Contec IPC-BX800-DC400 User manual

IPC Series
BOX-PC
for IPC-BX800 Series
User’s Manual
CONTEC CO.,LTD.

IPC-BX800 Series User’s Manual i
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that yourpackage is complete. If you discover damagedor missing items,
contact your retailer.
Product Configuration List
IPC-BX800-DC400
IPC-BX801-DC400
(Base model)
IPC-BX800-DC456
IPC-BX801-DC456
(Windows XP
Embedded
Installation model)
Name Pcs. Pcs.
BOX-PC 1 1
The attachment fittings 2 2
Screw complete set for fittings used to attach to themain body
Three-point sems screw (M4×8) 4 4
Three-point sems screw (M3×6) 4 4
Power supply connector complete set
Housing 1 1
Contact 4 4
Cable clamp 2 2
Product guide(this sheet) 1 1
IPC Precaution List 1 1
Royalty consent contract None 1
Setup Procedure Document None 1
Notes on using Windows XP Embedded None 1
IPC-SLIB-01 *1
(User’s manual, Driver & Utility Soft Set) 1 1
Recovery Media None 1
*1 Please confirm latest information on the CONTEC homepage though the user's manual is stored in IPC-SLIB-01.
Product Configuration Image
* See the Product Configuration List to check if all the components are included for the specified number of units.

ii IPC-BX800 Series User’s Manual
Copyright
Copyright 2007 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document.
The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel and Celeron are registered trademarks of Intel Corporation. MS, Microsoft and Windows are
trademarks of Microsoft Corporation. Other brand and product names are trademarks of their respective
holder.

IPC-BX800 Series User’s Manual iii
Table of Contents
Check Your Package............................................................................................................................ i
Copyright ............................................................................................................................................ii
Trademarks .........................................................................................................................................ii
Table of Contents...............................................................................................................................iii
1. INTRODUCTION 1
About the Product............................................................................................................................... 1
Features........................................................................................................................................ 1
Supported OS............................................................................................................................... 2
Customer Support ............................................................................................................................... 3
Web Site....................................................................................................................................... 3
Limited One-Year Warranty............................................................................................................... 3
How to Obtain Service ....................................................................................................................... 3
Liability............................................................................................................................................... 3
Safety Precautions .............................................................................................................................. 4
Safety Information....................................................................................................................... 4
Caution on the IPC-BX800/801 Series........................................................................................ 4
2. SYSTEM REFERENCE 7
Specification ....................................................................................................................................... 7
Physical Dimensions......................................................................................................................... 10
3. HARDWARE SETUP 11
Before Using the BOX-PC for the First Time.................................................................................. 11
Hardware Setup ................................................................................................................................ 12
Attaching the CF Card Retaining Bracket................................................................................. 12
Attaching the Fitting Used to Attach to the Main Unit............................................................. 12
Removing/Attaching the Recovery IDE Connector Cover....................................................... 13
Attaching the FG........................................................................................................................ 13
Fastening the Cable ................................................................................................................... 14
Installation Requirements.......................................................................................................... 15
4. BIOS SETUP 17
BIOS Setup ....................................................................................................................................... 17
Starting the Setup Screen........................................................................................................... 17
Main Menu................................................................................................................................. 17
Primary Master, Slave ............................................................................................................... 18

