Contec IPC SERIES User manual

IPC Series
PANEL-PC
PT-S2000HX/HXC/LX/LXC Series
User’s Manual
CONTEC CO., LTD.

ii PT-S2000HX/HXC/LX/LXC Series User’s Manual
Check Your Package
Thank you for purchasing the CONTEC product.
The product consists of the items listed below.
Check, with the following list, that your package is complete*1. If you discover damaged or missing items,
contact your retailer or the general CONTEC information.
◆Product Configuration List
PT-S2000HX/HXC-DCxxxxxxx
[Base model]
PT-S2000LX/LXC-DCxxxxxxx
[Base model]
Name
Pcs.
Pcs.
Panel-PC
1
1
The attachment fittings
10
8
Cable tie
2
2
Power supply connector complete set
Power connector
1
1
Contact
4
4
Product guide (this sheet)
1
1
*1 The user's manual for this product is available as a PDF file through CONTEC’s Web site.
The user's manual provides such information as hardware settings, functions for each component, and BIOS settings. Refer
to it as necessary.

PT-S2000HX/HXC/LX/LXC Series User’s Manual iii
◆Product Configuration Image
Panel PC
The attachment fitting
Cable tie
Power supply connector
complete set
Product guide
* See the Product Configuration List to check if all the components are included for the specifiednumber
of units.
Copyright
Copyright 2018 CONTEC CO., LTD. ALL RIGHTS RESERVED.
No part of this document may be copied or reproduced in any form by any means without prior written
consent of CONTEC CO., LTD.
CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this
document.
The information in this document is subject to change without notice.
All relevant issues have been considered in the preparation of this document. Should you notice an
omission or any questionable item in this document, please feel free to notify CONTEC CO., LTD.
Regardless of the foregoing statement, CONTEC assumes no responsibility for any errors that may
appear in this document or for results obtained by the user as a result of using this product.
Trademarks
Intel, Intel Atom, Intel Core and Celeron are registered trademarks of Intel Corporation. MS, Microsoft
and Windows are trademarks of Microsoft Corporation. Other brand and product names are trademarks
of their respective holder.

iv PT-S2000HX/HXC/LX/LXC Series User’s Manual
Table of Contents
Check Your Package............................................................................................................................ii
◆Product Configuration List........................................................................................................ii
◆Product Configuration Image...................................................................................................iii
Copyright............................................................................................................................................iii
Trademarks.........................................................................................................................................iii
Table of Contents................................................................................................................................iv
1. INTRODUCTION 7
About the Product................................................................................................................................ 7
◆Features..................................................................................................................................... 8
◆Supported OS............................................................................................................................ 8
Customer support................................................................................................................................. 9
◆Web Site ...................................................................................................................................9
Limited One-Year Warranty................................................................................................................ 9
How to Obtain Service......................................................................................................................... 9
Liability............................................................................................................................................. 10
Safety precaution............................................................................................................................... 10
◆Safety information .................................................................................................................. 10
◆Caution on the PT-S2000HX/HXC/LX/LXC-DC Series ........................................................10
2. SYSTEM REFERENCE 13
Specification...................................................................................................................................... 13
Power Management Features............................................................................................................. 16
Power Requirements.......................................................................................................................... 16
◆Power Consumption................................................................................................................ 16
Physical dimensions........................................................................................................................... 17
3. HARDWARE SETUP 19
Before Using the Product for the First Time......................................................................................19
Hardware setup..................................................................................................................................20
◆Panel mount & Attachment Fittings / PT-S2000HX/HXC...................................................... 20
◆Panel mount & Attachment Fittings / PT-S2000LX/LXC....................................................... 21
◆Fastening the Cable................................................................................................................. 22
◆Installing disk drives............................................................................................................... 22
◆Installing the mini card ........................................................................................................... 26
◆Installing the M.2 module.......................................................................................................27

