLC) .
(32GB, 1 partition)*1
LAN *2 2 port (RJ-45 connector)
USB USB3.0 compliant 1port (TYPE-A connector x1)
USB2.0 compliant 3port (TYPE-A connector x3)
RS-232C
2 port (9pin D-SUB connector [male])
F&eIT *3 1 port
PCI Express cable 1 port (18pin PCI Express External Cabling connector)
Power supply
Rated input voltage
12 - 24VDC *4
Range of input
voltage 10.8 - 31.2VDC
Power consumption 12V 1.5A, 24V 0.9A
(When no using USB-powered or F&eIT-powered peripherals)
12V 4.2A, 24V 2.2A (When using USB-powered or F&eIT-powered peripherals)
External device power
supply capacity
CFast card slot: +3.3V: 1A(500mAx2)
USB3.0 I/F: +5V: 0.9A (900mAx1)
USB2.0 I/F: +5V: 1.5A (500mAx3)
F&eIT I/F: +5V: 3A
Physical dimensions
(mm)
94 (W) x 120(D) x 74.7(H) (No protrusions)
Weight About 1.0kg (Excluding attachment fittings)
*2: If you use the 1000BASE-T, be careful of the operating temperature.
For more details on this, refer to chapter3, Installation Requirements.
*3: Windows Embedded Standard 7 32bit only
*4: Use a power cable shorter than 3m.

2. System Reference
BX-320 User’s manual 11
Table 2.2. Installation Environment Requirements
Model
BX-320-DC7xxxxx
Ambient
specifications
Operating temperature
*5 0 - 50°C(When using 1000BASE-T: 0 - 45°C)*5
Storage temperature
-10 - 60
°
C
Humidity
10 - 90%RH (No condensation)
Floating dust particles
Not to be excessive
Corrosive gases
None
Line-noise
resistance
Line noise
AC line / ±2kV (IEC61000-4-4 Level 3, EN61000-4-4 Level 3)*6,
Signal line / ±1kV (IEC61000-4-4 Level 3, EN61000-4-4 Level 3)
Static
electricity
resistance
Contact discharge / ±4kV (IEC61000-4-2 Level 2, EN61000-4-2 Level 2)
Atmospheric discharge / ±8kV (IEC61000-4-2 Level 3, EN61000-4-2 Level 3)
Vibration
resistance
Sweep
resistance
10 - 57Hz/semi-amplitude 0.15 mm 57 - 150Hz/2.0G
40 min. each in x, y, and z directions
(JIS C60068-2-6-compliant, IEC60068-2-6-compliant)
Impact resistance 15G, half-sine shock for 11 ms in x, y, and z directions
(JIS C60068-2-6-compliant, IEC60068-2-6-compliant)
Grounding
Class D grounding, SG-FG / continuity
Standard VCCI Class A, FCC Class A,
CE Marking (EMC Directive Class A, RoHS Directive)
*5: For more details on this, please refer to chapter 3, “Installation Requirements”.
*6: When AC-DC power supply unit “DLP75-24-1(manufactured by TDK-Lambda)” is used.
Power Management Features
- Support both ACPI (Advanced Configuration and Power Interface).
- ACPI v2.0 compliant
- Hardware automatic wake-up

2. System Reference
12 BX-320 User’s manual
Power Requirements
Your system requires a clean, steady power source for reliable performance of the high frequency CPU on
the product, the quality of the power supply is even more important. For the best performance makes sure
your power supply provides a range of 10.8 V minimum to 31.2 V maximum DC power source.
Power Consumption
For typical configurations, the CPU card is designed to operate withat least a 60W power supply. The
power supply must meet the following requirements:
- Rise time for power supply: 2 ms - 30 ms
The following table lists the power supply’s tolerances for DC voltages:
Table 2.3. DC voltage tolerance
DC Voltage
Acceptable Tolerance
+ 12V - 24V
+ 10.8V - 31.2V

2. System Reference
BX-320 User’s manual 13
Physical Dimensions
BX-320-DCxxxxxx
*1: Ensure that the penetration depth (L) from the chassis surface to the screw tip is 3 mm or lower for the top and
bottom and 4 mm or lower for the back.
Figure 2.1. BX-320-DCxxxxxx (Including screw hole dimensions *1)
*2: To secure this product with the included fittings, use the included screws (M3x7). In other situations, use screws
with a penetration depth (L) from the chassis surface to the screw tip of 3 mm or lower.
Figure 2.2. BX-320-DCxxxxxx (When mounting the DIN rail installation metal fittings *2)