iv IPC-BX800 Series User’s Manual
Advanced Menu................................................................................................................................ 19
Cache Memory Features ............................................................................................................20
Memory Features ....................................................................................................................... 21
PCI Features............................................................................................................................... 22
IDE Features ..............................................................................................................................23
Video Features ........................................................................................................................... 24
LAN Features............................................................................................................................. 25
USB Features .............................................................................................................................26
Audio Features........................................................................................................................... 26
I/O Features................................................................................................................................ 27
Keyboard Features.....................................................................................................................29
Boot Features.............................................................................................................................30
Security Menu................................................................................................................................... 31
Power Menu......................................................................................................................................32
ACPI Controls............................................................................................................................32
PC Health Menu................................................................................................................................ 33
Hardware Monitor Setup ........................................................................................................... 33
Boot Menu ........................................................................................................................................34
Exit Menu.......................................................................................................................................... 35
Locations and Settings of CMOS/ROM Clear Jumpers...................................................................37
5. EACH COMPONENT FUNCTION 39
Component Name .............................................................................................................................39
Front View ................................................................................................................................. 39
Side View................................................................................................................................... 39
System Configuration.......................................................................................................................41
Component Function......................................................................................................................... 42
Mode switch : DIP-SW..............................................................................................................42
LED: POWER, ACCESS, STATUS .........................................................................................43
DC Power Input Connector : DC-IN ......................................................................................... 44
Hardware Reset Switch : RESET SW ....................................................................................... 44
MIC input Interface : MIC......................................................................................................... 44
Line out Interface : LINE OUT.................................................................................................45
Fast-Ethernet : LAN...................................................................................................................46
USB Ports...................................................................................................................................47
Serial Port Interface : SERIAL1 - 3 .......................................................................................... 48
Display Interface : VGA............................................................................................................49
LVDS Interface : LVDS ............................................................................................................50
IDE Switch : IDE SW................................................................................................................ 50
Recovery IDE Master Connection (PrimaryIDE Connection) : R-IDE................................... 51
CF Card Connector (Primary IDE Connection) : CF................................................................52

IPC-BX800 Series User’s Manual v
6. APPENDIX 53
Memory Map .................................................................................................................................... 53
I/O Port Addresses............................................................................................................................ 54
Interrupt Level List........................................................................................................................... 55
POST Codes...................................................................................................................................... 56
COM I/O Address and Register Function ........................................................................................ 60
Voltage/temperature monitoring sequence....................................................................................... 66
Watch-Dog-Timer............................................................................................................................. 67
7. LIST OF OPTIONS 71

vi IPC-BX800 Series User’s Manual

1. Introduction
IPC-BX800 Series User’s Manual 1
1. Introduction
About the Product
This product is a small embedded computer that can be used under severe operating conditions such as
high/low temperatures and vibrations.
IPC-BX800 Series contains a power-saving high-performance Celeron (R) M process 800MHz, 852GM
chip set and 512MB of memory.
IPC-BX801 Series contains a power-saving high-performance Celeron (R) M process 1GHz, 852GM
chip set and 512MB of memory.
A number of extended interfaces such as serial, USB2.0 and LAN are all placed on the front side of the
main body for easier maintenance.
Adopting a CF card which has eliminated any moving parts, the product ensures maximum quietness.
Embedded-type CPU and chip set have been adopted. The use of readily available parts ensures the ease
of the use of the product. In addition, the use of a Contec-customized BIOS allows support to be
provided at the BIOS level.
The box computer (R) (BOX-PC series) is available in the following two models:
Base Model
IPC-BX800-DC400, IPC-BX801-DC400 (Memory 512MB, without OS, CF)
OS-installed Model
IPC-BX800-DC456, IPC-BX801-DC456 (Memory 512MB, Windows XP Embedded, CF 2GB)
Features
Ultra-low voltage Celeron M 800MHz, 852GM chip set, and 512MB of memory
(IPC-BX800-DC400, IPC-BX800-DC456)
The product has a power-saving, high-performance, ultra-low voltage Intel (R) Celeron (R) M processor
with 800MHz (FSB: 400MHz), Intel (R) 852GM chip set, and 512MB of memory.
Ultra-low voltage Celeron M 1GHz, 852GM chip set, and 512MB of memory
(IPC-BX801-DC400, IPC-BX801-DC456)
The product has a power-saving, high-performance, ultra-low voltage Intel (R) Celeron (R) M processor
with 1GHz(FSB400MHz), Intel (R) 852GM chip set, and 512MB of memory.
Extended interfaces located at the front for easier maintenance
Extended interfaces such as serial (RS-232C) x 3, USB2.0 x 2, 100BASE-TX x 1 and audio interfaces
are all placed at the front, providing excellent maintenance advantages. In addition to a general-purpose
analog RGB interface, the product has an LVDS interface, which enables dual screen display.