PT-S2000HX/HXC/LX/LXC Series User’s Manual v
4. BIOS SETUP 28
Introduction....................................................................................................................................... 28
Starting Setup.................................................................................................................................... 28
Using Setup....................................................................................................................................... 29
◆Getting Help ........................................................................................................................... 29
◆In Case of Problems................................................................................................................ 29
◆A Final Note About Setup....................................................................................................... 29
Main Menu........................................................................................................................................ 30
◆Setup Items............................................................................................................................. 31
Main .................................................................................................................................................. 31
Advanced........................................................................................................................................... 34
◆CPU Configuration................................................................................................................. 36
◆ACPI Settings......................................................................................................................... 39
◆SMART Setting...................................................................................................................... 41
◆Super IO Configuration .......................................................................................................... 42
◆Serial Port 1 (COM A)............................................................................................................ 43
◆Serial Port 2 (COM B)............................................................................................................ 44
◆H/W Monitor.......................................................................................................................... 46
◆S5 RTC Wake settings............................................................................................................ 47
◆Network Stack Configuration ................................................................................................. 49
Chipset............................................................................................................................................... 51
◆System Agent (SA) Configuration.......................................................................................... 52
◆Memory Configuration........................................................................................................... 53
◆Graphic Configuration............................................................................................................ 54
◆PCH-IO Configuration............................................................................................................ 55
◆Azalia HD Audio Configuration............................................................................................. 56
Security.............................................................................................................................................. 57
◆HDD Security......................................................................................................................... 59
◆Secure Boot ............................................................................................................................ 60
◆Secure Flash Update............................................................................................................... 62
Boot Configuration............................................................................................................................ 63
◆List Boot Device Type............................................................................................................ 66
Save & Exit ....................................................................................................................................... 67
5. EACH COMPONENT FUNCTION 68
Component name............................................................................................................................... 68
Component Function ......................................................................................................................... 69
◆LED: POWER, ACCESS........................................................................................................ 69
◆DC Power Input Connector: DC-IN........................................................................................ 69
◆POWER SW........................................................................................................................... 70
◆LINE OUT Interface: LINE OUT........................................................................................... 70
◆HDMI Interface: ..................................................................................................................... 70

vi PT-S2000HX/HXC/LX/LXC Series User’s Manual
◆USB3.0 Port: USB3.0............................................................................................................. 71
◆Giga bit-Ethernet: LAN A, B..................................................................................................72
◆Display Port Connector........................................................................................................... 73
◆Serial Port Interface: SERIAL A, B........................................................................................ 74
◆GPIO Port: DIO...................................................................................................................... 75
6. APPENDIX 76
POST Codes ...................................................................................................................................... 76
SERIAL I/O Address and Register Function .....................................................................................79
Baud Rate Settings............................................................................................................................. 84
PT-S2000HX/HXC/LX/LXC GPIO Programming guide.................................................................. 85
◆PT-S2000HX/HXC/LX/LXC GPIO v3.02..............................................................................85
Watchdog timer application guide..................................................................................................... 90
◆Design Note............................................................................................................................ 91
◆MiAPI Watchdog SetConfig Description................................................................................ 94
◆MiAPI Watchdog GetRange Description................................................................................ 94
◆MiAPI Watchdog Start Description........................................................................................ 95
◆MiAPI Watchdog Disable Description.................................................................................... 95
◆MiAPI Watchdog Refresh Description ...................................................................................96
7. LIST OF OPTIONAL PRODUCT 98

PT-S2000HX/HXC/LX/LXC Series User’s Manual 7
1. Introduction
About the Product
This product is a fanless computer for embedded applications. It features an Intel 6th Generation ULV
processor. Thanks to a Dual-core CPU, simultaneous stable high-speed processing for applications is
possible per cores. ULV (Ultra-Low Voltage) technology. This "resource-saving PC" helps you design
more compact, energy efficient equipment to reduce running costs and promote energy efficiency. It has
extension interfaces such as DP, HDMI, 1000BASE-T, USB 3.0, GPIO, and serial. It employs a 2.5” SSD
& mSATA for storage and is fanless to ensure a totally spindleless design that simplifies maintenance.
Embedded-type CPU have been adopted. The use of readily available parts ensures the ease of the use of
the product. In addition, the use of Contec-customized BIOS allows support to be provided at the BIOS
level.
This product is available in the following 4 models:
-15”panel PC Base model with Intel 6th Processor 3955U@ 2.00 GHz
PT-S2000HX/HXC-DC28xxxxx (Memory 8GB, without OS)
-15”panel PC Base model with Intel 6th Processor i5-6300U@ 2.40 GHz
PT-S2000HX/HXC-DC38xxxxx (Memory 8GB, without OS)
-12”panel PC Base model with Intel 6th Processor 3955U@ 2.00 GHz
PT-S2000LX/LXC-DC28xxxxx (Memory 8GB, without OS)
-12”panel PC Base model with Intel 6th Processor i5-6300U@ 2.40 GHz
PT-S2000LX/LXC-DC38xxxxx (Memory 8GB, without OS)