1. Introduction
2IPC-BX800 Series User’s Manual
Operation guaranteed in a temperature range from -20 to +60°C with a vibration resistance of 5G and an
impact resistance of 100G
The radiation structure with a built-in heater and the cabinet ensures a stable operation at any
temperature between -20 and +60 °C. With a vibration resistance of 5G and an impact resistance of
100G, the product can also be used for mobile devices.
Safety design required for embedded applications
Unnecessary trouble can be avoided by the use of insulation lock clamps for prevention of cable
disconnection and the use of metal fittings for prevention of CF card disconnection.
An abnormal voltage or temperature is detected to shut down the system automatically.
Retention of CMOS data by EEPROM allows the system to start up even when the battery has run out.
Windows XP Embedded EWF function allows the power to be switched off without shutting down the
system. For OS-installed Models, Windows XP Embedded EWF function allows the power to be
switched off without shutting down the system.
* EWF (Enhanced Write Filter) is a function specific to Windows XP Embedded that protects the disk from being actually written by
redirecting the writing to RAM.
The adoption of a fan-less, CF card configuration providing high levels of reliability and quietness
As the cabinet itself forms an aluminum heat sink without a fan and with a CF card (bootable) as the
storage device, high levels of reliability and quietness have been achieved.
A wide range of power supplies (12 - 24VDC) supported
Supporting a wide range of power supplies (12 - 24VDC) allows the power to be supplied even from the
battery inside a mobile device.
Various installation methods available
Since the adoption of a CF card and sealed structure frees the product from installation limitations, it can
be installed on a ceiling, wall or floor using the attached metal fixings.
Supported OS
- Windows XP Embedded

1. Introduction
IPC-BX800 Series User’s Manual 3
Customer Support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
Web Site
Japanese http://www.contec.co.jp/
English http://www.contec.com/
Chinese http://www.contec.com.cn/
Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
Free download
You can download updated driver software and differential files as well as sample programs available in
several languages.
Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price,
delivery time, or estimate information.
Limited One-Year Warranty
CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in material and
workmanship for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original
invoice and a Return Merchandise Authorization to the distributor or the CONTEC group office, from
which it was purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and
original products. The warranty is not applicable if the device has been tampered with or damaged
through abuse, mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in
which case repairs will be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please
obtain a Return Merchandise Authorization number (RMA) from the CONTEC group office where you
purchased before returning any product.
* No product will be accepted by CONTEC group without the RMA number.
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor
be liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.

1. Introduction
4IPC-BX800 Series User’s Manual
Safety Precautions
Understand the following definitions and precautions to use the product safely.
Safety Information
This document providessafety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels
to operate the equipment safely.
DANGER DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury.
WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury or in property damage.
Caution on the IPC-BX800/801 Series
Handling Precautions
WARNING
- Always check that the power supply is turned off before connecting or disconnecting power cables.
- Do not modify the product.
- Always turn off the power before inserting or removing circuit boards or cables.
- This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other
applications that require a very high level of reliability. Do not use the product in such applications.
- If using this product in applications where safety is critical such as in railways, automotive, or
disaster prevention or security systems, please contact your retailer.
- Do not attempt to replace the battery as inappropriate battery replacement poses a risk of explosion.
- For battery replacement, contact your retailer as it must be performed as a process of repair.
- When disposing of a used battery, follow the disposal procedures stipulated under the relevant laws
and municipal ordinances.

1. Introduction
IPC-BX800 Series User’s Manual 5
CAUTION
- Do not use or store this product in a location exposed to high or low temperature that exceeds range
of specification or susceptible to rapid temperature changes.
Example: - Exposure to direct sun
- In the vicinity of a heat source
- Do not use this product in extremely humid or dusty locations. It is extremely dangerous to use this
product with its interior penetrated by water or any other fluid or conductive dust. If this product
must be used in such an environment, install it on a dust-proof control panel, for example.
- Avoid using or storing this product in locations subject to shock or vibration that exceeds range of
specification.
- Do not use this product in the vicinity of devices that generate strong magnetic force or noise. Such
products will cause this product to malfunction.
- Take care that although an anti-condensation sheet is placed inside the cabinet of this product, this is
not a guaranteed anti-condensation measure.
- Do not use or store this product in the presence of chemicals.
- To clean the BOX-PC, wipe it gently with a soft cloth dampened with either water or mild detergent.
Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing or
discoloration of the paint.
- This product’s case may become hot. To avoid being burned, do not touch that section while this
product is in operation or immediately after turning off the power. Avoid installation in a location
where people may come into contact with that section.
- CONTEC does not provide any guarantee for the integrity of data on CF.
- To prevent corruption of files, always shutdown the OS before turning off this product.
- CONTEC reserves the right to refuse to service a product modified by the user.
- In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power
cord immediately and contact your retailer.
- To connect with peripherals, use a grounded, shielded cable.
- Component Life:
(1) Battery---The internal calendar clock and CMOS RAM are backed by a Lithium primary battery.
The backup time at a temperature of 25°C with the power disconnected is 10 years or
more.
(2) CF ---The OS-installed model uses a CF card in the OS storage area.
Estimated failure rates: 100,000 rewrite cycles, 1,000,000 hours MTBF
* Replacement of expendables is handled as a repair (there will be a charge).

1. Introduction
6IPC-BX800 Series User’s Manual
- Regarding “VCCI Class A, FCC PART 15 Class A and EMC Instruction Class A Notice”
The ferrite core must be installed in the following each cable so that this product may suit the
above-mentioned standard. For the type of ferrite core, refer to the following table (Equivalent
types are also available.)
IPC-BX800 Series
Port Name Maker Turn
LINE OUT FRC3013A-3 or E04SR301334 CONTEC or SEIWA 2
MIC FRC3013A-3 or E04SR301334 CONTEC or SEIWA 2
POWER FRC3013A-3 or E04SR301334 CONTEC or SEIWA 2
USB FRC3013A-3 or E04SR301334 CONTEC or SEIWA 2
SERIAL FRC3013A-3 or E04SR301334 CONTEC or SEIWA 2
IPC-BX801 Series
Port Name Maker Turn
LINE OUT FRC2009A-6 or E04SR200935A CONTEC or SEIWA 4
MIC FRC2009A-6 or E04SR200935A CONTEC or SEIWA 4
LVDS FRC2009A-6 or E04SR200935A CONTEC or SEIWA 1
USB FRC2009A-6 or E04SR200935A CONTEC or SEIWA 1
POWER FRC3013A-3 or E04SR301334 CONTEC or SEIWA 1
- Image diagram
FCC PART 15 Class A Notice (IPC-BX800-DC400, IPC-BX800-DC456, IPC-BX801-DC400,
IPC-BX801-DC456)
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference at his own expense.
NOTE
Change or modifications not expressly approved the manufacturer can void the user's authority to
operate this equipment.
WARNING TO USER
Ferrite core
Ferrite core
Cable
Turn : 1 Turn : 4Turn : 2