8PT-S2000HX/HXC/LX/LXC Series User’s Manual
◆Features
-Contributing to reduction of running cost and promotion of energy efficiency.
It adopts the low-power platform with Intel® Core i5 & Celeron Processor that realizes lower power
consumption while ensuring sufficient performance.
-Design that meets the safetystandard
This product, as in our other products, is designed to comply with the safety standard of FCC, CE, and
furthermore.
-Slitless/fanless design that reduces maintenancework
This product's spindleless design eliminates the heat dissipating slit and CPU fan and adopts 2.5”HDD/SSD&
mSATAfor the storage. There is no need to worry about the intrusion of dust or foreign objects, and theuse of
parts that degrade over time is minimized to facilitate maintenance.
-Major types of peripherals are supported with rich interfaces including the one 2.5”HDD frame. It has a
variety of extended interface such as HDMI x 1 & DP x1, 1000BASE-T x 2, USB3.0 x 4, serial x 2, GPIO x 1.
It has two storage interface, providing the ability to separate data from the operating system, as well as the
convenience of being able to use one slot for system startup and the other for maintenance or for taking home
system logs or collected data.
-Falling-off prevention tools and fixing clamps provided to avoid trouble caused by disconnected cable
This product stays trouble-free, being equipped with USB removal prevention fitting and cable clamp for
connectors with no locking mechanism, such as USB cable.
-A wide range of power supplies (12 - 24VDC ±10%)supported
As the product supports a wide range of power, it can be used in a variety of power environments. The
separately available AC adapter adds support for 100 - 240VAC power.
◆Supported OS
-Windows 7 32-bit.
-Windows 7 64-bit.
-Windows 10 64-bit.

PT-S2000HX/HXC/LX/LXC Series User’s Manual 9
Customer support
CONTEC provides the following support services for you to use CONTEC products more efficiently and
comfortably.
◆Web Site
Japanese http://www.contec.com/jp
English http://www.contec.com/
Chinese http://www.contec.com/cn
■Latest product information
CONTEC provides up-to-date information on products.
CONTEC also provides product manuals and various technical documents in the PDF.
■Free download
You can download updated driver software and differential filesas well as sample programs available in several
languages.
■Note! For product information
Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery
time, or estimate information.
Limited One-Year Warranty
CONTEC products are warranted by CONTEC CO., LTD. to be free from defects in material and workmanship
for up to one year from the date of purchase by the original purchaser.
Repair will be free of charge only when this device is returned freight prepaid with a copy of the original invoice
and a Return Merchandise Authorization to the distributor or the CONTEC group office, from which it was
purchased.
This warranty is not applicable for scratches or normal wear, but only for the electronic circuitry and original
products. The warranty is not applicable if the device has been tampered with or damaged through abuse,
mistreatment, neglect, or unreasonable use, or if the original invoice is not included, in which case repairs will
be considered beyond the warranty policy.
How to Obtain Service
For replacement or repair, return the device freight prepaid, with a copy of the original invoice. Please obtain a
Return Merchandise Authorization number (RMA) from the CONTEC group office where you purchased
before returning any product.
* No product will be accepted by CONTEC group without the RMA number.

10 PT-S2000HX/HXC/LX/LXC Series User’s Manual
Liability
The obligation of the warrantor is solely to repair or replace the product. In no event will the warrantor be
liable for any incidental or consequential damages due to such defect or consequences that arise from
inexperienced usage, misuse, or malfunction of this device.
Safety precaution
Understand the following definitions and precautions to use the product safely.
◆Safety information
This document provides safety information using the following symbols to prevent accidents resulting in
injury or death and the destruction of equipment and resources. Understand the meanings of these labels to
operate the equipment safely.
DANGER indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury or in property damage.
◆Caution on the PT-S2000HX/HXC/LX/LXC-DC Series
Handling Precautions
WARNING
-Always check that the power supply is turned off before connecting or disconnecting power cables.
-Do not modify the product.
-Always turn off the power before inserting or removing circuit boards or cables.
-This product is not intended for use in aerospace, space, nuclear power, medical equipment, or other
applications that require a very high level of reliability. Do not use the product in such applications.
-If using this product in applications where safety is critical such as in railways, automotive, or disaster
prevention or security systems, please contact your retailer.
-Do not attempt to replace the battery as inappropriate battery replacement poses a risk of explosion.
-For battery replacement, contact your retailer as it must be performed as a process of repair.
-When disposing of a used battery, follow the disposal procedures stipulated under the relevant laws and
municipal ordinances. For details on replacing thebattery, refer to the appendix.

PT-S2000HX/HXC/LX/LXC Series User’s Manual 11
CAUTION
-Do not use or store this product in a location exposed to high or low temperature that exceeds range of
specification or susceptible to rapid temperaturechanges.
Example: - Exposure to direct sun
- In the vicinity of a heat source
-Do not use this product in extremely humid or dusty locations. It is extremely dangerous to use this product
with its interior penetratedby water or any other fluid or conductive dust. If this product must beused in such
an environment, install it on a dust-proof control panel, for example.
-Avoid using or storing this product in locations subject to shock or vibration that exceeds range of
specification.
-Do not use this product in the vicinity of devices that generate strong magnetic force or noise. Such products
will cause this product tomalfunction.
-Do not use or store this product in the presence ofchemicals.
-To clean this product, wipe it gently with a soft cloth dampened with either water or mild detergent.
Do not use chemicals or a volatile solvent, such as benzene or thinner, to prevent pealing or discoloration of
the paint.
-This product’s case may become hot. To avoid being burned, do not touch that section while this product is
in operation or immediately after turning off the power. Avoid installation in a location where people may
come into contact with that section.
-CONTEC does not provide any guarantee for the integrity of data on SSD.
-Always remove the power cable from the power outlet before mounting or removing an expansion board and
before connecting or disconnecting aconnector.
-Always remove the power cable from the power outlet before connecting or disconnecting a connector.
-To prevent corruption of files, always shutdown the OS before turning off this product.
-CONTEC reserves the right to refuse to service a product modified by the user.
-In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord
immediately and contact yourretailer.
-To connect with peripherals, use a grounded, shieldedcable.
-Component:
(1) Battery---The internal calendar clock and CMOS RAM are backed by a Lithium primary battery.
*Replacement of expendables is handled as a repair (there will be acharge).
*The service life for consumable parts are reference values and are not guaranteed values.

12 PT-S2000HX/HXC/LX/LXC Series User’s Manual
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference at his own expense.
NOTE
Change or modifications not expressly approved the manufacturer can void the user's authority to
operate this equipment.
WARNING TO USER
FCC PART 15 Class A Notice