2. System Reference
IPC-BX800 Series User’s Manual 7
2. System Reference
Specification
Table 2.1. Functional Specification < 1 / 2 >
Model IPC-BX800-DC400
IPC-BX801-DC400
IPC-BX800-DC456
IPC-BX801-DC456
CPU IPC-BX800 Series :
Ultra Low Voltage Intel(R) Celeron(R) M Processor 800MHz(FSB400MHz)
IPC-BX801 Series :
Ultra Low Voltage Intel(R) Celeron(R) M Processor 1GHz(FSB400MHz)
Chip set Intel(R) 852GM + ICH4
L2 Cache None
Main
memory
512MB, 200pin SO-DIMM socket x 1, PC2100(DDR266) DDR SDRAM support
Memory
BIOS ROM 128KB E0000H - FFFFFH (Phoenix)
Controller Built in Intel 852GM
Video RAM Main memory shared
Video BIOS 48KB (C0000H - CBFFFF)
Video
Display I/F Analog RGB I/F x 1 (15pin HD-SUB connector x 1)
LVDS I/F x 1(26pin half pitch connector x 1)
RGB 640 x 480, 800 x 600, 1,024 x 768, 1,152 x 864, 1,280 x 600, 1,280 x 720, 1,280 x 768,
1,280 x 960, 1,280 x 1,024, 1,400 x 1050, 1,600 x 900, 1,600 x 1,200, 1,856 x 1392,
1,920 x 1080, 1,920 x 1,200 (16,770,000 colors), 1,920 x 1440 (65,536 colors)
System
resolution
*1
LVDS 640 x 480, 800 x 600, 1,024 x 768 (260,000 colors)
Audio AC97 compliant
LINE OUT: φ3.5 Stereo mini jack
Full-scale output level 1.5Vrms (Typ.), Dual 50mW Amplifier
MIKE IN : φ3.5 mono mini jack
Full-scale input level 1.6Vrms (Typ.)
CF CARD Type I, II x 1 (dedicated to memory card, selectable PrimaryMaster,
PrimarySlave) bootable
CF card slot
None Finished mounting CF (2GB) *2
Recovery IDE connector
(R-IDE)
Equipped with 36pin half pitch connector
(Connect the CD-ROM/DVD-ROM drive to the Primary using the dedicated optional cable)
(left surface)
SecondaryIDE None
Serial I/F RS-232C (general-purpose) : 3ch (SERIAL PORT1, 2, 3) 9pin D-SUB connector (male)
Baud rate : 50 - 115,200bps
For touch panel communication : 1ch (SERIAL PORT4) in LVDS connector
For communication with activation control microcontroller : 1ch (SERIAL PORT5) *3

2. System Reference
8IPC-BX800 Series User’s Manual
Table 2.1. Functional Specification < 2 / 2 >
Model IPC-BX800-DC400
IPC-BX801-DC400
IPC-BX800-DC456
IPC-BX801-DC456
I/F 100BASE-TX/10BASE-T RJ-45 connectorLAN
Controller Built in Intel ICH4
USB I/F 2ch (USB 2.0-compliant)
Keyboard/mouseI/F None *4
General-purpose I/O None
Watch dog timer Software programmable, 255 level (1sec - 255 sec)
Causes a reset upon time-out.
Expansion board slot None
RTC/CMOS Lithium backup battery life : 10 years or more
The real-time clock is accurate within ±3 minutes (at 25°C) per month
(ICH4 integrated RTC).
Input supply
voltage
12 - 24VDC ±5%
Current
consumption
When the usual time : 12V2.2A/24V1.1A(Max.)
When the heater is ON : 12V5.6A/24V 2.8A(Max.)
Power
supply *5
External
device power
supply
capacity
- Power connector for R-IDE I/F
+5V: 500mA
- CF card slot
+3.3V: 500mA
- USB I/F
+5V: 1A (500mA x 2)
Physical dimensions
(mm)
166(W) x 152(D) x 56(H) (No protrusions)
Weight About 1.6kg
*1: When setting the “Internal DDC ROM” to the “Enable (default)”, the max. resolution is SXGA.
*2 : The capacity of CF is a value when 1GB is calculated by one billion bytes. The capacity that can be recognized from
OS might be displayed fewer than an actual value.
*3 : It is used with the system so the user cannot use it.
*4 : Use USB I/F for the keyboard/mouse.
*5 : Use the 3mm or less cables for connection.

2. System Reference
IPC-BX800 Series User’s Manual 9
Table 2.2. Installation Environment Requirements
Parameter Requirement description
Operating temperature -20 - 60°C *6
Storage temperature -20 - 60°C
Humidity 10 - 90%RH (No condensation) *7
Floating dust particles Not to be excessive
Corrosive gases None
Line noise AC line/±2kV *8,
Signal line/±1kV (IEC61000-4-4 Level 3, EN61000-4-4 Level 3)
Line-noise
resistance Static
electricity
resistance
Contact discharge /±4kV (IEC61000-4-2 Level 2, EN61000-4-2 Level 2)
Atmospheric discharge /±8kV (IEC61000-4-2 Level 3, EN61000-4-2 Level 3)
Vibration
resistance
Sweep
resistance
10 - 57Hz/semi-amplitude 0.375mm 57 - 200Hz/5.0G
40 min. each in x, y, and z directions
(JIS C0040-compliant, IEC68-2-6-compliant, JISD1601 class A 3-compliant)
Impact resistance 100G, half-sine shock for 6 ms in x, y, and z directions
(JIS C0041-compliant, IEC68-2-27-compliant)
Ambient
specifications
Grounding Class D grounding (previous class 3 grounding)
SG-FG/continuity
*6 : Varies depending on the installation direction. Fore more details on this, please refer to “Chapter3 Installation
Requirements”.
*7 : Although an anti-condensation sheet is placed inside the cabinet of this product, this is not a guaranteed
anti-condensation measure.
*8 : When AC/DC power unit “LDA100W-24-SN” (by Cosel) is used