PT-S2000HX/HXC/LX/LXC Series User’s Manual 13
2. System Reference
Specification
Table 2.1. Functional specification< 1 / 2 >
MODEL
PT-S2000HX/HXC-DCxxxxxxx
PT-S2000LX/LXC-DCxxxxxxx
PT-S2000HX/HXC-DC2xxx
xxx
PT-S2000HX/HXC-DC3xxx
xxx
PT-S2000LX/LXC-DC2xxx
xxx
PT-S2000LX/LXC-DC3xxx
xxx
PROCESSOR
Intel® Celeron 3955U
Intel® Core i5-6300U
Intel® Celeron 3955U
Intel® Core i5-6300U
CHIPSET
Intel® SoC integrated
MEMORY
DDR4 2133/2400, 260-pin SO-DIMM x 2, Max. 32 GB (Non-ECC)
GRAPHICS
Intel® HD Graphics
ETHERNET
Intel® I219LM Giga LAN + I211AT Giga LAN
AUDIO
Realtek ALC283
I/O CHIPSET
Nuvoton NCT6104D
TPM
Nuvoton NPCT650ABCYX TPM2.0
EXPANSION SLOT
Storage: PCI Express Full-Length Mini Card slot (USB / PCIe /SATA)
Wireless: M.2 2230 E key (PCIe / USB)
BIOS
AMI BIOS
H/W MONITOR
Temperature Monitor, Voltage Monitor, Fan Monitor
WATCHDOG TIMER
1~255 Steps by Software Program
GRAPHICS
HDMI
Up to 4096 x 2160 @24 Hz
DISPLAYPORT
Up to 4096 x 2304 @60 Hz
LVDS (Internal)
Up to 1920 x 1200 @60 Hz
REAR I/O
USB
USB 3.0 x 4
DISPLAY I/O
HDMI x 1, DP x 1
AUDIO I/O
Audio jack (Line-out) x 1
GPIO PORT
8-bit General-purpose I/O
SERIAL PORT
COM A RS232 & COM B RS232/422/485
LAN I/O
Giga LAN X 2
POWER REQUIREMENT
POWER INPUT
Power header 4PIN
12~24VDC ±10%
OS
OS SUPPORT
Windows ® 7 32/64bit, Windows ® 10 64bit,
Linux (support by request)

14 PT-S2000HX/HXC/LX/LXC Series User’s Manual
PHYSICAL DIMENSIONS
UNIT: mm
372x303x84.7
316x256x85.4
WEIGHT
UNIT: Kg
4.6
3.7
Table 2.1. Functional specification< 2 / 2 >
MODEL
PT-S2000HX/HXC-DCxxxxxxx
PT-S2000LX/LXC-DCxxxxxxx
Display
LCD Panel
15" XGA
12" XGA
Resolution
1024 x768.262K colors
Luminance
450 nits
600 cd/m2 (Typ.)
Touch Panel
Touch Type
Projected capacitive
Transparency
89 ±3%
(tavg) > 85.0%
Viewable Area
305.10 x 229.10 ±0.5mm
247.50 x 186.00 ±0.2mm
Active Area
310.10 x 234.10 ±0.5mm
249.50 x 188.00 ±0.3mm
Total Thickness
2.20 ±0.20mm
2.70 ±0.15mm
Max. Operating
Force
80g ( R0.8 Touch pan )
Connection
Internal RS-232 connection
Mechanical
Cut out Size
358 x 289 mm
303 x 243 mm

PT-S2000HX/HXC/LX/LXC Series User’s Manual 15
Table 2.2. Installation Environment Requirements
MODEL
PT-S2000HX/HXC-DCxxxxxxx
PT-S2000LX/LXC-DCxxxxxxx
PT-S2000HX/HXC-DC2x
xxxxx
PT-S2000HX/HXC-DC3x
xxxxx
PT-S2000LX/LXC-DC2x
xxxxx
PT-S2000LX/LXC-DC3x
xxxxx
PROCESSOR
Intel® Celeron 3955U
Intel® Core i5-6300U
Intel® Celeron 3955U
Intel® Core i5-6300U
ENVIRONMENTAL
OPERATING
TEMPERATURE
0 ~ 50°C with 0.7m/s air flow (with Extended Temp. HDD/SSD/mSATA/RAM)
0 ~ 40°C with 0.7m/s air flow (with Standard Temp. HDD/SSD/mSATA/RAM)
STORAGE TEMPERATURE
-20 ~ 80°C
OPERATING HUMIDITY
10% ~ 90% RH, non-condensing
CERTIFICATION
CE & FCC
LINE NOISE RESISTANCE
Line noise
AC line / ±2kV
Signal line / ±1kV (IEC61000-4-4 Level 3, EN61000-4-4 Level 3)
Static electricity resistance
Contact discharge / ±4kV (IEC61000-4-2 Level 2, EN61000-4-2 Level 2)
Atmospheric discharge / ±8kV (IEC61000-4-2 Level 3, EN61000-4-2
Level 3)
VIBRATION RESISTANCE
Sweep resistance
Frequency：10～57Hz/0.075mm（(0-p)）
Frequency：57～150Hz/9.8m/s2(1G)
Speed/Cycle/ Frequency:1oct/min、1 cycle（10-150-10Hz）
Axes: XYZ 3 axes 5 cycle（40min/axis）
class 2:(operating: for SSD) / JIS C 60068-2-6：2010
IMPACT RESISTANCE
98m/s2(10G)/11ms/half sine Axes XYZ 3 axes (3 cycle /axis)
Class 2(operating: SSD only) / JIS C 60068-2-27：1995