2. System Reference
10 IPC-BX800 Series User’s Manual
Physical Dimensions
IPC-BX800-DC400, IPC-BX800-DC456, IPC-BX801-DC400, IPC-BX801-DC456
[mm]
2-R2.5
R5.5
5
20
202
186
166
152
10036
(6) (6)
12613
12 32 M3TAP
RESET DIP-SW
DC-IN
LINE-OUT MIC
CF SERIAL1 SERIAL2 SERIAL3
100
LINK/TIX
LAN
VGALVDS
56
Figure 2.1. IPC-BX800-DC400, IPC-BX800-DC456, IPC-BX801-DC400, IPC-BX801-DC456

3. Hardware Setup
IPC-BX800 Series User’s Manual 11
3. Hardware Setup
Before Using the BOX-PC for the First Time
Follow the next steps to set up the BOX-PC:
STEP1 By referring to the information in this chapter, install, connect and set the BOX-PC.
STEP2 Connect cables.
Connect the cable of necessary external devices, such as keyboard and a display, to this
product using appropriate cables.
STEP3 Turn on the power.
After verifying that you have correctly followed steps 1 and 2, turn on the power. If you
feel something is wrong after turning on the power, turn off the power immediately and
check to see if the BOX-PC has been set up correctly.
If the product is started at a low temperature (-20 - 0°C), the OS does not start up until the
temperature goes over 0°C.
STEP4 Set up BIOS.
By referring to Chapter 4, set up BIOS. This setup requires a keyboard and a display.
* Before using the BOX-PC, be sure to execute " LOAD SETUP DEFAULTS" to initialize
the BIOS settings to their default values.
(See Chapter 4, "Main Menu.")
CAUTION
Be sure to connect the keyboard and mouse to it before turning the power on for the first time.

3. Hardware Setup
12 IPC-BX800 Series User’s Manual
Hardware Setup
- Before you start, be sure that the power is turned off.
- Remove only those screws that are explained. Do not move any other screw.
Attaching the CF Card Retaining Bracket
(1) After inserting a CF Card, fasten the bundled CF Card retaining bracket with a screw.
CFCARD
(TOPSIDE)
Figure 3.1. Attaching the CF Card Retaining Bracket
CAUTION
Insert the CF Card face up.
Attaching the Fitting Used to Attach to the Main Unit
(1) Use screws to attach the bundled fitting to the main unit
Do not tighten screws with excess force. The tightening torque should be 4kg/cm or less.
Figure 3.2. Attaching the Fitting Used to Attach to the Main Unit
CAUTION
Screw holes may be damaged if screws are tightened with a torque greater than the specified torque.

3. Hardware Setup
IPC-BX800 Series User’s Manual 13
Removing/Attaching the Recovery IDE Connector Cover
(1) When using the optional CD-ROM/DVD-ROM drive (IPC-CDD-03) and IDE cable (IPC-CDC-04),
remove the recovery IDE connector cover before connecting them.
(2) After use, remove the CD-ROM/DVD-ROM drive and IDE cable and put back the recovery IDE
connector cover. Do not tighten screws with excess force. The tightening torque should be 4kg/cm
or less.
Figure 3.3. Attaching the Recovery IDE Connector Cover
CAUTION
Screw holes may be damaged if screws are tightened with a torque greater than the specified torque.
Attaching the FG
(1) Use screws to attach the FG
Figure 3.4. Attaching the FG
CAUTION
The FG pin of this product is connected to the GND signal of the DC power connector (DC-IN).
Note that the connection cannot be cut off.