16 PT-S2000HX/HXC/LX/LXC Series User’s Manual
Power Management Features
-Support both ACPI (Advanced Configuration and Power Interface).
-ACPI v2.0 compliant
-Hardware automatic wake-up
Power Requirements
Your system requires a clean, steady power source for reliable performance of the high frequency CPU on the
product, the quality of the power supply is even more important. For the best performance makes sure your
power supply provides a range of 12 V minimum to 24 V maximum DC power source.
◆Power Consumption
For typical configurations, the CPU card is designed to operate with at least a 60W power supply. The power
supply must meet the following requirements:
-Rise time for power supply: 2 ms - 30ms
The following table lists the power supply’s tolerances for DC voltages:
Table 2.3. DC voltage tolerance
DC Voltage
Acceptable Tolerance
+ 12V - 24V
+ 10.8V –26.4V

PT-S2000HX/HXC/LX/LXC Series User’s Manual 17
Physical dimensions
PT-S2000HX/HXC Series
Figure 2.1. PT-S2000HX/HXC Series
Figure 2.2. PT-S2000HX/HXC Series Front Panel & Panel mount cut out size

18 PT-S2000HX/HXC/LX/LXC Series User’s Manual
Figure 2.3. PT-S2000LX/LXC-DC Series
Figure 2.4. PT-S2000LX/LXC-DC Series Front Panel & Panel mount cut out size

PT-S2000HX/HXC/LX/LXC Series User’s Manual 19
3. Hardware Setup
Before Using the Product for the First Time
Follow the next steps to set up this product.
STEP1 By referring to the information in this chapter, install, connect and set this product.
STEP2 Connect cables.
Connect the cable of necessary external devices, such as keyboard and display, to this product
using appropriate cables.
STEP3 Turn on the Power.
After verifying that you have correctly follow steps 1 and 2, turn on the power. If you find any
abnormality after turning on the power, turn it off and check to see if the setup has been
performed properly.
STEP4 Set up BIOS.
By referring to Chapter 4, set up BIOS. This setup requires a keyboard and a display.
※Before using this product, be sure to execute “Restore Defaults” to initialize the BIOS
settings to their default values.
(See Chapter 4, “Save & Exit”)
-Be sure to connect the keyboard and mouse to it before turning the power on for the first time.
-Be sure to connect the display before turning the power on. Connecting the display after turning the
power on may prevent it from being displayedproperly.

20 PT-S2000HX/HXC/LX/LXC Series User’s Manual
Hardware setup
・Before you start, be sure that the power is turned off.
・Remove only those screws that are explained. Do not move any other screw.
◆Panel mount & Attachment Fittings / PT-S2000HX/HXC
-
-
-
-
Figure 3.1. PT-S2000HX/HXC Attaching the Attachment Fittings
-Screw holes may be damaged if screws are tightened with a torque greater than the specified torque. The
specified tightening torque is 5 - 6kgf･cm.
-CAUTION :
-The maximum thickness of the
mounting bracket is 7mm
Please place the mounting clip in the guide groove
according to the direction as figure.
Recommended to
secure the
screws in the
numerical order
as figure.
